Technical Manual

Table of Contents
Introduction.....................................................................Page 1
Technical Specifications.................................................Page 2
Flow Diagrams................................................................Page 3
Injector & Flow Control Selection....................................Page 4
Injector ...............................................................Page 4
Backwash flow control........................................Page 4
Brine refill flow control........................................Page 5
Installation
Assembly............................................................Page 6
Installation..........................................................Page 6
Installation check-out .........................................Page 7
Mixing valve.......................................................Page 7
Electronic Control Panel
Programming......................................................Page 10
Diagnostics level................................................Page 13
Parts Replacement
Printed Circuit Board..........................................Page 14
Drive motor.........................................................Page 15
Injector ...............................................................Page 15
Backwash flow control........................................Page 16
Brine refill flow control........................................Page 16
Brine tee.............................................................Page 16
Rotor assembly ..................................................Page 16
Seal disk.............................................................Page 16
Gasket................................................................Page 17
Float valve..........................................................Page 17
Timer head assembly.........................................Page 17
Worm drive shaft................................................Page 17
Impeller...............................................................Page 18
Synchronising valve body and timer head .........Page 18
Troubleshooting..............................................................Page 20
Annual Maintenance.......................................................Page 23
Exploded Views & Part Numbers
Electronic timer...................................................Page 24
Valve body .........................................................Page 26
Order Specifications .......................................................Page 28

 A Division of Aquion, Inc.
Art. Nr.: Tech_Man-ENG-2400VS-2013.06

2400VS SERIES
Erie Water Treatment Controls – Belgium
Page 1
Introduction
The 2400VS is an electronic 4-cycle regeneration control valve for softening of drinking and feed water supplies.
The unique motor driven rotor assembly has a minimum of moving parts; together with the 1-piece Noryl® body,
this guarantees extremely high flow rates and exceptional reliability. The microprocessor controlled programmer
with NOVRAM®, offers unrivalled programming simplicity for use in demand with days override systems. The
control valve is designed for hard water bypass during regeneration. A built in adjustable blending device for
mixing hard and soft water to suit the particular needs of each installation, is a standard feature. The control valve
requires only an aircheck; a conventional float-controlled brine valve system can be used as a double security. The
following sequence is followed:
1. SERVICE:
Untreated water flows down through the resin bed and up through the riser tube; the water is conditioned when
passing through the resin. The throughput is dependent on the maximum permissible pressure drop for the
complete water softener and the maximum permissible specific load of the resin (generally taken as 40 litres
soft water per hour per litre resin).
2. BACKWASH:
Water flows down through the riser tube and up through the resin bed to drain; the resin bed is fully expanded
and all foreign materials are thoroughly washed from the resin, allowing a good brine cycle to occur.
3. BRINE:
Salt brine, drawn from the brine tank by the injector, slowly flows down through the resin bed and up through
the riser tube to drain; the resin is being regenerated when the salt brine passes through. The brine cycle is
terminated when the air check is shut.
4. SLOW RINSE:
Slow rinse continues for the remainder of the brine cycle; the injectors motive water slowly flows down through
the resin bed and up through the riser tube to drain, slowly washing the brine from the resin tank.
5. FAST RINSE/BRINE REFILL:
Water flows to the brine tank and at the same time down through the resin bed and up through the riser tube to
drain, ensuring that all traces of brine are washed out and that the resin bed is compacted. The resin bed is now
ready for the next service cycle.

2400VS SERIES
Erie Water Treatment Controls – Belgium
Page 2
Technical Specifications
Valve body material
Connections
- inlet/outlet (optional)
- drain line
- brine line
- tank
- riser tube
Mixing valve
Glass filled Noryl®
Brass adapters BSP, 3/4” male/female, 1” male
3/4” NPT with hose barb 13 mm
Compression fitting 3/8” polytube
2 1/2” - 8 NPSM
1,050” / 26,7 mm
Standard
Flow rates (valve with riser)
- service
- backwash
- fast rinse
Kv = 5,5 / Cv = 6,4
Kv = 1,7 / Cv = 2,0
Kv = 1,0 / Cv = 1,2
Application Softener 7” - 16”
Operating pressure
Operating temperature
Electrical rating
1,4 - 8,3 bar / 20 - 120 psi
2 - 48 °C / 35 - 120 °F
24V - 50 Hz, max. 500 mA
Regeneration
Controller
- software
- regeneration initiation
- regeneration mode
- time of regeneration
- days override
- water hardness
- reserve capacity
- backwash
- brine draw/slow rinse
- fast rinse/brine refill
4 cycles, co-current brining
Electronic with µ-processor and NOVRAM®
EAZY
Demand with days override or manual
Adjustable: delayed, immediate or delayed with
immediate override
Adjustable
Adjustable: OFF, 1 - 30 days
Adjustable: 1 - 99 °f, °d
Self-calculating or adjustable (0-70% of total cap.)
Adjustable: 0 - 20 min
Adjustable: 0 - 180 min
Adjustable: 0 - 65 min
Flow meter accuracy 1,4 - 115 L/min: ±10%

2400VS SERIES
Erie Water Treatment Controls – Belgium
Page 3
Flow Diagrams
SERVICE BACKWASH
BRINE / SLOW RINSE FAST RINSE / BRINE REFILL

2400VS SERIES
Erie Water Treatment Controls – Belgium
Page 4
Injector & Flow Control Selection
Injector
The injector determines the brine concentration (ratio between brine suction and rinse water) and the brine flow
through the resin bed, thus the contact time between brine and resin. Injector performances vary significantly with
inlet pressure.
Press. Inj. 4 (PURPLE) Inj. 1 (RED) Inj. 2 (YELLOW) Inj. 5 (GREEN)
inlet Brine Rinse Brine Rinse Brine Rinse Brine Rinse
bar L/min L/min L/min L/min L/min L/min L/min L/min
1,38 0,64 0,72 1,32 1,21 1,63 1,86 1,14 3,14
2,07 0,64 0,91 1,63 1,40 1,97 2,08 1,48 3,56
2,76 0,64 0,98 1,82 1,51 2,23 2,27 1,70 3,94
3,45 0,68 1,06 2,01 1,63 2,42 2,46 1,97 4,28
4,14 0,68 1,17 2,04 1,78 2,61 2,65 2,20 4,58
!!! The following table is only an indication and is valid for an inlet pressure of 3 bar and a bed height of 30”.

Tank Injector
inch mm Nr. Colour
7 178 4 PURPLE
8 203 4 PURPLE
9 229 4 PURPLE
10 254 1-4 RED-PURPLE
12 305 1 RED
13 330 1 RED
14 356 2-1 YELLOW-RED
16 406 5-2 GREEN-YELLOW
Backwash flow control
The backwash flow control determines the resin bed expansion during backwash, independent of the inlet pressure.
The optimal bed expansion is generally obtained at a backwash flow of 1,8 L/min per dm2of resin bed surface.

Tank Backwash F.C.
inch mm Nr. Gal/min
(L/min)
7 178 E 1,6 (6,1)
8 203 E 1,6 (6,1)
9 229 G 2,0 (7,6)
10 254 J 2,6 (9,8)
12 305 K 3,5 (13,2)
13 330 L 4,0 (15,1)
14 356 M 5,0 (18,9)
16 406 N 6,0 (22,7)

2400VS SERIES
Erie Water Treatment Controls – Belgium
Page 5
Brine refill flow control
Together with the time of the fast rinse/brine refill cycle, the brine refill flow control determines
the quantity of refill to the brine tank, independent of the inlet pressure:
flow control x cycle time = quantity of refill
Do mind that the fast rinse/brine refill cycle can only be set by increments of 1 min!
!!! The following tables are only an indication and are valid for a brine valve with a refill rate that equals or
exceeds the rate of the refill flow control.
Brine refill F.C. Program: 3
e
cycle Quantity of refill
Nr. Gal/min
(L/min) min L (±10 %)
A 0,25 (1,0) 4 3,8
A 0,25 (1,0) 6 5,7
A 0,25 (1,0) 8 7,6
A 0,25 (1,0) 10 9,5
B 0,5 (1,9) 6 11,4
B 0,5 (1,9) 8 15,1
B 0,5 (1,9) 10 18,9
D 1,0 (3,8) 6 22,7
D 1,0 (3,8) 8 30,3
D 1,0 (3,8) 10 37,9
D 1,0 (3,8) 12 45,4
/ K
v
= 0,27 / /

Tank Brine refill F.C.
inch mm Nr.
7 178 A-B
8 203 A-B
9 229 B
10 254 B-D
12 305 D
13 330 D
14 356 D
16 406 /

2400VS SERIES
Erie Water Treatment Controls – Belgium
Page 6
Installation
Assembly
For proper assembly of control valve and resin tank, proceed as follows:
1. Rinse the resin tank well before use.
2. Attach the lower distributor to the riser tube using PVC-glue or a stainless steel pin.
3. Lower the riser tube into the resin tank so that it touches the bottom.
4. Cut the riser tube 13 mm (= 1/2”) below the top of the tank threads and chamfer the tube to prepare for
insertion into the control valve.
5. Temporary plug the top of the riser tube to prevent resin from entering the tube and fill the tank with resin for
max. 3/4 full.
6. Make sure the O-ring in the riser insert of the control valve is in the correct position; screw the upper
distributor onto the control valve.
7. Lubricate the threads, the top of the riser tube and the tank O-ring of the control valve.
8. Lower the control valve straight down onto the riser tube and screw it onto the tank.
Installation
!!! ATTENTION
For proper functioning of the unit, incoming water pressure should be between a minimum of 1,4 bar during
regeneration and a maximum of 8,3 bar in service; if necessary, a pressure reducer must be installed ahead of
the system.
Installation must only be undertaken by a person competent in plumbing.
All plumbing and electrical connections must be done in accordance with local codes.
Do not install the unit too close to a water heater (min. 3 m of piping between outlet of unit and inlet of heater);
water heaters can sometimes transmit heat back down the cold pipe into the control valve; always install a
check valve at the outlet of the system.
If the control valve is not equipped with a bypass, a three valve bypass system must be installed to enable
bypassing during servicing.
For proper installation of the unit, proceed as follows:
1. Inlet/outlet: connect the inlet and outlet to the control valve; when facing the front of the control valve, the
inlet is at the left and the outlet at the right side.
2. Drain line: connect a hose to the drain line fitting on the control valve and secure it; insert the drain hose into
a standpipe, with siphon if required; make sure the drain hose is:
as short as possible,
not elevated too much,
free of kinks,
as this will all create undesired counter-pressure.
3. Brine line: an aircheck is required for proper brining during regeneration, but a float-controlled brine valve
system can be used as a double security; 3/8” polytube must be used to connect the brine system to the control
valve; do not overtighten the nut.
4. Transformer: make sure the power source carries the same rating as the transformer; plug transformers output
lead (with plug ø 2,5 mm x 5,5 mm) into socket at the timers power lead and plug transformer into socket; the
connection can be secured by means of the wire clip.

