Westinghouse WHCH01KS User manual

INSTRUCTION MANUAL
MULTI-PURPOSE CHOPPER
WHCH01KS220~240V

SAFETY INFORMATION
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . 1 - 2
Electrical Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SETUP AND USE
Installation Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Parts and Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
. . . . . . . . . . . . . . . . . . . . . . . 5
CLEANING AND CARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 9
CONTENTS
Figures and illustrations in this User Manual are provided
for reference only and may differ from actual product appearance.
Product design and specifications may be changed without notice.
Multi-purpose Chopper Operation

© 2021 RVM Australia Pty Ltd. All Rights Reserved 1
IMPORTANT SAFETY INSTRUCTIONS
***WARNING***
1. Read all instructions carefully before using your new multi-purpose chopper.
Keep these instructions in a safe place.
2. Always use this multi-purpose chopper with a power outlet of the voltage
(A.C. only) marked on the back of the appliance.
3. DANGER Do not operate multi-purpose chopper if:
i) the cord or plug is split, melted or damaged.
ii) the appliance has malfunctioned.
iii) the appliance has been damaged in any manner.
If any of the above incidents occur, return the multi-purpose chopper to the
nearest authorised service center for examination, repair or adjustment.
4. DANGER Do not under any circumstances immerse the power cord, mains
plug or multi-purpose chopper body in water or any other liquid.
5. WARNING Incorrect operation and improper use may damage the multi-
or parts thereof, and cause severe personal injury.
6. WARNING When operating the multi-purpose chopper touch body and
buttons only as outer surfaces may become hot whilst the multi-purpose .
7. WARNING Do not blend hot or boiling foods or liquids as there is a risk of
burns or scalding.
8. WARNING T
he multi-function chopper blades are very sharp, avoid touching
handle with care.
9. WARNING Do not plug the appliance to mains before it is fully assembled.
10. WARNING Exercise caution when removing the attachments from the
attachments.
multi-purpose chopper and ensure the appliance is turned off and unplugged
whilst
11. WARNING
WARNING
Keep hands and utensils out of the blending container while
blending to reduce the risk of severe injury. A scraper may be used but must only
be used when the multi-purpose chopper is not running.
12. Do not handle the appliance with wet hands.
13. CAUTION The multi-purpose chopper should not be left unattended while
in operation.
14. CAUTION Keep the multi-purpose chopper and its cord out of reach of
children younger than 8 years old.
15. CAUTION It is not recommended to run the multi-purpose chopper
continuously for than 2 minutes at a time for light substances. Do
not mix dry, thick or mixtures continuously for more than 30 seconds.
Stop the operation and stir the ingredients before continuing.
DANGER - Immediate hazards
which WILL result in severe
personal injury or death.
DANGER
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death.
WARNING
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury.
CAUTION
purpose chopper
and
fitting
heavy
more
chopper is in use.
them

2
16. CAUTION Do not use this multi-function chopper with any attachment
other than the ones supplied.
as this may cause damage to the multi-function chopper.
17. CAUTION Do not chop extremely hard food items, such as ice cubes, nutmeg
18. All choppers are designed to operate only when the power buttons remain
depressed.
19. Always ensure hands are dry before handling the plug or switching on the
appliance.
Ensure the multi-purpose chopper is switched off and unplugged from the
20.
power source prior to cleaning.
21. This multi-purpose chopper is not intended for use by persons (including children)
reduced physical, sensory or metal capabilities or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the multi-purpose chopper in a safe way by the person
responsible for their safety,
and understand the hazards involved.
22. Children should be supervised not to play with the multi-purpose chopper.
Always turn off the power at the power outlet before you insert or remove the
23.
power plug. Remove by grasping the plug - do not pull on the cord.
24. This appliance is intended for non-commercial, indoor use only. Do not use this
appliance for anything other than its intended use.
25. Always hold the firmly and upright while in use.
26. Always use the appliance on a stable, secure, dry and level surface.
27. This appliance is not intended to be operated by means of an external timer or
separate remote-control system.
28. Wait for the multi-purpose chopper to cool before moving.
29. Pay close attention when using this appliance near children.
30. Do not place your multi-purpose chopper on or near a hot gas flame, electric
element, heated oven or any hot surface.
31. Do not place the multi-purpose chopper on top of any other appliance.
32. Do not permit the mains supply cord or plug to touch hot objects, or allow the
power cord to lay across the multi-purpose chopper body or blades.
33. Do not allow the power cord of this appliance to hang over the edge of a table or
bench top.
34. Do not use harsh or abrasive cleaning agents or any sharp instruments for cleaning
the appliance. When the appliance is cool to touch, the outside surface may be
wiped clean with a soft, damp cloth and then dried thoroughly. If necessary, a
mild dishwashing detergent may be applied to the cloth but not directly applied
to the multi-purpose chopper.
35. Immediately unplug the multi-purpose chopper from mains power if malfunction
occurs.
36. If the appliance has been dropped or damaged, it should not be used until
examined by an authorised service center.
37. If the mains supply cord is damaged, it must be replaced by the manufacturer,
it’s service agent or a similarly qualified person in order to a
void a hazard.
IMPORTANT SAFETY INSTRUCTIONS
chopper unit
For added safety, electrical appliances should be connected to a power outlet
that is protected by a residual current device (RCD), also often referred to as a
‘Safety Switch’. Your switchboard may already incorporate an RCD. If unsure, call
an electrician for verification and fitting if necessary.
38.
with

© 2021 RVM Australia Pty Ltd. All Rights Reserved 3
POWER SUPPLY CORD
1. Do not attempt to modify the power cord or plug in any way.
2. A short power supply cord is provided to reduce the risk of entanglement or
tripping over.
3. If the power supply cord is too short, do not use an extension cord. Have a
qualified electrician or serviceman install an outlet near the appliance.
NOTE: Neither Westinghouse nor the retailer can accept any liability for damage
to the product or personal injury resulting due to failure to observe the electrical
connection procedures.
ELECTRICAL REQUIREMENTS
INSTALLATION GUIDE
1. Carefully unpack your electric multi-purpose chopper.
2. Carefully remove packaging around the multi-purpose chopper and straighten
cord. Do not remove warning labels.
3. Wash blades, bowl and lid before use.
DANGER Do not under any circumstances immerse the power cord, mains plug or
body in water or any other liquid.
WARNING The multi-purpose chopper blades are very sharp, avoid touching
them and handle with care.
and ensure the appliance is turned off and unplugged whilst fitting
attachments.
WARNING Exercise caution when removing the attachments from the multi
chopper mini
the power
purpose chopper

4
PARTS AND FEATURES
DESCRIPTION:
1. Power Level 1 Button
2. Power Level 2 Button
3. Main Unit Body
4. Lid
5. Seal Ring
6. Side Blade Unit
7. Main Blade Unit
8. Spindle
9. Bowl
10. Non Slip Mat
1
2
3
4
5
6
7
10
9
8

© 2021 RVM Australia Pty Ltd. All Rights Reserved 5
MULTI-PURPOSE CHOPPER OPERATION
1. Before first use, the chopper accessories must be cleaned. Wash with warm
water and mild detergent. Rinse with fresh water and allow to dry.
Your multi-purpose chopper is now ready for use.
2. Ensure unit is unplugged from wall power outlet.
3. Assemble the main blade unit with the side blade unit by sliding the side blade
unit over the main blade unit shaft. Twist side blade to lock into place. **Note:
exercise caution when mating the blades together as they are very sharp**
4. Insert the assembled blade into the chopper bowl and onto the spindle.
5. Add ingredients into the bowl being careful not to touch the blades.
6. Place lid onto the bowl and insert the chopper body into the lid.
7. Ensuring
chopper body, plug the power cord into the A/C outlet and switch on.
your fingers are not pressing either of the buttons on the top of the
8. Begin operation by pressing the power level buttons on the top of the chopper
body.
9. After use, unplug from the wall power outlet.
WARNING The multi-purpose chopper blades are very sharp, avoid touching
them and handle with care.
and ensure the appliance is turned off and unplugged whilst fitting attachments.
WARNING Do not plug the appliance into power before it is fully assembled.
WARNING Exercise caution when removing the attachments from the chopper
NOTE: All multi-purpose choppers are designed to operate only when the power
buttons remain depressed.
WARNING Do not blend hot or boiling foods or liquids as there is a risk of burns
or scalding.
CAUTION It is not recommended to run the multi-purpose chopper
continuously for more than 2 minutes at a time for light substances. Do not mix dry,
thick or heavy mixtures continuously for more than 30 seconds. Stop the operation
and stir the ingredients before continuing. Allow the motor to rest for 1 minute
ween each use.bet

