National Instruments NI 6013 Quick start guide

SCB-68A

NOTE TO USERS
NI 60xx/60xxE Pinout Label for
the SCB-68A
Multifunction I/O E Series Modules/Devices Using the 68-Pin
Shielded Connector Block
If you are using an NI 60xx/60xxE (formerly referred to as E Series) multifunction I/O device
or module with the SCB-68A, you can print and attach a connector-specific pinout label to the
cover of the connector block for easy connection reference. This document provides the label for
the following models:
• NI 6011E
• NI 6013
• NI 6014
• NI 6015
• NI 6020E
• NI 6023E
• NI 6024E
• NI 6030E
• NI 6032E
• NI 6034E
• NI 6035E
• NI 6036E
• NI 6040E
• NI 6052E
• NI 6062E
• NI 6070E
• PCI-MIO-16E-1 (PCI-6070E)
• PCI-MIO-16E-4 (PCI-6040E)
• PCI-MIO-16XE-10 (PCI-6030E)
• PCI-MIO-16XE-50 (PCI-6011E)

© 2017 National Instruments. All rights reserved.
371807A-01 Jul17
Refer to the NI Trademarks and Logo Guidelines at ni.com/trademarks for more information on NI trademarks. Other product and company
names mentioned herein are trademarks or trade names of their respective companies. For patents covering NI products/technology, refer to the
appropriate location: Help»Patents in your software, the patents.txt file on your media, or the National Instruments Patents Notice at
ni.com/patents. You can find information about end-user license agreements (EULAs) and third-party legal notices in the readme file for your
NI product. Refer to the Export Compliance Information at ni.com/legal/export-compliance for the NI global trade compliance policy
and how to obtain relevant HTS codes, ECCNs, and other import/export data. NI MAKES NO EXPRESS OR IMPLIED WARRANTIES AS TO THE
ACCURACY OF THE INFORMATION CONTAINED HEREIN AND SHALL NOT BE LIABLE FOR ANY ERRORS. U.S. Government Customers: The data
contained in this manual was developed at private expense and is subject to the applicable limited rights and restricted data rights as set forth in
FAR 52.227-14, DFAR 252.227-7014, and DFAR 252.227-7015.
Figure 1. NI 60xx/60xxE
FREQ OUT
D GND
CTR 0 OUT
D GND
PFI 9/CTR 0 GATE
PFI 8/CTR 0 SOURCE
D GND
PFI 7/AI SAMP CLK
PFI 6/AO START TRIG
D GND
PFI 5/AO SAMP CLK
CTR 1 OUT
D GND
PFI 4/CTR 1 GATE
+5V
PFI 3/CTR 1 SOURCE
D GND
PFI 2/AI CONV CLK
1
35
2
36
3
37
4
38
5
39
6
40
7
41
8
42
9
43
DIGITAL
SCB-68A Quick Reference Label
NI 60xx/60xxE
E Series Devices
P0.5
P0.1
D GND
P0.6
P0.2
D GND
P0.7
+5V
P0.3
D GND
AI HOLD COMP
D GND
EXT STROBE
PFI 0/AI START TRIG
D GND
PFI 1/AI REF TRIG
51
17
50
16
49
15
48
14
47
13
46
12
45
11
44
10
DIGITAL
AI GND
AI 6 (AI 6+)
AI 14 (AI 6-)
AI GND
AI 7 (AI 7+)
AI 15 (AI 7-)
AI GND
AO 0
AO GND
AO 1
AO GND
AO EXT REF
D GND
P0.4
P0.0
D GND
59
25
58
24
57
23
56
22
55
21
54
20
53
19
52
18
ANALOG/
DIGITAL
AI 0 (AI 0+)
AI 8 (AI 0-)
AI GND
AI 1 (AI 1+)
AI 9 (AI 1-)
AI GND
AI 2 (AI 2+)
AI 10 (AI 2-)
AI GND
AI 3 (AI 3+)
AI 11 (AI 3-)
AI GND
AI SENSE
AI 4 (AI 4+)
AI 12 (AI 4-)
AI GND
AI 5 (AI 5+)
AI 13 (AI 5-)
68
34
67
33
66
32
65
31
64
30
63
29
62
28
61
27
60
26
ANALOG
Temp Sensor Disabled
(Factory Default)
Temp Sensor Enabled
(Differential)
+
V
T
–
AI 0+
Tem p
Sensor
AI 0–
123
1
2
S1 S2
123
1
2
S1 S2
Temp Sensor Enabled
(Single-Ended)
+
V
T
–
AI 0
AI GND
Tem p
Sensor
12 3
1
2
S1 S2
