ERA Addmore WD80 User manual

Wireless Vibration Sensor
Model: WD80
ERA Home Security Ltd
Valiant Way, Wolverhampton,
West Midlands, WV9 5GB.
Email: [email protected]
2. GET TO KNOW
YOUR PRODUCT
1. INTRODUCTION 4. PCB LAYOUT
1. LED Indicator
2. Antenna
Sensitivity Setting: High/Medium/Low Sensitivity
Mode Setting: Normal Zone or 24-Hour Zone
Tamper Switch: If the case is opened in working
state, the tamper switch will send a signal to
trigger the alarm system.
INSTALLATION
MANUAL
Tamper
Switch
Sensitivity
Setting
Mode Setting
3. LED
INDICATION
Flash Once: Vibration is detected, sending wireless signal
Flash Once Every 2 Seconds: Low battery indication,
please change batteries.
The Wireless Vibration Sensor adopts the theory of vibration,
touch and motion mode. Once it detects any vibration, it will
automatically send a wireless signal to the control panel to
activate the alarm. It’s widely used for objects with a solid or
thick structure, like a safe. It’s vibrating sensitivity can be
adjusted by three levels to prevent false alarms effectively.
Two AAA 1.5V LR03 batteries are included in the sensor,
which enables 12 months standby. AAA 1.5V LR03
AAA 1.5V LR03
1
2
3
JP4
1
2
5. SENSITIVITY
SETTINGS
Take off the back case with screwdriver, place the black
jumper cap onto the jumper of required sensitivity level
High Sensitivity Medium Sensitivity Low Sensitivity

7. INSTALLATION
6. MODE SETTING 9.CONNECT
WITH CONTROL
PANEL
Please connect the Sensor with Control Panel
before use:
1. Make sure the Control Panel is under pairing state
(please refe to the relative user manual)
2. Knock once on the surface of the sensor to simulate
an alarm (LED flashes once), when a beep is heard
from the control panel, it has been successful.
SPECIFICATIONS
Power Supply
Static Current
Alarm Current
Transmitting Distance
Radio Frequency
Housing Material
Operation Condition
Detector Dimensions
(L x W x H)
DC 3V (AAA LR03
1.5V Battery x2pcs)
<29uA
<22.2mA
100m (in open area)
433.92MHz
ABS Plastic
Temperature: 0°C ~ +55°C
Relative Humidity:
< 80% non-condensing)
54 x 14.5 x 107mm
8. NOTICE
1. Remove the insulating strip; the
sensor will enter working mode.
2. Clean the surface of object to be
installed.
3. Fix the sensor on the surface of the
object with double sided adhesive
tape and make sure the antenna is
upward.
Note: Whether a vibration signal will be detected
depends on not only the knocking strength on
objects, but also the strength, frequency, impact and
duration of the signal.
Normal Zone 24 Hour Zone
Normal Zone: In Armed or Home Mode state, the system
will alarm immediately once the sensors in normal zone are
triggered.
24 Hour Zone: The system will alarm immediately once
the 24 Hour Zone sensor is triggered. 24 hour zone setting
is recommended for sensors such as smoke detector, IR
beam sensors which need protection for 24 hours.
NOTES:
