Escene IS/IV 720 User manual

Smart Security IP Intercom
Smart Security IP Intercom
IS/IV 720 User Manual
IS720-01 IV720-01
IS720TD-01 IV720TD-01
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
Copyrig t and Disclaimer
Copyright
Any enterprises or individuals cannot extract, copy and spread in any form of this
document without our written permission .In accordance with the law, copying includes
translating the document into other languages or conversing into other formats. When
this document is transmitted in network media, Escene Communication Co. , Ltd allows
downloading or printing for private use. Any parts of the document are not allowed to e
modified or used for commercial purposes. Escene Communication Co. , Ltd will not
assume any responsi ility for the injuries and losses caused y any unauthorized
modification or conversion of the document.
Declaration
Information regarding t is guide is subject to c ange wit out any notice.
This manual provides accurate statement, information and recommendation to the largest
extent, ut will not guarantee any express or implies. Users should take full responsi ility
for the application of products. Escene Communication Co. , Ltd will not make any
guarantee for this manual, including ut not limited to warranties for implies
merchanta ility and particular purposes. Escene Communication Co. , Ltd does not
assume any responsi ility for indirect or consequential loss caused y the misuse of this
manual.
A out this manual
Thank you for choosing Smart Security IP Intercom IS/IV 720.This IP Intercom is
specially designed for the user under the pu lic environment with fashiona le
appearance and complete functions. This manual aims to help you quickly use Smart
Security IP Intercom IS/IV 720.Before use ,please read the packing list and safety notes
section of this manual ,communicate with the system administrator to confirm if the
current network environment can meet the requirements of configuring the Intercom. If
this is your first time to use Smart Security IP Intercom IS/IV 720, we recommend that
you should read the quick installation guide and product technical manual. The document
can e downloaded from the following we site: http://www.escene.cn/en/en.
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
Summary
Copyright and Disclaimer....................................................................................................2
1.Getting Started.................................................................................................................5
1.1 Outline....................................................................................................................5
1.2 Product Features...................................................................................................5
1.3 Technical Information.............................................................................................6
2. Intercom Installation........................................................................................................7
2.1 Em edded............................................................................................................10
2.2 Equipment installation..........................................................................................12
3.Configuration of IP intercom...........................................................................................13
3.1 Remote WEB Management.................................................................................14
3.2 Phone Status.......................................................................................................17
3.3 Network................................................................................................................18
3.3.1 LAN Port Configuration..............................................................................18
3.3.2 PC Port Configuration................................................................................19
3.3. 3 VLAN Settings..........................................................................................19
3.3. 4 Port management Settings.......................................................................20
3.3. 5 QoS...........................................................................................................20
3.3. 6 Network Packet Mirroring.........................................................................20
3.3. 7 LLDP.........................................................................................................20
3.3. 8 Paging Settings.........................................................................................20
3.3.9 Socket5 Proxy Server................................................................................21
3.4 SIP Accounts.......................................................................................................22
3.5 Programma le Keys............................................................................................24
3.6 Phone Settings.....................................................................................................25
3.6.1 Output...............................................................................................................25
3.6.2 Time Settings....................................................................................................26
3.6.3 Backlight............................................................................................................26
3.6.4 Ring tone...........................................................................................................26
3.6.5 Volume Setting..................................................................................................27
3.7 Features...............................................................................................................27
3.7.1 VoIP Call Forward.............................................................................................28
3.7.2 Auto Redial.......................................................................................................28
3.7.3 Pickup function..................................................................................................28
3.7.4 Hotline function.................................................................................................28
3.7.5 Auto Answer......................................................................................................29
3.7.6 Remote Control.................................................................................................29
3.7.7 Action URL........................................................................................................29
3.7.8 EP+...................................................................................................................29
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
3.7.9 Other features settings......................................................................................30
3.8 Advanced.............................................................................................................31
3.8.1 Audio.................................................................................................................31
3.8.2 Dial Plan............................................................................................................31
3.9 Phone call info.....................................................................................................31
3.10 Door card setting................................................................................................32
3.11 Maintenance......................................................................................................32
3.11.1 HTTP Upgrade.........................................................................................32
3.11.2 FTP Upgrade...........................................................................................33
3.11.3 TFTP Upgrade.........................................................................................33
3.11.4 Factory reset............................................................................................34
3.11.5 Re oot.....................................................................................................34
3.11.6 Log...........................................................................................................35
3.11.7 Auto Provision..........................................................................................35
4. Relay management................................................................................................37
4.1 RFID Card management...............................................................................38
4.1.1 RFID Card issuing/revoking in the WUI of the phone................................38
4.1.2 Add card Issuer and Revocation...............................................................39
4.2 Press key/Input/ServerControl/DTMF/TouchKey management..........................40
5. Brief pictures for application environment..............................................................40
5.1 Door security system application.........................................................................41
5.2 Fire protection system application.......................................................................41
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
1.Getting Started
1.1 Outline
ESCENE SN-SG IP Door Phone IS/IV 720, is the newest indoor VoIP intercom
which professional designed as the requirements from industry users. The device has the
characteristic of well compati ility with different platform, offering users a convenient
service.
