Equinox Systems Fusion 100 Spot User manual

Order code: EQLED069
Fusion 100 Spot
User Manual

www.prolight.co.uk Fusion 100 Spot User Manual
2
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE YOUR INITIAL START-UP!
• Beforeyourinitialstart-up,pleasemakesurethatthereisnodamagecausedduringtransportation.
• Shouldtherebeanydamage,consultyourdealeranddonotusetheequipment.
• Tomaintaintheequipmentingoodworkingconditionandtoensuresafeoperation,itisnecessary
fortheusertofollowthesafetyinstructionsandwarningnoteswritteninthismanual.
• Pleasenotethatdamagescausedbyusermodicationstothisequipmentarenotsubjecttowarranty.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance
of this manual or any unauthorised modication to the equipment.
OPERATING DETERMINATIONS
Ifthisequipmentisoperatedinanyotherway,thanthosedescribedinthismanual,theproductmaysufferdamageand
thewarrantybecomesvoid.Incorrectoperationmayleadtodangere.g:short-circuit,burnsandelectricshocksetc.
Donotendangeryourownsafetyandthesafetyofothers!
Incorrectinstallationorusecancauseseriousdamagetopeopleand/orproperty.
CAUTION!
KEEP THIS EQUIPMENT
AWAY FROM RAIN,
MOISTURE AND LIQUIDS
CAUTION!
TAKE CARE USING
THIS EQUIPMENT!
HIGH VOLTAGE-RISK
OF ELECTRIC SHOCK!!
• Neverletthepowercablecomeintocontactwithother
cables.Handlethepowercableandallmainsvoltage
connectionswithparticularcaution!
• Neverremovewarningorinformativelabelsfromtheunit.
• Donotopentheequipmentanddonotmodifytheunit.
• Donotconnectthisequipmenttoadimmerpack.
• Donotswitchtheequipmentonandoffinshortintervals,
asthiswillreducethesystem’slife.
• Onlyusetheequipmentindoors.
• Donotexposetoammablesources,liquidsorgases.
• Alwaysdisconnectthepowerfromthemainswhen
equipmentisnotinuseorbeforecleaning!Onlyhandle
thepower-cablebytheplug.Neverpullouttheplugby
pullingthepower-cable.
• Makesurethattheavailablemainssupplyvoltageis
between100~240VAC,50/60Hz.
• Makesurethatthepowercableisnevercrimpedor
damaged.Checktheequipmentandthepowercable
periodically.
• Iftheequipmentisdroppedordamaged,disconnectthe
mainspowersupplyimmediatelyandhaveaqualied
engineerinspecttheequipmentbeforeoperatingagain.

• Iftheequipmenthasbeenexposedtodrastic
temperatureuctuation(e.g.aftertransportation),
donotconnectpowerorswitchitonimmediately.
Thearisingcondensationmightdamagetheequipment.
Leavetheequipmentswitchedoffuntilithasreached
roomtemperature.
• Ifyourproductfailstofunctioncorrectly,stopuse
immediately.Packtheunitsecurely(preferablyinthe
originalpackingmaterial),andreturnittoyourProLight
dealerforservice.
• Onlyusefusesofsametypeandrating.
• Repairs,servicingandpowerconnectionmustonlybe
carriedoutbyaqualiedtechnician.THISUNITCONTAINS
NOUSERSERVICEABLEPARTS.
• Thislightingxtureisforprofessionaluseonly-itis
notdesignedfororsuitableforhouseholduse.The
productmustbeinstalledbyaqualiedtechnicianin
accordancewithlocalterritoryregulations.Thesafetyof
theinstallationistheresponsibilityoftheinstaller.The
xturepresentsrisksofsevereinjuryordeathduetore
hazards,electricshockandfalls.
• Warning!RiskGroup2LEDproductaccordingto
EN62471.Donotviewthelightoutputwithoptical
instrumentsoranydevicethatmayconcentratethebeam.
• WARRANTY:Oneyearfromdateofpurchase.

