ESC PGEN-30 User manual

1
ECS Protector Nitrogen Generator
PGEN-30 (PGEN-30E)
Specicaons
Dimensions (cabinet): 24.5”(W) x 52.5”(H) x 8.5”(D)
(622mm(W) x 1,334mm(H) x 216mm(D))
Dimensions (incl. bypass): 32.5”(W) x 52.5”(H) x 8.5”(D)
(826mm(W) x 1,334mm(H) x 216mm(D))
Weight: 152 Lbs (69 Kg)
Temperature Range: 40°F - 105°F (5°C - 40°C)
Power Supply: 120v/1 phase/60Hz - Dedicated Circuit
(230v/1 phase/50Hz - Dedicated Circuit)
Power Consumpon: 2 Amps
Gas Connecons: Air Inlet - ½” NPT Female
Nitrogen Outlet - ½” NPT Female
Drain Connecon: ¼” NPT Female
UL 508A Listed Industrial Control Panel
ECS Protector
Nitrogen Generator
designed for fire sprinkler systems
ECS Protector Nitrogen Generator PGEN-30 (PGEN-30E) June 2018 - Rev 5
Engineered Corrosion Solutions  11336 Lackland Road  St. Louis, MO 63146  Phone [phone] www.ecscorrosion.com
General Descripon
Ordering Informaon
Stock Number: PGEN-30 (PGEN-30E)
Replacement Filters: PGEN-FKS - Annual Maintenance
Gas Membrane: PGEN-MS - 20 Year Expected Service Life)
The ECS Protector Nitrogen Generator is designed for
use in maintaining supervisory gas and facilitang the
Dry Pipe Nitrogen Inerng (DPNI) process for
controlling oxygen corrosion in dry and pre-acon re
sprinkler systems. The ECS Protector is an on-site
nitrogen generaon system that is designed to be
installed inline between the compressed air supply
and the sprinkler system riser in dry or preacon pipe
sprinkler systems. The nitrogen generator ulizes
membrane gas separaon technology that exhausts
oxygen as a waste gas to produce 98%+ nitrogen on
demand with no nitrogen storage necessary for dry or
preacon systems.
The ECS Protector Nitrogen Generator cabinet has an
external bypass valve to allow for nitrogen generator
maintenance or “fast ll” needs, and is designed to
meet the NFPA 13 30-minute ll requirement for dry
pipe or preacon re protecon systems.
For use under U.S. Patents
8,720,591, 9,144,700 and 9,186,533

2
ECS Protector Nitrogen Generator PGEN-30 (PGEN-30E) June 2018 - Rev 5
Engineered Corrosion Solutions  11336 Lackland Road  St. Louis, MO 63146  Phone [phone] www.ecscorrosion.com
ECS Protector
Nitrogen Generator
designed for fire sprinkler systems
Operang Performance
† Capacity based on NFPA-13 30-minute ll requirement of largest single system
Nitrogen Quality
N2 Purity at Discharge: 98% or greater (Maximum of 2.0% oxygen)
N2 Pressure at Discharge: Min of 15 psig (1 bar) Max of feed air pressure minus 15 psig (1 bar)
N2 Water Dew Point: Typically less than -70ºF (- 57ºC)
Note: When connecng an ECS Protector Nitrogen Generator to an exisng dry pipe/preacon re sprinkler system, the
exisng re sprinkler system(s) must be limited to a maximum leak rate of less than 3 psig within a 24 hour period, per
system.
The ECS Protector Nitrogen Generator facilitates the
patented “ll and purge” breathing process in the re
sprinkler system when paired with a venng device
installed on the sprinkler riser such as the ECS
Protector Manual Vent (PAV-D) or the ECS Protector
Dry SMART Vent (PSV-D/DE) for dry and preacon
systems.
The ECS Nitrogen Generator unit that includes the
following components:
• Steel enclosure cabinet with membrane type
nitrogen generator (no nitrogen gas storage) and
manual bypass
• Power supply - 120 VAC/1 phase/60Hz
(230 VAC/1 phase/50Hz)
• Single point nitrogen/air discharge – ½” NPT
• Hour Run Meter
• Cycle Counter
The ECS Nitrogen Generator includes the following
funcon Indicaons:
• Bypass Alarm - Nitrogen generator is in the
“By-Pass” mode (Flashing Indicator)
• Leak Monitoring - Nitrogen generator running
excessively (Audible Signal)
The ECS Nitrogen Generator includes the following
monitoring outputs:
• System Power (Digital Output)
• Bypass Mode Alarm (Digital Output)
• Nitrogen Generaon Mode (Digital Output)
• Nitrogen Supply Line Pressure (Analog Output)
• Leak Monitoring (Digital Output)
The ECS Nitrogen Generator is designed to be used in
conjuncon with the following components as part of
the complete ECS Dry Pipe Nitrogen Inerng (DPNI)
system:
• Air maintenance device with on board adjustable
regulator (recommend Victaulic Series 757, Tyco
Model AMD-1 or Reliable Model A-2)
• Riser-mounted ECS Protector Manual Vent
(PAV-D) or ECS Protector Dry SMART Vent (PSV-D)
The ECS Nitrogen Generator can be used with the
following oponal equipment:
• ECS Protector SMART Gas Analyzer (SGA-1) - one
per nitrogen generator is recommended
• ECS In-Line Corrosion Detector (ILD-X) -
monitoring at least one system is recommended
Model
Number
Min. Supply Air
SCFM (L/min)
Total System Capacity
Gallons (Liters)
Single System Capacity† @
40 psig (2.4 bar)
Gallons (Liters)
Single System Capacity†
@ 20 psig (1.4 bar)
Gallons (Liters)
PGEN-30/(30E) 14.3 (405) 6,500 (24,605) 1,150 (4,353) 2,300 (8,706)

