Epson PowerLite 8300i withEasyMP.net module User manual

For extraordinary power and convenience, the EPSON PowerLite
8300i offers 5200 ANSI lumens, XGA resolution, and a 1200:1
contrast ratio, as well as out-of-the-box networking capabilities.
IS personnel will appreciate its EasyManagement™technology for
easy network monitoring and control, while presenters will enjoy
its versatile feature set. This 24.7 lb installable includes monitor
out capability, plus a preview function for easy switching between
sources. Engineered to meet virtually any presentation requirement,
the EPSON PowerLite 8300i provides extraordinary video
performance and QuickCorner™image correction capability. With
vertical and horizontal keystone correction, multiple inputs and a
variety of lens options, it offers exceptional installation flexibility.
Convenient networking capability with
EasyManagement technology
• Offers information on projector status via:
- Web browser - no special software required!
- SNMP (Simple Network Management Protocol) with OpenView
plug-in available
- EMP Monitor software and EMP network monitor utility
(included)
• Allows easy monitoring of:
- Lamp status
- Power status
- Source status
• Works with projector’s built-in Ethernet connection
• Enables secure access via password protection feature
• Monitors all Epson network projectors
• Provides real-time status information and projector error
detection
• Email notification via SMTP to alert issues related to temperature,
fan and lamp
Ultra bright 5200 lumens, weighs only 24.7 lb
• Astonishing brightness that’s great for large auditoriums
Superior detail and razor-sharp contrast
• Three 1.4" EPSON high-aperture LCDs for evenly distributed
color across the screen
• XGA (1024 x 768)
resolution for sharp,
vivid detail
• 1200:1 contrast ratio
for blacker blacks and
whiter whites
Easy installation, setup and operation
• Multiple lens options
• Keystone (45˚ vertical, 40˚ horizontal) and QuickCorner
image correction capability for flexible setup and installation
• Preview function with seven convenient SnapWindows™
• Monitor out capability for all input signals
• Easy-to-use remote control/control panel
• Manage the setup and installation process, power zoom lens,
picture-in-picture capability, focus controls, lens shift, and more
• Operate multiple projectors simultaneously
• Low fan noise for undisturbed presentations
• Improved air filter to protect projector life in smoky or dusty
environments
• Start Here Kit gets first time users projecting in just minutes
State-of-the-art video performance
• New progressive processing circuitry for better video image
quality
• Digital Visual Interface (DVI) for future digital connectivity/
compatibility
• HDTV-ready
Renowned EPSON service and support
(free for the duration of the warranty)
• Comprehensive two-year warranty
• 90-day bulb warranty for added dependability
• EPSON Road Service Program provides a replacement projector,
typically within 24 hours
• EPSON PrivateLineSM dedicated toll-free support line
available from 6 a.m. to 6 p.m. PST Monday – Friday
(Calls are answered live, typically in about a minute.)
• International warranty in over 45 countries
EPSON PowerLite®8300i
A mega-star that’s easy to manage
EPSON®
Back View
Front View
composite video
audio out
monitor out
computer 1
computer 2
s-video
audio
component video
hard-wired remote
lens shift/
optional lenses/
zoom lens
full-featured
IR remote
control
stylish metallic
silver finish
LAN RJ-45
DVI
RS-232C
USB
interface cover included
PL8300i CatSht c15653 72 4/9/03 10:00 AM Page 1

SM
Projection System EPSON original LCD prism technology
Projection Method Front/rear/ceiling mount
LCD
Size 1.4 inches
Driving method EPSON Poly-silicon TFT Active Matrix
Pixel number 786, 432 pixels x 3 (1024 x 768) LCDs
Native resolution XGA
Aspect ratio 4:3 (supports 16:9; 5:4)
Pixel arrangement Stripe
Projection Lens
Type Electric: Zoom/focus/lens shift
