INK TANK SYSTEM PRINTER
L1800
In creating the next wave of printing innovation, Epson
introduces the world’s first truly affordable 6 colour A3+
original ink tank system printer. The L1800 comes with
borderless printing capabilities and great colour fidelity,
along with low running costs. It’s the perfect solution for
large, stunning photos, graphics, posters and more.
The Epson L1800 is
bundled with a starter
kit of 6 bottles x 70ml of
photo colour Epson inks,
allowing up to 1,500^ 4R
photo prints.
BORDERLESS A3+
PHOTO PRINTING MADE
TRULY AFFORDABLE.
Cost
Effective
Print
up to A3+
High-Yield
Ink Bottles
1 Year
Warranty
A3+ Borderless Photo Printing
Supports borderless A3+ photo quality
printing for superior photos, graphics
and more.
Superb Savings and Page Yield
Large integrated ink tanks and
highly affordable ink bottles at just
US$10.50 each.
Unsurpassed Print Quality
With a resolution of 5760 dpi and the expanded
colour gamut of 6 inks, you can be assured of
the highest quality in photo printing.
^Refer to specifications.

The L1800 is the world’s first A3+ 6-colour original ink tank system
printer, giving you the ability to produce borderless, photo quality
prints at ultra low running costs. When it comes to sharing high
impact visuals on a larger scale, the L1800 is the solution you’ve
been waiting for.
INK TANK SYSTEM PRINTER
L1800
A3+ Borderless Photo Printing
The L1800 allows you to print borderless,
photo quality images up to A3+ in size. It
delivers superior colour reproduction for
large photos, graphics and more to achieve
the best impression on your audience.
Superb Savings and Page Yield
High capacity integrated ink tanks and highly affordable
genuine photo ink bottles at just US$10.50 each add up
to greater savings. The L1800 is bundled with 6 photo ink
bottles that yield up to 1,500^ borderless 4R photos.
^Refer to specifications.

Unsurpassed Print Quality
Designed for continuous printing
performance, Epson’s renowned Micro
Piezo™printhead is not only highly reliable
in operation, it also delivers an astoundingly
high resolution of 5760dpi. Paired with
the expanded colour gamut of 6 photo inks, the L1800
delivers superior colour, gradation and photographic tones
in every printout.
Designed for High Productivity
The L1800 is designed to achieve fast print
speeds of up to 15ppm (draft/black) and
45 sec per 4R borderless photo.
PARTNERS IN PERFECTION
Epson L800 Ink Tank System Printer
A4 photo quality printer with 6-colour original
ink tank system for superior colour fidelity.
Epson Expression 11000XL A3 Photo Scanner
Fast and flexible A3 scanner with 2400 x 4800 dpi resolution,
zero warm-up time and optional Transparency Unit for
handling a wide variety of film formats.
Media Flexibility
The L1800 supports printing to a wide variety
of printing media from 4R photo prints all
the way up to A3+ sizes, allowing you to
accomplish all your printing jobs, from the
simplest to the most demanding.
1-Year Warranty for Peace of Mind
Enjoy warranty coverage of one year or
30,000 prints, whichever comes first, for
maximum value from your printer and
freedom from maintenance worries.
Hassle-free Operation
Epson’s original ink tank system is engineered for easy,
mess-free refills. The special tubes in the printer are
designed to ensure smooth and reliable ink flow at all times.
Quality That Shines. Value That Lasts.
Epson genuine ink bottles are individually sealed to
ensure the purity of its contents and formulated to deliver
outstanding high-volume print quality with L-Series
printers. Choose Epson genuine ink bottles to enjoy lasting
quality with your L-Series printer and low printing costs.
Specially fitted tubes ensure reliable ink flow
without leakage
Smart tip design for easy, mess-free refills

MODEL NUMBER L1800
Printing
Print Method On-demand ink jet
Nozzle Configuration 90 nozzles each colour (Cyan, Light Cyan, Magenta, Light Magenta, Yellow, Black)
Print Direction Bi-directional printing, Uni-directional printing
Maximum Resolution 5760 x 1440 dpi (with Variable-Sized Droplet Technology)
Minimum Ink Droplet Volume 1.5pl
Print Speed *1
Max Draft Text - Memo A4 Approx. 15#1/15#2ppm (Bk/Cl)
Photo Default - 10x15cm/4x6" Approx. 45 sec per photo (Borderless)
Double-sided Printing Yes (Manual)
Paper Handling
Paper Feed Method Friction feed
Number of Paper Trays 1
Paper Hold Capacity
Input Capacity 100 sheets, A4 Plain paper (75g/m2), 30 sheets, Premium Glossy Photo Paper
Output Capacity 50 sheets, A4 Plain paper, 20 sheets, Premium Glossy Photo Paper
Paper Size A3+, A3, B4, A4, A5, A6, B5, 10x15cm (4x6"), 13x18cm (5x7"), 16:9 wide size,
Letter (8.5x11"), Legal (8.5x14"), Half Letter (5.5x8.5"), 9x13cm (3.5x5"),
13x20cm(5x8"), 20x25cm(8x10"), Envelopes: #10(4.125x9.5")
DL(110x220mm), C4 (229x324mm, C6(114x162mm)
Maximum Paper Size 12.95 x 44"
Print Margin 0mm top, left, right, bottom via custom settings. Otherwise 3mm top, left, right, bottom.
Connectivity
Standard USB 2.0 Hi-Speed
Printer Software
Operating System Compatibility Windows XP/XP Professional x64 Edition/Vista/7/8/8.1
Mac OS X 10.5.8, 10.6.x, 10.7.x, 10.8.x, 10.9.x
Electrical Specifications
Rated Voltage AC 220-240V (Rated voltage will vary depending on area)
Rated Frequency 50~60 Hz
Power Consumption
Printing Approx. 16W
Standby Approx. 6.8W
Sleep Approx. 2.2W
Power Off Approx. 0.4W
Epson Genuine Ink Bottle Photo Page Yield (4R) *2 Order Code
Black 8,700 pages T6731
Cyan T6732
Magenta T6733
Yellow 1,500 pages T6734
Light Cyan T6735
Light Magenta T6736
SPECIFICATIONS
L1800
Dimensions & Weight
322mm (12.7")
215mm (8.5")
705mm (27.8")
L1800
Weight: 12.5kg (27.6lb)
Photo 4R
(4 x 6")
#3
Black text
and graphics
#2
Black text
#1
*1 Print speed (Pages Per Minute) is calculated
when printed on A4 plain paper in the fastest
mode. Print speed may vary depending on
system configuration, print mode, document
complexity, software, type of paper used
and connectivity. Print speed does not include
processing time on host computer.
© 2014 Epson Singapore Pte Ltd. All Rights Reserved.
Reproduction in part or in whole, without the written
permission from Epson, is strictly prohibited.
EPSON and EXCEED YOUR VISION are registered
trademarks of Seiko Epson Corporation. All other
products names and other company names used
herein are for identification purposes only and are
the trademarks or registered trademarks of their
respective owners. Epson disclaims any and all rights
in those marks. Print samples shown are simulations
only. Specifications and product availability are
subject to change without notice and may vary
between countries. Please check with local Epson
offices for more information.
*2 Quoted yields are extrapolated based on Epson
original methodology from the print simulation
of Test Patterns provided in ISO/IEC 29103.
Quoted yields are NOT based on ISO/IEC
29103. Actual yields may vary depending
on manner of usage and print pattern.
Information correct as at April 2014
