Projection System EPSON original LCD prism technology
Projection Method Front/rear/ceiling mount
LCD
Size 0.9"
Driving method EPSON Poly-Silicon TFT Active Matrix
Pixel number 786,432 dots (1024 x 768) x 3
Native resolution XGA
Aspect ratio 4:3 (supports 16:9, 5:4)
Pixel arrangement Stripe
Projection Lens
Type Manual: zoom/focus
F-number 1.74 to 2.06
f-number 28.3mm to 37.98mm
Zoom ratio 1:1.35
Lamp
Type 200W UHE
Life (typical) 1500H (can last about 5 years. based on
6 hours/week x 50 weeks/year)
Screen Width Ratio (distance/width) 1.5 to 1.97:1
Screen Size (projected distance) 30" to 300" (0.87m to 12.48m)
Keystone Correction Vertical: +/- 30 degrees, Horizontal: +/-10 degrees
Brightness (typical) 2000 ANSI lumens
Contrast Ratio 400:1
Brightness Uniformity (typical) 85%
Color Reproduction 24 bit; 16.7ml
Audio Output 5W
Operating Temperature 5°C to 35°C (41°F to 95°F)
Power Supply Voltage 100-120V, 200-240V +/-10%, 50/60Hz AC
Power Consumption 280W (5.5W at stand by mode)
Maximum Dimensions (includes lens and feet) 10.87"D x 13.75"W x 4.5"H
Dimensions (includes lens and feet) 10.79"D x 13.71"W x 4.1"H
Weight 9.3 lbs/4.2kg
Fan Noise 38db
Effective Scanning Frequency Range
Pixel clock 14MHz to 230MHz
Horizontal 15KHz to 107KHz
Vertical 43Hz to 120Hz
Remote Control
Features Keystone (horizontal & vertical), Picture in
Picture, special effects, source selection, power,
resize, right/left mouse click, volume, presets
Operating angle Right/Left +/_30°, Upper/Lower +/_15°
Operating distance 30ft (10m)
RGB
Analog RGB I/O Digital RGB Input
Display performance
Native 1024 x 768 1024 x 768
Resize 1600 x 1200 1280 x 1024
1280 x 1024 800 x 600
800 x 600 640 x 480
640 x 480
Input terminal
Video Mini D-sub 15pin DVI Type l
DVI Type l
Audio Stereo mini jack Stereo mini jack
RCA x2
Output terminal
Video Mini D-sub 15pin (monitor out)
Video I/O
Display performance NTSC: 550 line, PAL: 550 line (Depend on
observation of multi burst pattern)
Input signal NTSC,NTSC4.43,PAL,M-PAL,
N-PAL,PAL60,SECAM; HDTV: 480p,
480i, 720p, 1080i, 1080p
Input terminal
Video Composite Video: RCA x 1
S-Video: Mini DIN
Video RGB: Mini D-sub 15pin
Component Video: Mini D-sub 15pin
Audio RCA x 2 (for composite video/S-video/
component video)
Stereo mini jack (for video RGB)
Control I/O
Mouse/USB I/O Mini DIN 9pin (for PS/2 mouse)
USB connector series A (for Hub)
USB connector series B (for mouse,
keyboard, audio control)
Serial I/O Mini D-sub 9pin
RS-232C
Input terminal Stereo mini jack (for remote control)
Security Kensington®-style lock provision
Warranty
Two year limited warranty, international warranty, 90-day lamp warranty,
EPSON Road Service Program and EPSON PrivateLine dedicated toll-free
support (U.S. and Canada only)
Supplied Accessories
Power cord, RCA video/audio cable, remote control, 2 batteries, computer
cable HD15/HD15, PS/2 mouse cable, USB mouse cable, Start Here kit
Product/Accessory Part Numbers
EPSON PowerLite 811p projector V11H066020
Replacement lamp V13H010L15
Soft shoulder bag ELPKS13
ATA shipping case ELPKS41
ATA molded hardshell case ELPKS40
Samsonite wheeled soft case ELPKS35
Digital video cables
DVI cable DVI to DVI, 3 meter ELPKC20
DVI cable DVI to DFP, 3 meter ELPKC21
DVI analog cable V12H005C25
Component video cable ELPKC19
Ceiling mount ELPMB36
Suspension adapter ELPMBAPL
False ceiling plate ELPMBFCP
Mac adapter set ELPAP01
Remote control receiver ELPST02
Remote control receiver kit ELPST04
Portable screens
50" portable screen ELPSC06
60" insta-theatre screen ELPSC07
80" insta-theatre screen ELPSC08
Wireless microphone system ELPCVSII
Presentation audio system ELPPAS1
Kensington security lock ELPSL01
High resolution document imager ELPDC02
Motion presentation camera ELPDC03
High resolution document camera V12H064020
Support–The Epson ConnectionSM
Pre-Sales Support U.S. and Canada 800-463-7766
Automated Technical Support 800-922-8911
Internet Web Site www.epson.com
presentersonline.com
SM
Get ready for 2000 lumens of brightness, XGA
resolution, and a remarkable combination of features that
give you the flexibility to meet virtually any presentation
requirement—in any situation. Available at a great value,
the 9.3 lb EPSON PowerLite 811p is engineered for maximum
power and versatility.
Bright enough to install in a conference room or auditorium, but light
enough to carry across town, this whisper-quiet portable has a feature
set that adapts to any presentation environment. With its advanced
optics and three Epson 0.9" high-aperture LCDs, it offers the greatest
color and detail for superior image quality.
This versatile product goes one step further, providing some impressive
features without costly expansion modules. Multiple inputs offer flexible
connectivity, while the 1.35x optical zoom lens supports a variety of
placement options. Horizontal keystone correction provides additional
positioning flexibility. The lamp access on top of the projector enables
easy changes, even when the projector is ceiling-mounted.
All in all, the EPSON PowerLite 811p offers exceptional brightness,
extreme flexibility, and incredible dependability. In fact, experienced
professionals who service and sell multimedia projectors choose Epson
5:1 as the most reliable.
Superior Image Quality and Performance
•Unbelievable 2000 lumens in a 9.3 lb projector
•XGA (1024 x 768) resolution for sharp, vivid detail
•Three EPSON 0.9" high-aperture LCDs for rich color
saturation across the screen
•400:1 contrast ratio for blacker blacks and whiter whites
•EPSON ColorReality™color processing technology provides
6 user-selectable modes for maximum flexibility, which
presenters can choose from based on their presentation
materials or environment
Powerful Feature Set
•No costly expansion modules necessary; complete set of
computer and video connections built-in
•Horizontal and vertical keystone correction (30° vertical,
10° horizontal)
•Quiet 38db operation to eliminate excessive sound
during presentations
•Multiple inputs and outputs, including component
and DVI inputs (compatible with digital and analog signals)
•5Watt audio so there’s no additional audio expense
Reliable and Easy to Use
•1.35x optical zoom ratio to position the projector closer
to the screen for unobtrusive operation
•Full-featured remote control with easy-to-use page-up
and page-down presentation control
•Conveniently placed lamp access on top of the projector,
designed for easy changes, even when the projector is
ceiling-mounted
•Intuitive menu functions
•Start Here Kit gets first time users projecting in just minutes
•EPSON PrivateLineSM toll-free person to person technical support,
available from 6 a.m. to 6 p.m. PST Monday through Friday.
Calls are typically answered within 45 seconds
CYAN
MAGENTA
YELLOW
BLACK
PANTONE 519 CV
PANTONE 5483 CV
CVPANTONE 519 CV
EPSON PowerLite 811p Specifications
EPSON PowerLite®811p
Smart features from a truly bright performer
Specifications and terms are subject to change without notice. EPSON is a registered trademark and EPSON ColorReality is a trademark of Seiko Epson Corporation. PowerLite is a registered trademark, SizeWise is a
trademark and Epson Connection, PrivateLine and Presenters Online are service marks of Epson America, Inc. All other product and brand names are trademarks and/or registered trademarks of their respective
companies. Epson disclaims any and all rights in these marks. © Copyright 2002 Epson America, Inc. CPD-13885 25K 5/02 WP Printed on Recycled Paper
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
3771 Victoria Park Ave, Toronto, Ontario M1W 3Z5
Epson Latin America
6303 Blue Lagoon Drive, Miami, FL 33126
EPSON®
full-featured
IR remote control
stylish metallic
silver finish
Front View
high
performance,
low profile
Back View
computer 2/
component video
mouse port
audio L/R
USB monitor out
RS-232C
S-video
remote
computer 1/DVI

Projection System EPSON original LCD prism technology
