Equinox Systems EQLED054 User manual

Fusion 200 Zoom Spot
User Manual
Order codes:
EQLED054 - Black Housing
EQLED054A - White Housing

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 2
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE YOUR INITIAL START-UP!
• Before your initial start-up, please make sure that there is no damage caused during transportation.
• Should there be any damage, consult your dealer and do not use the equipment.
• To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual.
• Please note that damages caused by user modications to this equipment are not subject to warranty.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance
of this manual or any unauthorised modication to the equipment.
OPERATING DETERMINATIONS
If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and
the warranty becomes void. Incorrect operation may lead to danger e.g: short-circuit, burns and electric shocks etc.
Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and/or property.
CAUTION!
KEEP THIS EQUIPMENT
AWAY FROM RAIN,
MOISTURE AND LIQUIDS
CAUTION!
TAKE CARE USING
THIS EQUIPMENT!
HIGH VOLTAGE-RISK
OF ELECTRIC SHOCK!!
• Never let the power cable come into contact with other
cables. Handle the power cable and all mains voltage
connections with particular caution!
• Never remove warning or informative labels from the unit.
• Do not open the equipment and do not modify the unit.
• Do not connect this equipment to a dimmer pack.
• Do not switch the equipment on and off in short intervals,
as this will reduce the system’s life.
• Only use the equipment indoors.
• Do not expose to ammable sources, liquids or gases.
• Always disconnect the power from the mains when
equipment is not in use or before cleaning! Only handle
the power-cable by the plug. Never pull out the plug by
pulling the power-cable.
• Make sure that the available mains supply voltage is
between 100~240V AC, 50/60Hz.
• Make sure that the power cable is never crimped or
damaged. Check the equipment and the power cable
periodically.
• If the equipment has been exposed to drastic
temperature uctuation (e.g. after transportation),
do not connect power or switch it on immediately.
The arising condensation might damage the equipment.
Leave the equipment switched off until it has reached
room temperature.
• Never touch the xture during operation as it may be hot.
• If the equipment is dropped or damaged, disconnect the
mains power supply immediately and have a qualied
engineer inspect the equipment before operating again.
• If your product fails to function correctly, stop use
immediately. Pack the unit securely (preferably in the
original packing material), and return it to your Pro Light
dealer for service.
• Only use fuses of same type and rating.
• Repairs, servicing and power connection must only be
carried out by a qualied technician. THIS UNIT CONTAINS
NO USER SERVICEABLE PARTS.
• This lighting xture is for professional use only - it is not
designed for or suitable for household use. The product
must be installed by a qualied technician in accordance
with local territory regulations. The safety of the installation
is the responsibility of the installer. The xture presents
risks of severe injury or death due to re hazards, electric
shock and falls.
• Warning! Risk Group 2 LED product according to
EN 62471. Do not view the light output with optical
instruments or any device that may concentrate the beam.
• WARRANTY: One year from date of purchase.

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 3
Safety advice
This xture falls under Protection Class 1, therefore it has to be connected
to a mains socket with a protective earthing connection.
Risk group 2, RG-2: CAUTION!
Do not stare at exposed LED in operation as it may damage/be harmful to
the eyes. Avoid looking directly into the light source.
CAUTION!
If the lens gets damaged ie. cracks or deep scratches so the output is impaired
then it must be replaced.
CAUTION!
The maximum ambient temperature (Ta) of 40° must not be exceeded.

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 4
0m 2m 3m 4m 5m
11° - Lux
25° - Lux
27900
9855
1m
111600
39420
12400
4380
25°
6975
2463
4464
1576
11°
Product overview & technical specications
• 1 x 200W white LED (7500K)
• Adjustable beam angle: 11°-25°
• 11° - 27,900 Lux @ 2m,
25° - 9,855 Lux @ 2m
• 4.3kHz refresh rate
• Motorised zoom and focus
• 6 facet circular rotating prism
plus 5 facet linear rotating prism
• Gobo wheel 1: 7 rotating,
replaceable gobos + open
• Gobo wheel 2: 7 static gobos + open
• Colour wheel: 7 colours + open
• DMX channels: 2/14 or 18 selectable
• Auto, sound active manual control
and master/slave modes
• Pan/tilt auto correction
• 16-Bit pan/tilt positioning
• Pan: 540°, Tilt: 270°
• 0-100% dimming and variable strobe
• Quick release omega clamps included
• Square hole spacing on omega clamp receivers
allows for clamps to be mounted in all
orientations
• 4 push button menu with 2.6” LCD display
• PowerCON input/output
• 3-Pin XLR input/output
• Fan cooled
Fusion 200 Zoom Spot
Specications Fusion 200 Zoom Spot
Power consumption 240W
Power supply 100~240V, 50/60Hz
Fuse F4A 250V
Dimensions 450 x 302 x 200mm
Weight 12.7kg
Order code EQLED054 - Black Housing
EQLED054A - White Housing
The Fusion 200 Spot features a single 200W LED and produces stunning light shows with an adjustable beam
angle of 11°- 25°. Offering 7 colours plus open along with a rotating and static gobo wheel each containing
7 gobos plus open, the xture is ideal for installation and performers alike. Two bi-directional prisms
(6 facet circular and 5 facet linear) further bolster the xtures comprehensive features and a motorised zoom
keeps the gobos razor sharp over any distance. PowerCON, DMX in/out and a four button LCD display further
enhance the xture.

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 5
Technical specications
355mm
450mm
274mm
405mm
293mm
302mm
96mm
183mm
200mm
96mm

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 6
Technical specications
01 - LCD display
02 - Function buttons
03 - 3-Pin DMX input
04 - 3-Pin DMX output
05 - PowerCON input
06 - PowerCON output
07 - Fuse F4A 250V
08 - Power switch
09 - Carry handles
In the box: 1 x xture,
2 x omega clamps,
1 x power cable
& 1 x user manual
09 07
01 02 04 08 05 0603
09

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 7
Installation
Before installing the xture, the supporting structure (ie. truss) must be able to hold a minimum of 10
times the xtures weight without any deformation (eg. 15kg - 150kg point load). The xture must be
secured with a secondary safety attachment when being installed (ie. an appropriate safety cable).
Never stand directly below the xture when mounting, removing, and/or servicing.
Overhead installation requires experience and qualications to calculate working load limits, the
material being used at the installation area and periodic safety inspections of the xture and installation
material. If you do not have the relevant experience and/or qualications please do not attempt the
installation yourself. The installation should be checked annually by a qualied person.
The Equinox Fusion 200 Zoom Spot can be operated in a number of mounting positions as shown
in the diagram above, hanging upside-down from the ceiling or truss, mounting sideways on truss or
stood upright on a at level surface. Always use a safety wire as an extra safety precaution to prevent
damage/injury in the event a clamp fails (see the next page for clamp installation).
Never use the carry handles for secondary attachments.

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 8
Installation
Installation:
1. Fasten each clamp to the omega clamps with a bolt and lock nut through the hole in the
omega clamp.
2. Align and insert the omega clamp quick-lock fasteners with the respective holes on the bottom
of the unit.
3. Tighten both locking fasteners clockwise on each omega clamp ensuring they’re fully secure.
4. Mount the xture onto your truss system via the clamps and tighten to ensure secure.
5. Pull the safety cable through the safety cable holes located on the metal base plate on the
underside of the xture and around the truss.
1
2
4
5
3

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 9
Operating instructions
Control Panel Menu:
The LCD control panel situated on the front of the xture allows the user to access the menu system to
adjust the xtures settings.
When the unit has been powered on the display will show “Equinox Fusion 200 Zoom Spot”,
“Motor Reset... Please Wait...” whilst the unit performs its motor reset.
The xture will then return to its home screen.
Pressing the “ENTER” button once will take the user to the xtures main menu. Using the “UP” and
“DOWN” buttons you can then navigate between the different options in the main menu. Pressing the
“ENTER” button on one of these options allows you to access the sub menu where you can use the
“UP” and “DOWN” buttons to select option/value required. Once the option/value has been selected
press the “ENTER” button once more to conrm the setting.
To exit out of any of the above options, press the “MENU” button.
DOWN
UP
ENTERMENU
DMX
200 ZOOM SPOT

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 10
1. DMX
Address
1. DMX Address
xxx
DMX address:
To access the DMX address mode, press the
“ENTER” button and use the “UP” and “DOWN”
buttons to show “DMX Address” on the LCD
display. Now press the “ENTER” button and use
the “UP” and “DOWN” buttons to set the required
DMX address. Press the “ENTER” button to
conrm the setting.
Main Menu - Defaults are in grey
DMX channel mode:
To access the DMX channel mode, press the
“ENTER” button and use the “UP” and “DOWN”
buttons to show “Channel Mode” on the LCD
display. Now press the “ENTER” button and use
the “UP” and “DOWN” buttons to set the required
DMX channel. Press the “ENTER” button to
conrm the setting.
Show mode:
To access the show modes, press the “ENTER”
button and use the “UP” and “DOWN” buttons
to show “Show Mode” on the LCD display. Now
press the “ENTER” button and use the “UP” and
“DOWN” buttons to set the required show mode.
Press the “ENTER” button to conrm the setting.
Show 4 is a forward facing show mode.
2. Channel
Mode 2 Channel
14 Channel
18 Channel
3. Show
Mode Show 1
Show 2
Show 3
Show 4
Operating instructions
Default
001

