Escort PASSPORT X70 Operator's manual

Quick Reference
R A D A R •L A S E R •D E T E C T O R
Contact Us Settings & Preferences
To enter preferences Press and Hold S EN and BRT button down for 2 seconds. To exit Preferences,
simply wait a few seconds without pressing a button. The unit will display Completed to confirm
your selections.
Controls & Features
Power
Press to turn
PASSPORT X70 on or off
Brightne ss (BRT)
Press to adjust display
brightness (Min, Med,
Max, Dark)
Vol•Mute
Press to mute an alert;
Press and hold + or −
to adjust volume
Mount Release
Press to remove device
from mounting
bracket
87 9 10
Display
Alert a rea
Notes for Se ttings & Preferenc es
For descriptions of features and functions
available when connected to ESCORT Live, visit
EscortR adar.com and download the PASSPORT
X70 Owner’s Manual.
To view serial number and software rev ision
press SEN and VOL– while powering on
detector.
To restore PASSPORT X70 to its origi nal factor y
settings, press and hold BRT and VOL+ while
powering on detector. Restored message will
display, acknowledgi ng the reset.
Softwar e Updates
PASSPORT X70 is easily updated usi ng our
exclusive detector sof tware tools found on our
web site. Firmware, or the operati ng software
for the detector, can be updated using these
tools.
In order to have access to these updates, please
register your PASSPORT X70 at ww w.
EscortR adar.com. Once registered, you will
receive email notifications that updates are now
available for your firmware. To handle your
software you need to connect your PASSPORT
X70 to a computer first. You can connect
PASSPORT X70 to a computer via USB A / Mini B
cable (not included).
Designed in the USA
ESCORT Inc.
5440 West Chester Road
West Chester OH 45069
Sales / Ser vice 800.433.3487
www.EscortRadar.com
©2015 ESCORT Inc. E scort®, Passpo rt®, X70, Escor t Live!™, AFR ®,
TrueLock™, Sma rtShield®, Sp ecDisplay™, Auto Sensitivit y™, ExpertM eter™
and Cincin nati Microwave are trademar ks of ESCORT I nc. Manufac tured
in Canada . Features, sp ecifications and prices sub ject to chan ge without
notice.
FCC NOTE: Mo difications n ot expressly approved by th e manufact urer
could void the user’s FCC gr anted authori ty to opera te the equipm ent.
FCC ID: QKLM4PP.
This device complies with p art 15 of the FCC r ules. Operation is s ubject
to t he fo llowing two cond itions: (1) T his de vice m ay not caus e harm ful
interf erence, and (2 ) This device must accept any interfer ence re ceived
including interferen ce that may cause undesired operation.
Accessories
800.433.3487
EscortRadar.com
Sensit ivity (SEN)
Press to adjust detector
sensitivity (Highway,
Auto, Auto NoX)
Display
• When connected to ESCORT Live,
the Speed limit data and actual
speed will display on screen.*
*Requires Optional SmartCord Live
and app subscription.
Press BRT to go from one Press VOL + or VOL – to change
band category to the next your setting within a category
X Band On* / Off Freq: 10.475 -10.575 GHz
K Band On* / Off Freq: 24.050 -24.250 GHz
Ka Band On* / Off Freq: 33.400-36.000 Ghz
NOTE: When Ka Band is off, you can select separate segments of the
band to turn on or off
KaN1 On* / Off Freq: 33.660 - 33.900 GHz
KaN2 On* / Off Freq: 34.200 - 34.400 GHz
KaN3 On* / Off Freq: 34.600 - 34.800 GHz
KaN4 On* / Off Freq: 35.400 – 35.600 GHz
Ka-POP On / Off*
Laser On* / Off Laser Detection
TSR On* / Off Automatically rejects traffic flow sensors-monitoring false alarms
RDR On* / Off Radar Detection Rejection
*Default Setting
Press SEN to go from Press VOL + or VOL – to change
one category to the next your setting within a category
Pilot Scan Bar* Scanning Bar with Full Word
Full Word Full Word: Auto*, Auto No X, or Highway
Display Color Blue*/Green/Red/Amber Set color to match your vehicle’s dash display. Adding
brighter max screens and lower brightness setting during
when user is in minimum bright setting
Meter Mode Standard* Single band with bar graph of signal strength
Spec Single band with numeric frequency
Expert Multiple bands with bar graph of signal strengths
Tones Standard* Standard ESCORT alert tones
Mild Mild doorbell chime alert tones
AutoMute On* / Off Automatically reduces audio during alert
Language English* / Espanol Language for voice and text
Voice On* / Off Voice announcements
Band Enables Default* Default Settings for North America
Modified Customize the bands you want to monitor
Open ➜
Compatible with

Congratulations
The PASSPORT X70 introduces the followi ng
state-of-the-art per formance a nd features:
• Long-range K and Ka-band radar performance,
including instant-on POP mode.
