Epson Runsense SF-810 User manual

UserManual
GPSSportsMonitor

Introduction
Thank you very much for purchasing this GPS Sports Monitor "RUNSENSE".
To use the device correctly, make sure you read the User Manual along with the supplied Quick Start Guide.
Keep the supplied Quick Start Guide handy to help you resolve any problems.
This device can measure running distance, pace, elapsed time, altitude, and calories burnt. You can also upload
recorded data to a dedicated website allowing you to look back over previous workouts.
Descriptions in the User Manual
c
Important: Indicates things you must or must not do. Ignoring these instructions or
mishandlingthisdevicecouldcausemalfunctionor operational problems
to the device.
Note: Indicates additional explanations and related information.
Menu Name Indicates menu items displayed on the screen of the device.
A/B/C/DIndicates the device buttons.
UIndicates related pages. Click the link in blue text to display the related
page.
Trademarks
EPSON and EXCEED YOUR VISION are registered trademarks of the Seiko Epson Corporation.
Microsoft and Windows are registered trademarks of the Microsoft Corporation in the United States of America and
other countries.
The Bluetooth
®
word mark and logos are the registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by the Seiko Epson Corporation is under licence.
Other product names are the trademarks or registered trademarks of their respective companies.
Caution:
❏Unapproved copying of part or all of this guide is strictly forbidden.
❏The content of this guide is subject to change without prior notice.
❏Although every effort has been made to ensure the accuracy of this guide, contact us if you have any questions or
notice any errors in descriptions in the content of this guide.
❏Despite the preceding clause, we cannot accept any responsibility for mishandling due to errors in this guide.
❏We cannot accept any responsibility for malfunctions and so on that occur due to ignoring the content of this
guide, the device being handled inappropriately, repairs or modifications performed by a third party that is not
our company or appointed by our company.
SF-810 User Manual
Introduction
2

Features
The SF-810 has a built-in heart rate sensor which will help you during workouts and make heart rate zone training
easy.
Chronograph function
Allows you to measure running data such as distance and time.
You can measure split and lap times, as well as using the GPS signal to measure distance
and pace.
U“Measuring Time, Distance, and Speed (Chronograph Function)” on page 40
Split Time: Elapsed time from the start
Lap time: Time taken for each lap
You can use the recall screen to check recorded measurement data.
U“Checking Measurement Data” on page 62
Interval function
Allows you to perform interval training.
Interval training:
Training method in which you repeat sets of light and hard exercise to increase your
athletic ability. An exercise menu is created using combinations of hard (sprint) and
light (recovery) exercise. An alarm sounds when it is time to change between sprinting
and recovering.
U“Setting a Time and Distance for Hard and Light Workouts (Interval Function)” on
page 45
Goal function (timed race)
Allows you to set a time as your goal and measure the time remaining until that goal is
reached.
You can exercise while checking the elapsed time. You can also calculate the estimated
distance you will cover during that time.
U“Measure until the Time or Distance Set in Advance Is Reached (Goal Function)” on
page 52
You can use the recall screen to check recorded measurement data.
U“Checking Measurement Data” on page 62
SF-810 User Manual
Introduction
3

Goal function (distance race)
Allows you to set a distance as your goal and measure the distance taken until that goal
is reached.
You can exercise while checking the distance. You can also calculate the estimated total
time to complete the set distance.
U“Measure until the Time or Distance Set in Advance Is Reached (Goal Function)” on
page 52
You can use the recall screen to check recorded measurement data.
U“Checking Measurement Data” on page 62
Measure settings
Allows you to change the measurement settings.
❏Measuring pulse (heart rate) (Heart Rate function)
U“Measuring Pulse (Heart Rate) during Exercise” on page 38
❏Automatically records laps when a time or distance set in advance has been
reached (AT Lap function)
U“Recording Laps Automatically (AT Lap Function)” on page 56
❏Automatically stops measuring when you stop running, and resumes when you
continue running (AT Pause function)
U“Automatically Start/Stop Measuring (AT Pause Function)” on page 58
❏Sets and measures the target time for one kilometre/mile (Target Pace function)
U“Setting a Pace and Measuring (Target Pace Function)” on page 59
❏You can change the items and layout of the measurement screen display (Screen
settings function)
U“Screen” on page 100
❏Tap to display a set function (Tap function)
U“Tap” on page 21
SF-810 User Manual
Introduction
4