www.prolight.co.uk Fusion 100 Spot User Manual
3
Product overview & technical specications
TheEquinoxFusion100Spotisacompact,feature-packedxtureideal
formobileapplicationsaswellasinstallation.Theengineofthisxture
isapowerful80WwhiteLED(max.),whichgeneratessharpbeamsand
patterns.Awheelwith7coloursplusopenallowsforrichhuestosaturate
theFusion100Spotsbeam,whilearotatinggobowheelwith5rotating
gobosincludingheartsandstarsplusopenaddstothearmouryof
on-boardeffects.Alsocrammedinsidethiscompacthousingisa3facet
circularprismandamotorisedfocustokeeptheprojectedimagesharpat
anydistance.WithaforwardfacingshowthisxtureisidealformobileDJs.
•1x80WwhiteLED(max.)
•Beamangle:10°
•13,200Lux@2m(fullon)
•Motorisedfocus
•3facetprism
•Gobowheel:5rotatinggobos+open
•Colourwheel:7colours+open
•DMXchannels:5or15selectable
•Auto,soundactiveand
master/slavemodes
•Pan:540°,Tilt:210°
•0-100%dimmingandvariablestrobe
•Suppliedwithhangingbracket
•4pushbuttonmenu
withLEDdisplay
•IECpowerinput
•3-PinXLRinput/output
•Fancooled
Fusion 100 Spot
Specications
Powerconsumption 90W
Powersupply 100~240V,50/60Hz
Fuse F2A250V
Dimensions 330x198x146mm
Weight 4.4kg
Ordercode EQLED069
330mm
198mm 146mm
0m 1m 2m 3m 4m 5m
10° - Lux 52800 13200 5870
10°
3300 2110

www.prolight.co.uk Fusion 100 Spot User Manual
4
Technical specications
MENU
MIC
DOWN UP ENTER DMX INPUT DMX OUTPUT
POWER INPUT:
100-240V~50/60Hz
FUSE: F2A
www.prolight.co.uk
03
02 01 04 05 07 06 08
01-LEDdisplay
02-Functionbuttons
03-Microphone
04-DMXinputsocket
05-DMXoutputsocket
06-IECpowerinputsocket
07-FuseF2A250V
08-Fan
Inthebox:1 x xture,
1 x power cable,
1 x hanging bracket,
1 x eye bolt
& 1 x user manual

www.prolight.co.uk Fusion 100 Spot User Manual
5
Operating instructionsOperating instructions
A 0 0 1
A 5 1 2
A 0 0 1
DMX address setting
5Ch
15Ch
C H N d
Channel modes
N A s t
S L 1
SLNd
Master/slave mode
H I s P
L o S P
S P N d
Pan/tilt speed setting
S H 1
S H 4
SHNd
Show modes
o n
oFF
S o u n
Sound mode on/off
o n
o F F
PAn
Pan invert
o n
oFF
t I L
Tilt invert
o n
oFF
d I S P
Display invert
000
100
N I C
Sound sensitivity
o n
oFF
r F A C
Reset factory settings
F
r
0 0 0
1 2 0
0 0 0
1 2 0
g
0 0 0
1 2 0
P
d E L E
t
C
0 0 0
1 2 0
0 0 0
1 2 0
0 0 0
1 2 0
r S t
Motor reset
MENU
A d t
Home position setting

www.prolight.co.uk Fusion 100 Spot User Manual
6
Operating instructions
DMX mode:
OperatinginaDMXcontrolmodeenvironmentgivestheuserthegreatestexibilitywhenitcomes
tocustomisingorcreatingashow.Inthismodeyouwillbeabletocontroleachindividualtraitof
thextureandeachxtureindependently.
ToaccesstheDMXaddressmode,pressthe“MENU”buttononthefrontoftheunittoshow
A001ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”
buttonstosettherequiredDMXaddress.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
DMX channel mode:
ToaccesstheDMXchannelmode,pressthe“UP”buttononthefrontoftheunittoshowCHNd
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoose
oneofthe5or15DMXchannelmodes.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
PLEASE NOTE:WhentheunitisreceivingDMXtherstreddotonthedisplaywillash.


5 channel mode:
Channel Value Function
CH1 000-255 Panadjustment0-540°
CH2 000-255 Tiltadjustment0-210°
CH3
000-007 Nofunction
008-047 LEDMacro1
048-087 LEDMacro2
088-127 LEDMacro3
128-167 LEDMacro4
168-207 LEDMacro5
208-247 LEDMacro6
248-255 Soundactive
CH4
000-007 Nofunction
008-058 Pan/tiltMacro1
059-110 Pan/tiltMacro2
111-162 Pan/tiltMacro3
163-240 Pan/tiltMacro4
241-255 Soundactive
CH5
000-050 Nofunction
051-100 Highspeedmotormovement
151-200 Lowspeedmotormovement
251-255 Reset(10seconds)

