ERNA MAS E 90 RL User manual

1
E 90 RL - FOOD PROCESSOR

2
E 90 RL – FOOD PROCESSOR
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed,
including the following:
1. Read all instructions before using the appliance. It is suggested that you keep these
instructions in a safe place for future references.
2. Your voltage must correspond to the voltage printed on the bottom of the appliances.
Connect to alternating current only.
3. To protect against electrical shock do not put the motor housing (base), cord or plug in
water or other liquid.
4. Close supervision is necessary when the appliance is used by or near children.
5. Unplug from outlet when not in use, before putting on or taking off parts, an before
cleaning.
6. Avoid contacting moving parts at all times.
7. Do not operate the appliance with a damaged cord or plug or after the appliance
malfunctions, or is dropped or damaged in any manner. Return the appliance to the
nearest authorized service facility for examination, repair or electrical or mechanical
adjustment.
8. The use of attachments including canning jars not recommended in the instruction
manual may cause fire, electric shock or injury to persons.
9. Do not use outdoors.
10. Do not let cord hang over edge of table or counter, or touch hot surfaces.
11. Keep hands and utensils away from moving blades or discs while processing food to
reduce the risk of severe injury to persons or damage to the food processor. A scraper
may by used but must be used only when the food processor is not running.
12. Blades are sharp. Handle carefully. When handling the chopper blade , always hold it by
the upper plastic part.
13. To reduce the risk of injury, never place cutting blades or discs on the base without
first putting bowl properly in place.Be certain cover is securely locked in place before
operating appliance
14. Never feed food by hand. Always use food pusher.
15. Do not attempt to defeat the cover interlock mechanism.
16. Always operate blender with cover in place.
17. When blending hot liquids, remove center piece of two-piece cover.
18. Do not use the appliance if juicer filter is damaged or broken.

3
*The appliance is not to be used by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction.
*Children being supervised not to play with the appliance.
*Do not use the appliance if the rotating sieve is damaged.
*Switch off the appliance and disconnect from supply before changing
accessories or approaching parts that move in use
*This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand
the hazards involved
*Children shall not play with the appliance
*Cleaning and user maintenance shall not be made by children without
supervision
*Always disconnect the appliance from the supply if it is left unattended and
before assembling, disassembling or cleaning.
*This appliance shall not be used by children. Keep the appliance and its cord
out of reach of children.
*Appliance can be used by persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and
if they understand the hazards involved.
*Children shall not play with the appliance.
This appliance is intended to be used in household and similar applications
such as:
- staff kitchen areas in shops, offices and other working environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
*Be careful when handing the sharp cutting blades, emptying the bowl and
during cleaning

4
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
IMPORTANT INFORMATION
Please read all the following instructions carefully.
For your protection, E 90 RL Food Processor has a double safety device so that it cannot
run unless the main lid (13) is locked in place and either the security cover (2) or the
blender (8) is also locked in place.
Please Note :
A. To remove security cover (2) or blender (8), you must first remove the main lid.
B. To operate the food processor, security cover (2) must be properly locked in place.
C. To operate blender (8) main lid (13) must be locked in place.
D. When operating blender (8), make sure that all attachments are first removed from
food processor bowl (11).
E. Do not attempt to use both blender and food processor at the same time.
F. Do not attempt to defeat the security cover (2) interlock mechanism or the main lid
interlock.
INSTRUCTIONS FOR USE
Control Panel
After properly locking the security cover (2) in place, correctly locating the bowl (11)
and locking the main lid (13), turn the operation button (4) to activate the unit from its
off position.
For intermittent use, press onto “PULSE” button (5)
(1) Food Processing
CAUTION : Make sure that the unit is unplugged from power source and operation button
is on “OFF” before inserting or removing any attachments an before cleaning.
WARNING : Use extreme caution, blades are sharp.
Place the security cover (2) in its place (3). Make sure that the two arrows face each
other and the security cover (2) is securely locked before operating the appliance. Do
not attempt to defeat the cover interlock mechanism.
IMPORTANT : The food processing unit will not operate if the security cover is not locked
in place. This must be done before the bowl is locked in place.

5
WARNING : To reduce risk of injury, never place the cutting blade on the base without
first putting the bowl properly in place.
Place the bowl (11) on the motor block (6). (There is no need to turn it – it will lock in
place by itself)
Insert the spindle (12) on the shaft inside the bowl.
Place the chopping blade (23) over the shaft of the spindle (12).
Make sure that the chopping blade is correctly positioned in its place.
Place the ingredients to be processed in the bowl (11).
Place the main lid (13) and lock it.
WARNING : Use extreme caution – Blades are sharp, handle carefully. Always hold the
chopping blade by the upper plastic part. After using the chopping blade, always take it out
of the bowl (11) before removing the processed food. Always store the chopping blade with
its protective cap on. Place the main lid (13) on the bowl and guide the nozzle on the lid into
the safety lock opening in the motor block, until you hear it snap in place. Turn the appliance
on.
Keep hands and utensils away from the cutting blade while chopping food, to reduce the
risk of severe injury to persons or damage to the food chopper. A scraper may be used,
but must be used only when the food processor is not running.
Never feed food by hand. Always use food pusher (14)
Do not leave the appliance unsupervised when it is operating i.e. when it is “ON”
Processing Examples :
The processing times indicated are approximate and also depend on the quality of the food
to be processed and the degree of fineness you require.
Food Processing :
Product Quantity Recommended Levels Operation Times
Meat 700g. Max 10 – 20 sec.
Onions 700g. 5-6 10 – 20 sec.
Nuts 600g. 8-Max 10– 20 sec.
Fish 700g. 1-8 10 – 20 sec.
Cheese 700g. 1-8 10 – 20 sec.
Liquids (soup) 700g. 1-8 20 sec.
Carrots 700g. 6-8 20 sec.
Bread 4 pieces 6-8 10 – 20 sec.
Apples 700g. 8-Max 10 – 20 sec.
Parsley Max 4 bundles Max 10 sec.
Mayonnaise Max 4 cups/1 lt. 8-Max 20 sec.
Butter-Honey 600g butter + 750g pine honey 3s On / 2min Off
mix

6
Butter-Honey
Mix
600g Butter +
750g Pine
honey
- 3s ON/2 min
OFF
(2) Dough Making
CAUTION : Make sure that the unit is unplugged from power source and operating button
is on “OFF” before inserting or removing attachments
Make sure the security cover (2) is securely locked in its place (3)
Place the bowl on the motor block.
Insert the spindle (12) on the shaft inside the bowl.
Insert the dough kneader (25) over the shaft of the spindle (12).
Place ingredients in the bowl.
Place the main lid (13) and lock it.
Recommended operation speed level is MAX.
Maximum capacity for processing dough is based on the mixture of 600g. Of flour plus
400 gr. of water in order to obtain 1 kg. of dough. When preparing knead –dough, do not
operate the machine longer than 20 seconds afterwards wait at least two minutes
before operating the machine again.
For your safety, keep the pusher in its place while operating the appliance.
(3) Whipping
CAUTION: Make sure that the unit is unplugged from power source and operating button
is on “OFF” before inserting or removing attachments.
Make sure the security cover (2) securely locked in its place (3).
Place the bowl on the motor block.
Attach the removable beater (27) to the main whipping beater attachment (26).
Place the beater (26) into the bowl.
Place the ingredients in the bowl.
Place the main lid (13) and lock it.
Recommended speed level for whipping is maximum.
For your safety, the pusher must stay in its place while operating the appliance. Keep
hands, hair, clothing as well as spatulas and other utensils away from beaters during
operation to reduce the risk of injury to person, and/or damage to the appliance.
IMPORTANT
WARNING:
Never use the whipping attachment for dough kneading.

7
Do not immerse the whipping attachment into water. For cleaning, remove beaters (27)
from the whipping attachment by pulling it out. Replace the beaters after washing the
beaters only.
(4) Citrus Juicer
CAUTION : Always operate the juicer only at minimum speed (MIN)
CAUTION : Make sure that the unit is unplugged from power source and operating button
is on “OFF” before inserting or removing attachments.
Make sure the security cover (2) is securely locked in its place (3)
Place the bowl on the motor block.
Place the citrus juicer filter (28) on the bowl and lock it by turning it.
Put on the juicer reamer (29)
Operation speed level for citrus juicing is MIN. Do not operate the juicer at higher
speed.
(5) Continuous Slicer / Shredder
CAUTION : Make sure that the unit is unplugged from power source and operating button
is on” “OFF” before inserting or removing attachments.
Make sure security cover (2) is securely locked in its place (3).
Place the bowl on the motor block.
WARNING : Use extreme caution – blades are sharp. Handle carefully.
Place the blade of your choice on the blade – holder (17)
Insert the spindle (12) on the shaft inside the bowl.
Place the blade holder (17) over the shaft of the spindle (12).
Place the main lid on the bowl and lock in place.
For your safety, always use the pusher to press down the ingredients Never feed food
by hand. Moving parts: keep fingers out of discharge opening.
Do not overload the bowl. In one operation, you can process maximum 1.5 kg. of food.
Processing Examples
For thin slicing : Blade – A (20) – Recommended speed level is between 5-6
(Cheese)
For thick slicing : Blade – B (21) – Recommended speed level is between 5-6
(Cabbage, carrots onions)
For thin shredding : Blade – C (18) – Recommended speed level is between 5-6
(Carrots, cucumbers, cabbage)
For thick shredding : Blade – D (19) – Recommended speed level is between 5-6

8
(lettuce, carrots, apples)
For French fries : Disc – (22) – Recommended speed level is between 5-6
(Potatoes)
(6) Blender
CAUTION : Make sure the unit is unplugged from power source and operating button is on
“OFF” before inserting or removing attachments.
First, remove the bowl (11) and main lid (13).
Remove the security cover (2) (Security cover can be removed only after the main lid
(13) is removed)
Place the blender on its place.
WARNING : Use extreme caution – blades are sharp. Handle carefully.
Place the bowl without any attachments on, and place the main lid and lock it in place.
IMPORTANT : Blender will not operate when lid (13) is not locked in place. The bowl must
be empty and without attachments when blender is used.
Place the lids of the blender (9, 10)
Recommended speed levels for blending are between 5-Max. For soft vegetables and
fruits (e.g: banana), shard with the low speed then increase according to your needs.
For hard vegetables and fruits (e.g: carrots) always use the highest speed or Max. Do
not load the blender with more than 300 gr. of hard vegetable in one time. Do not
operate continuously more than 20 sec. In one time.
You can crash 10 oz. O ice cubes in 15-20 sec. In the blender.
CAUTION : To prevent spilling, do not operate the blender with more than 1000 ml. Of
soft liquid (e.g: soup).
Always operate the blender with cover in place.
When blending hot liquids, remove the small lid (10)
Avoid contact with moving parts at all times.
Keep Hands, hair, clothing, as well as spatulas and other utensils out of the container
while blending, to reduce the risk of severe injury to persons of damage to the blender.
A spatula may be used, but must be used only when the unit is not running.
To remove blender, you must first remove the main lid (13)
(7) Juice Extractor
CAUTION : Make sure unit is unplugged from power source and operating button is on
“OFF”
Make sure the security cover lid is securely locked in its place.
Place the bowl on the motor unit.

9
Place in the juice extractor filter (30)
Place the juice extractor lid (31) and lock it.
The recommended speed level is MAX. For juice extracting.
For your safety, always use the pusher to press down the ingredient.
Always make sure juicer lid is locked securely in place before motor is turned on. Do not
remove the juice extractor lid (31) while operating.
Be sure to turn switch to “OFF” position after each use. Make sure the motor stops
completely and unplug unit before disassembling.
During use, turn “OFF the appliance temporarily to clean the pulp that remains in the
filter, with the help of the spatula (16)
Do not put your fingers of other objects into the juicer opening while it is in operation.
If food becomes lodged in the opening, use food pusher (32) or another piece of fruit
or vegetable to push it down. When this method of removing food lodged in the opening
is not possible, turn the motor “OFF” and disassemble juicer to remove the remaining
food.
CLEANING AND MAINTENANCE
CAUTION : Make sure the unit is unplugged from power and operating button is on “OFF”
before cleaning.
Never immerse the unit or cord or plug in water.
Clean the motor block with a damp cloth only.
Only the stainless steel blades can be washed in the dishwasher.
All other parts can be cleaned in warm sudsy water using regular dishwashing liquid.
Cleaning the blender :
-Fill with sudsy warm water.
-Place cover.
-Run blender at maximum speed for 30 seconds. Rinse at repeat if necessary.
Warning: Please wash the parts contact with food and dry with a cloth after each usage.
EASY STORAGE IDEAS
4 pcs. of slicing, shredding blades
1 pc of French fries cutting disc
Blade holder
Spindle
Can be stored on the storage basket.(15) You can also place this storage basket onto
the main lid (13) for more efficient space usage
Spatula
Can be placed on the spatula storage area which is on the unit.
Whipping beater attachment
Removable beater
Chopping blade

10
Can be stored on the storage housing (7) which is on the main body.
The power cord can be stored by pushing in to the inside of the main body.