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 11
Operating instructions
Master/slave mode:
To access the master/slave modes, press the
“ENTER” button and use the “UP” and “DOWN”
buttons to show “Master/Slave” on the LCD
display. Now press the “ENTER” button and
use the “UP” and “DOWN” buttons to set the
required mode. Press the “ENTER” button to
conrm the setting.
4. Master/Slave
5. Sound
6. Sound
Sensitivity
Master
Off
Sound
Sensitivity
xxx
Slave 1
On
Default
080
Slave 2
Sound mode:
To access the sound mode setting, press the
“ENTER” button and use the “UP” and “DOWN”
buttons to show “Sound” on the LCD display.
Now press the “ENTER” button and use the “UP”
and “DOWN” buttons to select between “ON”
and “OFF”. Press the “ENTER” button to conrm
the setting.
Sound sensitivity:
To access the sound sensitivity setting, press the
“ENTER” button and use the “UP” and “DOWN”
buttons to show “Sound Sensitivity” on the LCD
display. Now press the “ENTER” button and use
the “UP” and “DOWN” buttons to select between
“000” and “100”. Press the “ENTER” button to
conrm the setting.

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 12
Operating instructions
Manual control:
To access manual control mode, press the
“ENTER” button and use the “UP” and “DOWN”
buttons to show “Manual Control” on the LCD
display. Press the “ENTER” button and use the
“UP” and “DOWN” buttons to select the various
options. Press the “ENTER” button and use the
“UP” and “DOWN” buttons to select between
“000” - “255”. Press the “ENTER” button to
conrm the setting.
7. Manual
Control
Pan
xxx
Tilt
xxx
Dimmer
xxx
Strobe
xxx
Colour
xxx
Static Gobo
xxx
Rotating Gobo
xxx
Gobo Rotation
xxx
Focus
xxx
Prism Rotation
xxx
Zoom
xxx
Prism
xxx
Default
000

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 13
Operating instructions
No
Yes
9. Tilt Invert
Tilt invert:
To access the tilt invert setting, press the
“ENTER” button and use the “UP” and “DOWN”
buttons to show “Tilt Invert” on the LCD display.
Press the “ENTER” button and use the “UP”
and “DOWN” buttons to select between “No”
and “Yes”. Press the “ENTER” button to conrm
the setting.
Blackout
Hold
Show mode
10. DMX Fail
DMX fail:
Sets what the xture does when the DMX signal
is lost. To access the DMX fail setting, press the
“ENTER” button and use the “UP” and “DOWN”
buttons to show “DMX Fail” on the LCD display.
Now press the “ENTER” button and use the
“UP” and “DOWN” buttons to choose between
“Blackout”, “Hold” or “Show mode”. Press the
“ENTER” button to conrm the setting.
Pan invert:
To access the pan invert setting, press the
“ENTER” button and use the “UP” and “DOWN”
buttons to show “Pan Invert” on the LCD display.
Press the “ENTER” button and use the “UP”
and “DOWN” buttons to select between “No”
and “Yes”. Press the “ENTER” button to conrm
the setting.
No
Yes
8. Pan Invert

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 14
Operating instructions
11. Display
Settings Backlight
Invert
Off
No
On
Yes
Display backlight:
To access the display backlight setting,
press the “ENTER” button and use the “UP” and
“DOWN” buttons to show “Display Settings” on
the LCD display. Press the “ENTER” button and
use the “UP” and “DOWN” buttons to select
“Backlight”.Press the “ENTER” button and use
the “UP” and “DOWN” buttons to select between
“Off” and “On”. Press the “ENTER” button to
conrm the setting.
Display invert:
To access the display invert setting,
press the “ENTER” button and use the “UP” and
“DOWN” buttons to show “Display Settings” on
the LCD display. Press the “ENTER” button and
use the “UP” and “DOWN” buttons to select
“Invert”.Press the “ENTER” button and use the
“UP” and “DOWN” buttons to select between
“No” and “Yes”. Press the “ENTER” button to
conrm the setting.

