Epson PowerLite Pro G5200WNL User manual

Designed with your installation needs in mind, the widescreen
Epson PowerLite Pro G5200WNL offers the perfect solution for any
auditorium, classroom or boardroom. With 4200 lumens and WXGA
resolution, this powerful performer ensures amazing presentations.
Engineered to interface and integrate more easily with sophisticated
programming and controller applications — both IP and RS-232 —
this product works with modules and drivers for industry-leading
systems that can include touch-panel screens and multiple
content devices.
Engineered to integrate with complex presentation systems, the
PowerLite Pro G5200WNL includes a full feature set that makes
installation easy and affordable. And, Epson monitoring software
gives system administrators the power to monitor and control the
projector remotely.
Add to that the easy maintenance features and you’ve got everything
you need for brilliant presentations and a better bottom line. With
one-touch filter removal and easy lamp access, the PowerLite Pro
G5200WNL offers a low cost of ownership and added peace of
mind. It even includes a closed captioning decoder, so there are
no added costs to accommodate the hearing impaired. The Epson
PowerLite Pro G5200WNL is the ideal choice for both executive
boardrooms and educational institutions, with the value, power and
performance for all your presentation needs.
Features/Benefits
• Amazingpresentationsinanyclassroomorboardroom—
4200lumens,WXGAresolution(1280x800)
• Industry-leadingsystemsupport—advancedconnectivity:two
computerRGBinputs,threecomponentconnections(5BNCand
HD15)andanHDMIdigitalportwithHDCP
• Greaterpositioningflexibility—centeredlensdesign,vertical/
horizontallensshiftmechanismandstandardlenswith1.8xwider
zoom(lenssoldseparately)
• Closedcaptioningcapabilitieswithoutanyaddedcosts—
built-indecoder
• DirectOnandDirectOff—powerinstalledprojectorsoffandon
withtheflipofanoutletswitch
• Superiorcoloranddetail—800:1contrastratio
• Greaterinstallationflexibilitywithoptionalbayonetlenses—five
easilyexchangeableEpsonlensesavailable;standardlensfor
ceiling-mountedapplications(lenssoldseparately)
• Easyimagesetup—convenientQuickCorner®function
• Easymonitoringandcontrol—RJ-45withEpsonmonitoring
softwareincluded
• Simpleoff-axisinstallation—30-degreetiltoperation
• Convenientmaintenancefeatures—fast,easyfiltercleaningand
replacement,easysideaccesstothelamp
G5200WNL Top
G5200WNL Front
G5200WNL Remote
Speaker
Radio
LAN
RCA Audio
Composite Video 2
HDMI
S-Video
Audio
Computer 2/Component 2
Computer 1/Component 1
BNC Composite Video
Remote
Audio Out
Monitor Out
Control Panel
Power RS-232c
Component 5BNC
G5200WNL Back
PowerLite®Pro
G5200WNL
Astounding quality and reliability.
Lens not included

Projection System
High-aperture Epson 3-chip 3LCD technology
Projection Method
Front/rear/ceiling mount
LCD
Driving Method
Epson Poly-silicon TFT Active Matrix
Pixel Number
1,024,000 pixel x 3 LCDs (1280 x 800)
Native Resolution
WXGA (1280 x 800)
Aspect Ratio
Supports 16:10, 4:3, 16:9
Pixel Arrangement
Cross stripe
Projection Lens
Type
Manual focus/zoom
F-number
1.64 – 2.5 (standard lens), lens not included
Focal Length
21.27 mm – 37.93 mm (standard lens)
Zoom Ratio
Optical zoom 1.0 – 1.8
Lamp
Type
275 W
Lamp Life*
2000 hours (High Brightness Mode)
3000 hours (Low Brightness Mode)
Screen
Throw Ratio Range
1.64” – 2.5”
Size (projected distance)
30" – 300"
Lens Shift
Vertical: ±60 degrees
Horizontal: ±10 degrees
Keystone Correction
Vertical: -40 degrees to +40 degrees
Horizontal: -20 degrees to +20 degrees
Brightness (High Brightness Mode)
Light output — white: up to 4200 lumens (ISO 21118)
Light output — color: up to 4200 lumens
Contrast Ratio (High Brightness, Game Mode)
Up to 800:1
Brightness Uniformity (typical)
86%
Color Reproduction
16.7 million colors
Dimensions (W x D x H)
Including Feet (with standard lens)
18.5” x 13.26” x 5.94”
Excluding Feet, Lens
18.5” x 12.27” x 5.31”
Weight
14.81 lb
Effective Scanning Frequency Range
Pixel Clock
13.5 MHz – 162 MHz (up to UXGA 60 Hz)
Horizontal
15 KHz – 99 KHz
Vertical
50 Hz – 120 Hz
Remote Control
Features
Source search selection, power, aspect resize, color
mode, volume, e-zoom, A/V mute, freeze, menu,
page up and down, help, auto, mouse functions, ID
Operating Angle
Right/left ± 60 degrees
Upper/lower ± 20 degrees
Rear ± 30 degrees
Operating Distance
40 ft
Display Performance
Native
1280 x 800
Resize
640 x 480
800 x 600
1280 x 1024
1400 x 1050
1600 x 1200
Video I/O
Display Performance
NTSC: 560 line
PAL: 560 line
(depends on observation of the multi-burst pattern)
Input Signal
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/PAL60/
SECAM
SDTV: 480i, 480p; HDTV: 720p, 1080i
Pixel works: video chip
3D Y/C separation, noise reduction motion
compensated
Interlace-Progressive conversion (2 – 2,
3 – 2 film detection)
Interfaces
Computer/component video: mini D-sub HD 15 pin x 2
5BNC component x1
HDMI x1
Hardwire remote jack x1
S-video: mini DIN x 1
Composite video RCA x 1, composite x 1 BNC
Audio in (RCA (L & R) x 1, mini stereo x 1)
Variable audio out: mini stereo x 1
LAN networking: RJ-45 x 1
Serial: RS-232c x 1
Monitor out: mini D-sub 15 pin x 1
Other Features
Audio Output
7 W monaural
Audio Signal
500 m Vrms/47K ohm
Operating Temperature
32 ˚ to 104 ˚F (0 ˚ to 40 ˚C)
Power Supply Voltage
100 – 240 V ±10%, 50/60 Hz AC
Power Consumption
423 W (Operation)
0.6 W standby (network off)
Fan Noise
37 dB (High Brightness Mode)
30 dB (Low Brightness Mode)
Security
Kensington®-style lock provision, anchor (metal) bar
for security lock or cable
Support — Epson ConnectionSM
Pre-sales support
U.S. and Canada 800-463-7766
Internet website www.epson.com
Projector resources available at presentersonline.com
Service Programs
Three-year limited warranty, 90-day lamp warranty,
Epson Road Service Program and Epson PrivateLine®
dedicated toll-free support (U.S. and Canada only)
Contents
Power cable, computer cable, projector remote
control, batteries, cable cover, user manual CD, Easy
Management™ software CD, Quick Setup Sheet,
PrivateLine support card, password protection sticker
Accessory Part Numbers
Standard zoom lens <1.64 – 2.5> V12H004S03
Long throw zoom lens <1.84 – 2.32> V12H004L06
Middle throw zoom lens 1 <1.83 – 2.45> V12H004M04
Middle throw zoom lens 2 <1.83 – 2.53> V12H004M05
Rear projection wide lens <2.03> V12H004R03
Wireless mouse receiver for
remote control (ELPST16) V12H007T16
Air filter V13H134A17
Replacement lamp V13H010L46
Hardware remote control cable set V12H005C28
Replacement remote control 1485872
Advanced projector ceiling mount
with precision gear ELPMBPRG
High security projector ceiling mount ELPMBATA
Adjustable suspended ceiling channel kit ELPMBP01
False ceiling plate kit ELPMBP02
Structural round ceiling plate ELPMBP03
Adjustable extension column (pipe) 6” – 9” ELPMBC01
Kensington security lock ELPSL01
50-inch portable screen (4:3 aspect ratio) ELPSC06
60-inch portable pop-up screen
(4:3 aspect ratio) ELPSC07
80-inch portable pop-up screen
(4:3 aspect ratio) ELPSC08
Duet™ portable projector screen
(4:3/16:9 combination) ELPSC80
Component to VGA video cable ELPKC19
S-video cable ELPSV01
Distribution amplifier ELPDA01
Image presentation camera (ELPDC05) V12H162020
Projector Part Number
PowerLite Pro G5200WNL V11H298920
(Lens not included)
Epson PowerLite Pro G5200WNL Specifications
Packaging Specifications
PowerLite Pro G5200WNL
Dimensions 19.9” x 25.3” x 12.2” (W x D x H)
Weight 23.3 lb
Replacement Lamp
Dimensions 6.3" x 5.6" x 5.6" (W x D x H)
Weight 0.97 lb
Master Carton
Dimensions 28.4" x 13.1" x 6.8" (W x D x H)
Weight 11.7 lb
Units Per Master Carton 10
Replacement Air Filter
Dimensions 11.14" x 3.59" x 1.73" (W x D x H)
Weight 0.21 lb
Master Carton
Dimensions 19.17" x 11.78" x 4.84" (W x D x H)
Weight 3.09 lb
Units Per Master Carton 10
Specifications and terms are subject to change without notice. Epson and Quick Corner are registered trademarks, Epson Exceed Your Vision is a registered logomark and Easy Management is a trademark of
Seiko Epson Corporation. PowerLite and PrivateLine are registered trademarks, Duet is a trademark and Epson Connection and Epson PresentersOnline are service marks of Epson America, Inc. All other product
and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks. Copyright 2008 Epson America, Inc. CPD-24964 5/08 PDF
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
www.epson.com
www.epson.ca
* Lamp life results will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.
