ESA KVM User manual

Page 1of 9
KVM video extender
User Manual
HARDWARE
Connect
Ideas.
Shape
solutions.

Rev. 0
Date: 19/ 05/20 20
405.1300.2 65.0
Table of contents
Document description ...........................................................................3
KVM EXTENDER ....................................................................................3
HARDWARE DESCRIPTION.....................................................................4
Transmitter unit..............................................................................................................................................................4
Connection between the transmitter and the receiver .................................................................................................4
Receiver unit...................................................................................................................................................................4
Installation ...........................................................................................5
Before installation ..........................................................................................................................................................5
Transmitter unit..............................................................................................................................................................5
Receiver unit...................................................................................................................................................................5
Note ................................................................................................................................................................................ 5
Product specifications ...........................................................................6
Features ...............................................................................................7
LED Indicator ........................................................................................8

Rev. 0
Date: 19/ 05/20 20
405.1300.2 65.0
Document description
This document is the user manual of the ESA KVM touch and video extender.
Here below the user can find the description of the device, the functionality, the ESA product codes and installation
sheet.
KVM EXTENDER
KVM is an acronym that stands for Keyboard, Video and Mouse.
A KVM extender is a device that let the user increase the distance between a PC based device and the industrial
monitor.
The connection that can be reached with a video and USB cable is up to 5 meters long.
With the ESA KVM extender the distance can be increased up to 100 meters.

Rev. 0
Date: 19/ 05/20 20
405.1300.2 65.0
HARDWARE DESCRIPTION
The ESA KVM extender kit is made of two different components; the TRASMITTER and the RECEIVER.
ESAKVMSENDER000: transmitter unit
ESAKVMRECEIVER0: receiver unit
Transmitter unit
The transmitter unit has to be connected to the source PC with both the VIDEO and the USB cable.
The video signal and the touch screen can be remoted.
Connection between the transmitter
and the receiver
The connection between the transmitter and receiver unit is via a single Ethernet cable.
In order to reach the best video quality it is mandatory to use CAT5 or CAT6 shielded Ethernet cable.
Receiver unit
The receiver unit has to be connected to the remote monitor via the video and the USB cable.

Rev. 0
Date: 19/ 05/20 20
405.1300.2 65.0
Installation
Before installation
1. Define where the Transmitter and the Receiver unit will be located.
2. Use CATx ethernet cable (EIA/TIA 568B industry standard compliant) for the interconnection between
Transmitter and Receiver Unit.
3. Never disassemble or reassemble the enclosures for any purpose. This may cause personal injury and/or
property damage.
Transmitter unit
Insert a USB cable into the USB port of the host industrial computer, and a square port into
the USB port of the transmitter; use the DVI cable to connect one end to the DVI interface of
the host and the other end to the DVI in interface of the transmitter.
Plug one end of the network cable into the RJ-45 interface on the transmitter.
Plug the connector of the power supply into the port marked with the power supply on the
transmitter
Receiver unit
Insert the other end of the network cable into the port marked RJ45 on the receiver.
Connect the remote keyboard, mouse, touch screen, U disk and other USB devices to the
USB interface of the receiver, and the industrial monitor to the DVI interface of the receiver.
Plug the connector of the power supply into the power port of the receiver,
Note
The quality of the output signal will depend largely upon the quality of the video source, cable and display device
used.
Low quality cables degrade the output signal causing elevated noise levels.
Use the proper cable. (CAT5 Industrial grade cables).

Rev. 0
Date: 19/ 05/20 20
405.1300.2 65.0
Product specifications
Function
Input
Transmitter: one way (DVI, USB, on / off
indicator)
Output
Receiver: one way (DVI, on / off indicator), four
USB
Transmission distance
0 -100 m
Transmitter video interface
DVI
Receiver video interface
DVI
Video interface and
performance
Video resolution
800×600@60HZ;1024×768@60HZ;
1280×720@60H;1280×800@60HZ;
1280×1024@60HZ;1360×768@60HZ;
1440×900@60HZ;1600×1200@60HZ;
1680×1050@60HZ;1920×1080@60HZ;
1920×1200@60HZ; 2560×1080@60HZ;
4K×2K
USB interface Interface type
Transmitter B -type female port
Receiver A -type female port
Protocol
Support USB2.0
Transmission
interface
RJ45 Cat5E/ Cat6
Power part
Applicable voltage range
24V DC
Power waste
Transmitter
：
6W
Receiver
：
9W
Operating environment
Working temperature
-15℃-55℃
Storage temperature
-40 -80℃
Humidity
0 -95% (No condensation
）

Rev. 0
Date: 19/ 05/20 20
405.1300.2 65.0
Features
•Full digital, no compression, no delay transmission;
•Transmission rate up to 10Gbps;
•Support 1080p, 2560 × 1080 @ 60Hz, up to 4K × 2K, support multiple
resolutions.
•Support DVI-I dual link.
•Video compatibility is good, supporting access to various brands of monitors and
video cards.
•USB 2.0 protocol is supported. USB device has good compatibility and will not jam or
restart. It supports remote switch, restart of computer host and LED indicator light of
host switch, which is easy to use.
•Up to 4 USB interfaces can be connected to USB key mouse, touch screen, mobile
hard disk, etc. At the same time, it is designed with high current, does not drop the
line, and is convenient for users to use.
•The built-in strong anti interference circuit design has good handling for
electrostatic interference, surge interference and RF interference, and the
performance is reliable and stable.
•High speed circuit design, n o delay, will not affect the user's use effect .

Rev. 0
Date: 19/ 05/20 20
405.1300.2 65.0
LED Indicator
Indicator light
Color
Working state
Working description
Power Red
Always bright
The power supply is normal.
Not bright
There is no power supply.
Link Green
Always bright
The communication connection
between transmitter and
receiver is normal.
Not bright
No communication connection
established between transmitter
and
receiver.
Video Orange
Twinkle
Video signal input is normal.
Not bright
There is no video input or the
receiver is not connected to the
monitor.

Rev. 0
Date: 19/ 05/20 20
405.1300.2 65.0
Connect
ideas.
shape
solutions.
ESA S.p.A. | www.esa-automation.com |