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 15
Calibration:
Calibration settings for the xture.
To access the units calibration menu press the
“ENTER” button and use the “UP” and “DOWN”
buttons to show “Calibration”. Press the “ENTER”
button and use the “UP” and “DOWN” buttons
to select the various options. Press the “ENTER”
button and use the “UP” and “DOWN” buttons to
select between “000” - “255”.
Press the “ENTER” button to conrm the setting.
Please note: Calibration settings are set when
the xture is manufactured. This can be changed
manually for home position adjustment.
Performing a factory reset will not change these
settings.
12. Calibration Pan
xxx
Tilt
xxx
Dimmer
xxx
Strobe
xxx
Gobo Rotation
xxx
Colour
xxx
Focus
xxx
Static Gobo
xxx
Prism
xxx
Rotating Gobo
xxx
Prism Rotation
xxx
Zoom
xxx
Operating instructions

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 16
Operating instructionsOperating instructions
14. Auto Test
Yes
No
15. Motor Reset
Auto test:
Tests all functions and motors in the xture.
To access the auto test mode, press the
“ENTER” button and use the “UP” and “DOWN”
buttons to show “Auto Test” on the LCD display.
Press the “ENTER” button and the xture will
initiate auto test.
Please note: Auto test will automatically stop
when exiting the auto test menu.
Motor reset:
Resets all the xtures motors.
To access the motor reset setting, press the
“ENTER” button and use the “UP” and “DOWN”
buttons to show “Motor Reset” on the LCD
display. Press the “ENTER” button and use the
“UP” and “DOWN” buttons to select between
“Yes” and “No”. Press the “ENTER” button to
perform the motor reset when yes is selected.
System information:
To display the xtures system information,
press the “ENTER” button and use the “UP” and
“DOWN” buttons to show “System Information”
on the LCD display The unit will now display
the xtures current run time, total run time,
temperature and software version.
13. System
Information
Current Run
Time
xxHxxM
Total Run Time
xxxxxH
Temperature
xxx°C
Software
Version
Vx.x

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 17
Operating instructions
Factory Reset:
Resets all the xtures factory settings.
To access the factory setting reset, press the
“ENTER” button and use the “UP” and “DOWN”
buttons to show “Factory Reset” on the LCD
display. Press the “ENTER” button and use the
“UP” and “DOWN” buttons to select between
“Yes” and “No”. Press the “ENTER” button to
perform the factory reset when yes is selected.
Yes
No
16. Factory
Reset

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 18
14 channel mode:
Channel Value Function
CH1 000-255 Pan adjustment 0-540°
CH2 000-255 Tilt adjustment 0-270°
CH3 000-255 Pan/tilt speed
CH4 000-255 Master dimmer (0-100%)
CH5
000-004 LED off
005-250 Strobe (slow-fast)
251-255 LED on
CH6
000-004 Open (white)
005-013 Split colour (Open/Red)
014-022 Red
023-031 Split colour (Red/Orange)
032-040 Orange
041-049 Split colour (Orange/Green)
050-058 Green
059-067 Split colour (Green/Blue)
068-076 Blue
077-085 Split colour (Blue/Yellow)
086-094 Yellow
095-103 Split colour (Yellow/Cyan)
104-112 Cyan
113-121 Split colour (Cyan/Magenta)
122-130 Magenta
131-139 Open (white)
140-195 Colour scroll CW (fast-slow)
196-199 Colour scroll stop
200-255 Colour scroll CCW (slow-fast)
CH7
000-007 Open
008-017 Gobo 1
018-027 Gobo 2
028-037 Gobo 3
038-047 Gobo 4
048-057 Gobo 5
058-067 Gobo 6
068-077 Gobo 7
Operating instructions
2 channel mode:
Channel Value Function
CH1
000-015 No function
016-075 Show 1
076-135 Show 2
136-195 Show 3
196-255 Show 4 (forward facing show)
CH2 000 Blackout
001-255 Sound sensitivity (low-high)