6
CLEANING & CARE
1. After use, unplug from the wall power outlet then lift the chopper body from
lid to place aside or into storage. All remaining parts ie: bowl, lid, blades are
dishwasher safe and may be placed into the dishwasher or hand cleaned.
2. Do not use harsh or abrasive cleaning agents. The outside surface of the multi-
body may be wiped clean with a soft, damp cloth and dried
thoroughly. If necessary, a mild dishwashing detergent may be applied to the
cloth but not directly applied to the multi-purpose chopper.
3. Do not soak or immerse the multi-purpose chopper body in water or any other
4. Rinsing the blender blade under warm water should be sufficient to remove
most food substances.
5. When washing, non-abrasive cloths and plastic bristle kitchen brushes may be
used to remove stubborn food particles from the accessories. Do not use abrasive
cloths and cleaning materials as they will damage the surface.
6. Ensure all components are dried thoroughly after cleaning, before placing into
storage.
7. Store in a dry place away from steam and humidity where possible.
DANGER Do not under any circumstances immerse the power cord, mains plug or
chopper body in water or any other liquid.
WARNING The multi-purpose chopper blades are very sharp, avoid touching them
and handle with care.
-purpose chopper.
WARNING Exercise caution when removing the blade attachment from the multi-
purpose chopper
liquid.

© 2021 RVM Australia Pty Ltd. All Rights Reserved 7
TROUBLESHOOTING
BEFORE CALLING FOR SERVICE
If the multi-purpose chopper fails to operate:
1. Check to make sure the multi-purpose chopper is plugged in correctly and
securely. If it is not,remove the plug from the outlet, wait 10 seconds and plug it
2. Check for a blown or tripped circuit breaker in your home. If these seem to be
working correctly, test another appliance in the same outlet to ensure the outlet
is working correctly.
IF NONE OF THE ABOVE SOLVES THE PROBLEM, DO NOT TRY TO ADJUST OR
REPAIR THE MULTI-PURPOSE CHOPPER YOURSELF.
CUSTOMER SERVICE
In the event you believe your multi-purpose chopper to be defective, please return it
along with your sales receipt to the place of purchase for resolution.
For any enquiries, please call our service center on: Tel: [phone]
TROUBLESHOOTING
Troubleshoot your problem by using the chart below. If the multi-purpose chopper
still does not operate correctly, it may be defective.
TROUBLE POSSIBLE CAUSE
Mult-purpose chopper
does not turn on. is not plugged in.
Check that multi-purpose
is plugged into a
working power outlet
POSSIBLE REMEDY
Motor slowing down
and appears to be
struggling while in use.
Foods are too dense
or too much food in
the bowl.
Reduce quantity of food
and try again.
Multi-purpose chopper
chopper
and turned on.
back in securely