3
Installaon Instrucons
Installaon of the ECS Protector Nitrogen Generator requires ve (5) steps:
1. Mount the cabinet in the appropriate installaon locaon
2. Bring the dedicated power supply to the cabinet
3. Plumb the nitrogen/air supply line to the water based re sprinkler risers being served
4. Plumb the condensate drain line to oor drain or building exterior
5. Connect Nitrogen generator output signals to BMS or re alarm system, where applicable
Step 1: Mounng the nitrogen generator cabinet
The ECS Protector Nitrogen Generator is designed to be mounted directly to the oor and/or the wall at
the installaon locaon. Several factors should be considered in choosing the proper mounng locaon
for the nitrogen generator:
• Access to required power supply (dedicated circuit)
• Access to sprinkler risers being supplied from nitrogen generator
• Access to drain for the condensate discharge line
Note: The cabinet includes pre-punched holes in the feet for oor mounng and holes in the back panel
for wall mounng using standard anchors.
STEP 2: Power Supply
The ECS Protector Nitrogen Generator requires a dedicated power supply to prevent interrupon from
other equipment. The incoming power supply line es into the top of the terminal blocks inside the
nitrogen generator cabinet (see diagram). The landing points are labeled L1, N, and G.
Step 3: Plumb the Nitrogen/Air Supply Line
The nitrogen/air discharge plumbing from the ECS Protector Nitrogen Generator is to be connected
directly to the sprinkler system valve trim using ½” to 1” black steel, galvanized steel, or copper lines.
The size of the nitrogen/air supply line shall be based on both the length of pipe between the nitrogen
generator and re sprinkler systems and the total volume of re sprinkler systems being supplied. The
nitrogen generator requires an in-line Air Maintenance Device (AMD) that is equipped with an on board
eld adjustable pressure regulator for each zone being served. The preferred AMD is the Victaulic Series
757.
ECS Protector Nitrogen Generator PGEN-30 (PGEN-30E) June 2018 - Rev 5
Engineered Corrosion Solutions  11336 Lackland Road  St. Louis, MO 63146  Phone [phone] www.ecscorrosion.com
ECS Protector
Nitrogen Generator
designed for fire sprinkler systems
120v/1 Phase 60 Hz Connecons
(230/1 Phase 50 Hz Connecons)
GL1 N