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 19
Operating instructions
Channel Value Function
CH9
000-007 No function
008-129 Gobo rotation CW
(fast-slow)
130-133 No function
134-255 Gobo rotation CCW
(slow-fast)
CH10 000-255 Focus
CH11 000-255 Zoom
CH12
000-007 No function
008-099 Prism 1 (Circular)
100-130 No function
131-255 Prism 2 (Linear)
CH13
000-007 No function
008-129 Prism rotation CW
(fast-slow)
130-133 No function
134-255 Prism rotation CCW
(slow-fast)
CH14
000-040 No function
041-060 Enable BL/O whilst P/T
061-080 Disable BL/O whilst P/T
081-100 Enable BL/O whilst
colour change
101-120 Disable BL/O whilst
colour change
121-140 Enable BL/O whilst
gobo change
141-160 Disable BL/O whilst
gobo change
161-180
Enable BL/O whilst
P/T, colour change
& gobo change
181-200
Disable BL/O whilst
P/T, colour change
& gobo change
201-240 No function
241-255 Motor reset (hold 3s)
14 channel mode (cont.):
Channel Value Function
CH7 (cont.)
078-087 Gobo 1 shake (slow-fast)
088-097 Gobo 2 shake (slow-fast)
098-107 Gobo 3 shake (slow-fast)
108-117 Gobo 4 shake (slow-fast)
118-127 Gobo 5 shake (slow-fast)
128-137 Gobo 6 shake (slow-fast)
138-147 Gobo 7 shake (slow-fast)
148-199 Gobo wheel scroll CW
(fast-slow)
200-203 Gobo scroll stop
204-255 Gobo wheel scroll CCW
(slow-fast)
CH8
000-007 Open
008-017 Rotating gobo 1
018-027 Rotating gobo 2
028-037 Rotating gobo 3
038-047 Rotating gobo 4
048-057 Rotating gobo 5
058-067 Rotating gobo 6
068-077 Rotating gobo 7
078-087 Rotating gobo 1 shake
(slow-fast)
088-097 Rotating gobo 2 shake
(slow-fast)
098-107 Rotating gobo 3 shake
(slow-fast)
108-117 Rotating gobo 4 shake
(slow-fast)
118-127 Rotating gobo 5 shake
(slow-fast)
128-137 Rotating gobo 6 shake
(slow-fast)
138-147 Rotating gobo 7 shake
(slow-fast)
148-199 Gobo wheel scroll CW
(fast-slow)
200-203 Gobo scroll stop
204-255 Gobo wheel scroll CCW
(slow-fast)

www.prolight.co.uk Fusion 200 Zoom Spot User Manual 20
Operating instructions
18 channel mode:
Channel Value Function
CH1 000-255 Pan adjustment 0-540°
CH2 000-255 Pan ne adjustment
CH3 000-255 Tilt adjustment 0-270°
CH4 000-255 Tilt ne adjustment
CH5 000-255 Pan/tilt speed
CH6 000-255 Master dimmer (0-100%)
CH7
000-004 LED off
005-250 Strobe (slow-fast)
251-255 LED on
CH8
000-004 Open (white)
005-013 Split colour (Open/Red)
014-022 Red
023-031 Split colour (Red/Orange)
032-040 Orange
041-049 Split colour (Orange/Green)
050-058 Green
059-067 Split colour (Green/Blue)
068-076 Blue
077-085 Split colour (Blue/Yellow)
086-094 Yellow
095-103 Split colour (Yellow/Cyan)
104-112 Cyan
113-121 Split colour (Cyan/Magenta)
122-130 Magenta
131-139 Open (white)
140-195 Colour scroll CW (fast-slow)
196-199 Colour scroll stop
200-255 Colour scroll CCW (slow-fast)
CH9
000-007 Open
008-017 Gobo 1
018-027 Gobo 2
028-037 Gobo 3
038-047 Gobo 4
048-057 Gobo 5
058-067 Gobo 6
068-077 Gobo 7
Channel Value Function
CH9 (cont.)
078-087 Gobo 1 shake (slow-fast)
088-097 Gobo 2 shake (slow-fast)
098-107 Gobo 3 shake (slow-fast)
108-117 Gobo 4 shake (slow-fast)
118-127 Gobo 5 shake (slow-fast)
128-137 Gobo 6 shake (slow-fast)
138-147 Gobo 7 shake (slow-fast)
148-199 Gobo wheel scroll CW
(fast-slow)
200-203 Gobo scroll stop
204-255 Gobo wheel scroll CCW
(slow-fast)
CH10
000-007 Open
008-017 Rotating gobo 1
018-027 Rotating gobo 2
028-037 Rotating gobo 3
038-047 Rotating gobo 4
048-057 Rotating gobo 5
058-067 Rotating gobo 6
068-077 Rotating gobo 7
078-087 Rotating gobo 1 shake
(slow-fast)
088-097 Rotating gobo 2 shake
(slow-fast)
098-107 Rotating gobo 3 shake
(slow-fast)
108-117 Rotating gobo 4 shake
(slow-fast)
118-127 Rotating gobo 5 shake
(slow-fast)
128-137 Rotating gobo 6 shake
(slow-fast)
138-147 Rotating gobo 7 shake
(slow-fast)
148-199 Gobo wheel scroll CW
(fast-slow)
200-203 Gobo scroll stop
204-255 Gobo wheel scroll CCW
(slow-fast)