F-number 1.7 to 2.2
f-number 53 to 72mm
Zoom ratio 1.0:1.35
Lamp
Type 320W UHE
Life (typical) 2000H (High Brightness)
Screen Width Ratio: (Distance/Width) 1.79 to 2.47:1
Screen Size (Projected Distance) 22" to 300" (1.1m to 15m)
Keystone Correction Vertical: ±45˚, Horizontal: ±40˚
Brightness (typical) 5200 ANSI lumens, 3000 ANSI lumens (Low Brightness)
Contrast Ratio 1200:1
Brightness Uniformity (typical) 90%
Color Reproduction 24 bit; 16.7 mil
Audio Output 7W Monaural
Operating Temperature 41ºF to 104ºF (5ºC to 40ºC)
Power Supply Voltage 100-120V, 200-240V ±10%, 50/60Hz AC
Power Consumption 480W, (60W @ sleep mode Network ON, 1.5W @ sleep mode Network OFF)
Dimension (includes lens and feet) 19.3"D x 13.8"W x 7.6"H
Dimension (excludes lens and feet) 19.3"D x 13.7"W x 7"H
Weight 24.7lb/11.2kg
Fan Noise 36db in High Brightness, 33db in Low Brightness
Effective Scanning Frequency Range
Analog
Pixel Clock 13.5MHz to 230MHz
Horizontal 15KHz to 107KHz
Vertical 50Hz to 120Hz
Digital
Pixel Clock 25MHz to 135MHz
Horizontal 15KHz to 80KHz
Vertical 50Hz to 85Hz
Remote Control Features
Features Keystone, brightness, source selection, power,
PinP, preview, lens shift, page up/page down,
color mode, volume, presets, e-zoom, a/v
mute, freeze
Operating Angle Right/Left ± 30˚
Upper/Lower ± 15˚
Operating Distance 33 ft (10m)
RGB
Analog RGB I/O Digital RGB Input
Display performance
Native 1024 x 768 1024 x 768
Resize 1600 x 1200 1280 x 1024
1280 x 1024 800 x 600
800 x 600 640 x 480
640 x 480
Input terminal
Video Mini D-sub 15 pin x 2, DVI Type D x 1
5BNC x 1 (24 pin x 1)
Audio Stereo mini jack x 2 Stereo mini jack
(for Mini D-sub),
RCA x 2 (for 5BNC)
Output terminal
Video Mini D-sub 15 pin
(monitor out) x 1
Audio Stereo mini jack
Video I/O
Display performance NTSC: 560 lines
PAL: 560 lines
(Depends on observation of the
multi burst pattern)
Input signal NTSC/NTSC4.43/PAL/M-PAL/N-PAL/
PAL60/SECAM
HDTV: 480i, 480p, 720p, 1080i
Input terminal
Video Composite video: RCA (Yellow) x 1
S-Video: Mini DIN
Component video: Mini D-sub 15 pin
(in common with Analog RGB connector)
Video-RGB: Mini D-sub 15 pin (in common
with Analog RGB connector)
Audio RCA (White/Red) x 2
Audio signal 500m Vrms/47Kohm
Control I/O
USB I/O USB connector series B x 1 (for mouse,
keyboard)
Serial I/O Mini D-sub 9 pin x 1
RS-232C
Network interface RJ45 x 1
Input terminal Stereo mini jack x 1 (remote control)
Security Kensington®-style lock provision
Warranty
Two year limited warranty, 2-year international warranty, 90-day lamp
warranty, EPSON Road Service Program and EPSON PrivateLine dedicated
toll-free support (U.S. and Canada only)
Supplied Accessories
Power cable, remote control, 2 AA batteries, computer VGA cable,
audio cable, USB mouse cable, Cable Cover, CD-Rom (Windows-based
EasyManagement software), Start Here Kit
Product/Accessory Part Numbers
EPSON PowerLite 8300i Projector V11H068020
EPSON PowerLite 8300NL (no lens) Projector V11H068920
Replacement lamp V13H010L23
Air filter set V13H134A02
Rear projection wide lens V12H004R02
Wide zoom lens V12H004W02
Standard zoom lens V12H004S02
Middle throw zoom lens (2.42 to 3.67:1) V12H004M01
Middle throw zoom lens (3.57 to 5.45:1) V12H004M02
Long throw zoom lens V12H004L04
Remote control cable set V12H005C28
Ceiling mount ELPMB41
Suspension adapter ELPMBAPL
False ceiling plate ELPMBFCP
Distribution amplifier ELPDA01
Digital video cable DVI to DVI, 3m ELPKC20
Digital video cable DVI to DFP, 3m ELPKC21
Component video cable ELPKC19
S-video cable ELPSV01
Mac adapter set ELPAP01
ATA shipping case ELPKS47
50" portable screen ELPSC06
60" portable pop-up screen ELPSC07
80" portable pop-up screen ELPSC08
High resolution document imager ELPDC02
High resolution document camera V12H064020
Kensington security lock ELPSL01
Support–The Epson ConnectionSM
Pre-Sales Support U.S. and Canada 800-463-7766
Automated Technical Support 800-922-8911
presentersonline.com
EPSON PowerLite 8300i Specifications
