Equinox Systems Pulse Tube Lithium User manual

Pulse Tube Lithium
User Manual
Order code: EQLED080

www.prolight.co.uk Pulse Tube Lithium User Manual 2
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE YOUR INITIAL START-UP!
• Before your initial start-up, please make sure that there is no damage caused during transportation.
• Should there be any damage, consult your dealer and do not use the equipment.
• To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual.
• Please note that damages caused by user modications to this equipment are not subject to warranty.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance
of this manual or any unauthorised modication to the equipment.
OPERATING DETERMINATIONS
If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and
the warranty becomes void. Incorrect operation may lead to danger e.g: short-circuit, burns and electric shocks etc.
Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and/or property.
CAUTION!
KEEP THIS EQUIPMENT
AWAY FROM RAIN,
MOISTURE AND LIQUIDS
CAUTION!
TAKE CARE USING
THIS EQUIPMENT!
HIGH VOLTAGE-RISK
OF ELECTRIC SHOCK!!
• Never let the power cable come into contact with other
cables. Handle the power cable and all mains voltage
connections with particular caution!
• Never remove warning or informative labels from the unit.
• Do not open the equipment and do not modify the unit.
• Do not connect this equipment to a dimmer pack.
• Do not switch the equipment on and off in short intervals,
as this will reduce the system’s life.
• Only use the equipment indoors.
• Do not expose to ammable sources, liquids or gases.
• Always disconnect the power from the mains when
equipment is not in use or before cleaning! Only handle
the power-cable by the plug. Never pull out the plug by
pulling the power-cable.
• Make sure that the available mains supply voltage is
between 100~240V AC, 50/60Hz.
• Make sure that the power cable is never crimped or
damaged. Check the equipment and the power cable
periodically.
• If the equipment is dropped or damaged, disconnect the
mains power supply immediately and have a qualied
engineer inspect the equipment before operating again.
• If the equipment has been exposed to drastic
temperature uctuation (e.g. after transportation),
do not connect power or switch it on immediately.
The arising condensation might damage the equipment.
Leave the equipment switched off until it has reached
room temperature.
• If your product fails to function correctly, stop use
immediately. Pack the unit securely (preferably in the
original packing material), and return it to your Pro Light
dealer for service.
• Only use fuses of same type and rating.
• Repairs, servicing and power connection must only be
carried out by a qualied technician. THIS UNIT CONTAINS
NO USER SERVICEABLE PARTS.
• This lighting xture is for professional use only - it is
not designed for or suitable for household use. The
product must be installed by a qualied technician in
accordance with local territory regulations. The safety of
the installation is the responsibility of the installer. The
xture presents risks of severe injury or death due to re
hazards, electric shock and falls.
• Warning! Risk Group 2 LED product according to
EN 62471. Do not view the light output with optical
instruments or any device that may concentrate the beam.
• WARRANTY: One year from date of purchase.

www.prolight.co.uk Pulse Tube Lithium User Manual 3
In the box: 1 x xture,
1 x IR remote,
1 x charging adaptor,
& 1 x user manual
Product overview & technical specications
The Pulse Tube Lithium is a colour changing LED effect that can be mounted vertically, horizontally or free
standing with the included easy t feet. The rechargeable lithium battery offers a run time of up to 12 hours
from a single charge, and with no power cables to connect you are free to set up the unit wherever you want.
The tube will operate in chase, fade, static and sound active modes and is supplied with a handy IR remote.
• 1m LED colour tube with UV resistant
polycarbonate tubing
• 32 tri-colour SMD 5050 LEDs (RGB)
• Rainbow colour effect
• Includes handy IR remote for static colour
with variable strobe, auto with rainbow
effect and sound active modes
• Feet allow the tube to be stood vertically
• Rechargeable battery for
wireless applications
• Maximum run time: up to 12 hours (single colour)
• Charging time: 5 hours (max.)
• Supplied with 12V DC charging adaptor
Pulse Tube Lithium
1002mm
200mm
220mm
Specications
Power consumption 8W
Power supply 12V DC (by adaptor included)
Battery 12V 2500mAh
Tube diameter 50mm
Dimensions 1002 x 220 x 200mm
Weight 0.5kg
Order code EQLED080
Operation:
Please note: prior to operation the Pulse Tube Lithium must be charged fully.
Press the power button on the bottom of the xture to power on/off. If the xture requires
charging connect to a suitable mains outlet using the 12V DC charging adaptor.

www.prolight.co.uk Pulse Tube Lithium User Manual 4
Operating instructions & WEEE notice
Correct Disposal of this Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries
with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed of
with other household wastes at the end of its working life. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, please separate this from other
types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their
local government ofce, for details of where and how they can take this item for environmentally
safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product should not be mixed with other commercial wastes for disposal.
IR remote functions:
01 - Sets the unit into blackout off (LED on)
02 - Sets the unit into blackout on (LED off)
03 - Sets the static colour (see chart key for colours)
04 - Runs the built-in programs, use the ‘+’ and ‘-’ buttons
to go through the programs and then the ‘Speed’ button
followed by the ‘+’ and ‘-’ buttons to adjust the
program speed
05 - Runs the sound programs, use the ‘+’ and ‘-’ buttons
to go through the programs
06 - Sets the LEDs to ash, use the ‘+’ and ‘-’ buttons to
change the ash speed
07 - Sets the built in program speed. Press this button
followed by the ‘+’ and ‘-’ buttons to adjust the
program speed
08 - Adjusts the built-in programs and built-in program
speed, sound program, ash speed for static colour,
brightness of static colour
A - Red
B - Green
C - Blue
D - Orange
E - Lime Green
F - Pink
G - Amber
H - Cyan
I - Magenta
J - Yellow
K - Purple/Blue
L - White
Auto
–
G BR
ON OFF
+
Sound
Speed
Flash
03
01 02
06
08
05
04
07
A B C
D E F
G H I
J K L
