Equinox Systems Microbor EQLED60 User manual

Order code: EQLED60
USER MANUAL

WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!
CAUTION!
Keep this equipment away from rain,
moisture and liquids.
SAFETY INSTRUCTIONS
Every person involved with the installation, operation & maintenance of this
equipment should:
- Be competent
- Follow the instructions of this manual
CAUTION! TAKE CARE USING THIS EQUIPMENT!
HIGH VOLTAGE-RISK OF ELECTRIC SHOCK!!
Before your initial start-up, please make sure that there is no damage caused during
transportation. Should there be any, consult your dealer and do not use the
equipment.
To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual.
Please note that damages caused by user modications to this equipment are not
subject to warranty.
Equinox Microbar Safety

Equinox Microbar Safety
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused
by the non-observance of this manual or any unauthorised modication to the
equipment.
• Never let the power-cable come into contact with other cables. Handle the power-cable
and all mains voltage connections with particular caution!
• Never remove warning or informative labels from the equipment.
• Do not open the equipment and do not modify the equipment.
• Do not connect this equipment to a dimmer-pack.
• Do not switch the equipment on and off in short intervals, as this will reduce the
system’s life.
• Only use the equipment indoors.
• Do not expose to ammable sources, liquids or gases.
• Always disconnect the power from the mains when equipment is not in use or before
cleaning! Only handle the power-cable by the plug. Never pull out the plug by pulling the
power-cable.
• Make sure that the available voltage is between 220v/240v.
• Make sure that the power-cable is never crimped or damaged. Check the equipment and
the power-cable periodically.
• If the equipment is dropped or damaged, disconnect the mains power supply immediately.
Have a qualied engineer inspect the equipment before operating again.
• If the equipment has been exposed to drastic temperature uctuation (e.g. after
transportation), do not switch it on immediately. The arising condensation might damage
the equipment. Leave the equipment switched off until it has reached room temperature.
• If your product fails to function correctly, discontinue use immediately. Pack the unit
securely (preferably in the original packing material), and return it to your Prolight dealer
for service.
• Only use fuses of same type and rating.
• Repairs, servicing and power connection must only be carried out by a qualied
technician. THIS UNIT CONTAINS NO USER SERVICEABLE PARTS.
• WARRANTY; One year from date of purchase.
OPERATING DETERMINATIONS
If this equipment is operated in any other way, than those described in this manual,
the product may suffer damage and the warranty becomes void.
Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks,
lamp failure etc.
Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and property.

Equinox Microbar Technical specications
You should nd inside the carton the following items:
1, Equinox Microbar 2, Power cable 3, User manual
Technical Specications:
DMX channels: 6, 9 and 15 selectable
Operating modes: 1, Sound Activated
2, Built-in programmes
3, Auto Run
4, DMX
5, Slave
192 Ultra Bright 10mm LEDs (R: 36, G: 72, B: 84)
14 built-in programmes
4 Push button LCD digital display
Beam angle: 25˚
Mains IEC Power In/Out sockets
3-Pin XLR In/Out sockets for DMX
5-Pin socket for foot controller
Optional foot controller: MB-1 Foot Switch (EQLED61)
Power consumption: 35W
Power supply: 240V - 50Hz
Dimensions: 800 x 54 x 280mm
Weight: 5Kgs
Fuse: 0.5A
Overview
Identication:
1, Power output
2, Power input
3, On/Off switch
4, Remote input
5, DMX In
6, DMX out
O N
7, LCD digital display
8, Mode button
9, Setup button
10, Up button
11, Down button