2400VS SERIES
Erie Water Treatment Controls – Belgium
Page 7
Installation check-out
When installation has been completed, the unit is ready to be placed into service. Proceed as follows, while
checking the unit for any leakages:
1. Place unit in bypass and turn on main water supply; open a cold water tap nearby and allow water to run for a
few minutes until all foreign material that may have resulted from the installation is washed out; close the tap.
2. Slowly shift the bypass valve to the service position and secure it; allow water to completely fill the resin tank.
3. Carefully open a cold water tap and allow water to run for at least 2 minutes to set the resin bed and purge air
from the unit; close the tap.
4. Program the control valve according to the specific installation (refer to “Programming” on pg. 11).
5. Press the scroll button repeatedly until the display shows:
6. Leave the control valve in this position; the countdown timer will countdown to 0 sec and start a regeneration.
7. The motor will start and the display will show:
8. You can press the scroll button again to switch the motor to full speed, which will shorten the transfer time
needed by the control valve to reach the next position.
9. The motor will move the control valve into backwash position; allow water to run to drain until all of the air is
purged from the system.
10.Fill the brine tank with water, higher then the air-check level.
11.Press the scroll button; the motor will start and the display will show:
12.The motor will move the control valve into brine/slow rinse position; allow it to draw water from the brine tank
until the aircheck closes.
13.Press the scroll button; the motor will start and the display will show:
14.The motor will move the control valve into fast rinse/brine refill position; allow water to run to drain and brine
tank for the entire cycle time, to fill the brine tank to the programmed level.
15.Add salt to the brine tank.
Mixing valve
To adjust the residual hardness, the incorporated mixing valve must be regulated in function of the hardness of the
incoming water and the desired residual hardness
To increase the residual hardness: turn screw counter clockwise.
To decrease the residual hardness: turn screw clockwise.
Regen in 10 sec
Rgn:XXX Cyc1: YY
Rgn:XXX Cyc2:YYY
Rgn:XXX Cyc3: YY

2400VS SERIES
Erie Water Treatment Controls – Belgium
Page 8
Electronic Control Panel













display
POWER led: lights up when electrical power is applied
DOWN button: to decrease the value of the parameter
UP button: to increase the value of the parameter
SCROLL button: to advance to the next parameter
Power-up
After power-up, the display will show the installed software version for 5 seconds, f.e.:
Afterwards it will automatically revert back to the service display.
The POWER led will light up.
Power failure
In the event of a power failure, the program will remain stored in the NOVRAM® during an undefined period,
while an incorporated SuperCap (capacitor) will maintain the correct time of day during a period of several hours;
consequently, in case of prolonged power failure, the time of day might not be maintained; if this happens, the time
of day indication will flash when the power supply is re-established, indicating that the time of day needs to be set.
When the power failure occurs during the execution of an automatic regeneration, the control valve will remain in
it’s last position; when the power supply is re-established, the control valve will return to the service position, stay
there for 60 sec. and restart a complete regeneration from the beginning.
Timer failure
In the event of a timer failure, the display will show the message:
In such case, entering one of the programming levels can possibly solve the problem. However if the problem
persists, professional service is required.
EZRSDg EZ Rot0.8
Service Required

2400VS SERIES
Erie Water Treatment Controls – Belgium
Page 9
Service mode
In service mode the display shows the time of day, the remaining capacity and the water usage indicator:
Every day the control valve automatically recalculates the reserve capacity, as a progressing average. Permanently
it compares the remaining capacity with the calculated reserve capacity; as soon as the remaining capacity equals
the calculated reserve capacity, the display will show the time of day and the indication “REGEN”, indicating that
a delayed regeneration will be started at the pre-programmed time of regeneration:
In case the resin bed is fully exhausted (remaining capacity equals zero) before a delayed regeneration can take
place, the unit will regenerate immediately.
Regeneration mode
In regeneration mode the display shows the total remaining regeneration time, the actual regeneration cycle and
the remaining cycle time:
total remaining actual regen. remaining
regen. time cycle cycle time
The control valve can be reset to service mode at any time by pressing the scroll button, as such manually
advancing it through the regeneration cycles.
Checking the flow meter
In case of water usage, the remaining capacity counter in the service display will count back per unit, i.e. per litre;
furthermore the water usage indicator will revolve. This way the correct functioning of the water meter can be
verified.
Manual regeneration
It is possible to manually initiate a rgeneration.
1. Press the scroll button repeatedly until the display shows:
If the control valve is left in this position, the countdown timer will countdown to 0 sec and start a
regeneration.
To cancel this mode, press the scroll button before the countdown timer has reached 0 sec; the control
valve will return to the service mode.
20:51 1000L -
20:51 REGEN-
Rgn: 67 Cyc2: 45
Regen in 10 sec

2400VS SERIES
Erie Water Treatment Controls – Belgium
Page 10
Programming
During programming, it is necessary to enter the desired change within 60 sec. Otherwise the microprocessor
will automatically break off the programming and return to the service mode, while all possibly entered
changes to the program are lost. If this occurs, it will be necessary to re-initiate the programming process.
All programming parameters are grouped into different user-specific levels (End-User / Parameter Set /
Diagnostics). The end-user level is accessible freely; in order to access one of the other specific levels, the
proper access code, i.e. key sequence, needs to be entered.
In the programming modes, a flashing indication implicates that this parameter can be adjusted by pressing the
up button or down button; in this technical manual this is indicated by means of an italic font.
Programming instructions - End-User level
Before entering the programming mode, make sure that the control valve is in the service mode.
1. Press the scroll button; the display will show:
Press the up button or down button to set the language.
2. Press the scroll button again; the display will show:
Press the up button or down button to set the time of day.
3. Press the scroll button again; the display will show:
Press the up button or down button to set the water hardness of the incoming untreated water.
Language:English
Set time: 20:51
Set hardn.: XX°f

2400VS SERIES
Erie Water Treatment Controls – Belgium
Page 11
Programming instructions - Parameter Set level
In the Parameter Set level the basic configuration parameters of the unit can be programmed, depending on the
specific configuration of the unit.
Before entering the programming mode, make sure that the control valve is in the service mode.
1. Press the scroll button and hold it for 5 sec until the display shows:
2. Within 10 sec, press the up button; the display will show:
Press the up button or down button to set the units of hardness.
3. Press the scroll button again; the display will show:
Press the up button or down button to set the exchange capacity per litre of resin.
4. Press the scroll button again; the display will show:
Press the up button or down button to set the volume of resin.
5. Press the scroll button again; the display will show:
Press the up button or down button to set the number of days between regenerations.
6. Press the scroll button again; the display will show:
Press the up button or down button to set the length of the regeneration cycle.
Default setting Setting range
Cycle 1 Backwash 5 min 0-20 min
Cycle 2 Brine draw/slow rinse 60 min 0-180 min
Cycle 3 Fast rinse/refill 5 min 0-65 min
7. Press the scroll button again; the display will show:
Press the up button or down button to set the model of flow meter used:
-SNAP SENSOR: model with snap-on flow meter sensor.
-SCREW SENSOR: model with sensor fixed by means of screw.
System Check
Cycle 1: 5min
HardUnit:°f
ExCap:5.2°f M3/L
Resin: 20 liters
Override: 4days
MTR:SNAP SENSOR
5:
XX
min

2400VS SERIES
Erie Water Treatment Controls – Belgium
Page 12
8. Press the scroll button again; the display will show:
Press the up button or down button to set the regeneration mode:
-Dlyd/Immd: when the remaining capacity equals the reserve capacity, a delayed regeneration
is started at the programmed time of regeneration; however when the remaining capacity equals
0 before the programmed time of regeneration is reached, an immediate regeneration is started.
-Immediate: when the remaining capacity equals 0, an immediate regeneration is started.
-Delayed: when the remaining capacity equals the reserve capacity, a delayed regeneration is
started.
9. Press the scroll button again; the display will show (only when the regeneration mode was set to 'Delayed'
or 'Dlyd/Immd'):
Press the up button or down button to set the time of regeneration.
10. Press the scroll button again; the display will show (only when the regeneration mode was set to 'Delayed'
or 'Dlyd/Immd'):
Press the up button or down button to set the reserve capacity:
-Variable: the reserve capacity is calculated automatically, based on the registered daily water
usage.
-Fxd: press the scroll button again and press the up button or down button to set the
reserve capacity to a fixed amount.
11. Press the scroll button again; the display will show:
Press the up button or down button to save the program to the NOVRAM® and exit the
programming level.
Exit
Regen @ 2:00
SENSOR 5:
XX
Regen:Dlyd/Immd
Rsrv Variable