IS/IV 720 is dust proof, water proof and dismantle prevention, having a fashion
appearance and high protection. IS/IV 720 is a ond of door opening y long-distance
DTMF, Password and RFID. Its powerful performance, sta ility and reasona le price
make it a perfect choice of industry user.
NOTE: IS/IV 720-PRT, P is POE, R is Reader(optional), T is Touchpad(optional).
1.2 Product Features
Support em edded or wall-mounted installation.
High-fidelity sound quality, HD codec, Full duplex hands-free calls;
WEB supports multi-language: Chinese, Russian, French, etc.
4 SIP accounts, support 3-way conferencing;
2*RJ45 standard Ethernet Ports(LAN/PC), Support PoE;
Backlit Digital Key oard, can provide dial-up or password input(Option);
*Built-in RFID reader; Indoor open-door interface and external power supply
interface;
User-defined DSS keys, which can e set up to Speedy dial, intercom, etc.
Support Plug-and-Play, auto-provision, remote maintenance and management;
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
1.3 Tec nical Information
INTERFACE SPECIFICATION:
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD
Intercom features
WEB support Multi-Language ;4 SIP account; Hotline; Call hold, Call waiting, Call forward;
Call transfer ( lind/ usy/ask);Mute, DND; Auto-answer, 3-way conferencing;1 DSS
programma le key(Speed dial, Intercom etc.);Volume control; Direct IP call without SIP proxy;
Default Ring tone 1 selection/import/delete; Custom Ring tone 2 selection/import/delete;
Time setting(SNTP/SIP Server/Manual);Support SIP main/stand y server;
LED Status
Availa le--OFF；Busy--Steady；registration failed--Flashing
Network parameters
SIP v1 (RFC2543), v2 (RFC3261);DNS SRV (RFC3263);NAT Traversal: STUN mode; DTMF:
In-Band, RFC2833, SIP Info, Auto; HTTP/HTTPS We Management;
IP Assignment: Static/DHCP/PPPoE; Network support Bridge mode;
TFTP/DHCP/PPPoE client; DNS client, NAT/DHCP server;
Security
LLDP, VLAN QoS (802.1pq),VPN(L2TP);Transport Layer Security (TLS);Digest authentication
using MD5/MD5-sess;Secure configuration file via AES encryption; Admin/User 2-level
configuration mode;
Voice features
Wide and Codec: G.722;Narrow and codec: G.711μ/A, G.723.1;G.726, G.729a/ , iLBC;
VAD, CNG, AEC, AGC; Full-duplex;
Video features
Video codec: H.264 ; Image codec: JPEG/PNG/BMP/GIF; Video format: MP4/3GP/FLV;
Video call resolution: QCIF / CIF / VGA / 4CIF (1280x720P); Bandwidth selection:
64k ps~4M ps; Frame rate selection: 10~30fps.