4
ECS Protector Nitrogen Generator PGEN-30 (PGEN-30E) June 2018 - Rev 5
ECS Protector
Nitrogen Generator
designed for fire sprinkler systems
Engineered Corrosion Solutions  11336 Lackland Road  St. Louis, MO 63146  Phone [phone] www.ecscorrosion.com
Note: When both dry pipe and preacon re sprinkler systems are connected to one nitrogen generator,
addional equipment may be required if the re sprinkler systems operate at dierent supervisory gas
pressures.
Step 4: Plumb the Condensate Drain Line
The ECS Protector Nitrogen Generator will occasionally discharge a small amount of condensate water
from the coalescing lters inside the cabinet. It is recommended that the ¼” drain connecon be
plumbed to a oor drain or building exterior. When plumbing to a drain is not feasible an evaporave
collecon chamber can be used.
Step 5: System Signals and Monitoring, where used
The nitrogen generator cabinet has two (2) system signals and ve (5) outputs that can be monitored
by the facility’s BMS or re alarm system.
• The nitrogen generator is operang in the bypass mode which is acvated when the bypass valve is
in the “fast ll” posion to fast ll the re sprinkler system and the air supplied directly from the
air compressor has reached a pressure of 20 psig (1.4 bar). (Flashing amber light)
• The nitrogen generator is equipped with a leak monitor audible signal which is acvated when the
nitrogen generator runs excessively. (Audible signal)
The nitrogen generator cabinet includes system monitoring signals which can be monitored through a
building monitoring system, if desired:
• Nitrogen Generator Loss of Power (Form C contacts)
• Bypass Mode Alarm (Form C contacts)
• Nitrogen Generaon Mode (Form C contacts)
• Nitrogen System Supply Line Pressure (Analog Signal)
• Leak Monitoring (Form C contacts)
Nitrogen Generaon
Monitoring Output
Leak Monitoring Output
Nitrogen Generator
Power Monitoring Output
By-Pass Alarm
Monitoring Output

5
ECS Protector Nitrogen Generator PGEN-30 (PGEN-30E) June 2018 - Rev 5
Engineered Corrosion Solutions  11336 Lackland Road  St. Louis, MO 63146  Phone [phone] www.ecscorrosion.com
ECS Protector
Nitrogen Generator
designed for fire sprinkler systems
Typical ECS Protector Nitrogen Generator Dry/Preacon System Schemac
Maintenance of the ECS Protector Nitrogen Generator
The nitrogen cabinet contains three (3) separate cartridge lters. It is recommended that each lter be replaced
as part of an annual preventave maintenance program. In some environments it may be necessary to replace
lters more frequently. The lter kit for the PGEN-30 (PGEN-30E) is part number PGEN-FKS. When maintained
properly the nitrogen separaon membrane will provide up to 20 years of service life.
Filter Replacement Procedure
Preliminary Steps (taking the nitrogen generator out of service)
1. Turn the power supply to the unit o
2. Close the inlet and outlet ball valves on the bypass loop
3. Depressurize the nitrogen generator internal inlet piping by slowly unscrewing the petcock valve on the boom
of the lemost lter housing
Coalescing Filter Cartridge Replacement Procedure
The lters with condensate drain tube extending from the boom of the lter housing are coalescing lters. To
replace the lter cartridges follow Steps 1 through 6 on the following page.
Clear Drain
Nitrogen
Generator
Air Compressor
Dry/Preacon
Sprinkler Risers
ECS Protector Dry Pipe
Venng Device
Nitrogen/Air
Supply Line

6
ECS Protector Nitrogen Generator PGEN-30 (PGEN-30E) June 2018 - Rev 5
Engineered Corrosion Solutions  11336 Lackland Road  St. Louis, MO 63146  Phone [phone] www.ecscorrosion.com
ECS Protector
Nitrogen Generator
designed for fire sprinkler systems
Step 1: Grasp the ¼” clear drain tube on the boom of the lter housing with the right hand. With the le hand,
push upward on the grey retaining ring on the lter housing outlet ng. This will allow for the ¼” clear
drain tube to be removed from the ng.
Step 2: Once the ¼” clear drain tube has been disconnected, the lter housing bowl may be unscrewed from the
top poron of the lter housing which is connected to the internal system piping.
Step 3: Once the lter housing bowl has been unscrewed, the lter cartridge inside is removed by rst
unscrewing the black retaining disc at the base of the cartridge and then pulling down on the cartridge.
Discard the old lter cartridge and replace it with the appropriately marked lter cartridge from the
lter replacement kit by pushing up so that it ts snugly onto the receiving cylinder in the upper part of
the lter housing. Screw the black retaining disc back onto the central metal threaded rod.
Important: HAND TIGHTEN ONLY!
Step 4: Replace the lter housing bowl by screwing it onto the lter housing top.
Important: HAND TIGHTEN ONLY!
Step 5: Reconnect the ¼” clear drain tube into the ng on the lter housing bowl. Make sure that it fully seats
in the ng and is retained snugly.
Step 6: Repeat Step 1 through Step 5 for each addional lter.
Black Disc
Filter Cartridge
Top of Filter
Housing