Settings
Allows you to change the settings for the device.
❏Communicates with external devices (Communication function)
U“Smart Phone” on page 96
❏Inverts the screen's display (Invert function)
U“System Settings” on page 98
❏Adjusts the screen's contrast (Adjust contrast function)
U“System Settings” on page 98
❏Turns on the light automatically when the screen changes (Auto Light function)
U“System Settings” on page 98
❏Sets an alarm (Alarm function)
U“System Settings” on page 98
❏Turns off operation tones (Operation Tones function)
U“System Settings” on page 98
❏Resets configuration information in the device's memory (Initialize function)
U“System Settings” on page 98
Other features
❏You can measure pitch and stride using the built-in stride sensor.
U“Educating Your Pulse and Stride Sensor” on page 34
❏You can skip GPS positioning if it is taking too long.
U“Skipping GPS positioning” on page 31
❏You can take measurements without performing GPS positioning.
U“Indoor mode” on page 31
❏You can monitor, analyse, compare and share your recorded data using the
dedicated Web application "RUNSENSE View".
U“Data Management Using the Web Application (RUNSENSE View)” on
page 65
SF-810 User Manual
Introduction
5

Contents
Introduction
Features.................................3
Using this Device Safely
SymbolsinthisManual......................8
NotesonUsage............................9
Notes on using the product and components
.....................................9
Notesonusingthecradle..................9
NotesonElectromagneticWaves..............10
Preparing and Basic Operations
CheckingtheItemsProvided.................13
Wearingthedevice........................14
BasicOperations..........................15
Changingscreens.......................15
Functionofeachbutton..................17
Tap.................................21
Alarm(tones/vibration)..................22
Charging...............................23
Beforeuse.............................23
Charging.............................24
InitialSettings............................27
Aboutthebattery.......................29
SpecifyingaGPS(GPSPositioning)............30
Measuringfunctionforthedevice...........30
GPSpositioning........................31
Indoormode...........................31
Makingprecisemeasurements..............33
EducatingYourPulseandStrideSensor.........34
Aboutthepulse/stridesensor...............34
Educating the sensors for pulseandstride.....34
MeasurableItems.........................35
Measure
Measuring Pulse (Heart Rate) during Exercise. . . . 38
Measuringpulse(heartrate)...............38
Displaying the measured pulse (heart rate)
screen................................39
Measuring Time, Distance, and Speed
(ChronographFunction)....................40
Whatisthechronographfunction?..........40
Measuring............................41
Screendisplay..........................43
Setting a Time and Distance for Hard and Light
Workouts(IntervalFunction)................45
Whatistheintervalfunction?..............45
Setting interval conditions and measuring. . . . . 46
Loading interval conditions that have already
beenset..............................49
Screendisplay..........................51
Measure until the Time or Distance Set in
AdvanceIsReached(GoalFunction)...........52
Whatisthegoalfunction?.................52
Measuringbysettingthetimeordistance......53
Screendisplay..........................55
Recording Laps Automatically (AT Lap
Function)...............................56
Automatically Start/Stop Measuring (AT Pause
Function)...............................58
Setting a Pace and Measuring (Target Pace
Function)...............................59
Checking Measurement Data (Recall
Function)
CheckingMeasurementData.................62
Measurement data that can be checked in
recall................................62
Deleteunnecessarymeasurementdata........63
Data Management Using the Web
Application (RUNSENSE View)
What is the Web Application (RUNSENSE
View)?.................................66
Installing Run Connect (Uploader Software). . . . . 68
Creating an Account (When Using for the First
Time)..................................69
UploadingMeasurementData................71
CheckingUploadedMeasurementData.........74
Setting Measurements Using the PC
Application (Run Connect)
What is the PC Application (Run Connect). . . . . . 78
Starting Run Connect and Displaying the Settings
Screen.................................80
SettingtheATLapFunction.................82
SettingATlap..........................82
SF-810 User Manual
Contents
6

Measuring............................83
SettingtheTargetPaceFunction..............84
Settingthetargetpace....................84
Measuring............................86
SettingtheIntervalFunction.................87
Settingintervals........................87
Measuring............................88
Settings
HowtoChangetheSettings..................90
Measuresettings..........................91
ChangingtheMeasuresettings.............91
Measureset.table.......................93
Settings.................................95
ChangingtheSettings....................95
Settingstable...........................96
Screen.................................100
Screensettings........................ 100
Screenpatterntable.....................101
Measurementdisplayabbreviations......... 104
Changingthemeasurementscreen..........107
ChangingtheLapscreen................. 110
Maintenance
Lookingafteryourdevice..................114
Aboutthestrap........................114
Replacing the Battery on your GPS Sports
Monitor............................... 115
About the device's built-in rechargeable
battery.............................. 115
UpdatingtheFirmware.................... 116
Checkingthefirmwareversion.............116
Updatingthefirmware.................. 116
Troubleshooting
Caution............................... 118
ProblemSolving......................... 118
ResettingtheSystem...................... 121
ContactingusAboutthisProduct............122
After-salesService........................123
Appendix
UnderstandingtheIcons................... 125
ProductSpecifications.....................127
Devicespecifications....................127
Cradlespecifications.................... 128
ACadapterspecifications(optional).........128
Glossary............................... 129
Index
SF-810 User Manual
Contents
7

Using this Device Safely
Make sure you read the manuals (Quick Start Guide and User Manual) first to use this product safely.
The product may malfunction, or an accident may occur if it is handled incorrectly.
❏Keep the manuals handy to help you resolve any problems.
❏When taking this product out of the country of purchase, check the laws and regulations in the destination
country before you travel.
❏This product is not a medical device. Use this product as an indicator during physical exercise.
Symbols in this Manual
The following symbols are used in this guide to indicate possible dangerous operations or handling. Make sure you
understand these warnings before using the product.
!
Warning:
This symbol indicates information that, if ignored, could possibly result in serious personal injury.
!
Caution:
Ignoring these instructions and mishandling this device could cause injury or damage to property.
This symbol indicates an action that should be done.
This symbol indicates an action that must not be done.
SF-810 User Manual
Using this Device Safely
8

Notes on Usage
Notes on using the product and components
Warning
Exercise according to your physical capabilities. Stop exercising and consult your doctor if you
feel unwell during exercise.
Do not use or store this product in the following environments. It may cause an electric shock or
fire, or the product may malfunction or be damaged.
❏Locations with very high or low temperatures or humidity
❏Near volatile substances
❏Dusty places
❏Near a strong magnetic field (for example, near a loudspeaker)
Do not disassemble this product, and do not attempt to repair this product by yourself. It may
cause an electric shock or accident.
Do not leave this product within reach of young children.
Caution
Stop using the device immediately and consult your doctor if you have an allergic reaction or a
rash during use.
The device is water resistant at 5 bar (5 ATM). Although you can use the device for swimming and
so on, do not perform button operations under water.
Do not pour water directly from the tap onto this product. The power of the tap water stream may
be strong enough to compromise the product’s waterproof feature.
Do not wear this product in a bath or sau na. The steam and soap may compromise the waterproof
feature or cause corrosion.
Notes on using the cradle
Warning
Do not use the cradle or AC adapter if they are in any way damaged, faulty or contaminated by
foreign material such as dust, water or dirt. Do not use any adapter other than the specified
adapter for charging.
SF-810 User Manual
Using this Device Safely
9

Notes on Electromagnetic Waves
This device is equipped with Bluetooth
®
Smart technology. When operating supported smartphones, this function
wirelessly sends and receives measurement data to the device.
This device has been classified as a low electronic data communication system based on Radio Law. Therefore, this
device does not require a radio station licence. The following acts may be punishable by law.
❏Disassembling or remodeling the device
❏Removing the verification or certification number for the device
VCCI Class B Information Technology Device
This device is a class B information technology device. This device is designed for home
use, but interference could occur when using in close proximity to radios or television
aerials.
Certification information
Frequency
This device uses the frequency bands 2.402 to 2.480 GHz. Other wireless devices may
use the same frequency. Note the following points to avoid wireless interference with
other wireless devices.
Precautions when performing wireless communication
This device operates on the 2.4 GHz band.
This device operates in the same frequency bandwidth as industrial, scientific, and medical devices such as microwave
ovens and mobile object identification (RF-ID) systems (licensed premises radio stations, amateur, and unlicensed
specified low-power radio stations (hereafter "other radio stations")) used in factory production lines.
1. Before using this device, make sure there are no "other radio stations" being used in the vicinity.
2. If this device causes RF interference between the device and "other radio stations", promptly move to a different
location, stop using the device, and contact your local reseller to ask for advice on preventing interference (for example
setting up partitions).
3. In addition, when harmful radio wave interference occurs between the device and "other radio stations", and refer to
"Contacting us about this product" to contact our service centre.
U“Contacting us About this Product” on page 122
SF-810 User Manual
Using this Device Safely
10