www.prolight.co.uk Fusion 100 Spot User Manual
7
Operating instructions
15 channel mode:
Channel Value Function
CH1 000-255 Panadjustment0-540°
CH2 000-255 Panneadjustment
CH3 000-255 Tiltadjustment0-210°
CH4 000-255 Tiltneadjustment
CH5 000-255 Pan/tiltspeed
CH6 000-255 Masterdimmer(0-100%)
CH7
000-009 Blackout
010-245 Strobe(slow-fast)
246-255 LEDon
CH8
000-013 Open(white)
014-031 Red
032-049 Yellow
050-067 Cyan
068-085 Green
086-103 Orange
104-121 Magenta
122-130 Blue
131-139 Open(white)
140-195 Rainboweffect(fast-slow)
196-199 Rotationstop
200-255 Reverserainboweffect
(slow-fast)
CH9
000-008 Open(white)
009-033 Gobo1
034-058 Gobo2
059-083 Gobo3
084-108 Gobo4
109-133 Gobo5
134-194 Rainboweffect(fast-slow)
195-255 Reverserainboweffect
(slow-fast)
Channel Value Function
CH10
000-009 Rotationstop
010-129 Forwardgoborotation
(fast-slow)
130-134 Rotationstop
135-255 Reversegoborotation
(slow-fast)
CH11 000-255 Focus
CH12 000-007 Open(white)
008-255 Prism
CH13
000-007 Nofunction
008-047 LEDMacro1
048-087 LEDMacro2
088-127 LEDMacro3
128-167 LEDMacro4
168-207 LEDMacro5
208-247 LEDMacro6
248-255 Soundactive
CH14
000-007 Nofunction
008-058 Pan/tiltMacro1
059-110 Pan/tiltMacro2
111-162 Pan/tiltMacro3
163-240 Pan/tiltMacro4
241-255 Soundactive
CH15
000-050 Nofunction
051-100 Highspeedmotormovement
151-200 Lowspeedmotormovement
251-255 Reset(10seconds)
PLEASE NOTE:
Highspeedmotormovementissuitablefor
highenergyshows.Forsmoothmovement
pleaseselectlowspeedmotormovement.
Gobos:
Open Gobo1 Gobo2 Gobo3 Gobo4 Gobo5

www.prolight.co.uk Fusion 100 Spot User Manual
8
Pan/tilt speed setting:
Toaccessthepan/tiltspeedsetting,pressthe“UP”buttononthefrontoftheunittoshowSPNd
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoose
betweenHISP(fast)orLoSP(slow).Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Master/slave mode:
Tosetthemasterunit,pressthe“UP”buttononthefrontofthemasterunittoshowSLNd ontheLED
display.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochooseNast.Press
the“ENTER”buttontoconrmthesetting.Thenselectyourdesiredprogram(soundactiveoroneofthe
showmodes).
Tosettheotherunitsinslavemode,pressthe“UP”buttononthefrontoftheunittoshowSLNd
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoose
eitherSL 1.Pressthe“ENTER”buttontoconrmthesetting.Theunitwillnowruninsequencewith
themasterunit.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
PleaseensurethatallslaveunitsaresettothesameDMXchannelmodeasthemasterunit.
Show mode:
Toaccesstheshowmodes,pressthe“UP”buttononthefrontoftheunittoshowShNd
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoose
betweenSH 1~SH 4.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
SH 1 – full show
SH 2 – slow show 1
SH 3 – slow show 2
SH 4 – forward facing show
Sound/sound sensitivity:
Toturnthesoundmodeonoroff,pressthe“UP”buttononthefrontoftheunittoshowSounonthe
LEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoosebetween
onor oFF.Pressthe“ENTER”buttontoconrmthesetting.
Toadjustthesoundsensitivity,pressthe“UP”buttononthefrontoftheunittoshowNIC onthe
LEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoosebetween
000~100.Value: 000 - 100 (000 = low, 100 = high)
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Operating instructions

www.prolight.co.uk Fusion 100 Spot User Manual
9
Operating instructions
Pan invert setting:
Toaccessthepaninvertsetting,pressthe“UP”buttononthefrontoftheunittoshowPAn
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoose
betweenonoroff.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Tilt invert setting:
Toaccessthetiltinvertsetting,pressthe“UP”buttononthefrontoftheunittoshowtIL
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoose
betweenonoroff.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Display invert setting:
Toaccessthedisplayinvertsetting,pressthe“UP”buttononthefrontoftheunittoshowdISP
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoose
betweenonoroff.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Reset factory settings:
Toresettheunitsfactorysettings,pressthe“UP”buttononthefrontoftheunittoshowrFAC
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoose
betweenon(reset)orofF.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Pan/Tilt/Zoom home position:
Toaccessthepan/tilt/focushomepositionsetting,pressthe“UP”buttononthefrontoftheunitto
showAd tontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”
buttonstoselectdELE(defaulthomeposition),P(panhomeposition),t(tilthomeposition),
C(colour),g(gobo),F(focushomeposition),andr(rotationhomeposition).
WhenondELE,pressthe“ENTER”buttonandtheunitshomepositionswillberesettothefactory
default(000).
WhenonP,t,C,g,Forr,pressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonsto
adjustthevaluebetween000~120.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Motor reset:
Toresetthemotors,pressthe“UP”buttononthefrontoftheunittoshowrStontheLEDdisplay.
Pressthe“ENTER”buttontoperformthereset.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.