7
ECS Protector Nitrogen Generator PGEN-30 (PGEN-30E) June 2018 - Rev 5
Engineered Corrosion Solutions  11336 Lackland Road  St. Louis, MO 63146  Phone [phone] www.ecscorrosion.com
ECS Protector
Nitrogen Generator
designed for fire sprinkler systems
Acvated Carbon Filter Replacement Procedure
The lter without condensate drain tube extending from the boom of the lter housing is an acvated carbon
lter. To replace the lter cartridge follow the steps below:
Step 7: Remove the lter housing bowl by unscrewing it from the top poron of the lter housing which is
connected to the internal system piping.
Step 8: Once the lter housing bowl has been removed, the lter cartridge inside is removed by rst unscrewing
the black retaining disc at the base of the cartridge and then pulling down on the cartridge. Discard the
old lter cartridge and replace it with the appropriately marked lter cartridge from the maintenance kit
by pushing up so that it ts snugly onto the receiving stepped cylinder in the upper part of the lter
housing. Screw the black retaining disc back onto the central metal threaded rod.
Important: HAND TIGHTEN ONLY!
Step 9: Replace the lter housing bowl by screwing it onto the lter housing top.
Important: HAND TIGHTEN ONLY!
Step 10: Tighten the petcock valve to the closed posion.
Step 11: The ECS Protector Nitrogen Generator can now be placed back into service.
Return the ECS Protector Nitrogen Generator to Service
1. Turn the power supply to the unit on.
2. Open the inlet and outlet ball valves, and close the bypass valve on the bypass loop.
3. Check inside the nitrogen generator cabinet for leaks using a soap water soluon. Tighten ngs where
needed.
ECS Protector Nitrogen Generator Oponal Monitoring Equipment
• ECS Protector Handheld Gas Analyzer (PHGA-1): portable handheld gas analyzer includes one-buon
calibraon and enables user to measure nitrogen concentraon at nitrogen generator cabinet or gas
sampling ports on ECS venng devices
• ECS Protector SMART Gas Analyzer (SGA-1/1E): permanently installed near an ECS Protector Manual/
SMART Vent to connuously report nitrogen gas concentraon to a building informaon or management
system; includes digital display and provides 0-5V DC or 4-20mA output signals
• ECS In-Line Corrosion Detector (ILD-X): installed in-line within the re sprinkler system piping at
locaons most suscepble to corrosion; provides either a local push-buon test/indicator or control
panel monitoring

8
(1) Single system capacity based on 30 min. ll requirement of largest single sprinkler system; a secondary air compressor with normally
closed isolaon valve can be used to meet ll requirement for larger individual systems
(2) Size and weight of nitrogen generator only, does not include separate air compressor
(3) All nitrogen generators include 1 year manufacturer’s warranty per ECS terms and condions
Wall Mount Skid Mount Stand Alone w/Separate Air Compressor
PGEN-3PGEN-5PGEN-10 PGEN-20 PGEN-30 PGEN-40 PGEN-50 PGEN-60
Total System Capacity 675 gal 950 gal 2,000 gal 3,200 gal 6,500 gal 11,000 gal 18,500 gal 22,500 gal
Single System Capacity @ 40 psi(1) 215 gal 265 gal 560 gal 950 gal 1,150 gal 1,440 gal 2,025 gal 2,900 gal
Single System Capacity @ 20 psi(1) 540 gal 590 gal 1,120 gal 1,800 gal 2,300 gal 2,880 gal 4,050 gal 5,800 gal
Air Compressor Integral Integral Integral Integral Separate Separate Separate Separate
Size (H x W x D) 36x24x9 36x24x9 38x29x11 57x32x40
Weight 115 lbs 125 lbs 175 lbs 420 lbs 152 lbs(2) 264 lbs(2) 300 lbs(2) 300 lbs(2)
Engineered Corrosion Solutions  11336 Lackland Road  St. Louis, MO 63146  Phone [phone] www.ecscorrosion.com