2400VS SERIES
Erie Water Treatment Controls – Belgium
Page 13
Diagnostics level
Besides of all programming parameters, a series of operating parameters can be consulted in the diagnostics level;
particularly during a service intervention, these parameters can be helpful to identify the cause of a problem.
1. Accessing the Diagnostics level:
Make sure that the control valve is in the service mode.
Press the scroll button and hold it for 5 sec until the display shows:
Within 10 sec, press the down button; the display will show:
You are now in the Diagnostics level; use the scroll button to advance through the different diagnostics
parameters.
2. Exiting the Diagnostics level:
If no button is pressed within a time frame of 5 minutes, the microprocessor will exit the diagnostics level
end return to the service mode.
Press the scroll button until the display shows:
Press the up button or down button to exit the Diagnostics level.
3. Available diagnostic parameters:
Regen X days ago: display shows number of days since last regeneration of the unit.
In Srvc: displays show how many days the unit has been in service.
# of Regens: display shows the number of regenerations that have taken place since installation.
TotVol: display shows the total water usage through the unit since installation.
LastRgn@: display shows the water usage at the moment of the last regeneration.
InstFlow: display shows the instantaneous flow rate.
AvgVol: display shows the average daily water usage.
Capacity: display shows the calculated volume of softened water between regenerations.
Hardness: display shows the setting of the water hardness.
Rsrv: display shows the setting of the reserve capacity.
Regen @: display shows the setting of the time of regeneration.
Override: display shows the setting of the number of days between regenerations.
Cycle X: display shows the setting of the length of the corresponding regeneration cycle.
Units: display shows that control is programmed for Metric units.
MTR: display shows the setting of the water meter.
Capacity: display shows that control is programmed for hardness setting.
Regen: display shows the setting of the regeneration mode.
Valve Type: display shows the valve type setting.
MP Resets: display shows the number of resets of the microprocessor (for factory purpose only).
Memory Reset: display shows the number of corrupt memory start-ups (for factory purpose only).
EZ: display shows the software version (for factory purpose only).
CapToUse: display shows the remaining capacity.
System Check
Exit
Regen XXdays ago

2400VS SERIES
Erie Water Treatment Controls – Belgium
Page 14
Parts Replacement
!!! BEFORE SERVICING:
MAKE SURE THE CONTROL VALVE IS IN SERVICE POSITION
DISCONNECT ALL ELECTRICAL POWER TO THE UNIT
BYPASS OR DISCONNECT THE WATER SUPPLY
RELIEF THE WATER PRESSURE
Printed Circuit Board
1. Loosen the 3 front cover screws and remove the front cover.
2. Disconnect all connectors from the PCB.
3. Remove the flat cable of the 3-button control pad from the push-in connection on the PCB.
4. Remove the screws holding the PCB in place.
5. Push aside the clip holding the PCB in place and remove the PCB.
6. Reverse the procedure for reassembly; refer to wiring diagram for proper lead connections.