8
LIMITED WARRANTY
1.
Consumer Law. The benefits to the Consumer under this Warranty are in addition
Nothing in this warranty affects the Consumer’s rights under the Australian
to the rights and remedies of the buyer under anyConsumer Guarantees. The
Australian Consumer Law requires that we confirm that:
Our goods come with guarantees thatcannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure
and for compensation for anyother reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
2. Subject to Clause 1, the Seller warrants thatWestinghouse branded products will
be free of manufacturing defects and will perform to the Seller’s specifications
subject to the following clauses.
3. The benefit of this Warranty extends only to the owner of the property in which
the Products manufactured or supplied bythe Seller are installed and used bythe
owner for the duration of the Warranty Period.
4. The Warranty commences on the date of the purchase of the product and
continues for the benefit of the Owner for the Warranty Period. If within the
Warranty Period a manufacturing defect is discovered in the Product, or the
Product fails to perform to the Seller’s specifications as a result of some defect in
:noitercsidnwostitalliwrelleSehtneht,tcudorPehtnipihsnamkrowrolairetam
a.) Repair or replace the Product atthe costof the Seller, including but not
limited to labour and travel costs. Goods repaired or replaced under this
Warranty will be warranted for the remaining period of the Warranty.
b.) Refund the purchase price paid by the consumer.
5. The Warranty does not apply to Product that:
a.) Has failed due to excessive wear and tear beyond whatis considered to be
reasonable.
b.) Has been misused or neglected.
c.) Has been damaged accidentally or byacts of God including fire and flooding.
d.) Has been used or operated contrary to operating or maintenance instructions.
e.) Has been damaged bythe Consumer or a third party authorised to act for the
consumer in transit from the Sellers store to the Consumer.
6. In order to make a claim under the Warranty, the Owner must, where possible
return the goods to the Seller’s store atthe Owner’s cost. Proof of purchase must
be supplied in all cases.
7. The seller will examine anyreturned Products and if the Seller determines that
there is an apparent defect through no fault of the Owner, the Seller will:
a.) Make note of the Owner’s contact details including the Owner’s telephone
number which the owner can be contacted during business hours, postal
address and e-mail address.

© 2021 RVM Australia Pty Ltd. All Rights Reserved 9
b.) Make note of the defects reported by the Owner.
c.) Take back the defective goods from the owner and determine within a
reasonable time through dialogue with the Seller whether the goods are
defective.
d.) Advise the owner within a reasonable time frame whether it accepts or
rejects the Product claim.
e.) If the Seller accepts the return of the Product, the Seller must arrange to have
i) The Product repaired or,
ii) Replace the damaged or faulty Product or,
iii) Refund the purchase price.
8. The Seller will not accept any returned Product which has not been returned
strictly in accordance with this Warranty.
9. For the purpose of this Warranty:
a.) Australian Consumer Law means the law as set out in Schedule 2 of the
Competition and Consumer Act 2010 (Cth).
b.) Consumer means the Purchaser of goods from the seller.
c.) Consumer means a Consumer as that term is set out in section 3 of the
Australian Consumer Law.
d.) Consumer Guarantees means the guarantees under the Australian Consumer
Law.
e.) Implied terms means any guarantees, conditions, warranties or other terms
implied by any Australian Commonwealth, State or Territory laws, (excluding
the Australian Consumer Law) or the law of any other jurisdiction.
f.) Owner has the meaning set out in clause 3.
g.) Warranty means this warranty.
h.) Product means the Product/s bought by the Owner from the Seller that fall
under this warranty.
i.) Warranty Period means:
i) In relation to Cast Iron Cookware: 3 Year Limited Warranty.
ii) In relation to Non-Stick Cookware: 3 Year Limited Warranty
iii) In relation to Cooking Utensils: 3 Year Limited Warranty
iv) In relation to Knives/Knife Block Sets: 3 Year Limited Warranty
v) In relation to Stainless Steel Cookware: 10 Year Limited Warranty
vi) In relation to Chopping boards: 1 Year Limited Warranty
vi) In relation to Small Appliances: 1 Year Limited Warranty

14
220~240V
CUSTOMER SERVICE - AU: 1300 883 109
CUSTOMER SERVICE - NZ: 0508 776 546
[e-mail]
[e-mail]
www.westinghousesmallappliances.com.au
IMPORTED AND DISTRIBUTED BY RVM AUSTRALIA PTY LTD.
11 Tamara Drive, Cockburn Central, WA 6164
MADE IN CHINA
© 2021 RVM AUSTRALIA PTY LTD. ALL RIGHTS RESERVED.
W& ESTINGHOUSE are trademarks of Westinghouse Electric Corporation.
Used under license by RVM AUSTRALIA PTY LTD. ALL RIGHTS RESERVED.
