Equinox Systems EQLED12B User manual

Order code: EQLED12B
DJ Booth
White LED Starcloth
User Manual

www.prolight.co.uk DJ Booth White LED Starcloth User Manual
2
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE YOUR INITIAL START-UP!
• Beforeyourinitialstart-up,pleasemakesurethatthereisnodamagecausedduringtransportation.
• Shouldtherebeanydamage,consultyourdealeranddonotusetheequipment.
• Tomaintaintheequipmentingoodworkingconditionandtoensuresafeoperation,itisnecessary
fortheusertofollowthesafetyinstructionsandwarningnoteswritteninthismanual.
• Pleasenotethatdamagescausedbyusermodicationstothisequipmentarenotsubjecttowarranty.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance
of this manual or any unauthorised modication to the equipment.
OPERATING DETERMINATIONS
Ifthisequipmentisoperatedinanyotherway,thanthosedescribedinthismanual,theproductmaysufferdamageand
thewarrantybecomesvoid.Incorrectoperationmayleadtodangere.g:short-circuit,burnsandelectricshocksetc.
Donotendangeryourownsafetyandthesafetyofothers!
Incorrectinstallationorusecancauseseriousdamagetopeopleand/orproperty.
CAUTION!
KEEP THIS EQUIPMENT
AWAY FROM RAIN,
MOISTURE AND LIQUIDS
CAUTION!
TAKE CARE USING
THIS EQUIPMENT!
HIGH VOLTAGE-RISK
OF ELECTRIC SHOCK!!
• Neverletthepowercablecomeintocontactwithother
cables.Handlethepowercableandallmainsvoltage
connectionswithparticularcaution!
• Neverremovewarningorinformativelabelsfromtheunit.
• Donotopentheequipmentanddonotmodifytheunit.
• Donotconnectthisequipmenttoadimmerpack.
• Donotswitchtheequipmentonandoffinshortintervals,
asthiswillreducethesystem’slife.
• Onlyusetheequipmentindoors.
• Donotexposetoammablesources,liquidsorgases.
• Alwaysdisconnectthepowerfromthemainswhen
equipmentisnotinuseorbeforecleaning!Onlyhandle
thepower-cablebytheplug.Neverpullouttheplugby
pullingthepower-cable.
• Makesurethattheavailablemainssupplyvoltageis
between100~250VAC,50/60Hz.
• Makesurethatthepowercableisnevercrimpedor
damaged.Checktheequipmentandthepowercable
periodically.
• Iftheequipmentisdroppedordamaged,disconnectthe
mainspowersupplyimmediatelyandhaveaqualied
engineerinspecttheequipmentbeforeoperatingagain.
• Iftheequipmenthasbeenexposedtodrastic
temperatureuctuation(e.g.aftertransportation),
donotconnectpowerorswitchitonimmediately.
Thearisingcondensationmightdamagetheequipment.
Leavetheequipmentswitchedoffuntilithasreached
roomtemperature.
• Ifyourproductfailstofunctioncorrectly,stopuse
immediately.Packtheunitsecurely(preferablyinthe
originalpackingmaterial),andreturnittoyourProLight
dealerforservice.
• Onlyusefusesofsametypeandrating.
• Tocleanthecloth,disconnectthemainspowersupplyand
thenwipewithadampcloth.Donotimmerseinliquid.
Theclothwillrequiremonthlycleaning.Donotusealcohol
orsolvents.ConnectionsandLEDsmustbekeptclean
anddryatalltimes.
• Repairs,servicingandpowerconnectionmustonlybe
carriedoutbyaqualiedtechnician.THISUNITCONTAINS
NOUSERSERVICEABLEPARTS.
• WARRANTY:Oneyearfromdateofpurchase.