2400VS SERIES
Erie Water Treatment Controls – Belgium
Page 15
Drive motor
1. Remove the timer head assembly; refer to Parts Replacement “Timer head assembly”.
2. Loosen the 3 front cover screws and remove the front cover.
3. Disconnect the wire connector from the drive motor.
4. At the back of the back plate, remove the 2 screws holding the drive
motor assembly in place and remove the micro switch assembly and
drive motor.
5. Remove the retaining ring securing the worm and remove the worm
from the drive shaft.
6. Pull the drive shaft out of the drive motor.
7. Install the drive shaft in the drive motor, with the flat side on the
drive shaft pointing down (mark on the drive shaft pointing up (1)).
8. Install the worm on the drive shaft and install the retaining ring
securing the worm.
9. Put the micro switch assembly on the drive motor; make sure the
switch cam is in the service position (2).
10.Install the micro switch assembly and drive motor on the back plate
and secure it with the 2 screws.
11.Connect the wire connector on the drive motor; refer to wiring
diagram for proper connection.
12.It is now necessary to check the synchronisation of valve body and
timer head; refer to to Parts Replacement “Synchronising valve body
and timer head”.
Injector
1. Remove the drain hose from the drain elbow.
2. Remove the 6 bolts holding the valve body and cover
together.
3. Lift the valve cover away from the valve body.
4. Remove the rotor assembly from the valve cover; the white
Teflon O-ring will remain in the valve cover.
5. Remove the seal plate from the valve body.
6. Remove the insert plate and gasket from the valve body.
7. Using a needle nose pliers grasp one side of the injector and
pull the injector straight out of the valve body.
8. Make sure the float valve is straight up into the float chamber
of the valve body.
9. Install the insert plate and gasket in the valve body.
10.Lightly lubricate the O-rings of the new injector with a soap
water solution.
11.Install the injector with one of the rectangular openings on the injector facing directly towards the centre of the
valve body; push the injector firmly down.
12.Install the seal disk in the valve body, with the green side facing up.
13.Install the rotor assembly into the valve body ensuring that the
arrow on the worm gear is pointing directly towards the second
tooth on the worm drive shaft (facing the front of the control valve);
the 2 holes in the rotor assembly should now be exactly aligned with
the corresponding holes in the seal disk.
14.Centre the PVC sleeve on the worm gear.
15.Make sure the valve cover O-ring is clean and securely installed
around the raised rib on the valve cover.
16.Lower the valve cover straight down onto the valve body and press it
down firmly and evenly to seat the valve cover.
17.Install the 6 bolts and tighten them in a cross pattern.
18.Install the drain hose to the drain line fitting.

2400VS SERIES
Erie Water Treatment Controls – Belgium
Page 16
Backwash flow control
1. Remove the drain hose from the drain elbow and remove the drain elbow.
2. Unscrew the backwash flow control using a 3/8” Allen wrench.
3. Reverse the procedure for reassembly.
Brine refill flow control
1. Remove the clip securing the refill elbow.
2. Remove the brine refill flow control from the refill elbow.
3. Reverse the procedure for reassembly.
Brine tee
1. Remove the brine line and brine refill tube from the brine tee.
2. Remove the brine tee by turning it counter clockwise.
3. Remove the O-ring, the retainer and check ball from the brine tee.
4. Reverse the procedure for reassembly.
Rotor assembly
1. Remove the drain hose from the drain elbow.
2. Remove the 6 bolts holding the valve body and cover together.
3. Lift the valve cover away from the valve body.
4. Remove the rotor assembly from the valve cover; the white Teflon O-ring will remain in the valve cover.
5. Inspect the rotor plate’s surface; it should be smooth and free of any circular grooves or scratches; replace if
necessary.
6. Install the rotor assembly into the valve body ensuring that the
arrow on the worm gear is pointing directly towards the second
tooth on the worm drive shaft (facing the front of the control valve);
the 2 holes in the rotor assembly should now be exactly aligned with
the corresponding holes in the seal disk.
7. Centre the PVC sleeve on the worm gear.
8. Make sure the valve cover O-ring is clean and securely installed
around the raised rib on the valve cover.
9. Lower the valve cover straight down onto the valve body and press it
down firmly and evenly to seat the valve cover.
10.Install the 6 bolts and tighten them in a cross pattern.
11.Install the drain hose to the drain line fitting.
Seal disk
1. Remove the rotor assembly; refer to Parts Replacement “Rotor assembly”.
2. Remove the seal disk from the valve body.
3. Inspect the seal disk; make sure the raised ribs are intact; the green Teflon coating may be worn off of the ribs,
but this won’t affect the sealing performance of the seal disk; replace if necessary.
4. Use silicone base lubricant to lubricate the green side of the seal disk.
5. Install the seal disk in the valve body, with the green side facing up.
6. Reverse the procedure for reassembly; refer to Parts Replacement “Rotor Assembly”.
