Mobile Communications
EDACSTM Jessica
PBX Gateway
Operator’s Manual
LBI-39080

MAKING PHONE CALLS
FROM AN EDACS RADIO
To determine the exact sequences
to access Jessica features from a
specific radio, refer to the
operator's manual for that radio.
Placing a Call
To place a call, perform one of
the steps below.
1. Press *, enter the
phone number, and then
depress PTT .
2. Enter the phone number, press
*, and then depress
PTT .
3. Press the special call button
(typically SCN or
SCAN ). Select the special
telephone number from the
list and press PTT .

Answering a Call
Press
PTT and hold while
talking. Full duplex radio
users need only press PTT
initially.
Sustaining a Call
Press
PTT whenever you
hear the hang time warning
tone to ensure that your call is
not disconnected. Full duplex
radio users need only press
PTT initially.
Ending a Call
Press the clear button on your
radio. Please consult your
operator's manual for details.

Common Speed Dialing
Consult your System
Administrator for the common
speed dial numbers. Follow
the steps for "Placing a Call"
and use the common speed dial
number.
CALLING EDACS
RADIOS FROM A PHONE
Placing a Call
1. When calling a radio that has
a direct inward dial (DID)
number, dial the PSTN
number for that group or
individual.
2. For all other radios, follow
one of the sequences below.
With some systems, the phone
user may need to enter an
EDACS selector number (not
shown here). Valid logical
identification (LID)

numbers range from 00001 to
16382, and valid group
identification (GID) numbers
range from 0000 to 2047.
•Dial the EDACS telephone
number.
•At the dial tone, enter the
EDACS selector, if necessary.
To Call:
•An individual radio, enter the
5-digit radio ID.
•A digital individual radio,
press def
3+ 5-digit radio
ID.
•A group of radios, press
abc
2+ 4-digit group ID.
•A digital group of radios,
press def
3+ abc 2+ 4-
digit group ID.

Example 1: To call radio 6107
•Dial the EDACS telephone
number.
•At the dial tone, enter the
EDACS selector (optional).
•Enter 0+mno
6+
1+ 0+prs
7
(Remember the LID must be
5 digits, i.e., 06107.)
Example 2: To call group 372
•Dial the EDACS telephone
number.
•At the dial tone, enter the
EDACS selector (optional).
•Enter abc
2+ 0+
def
3+prs 7+abc 2
(Remember the GID must be
4 digits , i.e., 0372.)

Some systems will be set up
using feature and authorization
codes that are a variable number
of digits. (Contact your System
Administrator for more
information.) The authorization
code must be entered after the
EDACS selector and before the
digits specifying call type and
radio ID.
Example 3: This is the same call
to group 372 as described in
Example 2 except that the
authorization code *6*123# is
required and the EDACS selector
is tuv
8.
•Dial the EDACS telephone
number.
•At the dial tone, enter the
EDACS selector, tuv
8.

•Enter the authorization code
*+mno
6+*+
1+ abc
2+ def 3+
#
•Enter abc
2+ 0+
def
3+prs 7+abc 2
Ending a call
Simply hang up the phone.
Ericsson GE Mobile Communications Inc.
Mountain View Road •Lynchburg, Virginia 24502
Printed in U.S.A.