www.prolight.co.uk DJ Booth White LED Starcloth User Manual
3
Product overview & technical specications
UpgradeyourEquinoxDJMICRONBoothwiththisblackstarcloth
featuring72x5mmLEDs.TheStarclothissuppliedcompletewith
acomprehensivecontrollerfeaturingAuto,SoundActiveandDMX
controloptions.Additionallyyoucancreateawhitestarclotheffect
whencombiningthewhitelycrasuppliedwiththeEQLED12Land
thisblackstarcloth.
Cloth:
72x5mmwhiteLEDs
Fastxxvelcrotabs
Lowreection,reretardantmaterial
Controller:
DMXchannels:5
Soundactive,autorunandautofademodes
IECpowerinsocket
3-pinXLRDMXin/outsockets
DJ Booth White LED Starcloth
Specications Controller
Powersupply 100~240V,50/60Hz
Fuse T1A250V
Dimensions 55x205x145mm
ESC ENTER UP DOWN
WHITE STARCLOTH
CONTROLLER
www.prolight.co.uk
OUTPUT TO
STARCLOTHDMX INDMX OUTMICFUNCTION
PUSH
ON
OFF
POWER SUPPLY: 100-250V~50/60Hz
FUSE: T1A 250V
ESC ENTER UP DOWN
WHITE STARCLOTH
CONTROLLER
www.prolight.co.uk
OUTPUT TO
STARCLOTHDMX INDMX OUTMICFUNCTION
PUSH
ON
OFF
POWER SUPPLY: 100-250V~50/60Hz
FUSE: T1A 250V
ESC ENTER UP DOWN
WHITE STARCLOTH
CONTROLLER
www.prolight.co.uk
OUTPUT TO
STARCLOTHDMX INDMX OUTMICFUNCTION
PUSH
ON
OFF
POWER SUPPLY: 100-250V~50/60Hz
FUSE: T1A 250V
205mm
145mm
145mm
55mm

www.prolight.co.uk DJ Booth White LED Starcloth User Manual
4
Technical specications
Fitting instructions:
ThisclothisdesignedtobettedtotheEquinoxDJBooth.
Fittheclothfromoneuppercornerrstbyhangingthesewninpocketsontothebooth.
Carefullyunfoldtheclothandattachtheoppositecorner,againbythesewninpocket.
Onceattached,theclothmustbetensionedbytheintegralvelcrostraps.
ESC ENTER UP DOWN
WHITE STARCLOTH
CONTROLLER
www.prolight.co.uk
OUTPUT TO
STARCLOTHDMX INDMX OUTMICFUNCTION
PUSH
ON
OFF
POWER SUPPLY: 100-250V~50/60Hz
FUSE: T1A 250V
01-LEDdisplay
02-Escbutton
03-Enterbutton
04-Upbutton
05-Downbutton
06-Signalindicator
07-Powerindicator
08-Powerinsocket
09-FuseT1A250V
10-Earthpoint
11-On/offswitch
12-Functionknob*
13-Microphone
14-DMXout
15-DMXin
16-Outputtostarcloth
Inthebox:
1 x starcloth,
1 x power cable,
1 x controller &
1 x user manual
ESC ENTER UP DOWN
WHITE STARCLOTH
CONTROLLER
www.prolight.co.uk
OUTPUT TO
STARCLOTHDMX INDMX OUTMICFUNCTION
PUSH
ON
OFF
POWER SUPPLY: 100-250V~50/60Hz
FUSE: T1A 250V
ESC ENTER UP DOWN
WHITE STARCLOTH
CONTROLLER
www.prolight.co.uk
OUTPUT TO
STARCLOTHDMX INDMX OUTMICFUNCTION
PUSH
ON
OFF
POWER SUPPLY: 100-250V~50/60Hz
FUSE: T1A 250V
02
08 10 11 12 13 14 15 1609
0403
05
06
07
01
*Rotatetoscrollthroughmenu.Presstoenterorpressandholdtoexit.

www.prolight.co.uk DJ Booth White LED Starcloth User Manual
5
Operating instructions
Auto mode
Toaccesstheautomode,pressthe“UP/DOWN”buttonsonthefrontoftheunittoshow
“Auto”ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttons
tosettheautomodeyourequire.Pressthe“ENTER”buttontoconrmthesetting.Nowusethe“UP”and
“DOWN”buttonstosetthethespeedrequired.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“ESC”button.
Fade mode
Toaccessthefademode,pressthe“UP/DOWN”buttonsonthefrontoftheunittoshow
“FAde”ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttons
tosetthethespeedrequired.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“ESC”button.
Sound active mode
Toaccessthesoundactivemode,pressthe“UP/DOWN”buttonsonthefrontoftheunittoshow
“Soud”ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttons
tosetthesoundprogramyourequire.Pressthe“ENTER”buttontoconrmthesetting.Nowusethe
“UP”and“DOWN”buttonstosetthethesoundsensitivity(00:lowest,31:highest).
Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“ESC”button.
Pattern mode:
Toaccesspatternmode,pressthe“UP/DOWN”buttonsonthefrontoftheunittoshow
“PAtt”ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttons
tosetthebrightnessofLEDstring1.Pressthe“ENTER”buttontoconrmthesetting.Repeatthisstepfor
LEDstring2-4.Pressthe“ENTER”buttontoconrmthesetting.Nowusethe“UP”and“DOWN”buttons
tosetthetheashspeedrequired.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“ESC”button.
Slave mode:
Toaccesstheslavemode,pressthe“UP/DOWN”buttonsonthefrontoftheunittoshow
“SLav”ontheLEDdisplay.Theunitisnowinslavemode.Pressthe“ENTER”buttonto
conrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“ESC”button.
DMX address:
TochangetheDMXaddress,pressthe“UP/DOWN”buttonsonthefrontoftheunittoshow
“Addr”ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttons
tosettheaddressyourequire.Pressthe“ENTER”buttontoconrmthesetting.Thisisalsothe
modethatneedstobeusedwhencontrollingthestarclothviaDMX.
Toexitoutofanyoftheaboveoptions,pressthe“ESC”button.

www.prolight.co.uk DJ Booth White LED Starcloth User Manual
6
Operating instructions
Software version:
Toviewthesoftwareversionofthecontrollerusethe “UP/DOWN”buttonsonthefrontoftheunitto
show“VEr ”ontheLEDdisplay.Nowpressthe“ENTER”buttonandtheversionwillbedisplayedin
theformat“V---”.
Toexitoutofanyoftheaboveoptions,pressthe“ESC”button.
Static mode:
Toaccessthestaticmode,pressthe“UP/DOWN”buttonsonthefrontoftheunittoshow
“StAt”ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttons
tosetthestaticmodeyourequirebetween“S000-S015”.









Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“ESC”button.
Channel Value Function
1 0-20 LEDgroup1blackout
21-230 LEDgroup1ashspeed
231-255 LEDgroup1fullon
20-20 LEDgroup2blackout
21-230 LEDgroup2ashspeed
231-255 LEDgroup2fullon
30-20 LEDgroup3blackout
21-230 LEDgroup3ashspeed
231-255 LEDgroup3fullon
4 0-20 LEDgroup4blackout
21-230 LEDgroup4ashspeed
231-255 LEDgroup4fullon
5 0-100 Allchannelsashatspeedsetabove
101-255 Allchannelsfullon
S000 Blackout
S001 LEDgroup1on
S002 LEDgroup2on
S003 LEDgroup3on
S004 LEDgroup4on
S005 LEDgroup1&2on
S006 LEDgroup1&3on
S007 LEDgroup1&4on
5 channel mode:
S008 LEDgroup2&3on
S009 LEDgroup2&4on
S010 LEDgroup3&4on
S011 LEDgroup1,2&3on
S012 LEDgroup1,2&4on
S013 LEDgroup1,3&4on
S014 LEDgroup2,3&4on
S015 AllLEDson

www.prolight.co.uk DJ Booth White LED Starcloth User Manual
7
Setting the DMX address:
TheDMXmodeenablestheuseofauniversalDMXcontroller.Eachxturerequiresa“startaddress”
from1-511.Axturerequiringoneormorechannelsforcontrolbeginstoreadthedataonthechannel
indicatedbythestartaddress.Forexample,axturethatoccupiesoruses7channelsofDMXandwas
addressedtostartonDMXchannel100,wouldreaddatafromchannels:100,101,102,103,104,105
and106.Chooseastartaddresssothatthechannelsuseddonotoverlap.E.g.thenextunitinthe
chainstartsat107.
DMX 512:
DMX(DigitalMultiplex)isauniversalprotocolusedasaformofcommunicationbetweenintelligent
xturesandcontrollers.ADMXcontrollersendsDMXdatainstructionsformthecontrollertothexture.
DMXdataissentasserialdatathattravelsfromxturetoxtureviatheDATA“IN”andDATA“OUT”
XLRterminalslocatedonallDMXxtures(mostcontrollersonlyhaveadata“out”terminal).
DMX linking:
DMXisalanguageallowingallmakesandmodelsofdifferentmanufacturestobelinkedtogether
andoperatefromasinglecontroller,aslongasallxturesandthecontrollerareDMXcompliant.
ToensureproperDMXdatatransmission,whenusingseveralDMXxturestrytousetheshortest
cablepathpossible.TheorderinwhichxturesareconnectedinaDMXlinedoesnotinuencethe
DMXaddressing.Forexample;axtureassignedtoaDMXaddressof1maybeplacedanywherein
aDMXline,atthebeginning,attheend,oranywhereinthemiddle.Whenaxtureisassigneda
DMXaddressof1,theDMXcontrollerknowstosendDATAassignedtoaddress1tothatunit,
nomatterwhereitislocatedintheDMXchain.
DATA cable (DMX cable) requirements (for DMX operation):
ThisxturecanbecontrolledviaDMX-512protocol.TheDMXaddressissetonthebackoftheunit.
YourunitandyourDMXcontrollerrequireastandard3-pinXLRconnectorfordatainput/output,
seeimagebelow.
Note: DMX cable must be daisy chained and cannot be split.
DMX setup
FurtherDMXcablescanbe
purchasedfromallgoodsound
andlightingsuppliersor
ProLightConceptsdealers.
Pleasequote:
CABL10 – 2m
CABL11 – 5m
CABL12 – 10m