Operation modes:
The Equinox Microbar has ve modes of operation as follows:
1, Sound active mode
To select the sound active mode, press the “MODE” button to show “SOUND MODE” in the LCD
display window. Now press the “SETUP” button and use the “UP” and “DOWN” buttons to
adjust the sound sensitivity level (SENS00-31) and press the “SET UP” button again to adjust the
frequency level (FQN01-99). Finally press the “SETUP” button to conrm your setting.
2, Built-in programmes mode
To access the built-in programme mode, press the “MODE” button to show “01.STATIC” in the
LCD display window. Now press the “SETUP” button and use the “UP” and “DOWN” buttons to
choose one of the 14 built-in programmes (01-14) (see table overleaf).
To choose one of the seven colours in the “STATIC” mode, press the set “SETUP” button and
use the “UP” and “DOWN” buttons to choose one of the following 7 colours:
(1) RGB = all on, (2) BR = purple, (3) B = blue, (4)GB = cyan,
(5) G = green, (6) RG = yellow, (7) R = red, BLA = blackout.
To adjust the speed level in the remaining 13 built-in programmes, press the SETUP” button and
use the “UP” and “DOWN” buttons to set the desired speed level (00-99).
To adjust the ash speed press the “SETUP” button and use the “UP” and “DOWN” buttons to
set the desired ash speed level (00-99). Finally press the “SETUP” button to conrm
your setting.
3, Auto Run mode
To select the Auto run mode, press the “MODE” button to show “AUTO RUN” in the LCD display
window. Now press the “SET UP” button to adjust the frequency level (FQN01-99). Finally press
the “SETUP” button to conrm your setting. The unit will now run all 13 built-in programmes one
after another.
4, DMX mode
To select the DMX mode, press the “MODE” button to show “DMX MODE” in the LCD display
window. Press the “SETUP” button and use the “UP” and “DOWN” buttons to set a DMX
address from 001-512. Now press the “SETUP” button again and use the “UP” and “DOWN”
buttons to choose one of the 3 DMX channel settings (6CH, 9CH or 15CH) Finally press the
“SETUP” button to conrm your setting. (see DMX chart). The starting address for this xture is
001.
5, Slave mode
To select Slave mode, rst link the units together via 3-Pin XLR cable(s), press the “MODE”
button to show “SLAVE MODE” on all of the slave units. Now the slave units will follow in
conjunction with the master unit.
NOTE: If the Micro Bar is being used in conjunction with the optional MB-1 foot controller
any number of Micro bars can be controlled via the foot controller by setting all Micro Bars
to 6 channel DMX mode.
NOTE: The frequency level (FQN01-99) adjusts how many times the programme repeats
before moving to the next programme.
Equinox Microbar Operation modes

Built-in programme chart
Equinox Microbar Operation modes
Static Colour
BLAC-RGB Flash00-99
Dream
Speed00-99 Flash00-99
Meteor
Speed00-99 Flash00-99
Fade
Speed00-99 Flash00-99
Change
Speed00-99 Flash00-99
Flow 1
Speed00-99 Flash00-99
Flow 2
Speed00-99 Flash00-99
Flow 3
Speed00-99 Flash00-99
Flow 4
Speed00-99 Flash00-99
Flow 5
Speed00-99 Flash00-99
Flow 6
Speed00-99 Flash00-99
Flow 7
Speed00-99 Flash00-99
Flow 8
Speed00-99 Flash00-99
1. BLAC-RGB 2. BLAC-RGB
Flow 9
Speed00-99 Flash00-99
1. BLAC-RGB 2. BLAC-RGB
Red-Yellow-Green-Cyan-Blue-Purple-White-Blackout
Flash speed adjustable
7 colour dreaming
Speed & Flash adjustable
7 colour ow
Speed & Flash adjustable
7 colour fade
Speed & Flash adjustable
7 colour change
Speed & Flash adjustable
7 colour chase in 1 direction
Speed & Flash adjustable
7 colour chase in 2 directions
Speed & Flash adjustable
7 colour relay chase in 1 direction
Speed & Flash adjustable
7 colour relay chase in 2 directions
Speed & Flash adjustable
7 colour chase from sides to centre
Speed & Flash adjustable
7 colour chase from centre to side
Speed & Flash adjustable
7 colour chase
Speed & Flash adjustable
2 colour chase in 1 direction
Speed & Flash adjustable
Red-Yellow-Green-Cyan-Blue-Purple-White-Blackout
2 colour chase in 2 directions
Speed & Flash adjustable
Red-Yellow-Green-Cyan-Blue-Purple-White-Blackout

6 channel DMX chart (All four LED pods adjusted at the same time)
9 channel mode (Adjusts the LED pods in pairs)
15 channel mode (Adjusts each LED pod individually)
Equinox Microbar DMX Charts
CH 4
Red
pods
3+4
CH 5
Green
pods
3+4
CH 6
Blue
pods
3+4
CH 7
Red
pods
1+2
CH 8
Green
pods
1+2
CH 9
Blue
pods
1+2
CH 4
Red
pod
4
CH 5
Green
pod
4
CH 6
Blue
pod
4
CH 7
Red
pod
3
CH 8
Green
pod
3
CH 9
Blue
pod
3
CH 10
Red
pod
2
CH 11
Green
pod
2
CH 12
Blue
pod
2
CH 13
Red
pod
1
CH 14
Green
pod
1
CH 15
Blue
pod
1

Further DMX cables can be purchased from all
good sound and lighting suppliers or Prolight
dealers.
Please quote:
CABL10 – 2M
CABL11 – 5M
CABL12 – 10M
DMX Control Mode
Operating in a DMX control mode environment gives the user the greatest exibility when it comes
to customising or creating a show. In this mode you will be able to control each individual trait of
the xture and each xture independently.
Setting the DMX address
The DMX mode enables the use of a universal DMX controller. Each xture requires a
“start address” from 1- 511. A xture requiring one or more channels for control begins to read the
data on the channel indicated by the start address. For example, a xture that occupies or uses 7
channels of DMX and was addressed to start on DMX channel 100, would read data from
channels: 100,101,102,103,104,105 and 106. Choose a start address so that the channels used
do not overlap. E.g. the next unit in the chain starts at 107.
DMX-512:
• DMX (Digital Multiplex) is a universal protocol used as a form of communication between
intelligent xtures and controllers. A DMX controller sends DMX data instructions form the
controller to the xture. DMX data is sent as serial data that travels from xture to xture via the
DATA “IN” and DATA “OUT” XLR terminals located on all DMX xtures (most controllers only have
a data “out” terminal).
DMX Linking:
• DMX is a language allowing all makes and models of different manufactures to be linked together
and operate from a single controller, as long as all xtures and the controller are DMX compliant.
To ensure proper DMX data transmission, when using several DMX xtures try to use the
shortest cable path possible. The order in which xtures are connected in a DMX line does not
inuence the DMX addressing. For example; a xture assigned to a DMX address of 1 may be
placed anywhere in a DMX line, at the beginning, at the end, or anywhere in the middle. When a
xture is assigned a DMX address of 1, the DMX controller knows to send DATA assigned to
address 1 to that unit, no matter where it is located in the DMX chain.
DATA Cable (DMX cable) requirements (for DMX operation):
• The Equinox Microbar can be controlled via DMX-512 protocol. The DMX address is set on the
back of the unit. Your unit and your DMX controller require a standard 3-pin XLR connector for
data input/output (gure 1).
Figure 1
Also remember that DMX cable must be daisy chained and cannot be split.
Equinox Microbar DMX set up

Notice:
• Be sure to follow gures 2 & 3 when making your own cables. Do not connect the cable’s shield
conductor to the ground lug or allow the shield conductor to come in contact with the XLR’s outer
casing. Grounding the shield could cause a short circuit and erratic behaviour.
Special Note: Line termination:
• When longer runs of cable are used, you may need to use a terminator on the last unit to
avoid erratic behaviour.
Using a cable terminator (part number CABL90) will decrease the possibilities of erratic
behaviour.
5-Pin XLR DMX Connectors:
• Some manufactures use 5-pin XLR connectors for data transmission in place of 3-pin. 5-Pin
XLR xtures may be implemented in a 3-pin XLR DMX line. When inserting standard 5-pin
XLR connectors in to a 3-pin line a cable adaptor must be used. The Chart below details the
correct cable conversion.
Termination reduces signal transmission problems
and interferance. it is always advisable to connect a
DMX terminal, (resistance 120 Ohm 1/4 W) between
pin 2 (DMX-) and pin 3 (DMX+) of the last fixture.
Equinox Microbar DMX Set Up

Notes:
Equinox Microbar Notes

Notes:
Equinox Microbar Notes