• Exclusive AutoSensitivit y intell igently filters
out annoying false alar ms, plus Highway,
Auto, and Auto No X settings.
• Exclusive ExpertMeter tracks a nd displays up
to 4 radar signals simultaneously.
• Exclusive SpecDisplay provides actual
numeric frequency for any radar signal and
aler t bar.
• Plus, it’s compatible with ESCORT Live, our
exclusive real-time ticket-protection network,
which warns you of upcomi ng alerts received
and reported by other users in the a rea, and
gives you access to local speed limit data for
over-speed alerts.*
*Requi res Optional SmartCord
Live and app subscription.
Controls & Features PASSPORT X70 Features
5432
Continued ➜
Mini USB Jac k
Connects to your computer via USB A / Mi ni B
cable for downloading soft ware updates
Modular J ack
Connects to SmartCord for powering your device
Earphone J ack
Connects to optional 3.5 mm stereo earphone.
Modular Co nnector
Plugs into detector jack
Lighter Ada pter
Connects to l ighter/accessory socket
6
Installation
Windshie ld Mount
PASSPORT X70’s EasyMount windshield bracket
is designed for unobtrusive and hassle-free
mounting.
Mountin g Tips:
• Center of windshield between driver and
passenger.
• Ensure clear view of road ahead and sk y
above.
• Avoid windshield wipers and heavi ly tinted
areas.
PASSPORT X70 Mounting Location
WARNING: ESCORT cannot anticipate the
many ways PASSPORT X70 can be mounted.
It is important that you mount PASSPORT
X70 where it will not impair your view nor
present a hazard in case of an accident.
For optimum detection performance, we
recommend the following:
• Using the Windshield Mount, mount your
PASSPORT X70 level, and high enough on your
front windshield to provide a clear view of the
road from the front and rear.
• Mount PASSPORT X70 away from windshield
wipers, other solid objects, and heavily tinted
areas that might obstruct the radar antenna or
laser lens.
Using PASSPORT X70
1 Plug small end of SmartCord into modular
jack on PASSPORT X70 and large end of
Smar tCord into your car’s lighter/accessory
socket.
2 PASSPORT X70 should power on
automatica lly. If not, press the device’s power
button.
NOTE: You can easily access and customize all
of your Settings and Preferences by pressing
and holding the SEN and BRT buttons. See
Settings & Preferences for details.
Using Smar tCord
• Mute Button: Press to mute an a lert.
• Aler t Light: Blinks orange when receiving an
aler t.
• Power Light: L ights blue when receiving
power.
R A D A R •L A S E R •D E T E C T O R
1 Depress the adjustment button on the top of
PASSPORT X70 (by the word ESCORT) and slide
the EasyMount Bracket into the slot until it is
locked into the position which best fits the angle
of your windshield (there are four settings
available). For extremely horizontal or extremely
sloped windshields, the EasyMount Bracket can
be bent.
To ensure that the suction cups adhere to the
windshield firmly, be sure to keep both your
windshield and the suction cups clean.
2 To adjust the PASSPORT X70 on your
windshield, use the EasyMount adjustment
button located on the top of the PASSPORT X70,
and slide PASSPORT X70 forward or backward to
obtain a level position.
When installed and adjusted properly, the back
top edge of the PASSPORT X70 should rest solidly
against your windshield.
Compatibl e with
You’ve purchased the
all- new PASSPORT X70 which is the one of
the most advanced high-performance radar and
laser detector on the market. The PASSPORT
X70 provides long-range warning on al l radar
bands and laser bands.
PASSPORT X70 features a new multi- color OLED
display. Brilliant graphics il luminate intuitive
icons that identi fy the t ype of threat at a glance.
Go to EscortRadar.com for the full featu red
PASSPORT X70 Owner’s Manua l.
Guía de Referencia Rápida Española traducida y
manual con todas las funciones también son
disponibles a www.EscortRadar.com
User’s Tip: You can leave the EasyMount
bracket in place on your windshield, and easily
remove PASSPORT X70 by pressing the
adjustment button and sliding PASSPORT X70 off
the mount. Again, be sure to position the bracket
where it won’t present a hazard in the event of an
accident.
Additional mounts are available at EscortRadar.
com