www.prolight.co.uk DJ Booth White LED Starcloth User Manual
8
Notice:
Besuretofollowthediagramsbelowwhenmakingyourowncables.Donotconnectthecables
shieldconductortothegroundlugorallowtheshieldconductortocomeincontactwiththeXLRs
outercasing.Groundingtheshieldcouldcauseashortcircuitanderraticbehaviour.
Special note:
Line termination:
Whenlongerrunsofcableareused,
youmayneedtouseaterminatoron
thelastunittoavoiderraticbehaviour.
Using a cable terminator will decrease
the possibilities of erratic behaviour.
(3-pin - Order code: CABL90, 5-pin - Order code: CABL89)
5-pin XLR DMX connectors:
Somemanufacturesuse5-pinXLRconnectorsfordatatransmissioninplaceof3-pin.5-pinXLRxtures
maybeimplementedina3-pinXLRDMXline.Wheninsertingstandard5-pinXLRconnectorsintoa
3-pinlineacableadaptormustbeused.Thediagrambelowdetailsthecorrectcableconversion.
Terminationreducessignaltransmission
problemsandinterference.Itisalways
advisabletoconnectaDMXterminal,
(resistance120Ohm1/4W)betweenpin2
(DMX-)andpin3(DMX+)ofthelastxture.
5-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
3-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
3-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
5-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
DMX setup

www.prolight.co.uk DJ Booth White LED Starcloth User Manual
9
Related items
Pleasecontactyourlocalretailertopurchasetheseaccessories.
Optional accessories Order code
Overheadkit EQLED12E
Blackstarcloth
withtri-colourLEDs EQLED12F
Blackstarcloth
withwhiteLEDs EQLED12B
Blacklycra EQLED12A
Replacementwhitelycra EQLED12C
LightweightDJBooth EQLED12L
Optional Overhead kit - This allows the user to create a full light show
without the need to have separate lighting stands
Order ref: EQLED12E
Overhead kit close-up
and how it connects
to the DJ Booth System
Optional Black Lycra
Order ref: EQLED12A
Lightweight DJ Booth
Order ref: EQLED12L
Optional Black Starcloth
with tri-colour LEDs and controller
Order ref: EQLED12F
Optional White Lycra available to purchase
should you need one in the future
Order ref: EQLED12C
You can also create a white starcloth effect
by covering the optional black starcloth
with the supplied white lycra

www.prolight.co.uk DJ Booth White LED Starcloth User Manual
10
Correct Disposal of this Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries
with separate collection systems)
Thismarkingshownontheproductoritsliterature,indicatesthatitshouldnotbedisposedof
withotherhouseholdwastesattheendofitsworkinglife.Topreventpossibleharmtothe
environmentorhumanhealthfromuncontrolledwastedisposal,pleaseseparatethisfromother
typesofwastesandrecycleitresponsiblytopromotethesustainablereuseofmaterialresources.
Householdusersshouldcontacteithertheretailerwheretheypurchasedthisproduct,ortheir
localgovernmentofce,fordetailsofwhereandhowtheycantakethisitemforenvironmentally
saferecycling.
Businessusersshouldcontacttheirsupplierandcheckthetermsandconditionsofthe
purchasecontract.Thisproductshouldnotbemixedwithothercommercialwastesfordisposal.
WEEE notice

www.prolight.co.uk DJ Booth White LED Starcloth User Manual
11

www.prolight.co.uk DJ Booth White LED Starcloth User Manual
12
