EPSON PhotoPC 750Z
Megapixel Zoom Digital Camera
FEATURES BENEFITS
•Maximum 6X Supports a variety of shots at varying focal
zoom (3X optical lengths from 34mm to 102mm
zoom and 2X
digital zoom)
•Up to 1600 x 1200 Epson’s revolutionary image enhancement
pixel resolution technology increases the 1.25 megapixel CCD
with HyPict sensor resolution for great 8” x 10” images
technology
•12MB of memory: Stores up to 178 standard images
4MB built-in,
8MB Lexar Media
CompactFlash
•Solar Assist 2” Review, preview and delete images prior to
LCD monitor transferring to computer. Saves battery life by
using direct sunlight to illuminate the LCD
monitor outdoors
•Includes Saves money on batteries; pocket-sized charger
rechargeable AA recharges batteries within 3 hours
NiMH batteries and
portable, fast charger
• Presentation Upload presentations and images into the camera
capabilities for display on a multimedia projector, TV or VCR
• Direct camera-to- Print pictures directly to the EPSON Stylus®
printer printing Photo, Photo 700, Photo EX and EPSON Stylus®
Color 600, 740, 800, and 850 printers without
a computer
TAKING DIGITAL PHOTOGRAPHY TO A
BREATHTAKING NEW LEVEL.
The EPSON PhotoPC®750Z is the first digital
camera equipped with EPSON’s HyPict™ technology,
very big news if you want to take high quality digital
photographs.
Epson’s breakthrough image enhancement
technology boosts the PhotoPC 750Z’s 1.25 megapixel
CCD sensor resolution to a stunning 1600 x 1200 pixel
resolution, resulting in color photos with sharper
details–even when printed out at 8” x 10”.
The PhotoPC 750Z’s built-in 6X zoom lens (a
combination 3X optical and 2X digital zoom) captures
high-resolution photos from 34mm to 102mm. So you
can easily shoot a variety of striking images, from wide
angle panoramic shots to closeups, without ever
changing a lens. And it’s always ready to take pictures,
up to 178 standard images with 4MB of built-in
memory and an 8MB Lexar Media™ CompactFlash™
card.
The PhotoPC 750Z also features a state-of-the-art
Solar Assist™ panel. With Solar Assist, the 2” LCD monitor
is illuminated by direct sunlight to conserve battery
power. To further extend battery life, the Power Save
mode automatically shuts down the LCD after each
shot. Four rechargeable AA NiMH batteries and a fast,
portable charger are included.
For all its sophisticated engineering, the PhotoPC 750Z
is one of the easiest digital cameras to use. It's armed
with a number of automatic features, including auto
focus, flash, shutter, white balance and exposure
adjustment. Whether you’re shooting images for a
“make or break” presentation, internet e-mail, a brochure
or even an occasional family photo, you’ll find no other
digital camera comes close to the technology, ease-of-
use and features of the PhotoPC 750Z.
EPSON
2361 McGaw Ave
Irvine, California 92614
PHONE: [phone]
FAX: [phone]
CYAN
MAGENTA
YELLOW
BLACK
PMS 280

EasyTouch Controls and Display
User selectable controls and LCD status display
Direct Print
Supports direct printing to EPSON Stylus®Photo,
Photo 700, Photo EX and EPSON Stylus Color 600,
740, 800 and 850 ink jet printers without a computer
Software on CD-ROM
Sierra Imaging®Image Expert™, EPSON Photo!2™
TWAIN driver and standalone utility driver, EPSON
Photo File Uploader, EPSON Program Uploader, and
Direct Print driver
Minimum System Requirements
CD-ROM driver, 16MB RAM, 30MB of available hard
disk space, serial communications port, VGA monitor
minimum resolution of 640 x 480 with 16 colors,
mouse or pointing device
Windows®: 486/66 or higher processor,
Windows 95, Windows 98,
Windows NT 3.5 or later
Macintosh®: PowerPC or G3, System 7.x
or later
Data Communication Interface
Camera side: 8 pin mini-DIN
