ERKUL SKI CARRIER User manual

SKI CARRIER
ASSEMBLY
INSTRUCTIONS
Watch our installation video using the QR code.

PACKAGE
CONTENT
1 www.erkulauto.com
B (x4)
C (x4) D (x4)
E
A (x2)
F (x1)

ASSEMBLY
INSTRUCTIONS
3
1
2
Tighten T screws into the
canal over (B) crossbar.
Install C parts to the t-bolts.
Insert the ski carrier into
t-screws through the holes
in the bottom of (A).
2 www.erkulauto.com

ASSEMBLY
INSTRUCTIONS
LoremIpsum
4
5
6
Press the button to open
the cover and remove the
lock on the slide.
Move the slide outwards.
Fix D brackets by tightening
two screws.
3 www.erkulauto.com

ASSEMBLY
INSTRUCTIONS
8
Apply the same for the second
ski carrier.
Tighten the both brackets and
then lock it by tilting them
downwards.
Load your skis on the slide and
push the slide in its place. Be
sure that your skies front sides
looks at your cars backside.
(D)Aparatlarını iki vidayada
çevirereksabitleyin.
4 www.erkulauto.com
9
7

ASSEMBLY
INSTRUCTIONS
12
10
11
Close the covers of both
carriers.
Push the slide all the way
through, then push the lock
downwards and fix the ski.
Lock your ski carrier with the
key (E).
5 www.erkulauto.com

Watch our factory video using the QR code
SKI CARRIER
ASSEMBLY
INSTRUCTIONS
