Epson PhotoPC PhotoPC Mac User manual

EPSON PhotoPC-Macintosh
viewfinder
red timer
Poe
cover
Power switch
viewfinder
\
control panel
\
shutter
bultpn
memory lmoduie
I
cover
hand strap holder
Specifications
Technical
Product type CCD (charge coupled device) still frame
camera
Image size
Bit depth
Serial interface
640 x 480 pixels (high resolution)
320 x 240 pixels (standard resolution)
16 million colors, 24bit
S-pin DIN (camera);
B-pin DIN (Macintosh)
cable adapter for RS-232C interface in
PhotoPC Mac version
Digital Camera 5/96
Internal memory
Optional expansion
1MB flash memory
2MB (0.5MB flash memory x 4 chips)
memory
Photographic
L&IS
4MB (0.5MB flash memory x 8 chips)
Range
Exposure
Shutter
Viewfinder
Aperture
Flash modes
Flash range
f = 6 mm (equivalent to a 43 mm lens
on a 35 mm camera)
2 ft (60 cm) to infinity
Equivalent to I!30 130
Automatic electronic shutter,
l/30 to1 /lO,OOO second
Optical
f5.6
Auto, forced flash, off
3fttolOft(lmto3m)
Physical Dimensions
Width
Height
Depth
Weight
Power
Sources
Consumption
Batteries
6.5 in. (166 mm)
3.5 in. (88 mm)
1.9 in. (47 mm)
11 oz. (310 g) without batteries
4 AA batteries (single-use alkaline, single-
use lithium, or rechargeable NiCad)
Optional AC adapter (A882421)
Approximately 100 milliwatt at power-on
Approximately 4 Wduring image
processing
Maximum 12 Wduring flash discharge
Replace all four PhotoPC batteries with any of the following:
DSingle-use AA alkaline batteries
c3 Single-use AA lithium batteries (longest battery life)
Cl Rechargeable AA N&Cad batteries.
Caution
To avoid the danger ofjre or explosion, do not mix different types
of batter&. Do not allow the battery contacts to fouch metal objects
such as coins or keys, which could short out the battery’s circuifs.
EPSON PhotoPC-Macintosh-1

EPSON PhotoPC-Macintosh
Note the following when handling batteries:
a
cl
Q
a
a
cl
Do not use manganese batteries.
Replace all four batteries at the same time.
Do not drop, puncture, disassemble, or mutilate batteries.
Do not get them wet or expose them to fire.
When the camera is not used for long periods of time,
remove the batteries and store them at a low temperature
in a dry location.
Dispose of used batteries according to the battery
manufacturer’s instructions and in compliance with all
applicable laws. Contact your local government agency
for information about battery recycling and disposal.
If you use rechargeable N&Cad batteries, replace them
with four fully-charged batteries. If you find that your
batteries run out faster after you recharge them a number
of times, make sure you discharge them completely before
recharging.
Checking the Battery Icon
Before you take pictures, check the battery icon on the
control panel. The icon shows how much battery power you
have left, in the following four stages:
_ Full battery power (or AC adapter in use)
(r Battery power is decreasing
n Battery power is almost out
;e Change batteries
The Control Panel
The control panel keeps track of how many pictures have
been taken and gives important information about the status
of the battery and various settings.
resolution,
pictures taken
I
mode
Hi
pictures
,f
remaining
4
a
timer
battery level
erase last
Hi High resolution images are captured at 640 x 480; the
camera can hold at least 16 pictures at high resolution
‘flash mods
The Control Buttons
You can adjust the following settings using the control
buttons on the top of the camera:
Q Flash
Ll Resolution
Ll Timer.
All control button settings (except the timer) remain in effect
even after you turn off the camera. However, they return to
their factory settings when you remove or change the
batteries.
resoiution timer flash
&se
Flash
The built-in flash has these three settings, which are effective
within a range of 3 to 10 feet:
AUTO
f
Auto sets the flash to go off automatically whenever
it’s needed (factory setting)
Forced flash sets the flash to go off for every picture.
Flash off disables the flash even in inadequate
lighting.
Resolution
The PhotoPC has the following two resolution settings:
S
Standard resolution images are captured at 320 x 240;
the camera can hold at least 32 pictures at this
resolution
Timer
The timer sets a lo-second delay between the time the
shutter button is pressed and the image is captured.
Erase
Press the erase button with a small pointed object to era= the
last picture from the camera’s memory.
EPSON PhotoPC-Macintosh-2
5/96
Digital Camera

EPSON PhotoPC-Macintosh
Connecting the Camera to the Macintosh Maintenance
Follow these steps to connect the camera to the Macintosh to
transfer pictures:
1, Press on the armws on the camera’s port cover and slide
down the cover.
no
arrow’
2. Align the cable connector with the camera’s serial port as
shown. If you are using the Mac Connectivity Kit cable,
use the white end. If you are using the cable that came
with the PhotoPC Mac version, use the long cable with the
DB9 connector. Attach the DB9 connector to the DEW
connector on the Mac adapter and tighten the screws.
Mac adapter
DB9 connector Photo PC cable
3. Connect the other end of the cable or adapter to either the
See the EPSON PhotoPC Macintosh User’s Guide for
printer port or the modem port. instructions on installing
a PhotoSpan module.
4. Turn on the camera and the Macintosh system. A frame
appears around the picture counter on the control panel. You can connect the PhotoPC to a standard electrical outlet
using the AC adapter (A8824.21, model PCDCO02) to save
power when transferring pictures to the Macintosh or
operating the camera from the Macintosh. The adapter does
not charge the camera’s batteries.
You can use any standard 37mm video camcorder lens or
filter with PhotoPC. To attach a lens, screw it on to the
camera as shown:
Note:
When fhe camera is connected to the Macintosh, you cannot use the
shutter button or any ofthe control buttons.
Use EasyPhoto to transfer pictures to the Macintosh; see the
EPSON PhotoPC Macintosh User’s Guide for instructions.
Note:
EasyPhoto automaticdly chooses a speed that works with most
Macintosh computers. You can experiment and choose the fastest
speed that works with your system:
cl 9600
a 29,200
cl 38,400
Cl 57,600
Increasing port speed wdl make pictures transfer much more
quickly to the Macintosh.
Digital Camera 5/96
Care for the camera as follows:
a
a
a
a
a
Use a clean, dry cloth to keep the camera free of dust.
Do not use harsh abrasive cleaners.
To clean the lens, blow off any loose dust; then breath on
the lens and wipe off the moisture with a soft, lint-free
cloth or lens cleaning tissue. To avoid scratching the lens,
do not press too hard.
Cover the lens (power switched off) when you are not
using the camera.
If necessary, clean the battery contacts with a dry cloth.
In storage, do not expose the camera to the following:
Ci Direct sunlight, bright light sources, or heat sources (such
as a closed car)
D Excessive dust, dirt, humidity, strong vibrations, or
magnetic fields.
Optional Accessories
You can increase the camera’s storage capacity by installing a
2MB or 4MB PhotoSpan memory module, as described in
this table:
EPSON PhotoPC-Macintosh-3

EPSON PhotoPC-Macintosh
Information Reference List
Engineering Change Notices
None.
Product Support Bulletins
None.
Technical Support Bulletins
None.
Related Documentation
CPD3585
PhotoPC Macintosh User’s Guide
EPSON PhotoPC-Macintosh-4
5/96 Digital Camera