Computer side: Compatible with RS-232C
serial port (Windows)
8 pin DIN serial port (Macintosh)
Serial communication speed up to 230.4 kbps with
high-speed serial port
Video Interface
Provides NTSC video output signal
Power
Includes 4 rechargeable EPSON AA NiMH batteries
and portable charger
Accepts 4 AA sized batteries (alkaline, lithium,
Ni-Cd and NiMH)
Optional AC adapter
Contents
EPSON PhotoPC 750Z camera, software, serial
communications/Direct Print cables, video cable, NiMH
batteries and charger, wrist strap, lens cap, Lexar Media
8MB CompactFlash card, user’s guide and camera bag
Warranty
1 year limited: camera
90 day limited: NiMH batteries and charger
Environmental Requirements (Operating range)
Temperature: 41º to 95º F (5º to 35º C)
Humidity: 30% to 90% (non-condensing)
Product/Accessory Codes
EPSON PhotoPC 750Z Digital Camera B080011F
EPSON PhotoPC 750Z Adapter B867038
EPSON PhotoPC 750Z NiMH Power Pak B818051
EPSON PhotoPC 750Z NiMH Batteries (4x AA) B818061
Accessory Removable Storage Cards
Optional CompactFlash cards available through Lexar
Media Inc. and SanDisk®
Support–The Epson ConnectionTM
Pre-Sales Support U.S. and Canada 800-463-7766
Automated Technical Support 800-922-8911
Download Service 800-442-2007
Internet Website www.epson.com
PhotoPC 700
Awards
Specifications and terms are subject to change without notice. EPSON is a registered trademark of Seiko Epson Corporation. PhotoPC is a registered trademark and Clear
Optics, HyPict and Solar Assist are trademarks of Epson America, Inc. and Epson Connection is a service mark of Epson America, Inc. Lexar Media is a trademark of Lexar Media.
Sierra Imaging is a registered trademark and Image Expert is a trademark of Sierra Imaging, Inc. All other product and brand names are trademarks and/or registered trade-
marks of their respective companies. Epson disclaims any and all rights in these marks. © Copyright 1999 Epson America, Inc. CPD-7411 50M 1/99
Epson America, Inc.
20770 Madrona Ave., Torrance, CA 90503
Epson Canada, Ltd.
550 McNicoll, Willowdale, Ontario M2H 2E1
Epson Latin America, Inc.
6303 Blue Lagoon Drive, Miami, FL 33126 1-305-265-0092
Printed on recycled paper
DIGITAL CAMERA SPECIFICATIONS
CCD Sensor
1/2.7 inch color CCD (1.25 million pixels)
Resolution Modes
HyPict™: 1600 x 1200 pixels
Super Fine: 1280 x 960 pixels (low compression)
Fine: 1280 x 960 pixels (high compression)
Standard: 640 x 480 pixels
Picture Modes
Quick shot, continuous shoot VGA, 2x digital zoom
and panorama
Color Modes
24-bit color and grayscale
File Format
JPEG (JFIF)
Solar Assist LCD Monitor
2” low-temperature poly-silicon TFT color LCD solar
illuminated by direct sunlight
1/30 second refresh rate
Supports instant preview and playback
Storage Capacity (12MB included)
4MB internal memory and 8MB Lexar Media
CompactFlash card
Average number of images stored on 12MB:
HyPict: 16 images
Super Fine: 26 images
Fine: 54 images
Standard: 178 images
EPSON ClearOptics™ Glass Lens
7 elements in 7 groups including 2 aspherical lenses,
Aperture f2.8 and f8
3X optical zoom; focal length equivalent to 34mm to
102mm lens on a 35mm camera
Auto-focus with Focus Lock
Macro mode focus range: 8” to 32” (0.2 - 0.8m)
Normal mode focus range: 32” to infinity (0.8m - infinity)
Optical Viewfinder
Real-image optical viewfinder with power zoom
Shutter
(Auto iris electronic control shutter with
mechanical shutter)
1/4 to 1/750 second without flash
1/30 to 1/750 second with flash
Exposure Control
Program auto exposure with manual +/-2.0 exposure
value adjustment
White Balance Modes
Auto/Fixed 5200oK/User preset
Built-in Flash
Range: 8” to 8’ (0.2m - 2.3m)
Modes: Auto Flash, Forced Flash, Flash Off and
Slow Synchronized
Sensitivity
Equivalent to ISO 90/180/360