P ysical properties
1 Digital Keypad, acklit digital (Option)
1 LED display (LED digital tu e, availa le in touchpad model)
1 Speaker Key or DSS key ; 1 Reader Light,
1 Ringing status Light, 1 Network & SIP Light
1 Talking status light
2 RJ-45 10/100M Ethernet
Power adapter: DC 12V/1A; Power over Ethernet ,IEEE 802.3af,class 0;
Each mother oard port, check the picture illustration elow "Mother Broad Interface".
Carton packaging
The whole Size：162*112*40mm
Product Certification
Platform Compatibility Test (non-certificate)
ZTE/Alcatel-Lucent/Asterisk/Broadsoft/Metaswitch/Yeastar/Avaya/3CX/Elastix/HUAWEI
etc.

Smart Security IP Intercom
Expansion Board Connector Diagram
Mother Board Connector Diagram
*This data is for information purposes only and is su ject to change without notice.
2. Intercom Installation
Generally system administrator will connect your new IS/IV 720 IP Intercom to company
LAN network. If not, please refer to elow illustration.
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
Open IS/IV 720 packing ox, according to the packing list, check the related attachment
to make sure to no omitting. Packing list as follows.
IS/IV 720 Intercom
Quick operating guide
8*Screws
2*Ru ers
IS/IV 720 could e installed to internet according to the elow steps.
A)Connect Network
B)Internal/External Electric Lock Connection Driver Option
C)Internal/External Electric Lock Connection
Connect network
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
Internal/External Electric Lock Connection Driver Option
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
Internal/External Electric Lock Connection
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
2.1 Embedded
If the product is used for em edding,then the cutting of em edded need to e a little
igger than the installing hole of standard dimension 168*116*42mm .(42mm means the
extra aluminum housing thickness.),as follows. Notice: the em edded value is up to the
actual situation.
ront and side structure
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
Back structure
2.2 Equipment installation
1、Open the aluminum housing.
2、Put the IP intercom into it according to the cutting em edded specification. After that,
fix four M3*12 screws on the wall with the screw driver.
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
3、After installing inter housing, well-set the related wiring and replace the aluminum
housing. Power on and start testing.
3.Configuration of IP intercom
You need to know the IP address of IP Intercom efore starting setting. You could learn
how to get IP address elow.Default IP address is 192.168.1.153.in static status.If getting
from DHCP,you need to search the related IP address y the third software scanning
equipment MAC.(Getting IP y DHCP is not suggested.)
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
3.1 Remote WEB Management
This equipment's factory IP address is using static IP(ip:192.168.1.100,
Gateway:192.168.1.1).
http://192.168.1.100/user.asp is easy we management.
http://192.168.1.100/home.asp is all-round we management.
Once input the IP address of intercom on the we rowser and tap the “enter” on the
key oard. Then a login screen will pop up from the intercom equipment. You need to
input user name and password. Both default user name and password of system is case
letters “root”
After the log-in，the easy administrate we page of the intercom will pop up.
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
If you want to open the all-round we management, you can enter an URL as follow:
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
Here you can see as elow information: System Run Time, Register Status, Network
Status, System Information,
3.2 P one Status
Here you can see as elow information: System Run Time, Register Status, Network
Status, System Information,
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
3.3 Network
3.3.1 LAN Port Configuration
ITEM DESCRIPTION
N e t w o r k C o n n e c t i o n
Mode
Network Connection Mode has DHCP, Static IP, PPPoE.
DNS SETTINGS Select the DNS mode that you want.
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD

Smart Security IP Intercom
3.3.2 PC Port Configuration
Bridge mode
Normally, you should choose “bridge” feature, it means that pc port and LAN port will share
the
same network.
Router mode
Router feature is for the phone PC Port. You must input IP address (it’s equivalent to a
gateway)
and Net mask. If you want to use DHCP function, please turn it on, input start IP and end IP.
3.3. 3 VLAN Settings
When using VLAN Setting option, you can set several parameters as follow:
VLAN Setting
Enable VLAN You can enable/disable VLAN for phone and pc
www.escene.cn/en
ESCENE COMMUNICATION CO.,LTD