www.prolight.co.uk Fusion 100 Spot User Manual
10
Setting the DMX address:
TheDMXmodeenablestheuseofauniversalDMXcontroller.Eachxturerequiresa“startaddress”
from1-512.Axturerequiringoneormorechannelsforcontrolbeginstoreadthedataonthechannel
indicatedbythestartaddress.Forexample,axturethatoccupiesoruses7channelsofDMXandwas
addressedtostartonDMXchannel100,wouldreaddatafromchannels:100,101,102,103,104,105
and106.Chooseastartaddresssothatthechannelsuseddonotoverlap.E.g.thenextunitinthe
chainstartsat107.
DMX 512:
DMX(DigitalMultiplex)isauniversalprotocolusedasaformofcommunicationbetweenintelligent
xturesandcontrollers.ADMXcontrollersendsDMXdatainstructionsformthecontrollertothexture.
DMXdataissentasserialdatathattravelsfromxturetoxtureviatheDATA“IN”andDATA“OUT”
XLRterminalslocatedonallDMXxtures(mostcontrollersonlyhaveadata“out”terminal).
DMX linking:
DMXisalanguageallowingallmakesandmodelsofdifferentmanufacturestobelinkedtogether
andoperatefromasinglecontroller,aslongasallxturesandthecontrollerareDMXcompliant.
ToensureproperDMXdatatransmission,whenusingseveralDMXxturestrytousetheshortest
cablepathpossible.TheorderinwhichxturesareconnectedinaDMXlinedoesnotinuencethe
DMXaddressing.Forexample;axtureassignedtoaDMXaddressof1maybeplacedanywherein
aDMXline,atthebeginning,attheend,oranywhereinthemiddle.Whenaxtureisassigneda
DMXaddressof1,theDMXcontrollerknowstosendDATAassignedtoaddress1tothatunit,
nomatterwhereitislocatedintheDMXchain.
DATA cable (DMX cable) requirements (for DMX operation):
ThisxturecanbecontrolledviaDMX-512protocol.TheDMXaddressissetonthebackoftheunit.
YourunitandyourDMXcontrollerrequireastandard3-pinXLRconnectorfordatainput/output,
seeimagebelow.
Also remember that DMX cable must be daisy chained and cannot be split.
DMX setup
FurtherDMXcablescanbe
purchasedfromallgoodsound
andlightingsuppliersor
ProLightConceptsdealers.
Pleasequote:
CABL10 – 2m
CABL11 – 5m
CABL12 – 10m

www.prolight.co.uk Fusion 100 Spot User Manual
11
Notice:
Besuretofollowthediagramsbelowwhenmakingyourowncables.Donotconnectthecables
shieldconductortothegroundlugorallowtheshieldconductortocomeincontactwiththeXLRs
outercasing.Groundingtheshieldcouldcauseashortcircuitanderraticbehaviour.
Special note:
Line termination:
Whenlongerrunsofcableareused,
youmayneedtouseaterminatoron
thelastunittoavoiderraticbehaviour.
Using a cable terminator will decrease
the possibilities of erratic behaviour.
(3-pin - Order ref: CABL9O, 5-pin - Order ref: CABL89)
5-pin XLR DMX connectors:
Somemanufacturesuse5-pinXLRconnectorsfordatatransmissioninplaceof3-pin.5-pinXLRxtures
maybeimplementedina3-pinXLRDMXline.Wheninsertingstandard5-pinXLRconnectorsintoa
3-pinlineacableadaptormustbeused.Thediagrambelowdetailsthecorrectcableconversion.
Terminationreducessignaltransmission
problemsandinterferance.itisalways
advisabletoconnectaDMXterminal,
(resistance120Ohm1/4W)betweenpin2
(DMX-)andpin3(DMX+)ofthelastxture.
5-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
3-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
3-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
5-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
DMX setup

www.prolight.co.uk Fusion 100 Spot User Manual
12
WEEE notice
Correct Disposal of this Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries
with separate collection systems)
Thismarkingshownontheproductoritsliterature,indicatesthatitshouldnotbedisposedof
withotherhouseholdwastesattheendofitsworkinglife.Topreventpossibleharmtothe
environmentorhumanhealthfromuncontrolledwastedisposal,pleaseseparatethisfromother
typesofwastesandrecycleitresponsiblytopromotethesustainablereuseofmaterialresources.
Householdusersshouldcontacteithertheretailerwheretheypurchasedthisproduct,ortheir
localgovernmentofce,fordetailsofwhereandhowtheycantakethisitemforenvironmentally
saferecycling.
Businessusersshouldcontacttheirsupplierandcheckthetermsandconditionsofthe
purchasecontract.Thisproductshouldnotbemixedwithothercommercialwastesfordisposal.
