ASSEMBLY
The SODIR CT-3000 Conveyer Toaster comes from the factory completely
assembled. The CT-540 back shelf and diverter must be assembled if pass through
operation is desired.If you choose to use the conveyer in pass-through mode,
attach the wire rack to the back of the unit by inserting the two wire ends of the rack
into the holes provided, and then attaching the diverter door, ‘U’ channel down, to
the lower set of pins, making a shelf for the product to be pushed onto the back
rack. If you desire the front loading/unloading option, attach the diverter door in the
back opening by placing the ‘U’ channel over the pins at the top left and right,
closing off the rear opening and allowing the product to hit the diverter and drop
down onto the slope below. Finally, attach the front sloped shelf by inserting the
two screws at the front of the conveyer through the two keyhole shaped slots on the
shelf.
(unfortunately, you probably need a diagram of all three assemblies described
above)
The toasters may be shipped with plastic exterior and interior protective film, all of
which must be removed before operation.
DO NOT
operate the toaster prior to
removing the protective film completely.
OPERATION
Cooking
The units are provided with removable crumb trays at the bottom to allow for easier
cleanup.
Turn toaster power switch to desired power configuration and adjust knob for desired
belt speed. The CT-540 features an angled loading shelf that will feed product into
the toaster as the belt advances.
When loading the CT-3000, first adjust the throat height before preheating by sliding
the movable panels to the left, raising or lowering to the desired height, and then
sliding the panel back to towards the right to lock into place. Next, place product in
the toaster far enough that the belt will pull it through. Finished products will exit the
other end of the toaster, onto the rack
