ESI ES2247B Operating instructions

ES2247B
2 Channel Programmer
User and Installaon
Instrucons

What is a Channel Programmer? 1
Introducon to the 2 Channel Programmer 2
Quick Operang Guide 3
Programming the Unit
The Factory-set Programme 5
Seng the Programmer Opon (5/2, 7 Day, 24hr) 6
Seng the Central Heang Programme 6
Seng the Hot Water Programme 6
Seng the Operaon (ON/OFF/AUTO/ALL DAY) 7
Operang the Unit
Temporary Overrides (Advance and +HR Boost) 8
Holiday Mode 9
Basic Sengs
Seng the Time & Date 10
Seng the Backlight 11
Reseng the Unit 11
INDEX
User Instrucons

Installaon Instrucons
Technical Data 12
Installaon Safety Instrucons 13
Maintenance 13
Safety Noce 13
Technical Sengs 14
Fing the Back Plate 14
Exisng Installaons 15
Wiring Diagram 15
Commissioning 16
INDEX

User
Instrucons
Technical Data 12
Installaon Safety Instrucons 13
Maintenance 13
Safety Noce 13
Technical Sengs 14
Fing the Back Plate 14
Exisng Installaons 15
Wiring Diagram 15
Commissioning 16

What is a Channel Programmer?...
An explanaon for householders
On some programmers you must also set whether you want the
Central Heang and Hot Water to run connuously, run under the
chosen ‘On’ and ‘Off’ heang periods, or be permanently off. The
me on the programmer must be correct. Some types have to be
adjusted in Spring and Autumn upon the changes between Winter
and Summer me.
You may be able to temporarily adjust the heang programme, for
example, ‘Override’,‘Advance’ or ‘Boost’. These are explained in the
manufacturer’s instrucons. The Central Heang will not work if the
room thermostat has switched the Central Heang off. And, if you
have a Hot Water cylinder, the water heang will not work if the
cylinder thermostat detects that the Central Hot Water has reached
the correct temperature.
1
Programmers allow you to set ‘On’ and ‘Off’ me
periods. Some models switch the Central Heang and
domesc Hot Water on and off at the same me, while
others allow the domesc Hot Water and Central Heang to come
on and go off at different mes. Set the ‘On’ and ‘Off’ me periods
to suit your own lifestyle.

What is a Channel Programmer?...
An explanaon for householders
Introducon to the 2 Channel Programmer
This programmer can automacally switch your Central Heang or
Hot Water ON and OFF either 2 or 3 mes a day, at whatever mes
you choose. Timekeeping is maintained through power interrup-
ons by a replaceable internal baery (by Qualified Installer/Electri-
cian only) designed to last for the lifeme of the programmer and
the clock is automacally put forward 1 hour at 1:00am on the last
Sunday of March and back 1 hour at 2:00am on the last Sunday of
October. The clock is factory pre-set to UK me and date, but you
can alter it if you want. During installaon, the installer selects 24
hour, 5/2 day, or 7 day programming and either 2 or 3 on/off
periods per day, via the Technical Sengs (see installaon instruc-
ons).
The large, easy to read display makes programming easy and the
unit is designed to eliminate the possibility of accidental changes to
your programme. Buons normally visible, only affect your set
programme temporarily. All buons which can permanently change
your programme are located behind the flip over facia.
- The 24 hour programmer opon runs the same programme every
day.
- The 5/2 Day programmer opon allows different ON/OFF mes at
weekends.
- The 7 Day programmer opon allows different ON/OFF mes for
each day of the week.
- Pumped System (PU) allows independent control of Central
Heang and Hot Water.
- Gravity System (Gr) does not allow Central Heang without Hot
Water but can provide Hot Water without Central Heang.
IMPORTANT: These sengs should only be changed by a qualified
person. Contact your installer. This programmer is not suitable for
the switching of devices greater than 6Amp rated. (e.g. Not suitable
for use as an immersion mer)
2

Introducon to the 2 Channel Programmer
3
①② ③
Home (takes you back to home screen)
Next (moves you to the next opon within a funcon)
Advance to the next programmed ON/OFF (ADV)
①
②
③
④
⑩
⑤
⑥
⑦
⑧
⑨
Quick Operang Guide
Add up to 3 hours of extra Central Heang/Hot Water (+HR)
Set Time and Date
Set Programmer Opon (24hr, 5/2, 7 Day) & Central Heang
Set Programmer Opon (24hr, 5/2, 7 Day) & Hot Water
Reset
Set Operaon Mode (ON/AUTO/ALL DAY/OFF)
Runs the programme
+/- buons for sengs adjustment
Moves between days when programming Central Heang/Hot
Water (DAY)
Copy funcon (COPY)
Holiday Mode
⑤ ⑥ ⑦⑧ 11 12 13
⑨
⑩
④
11
12
13
14
14

4
Day of the week
Time Display
AM/PM
Date Display
Displays which ON/OFF period (1/2/3) is being set when
programming Central Heang/Hot Water
Displays whether seng the ON me or OFF me when
programming Central Heang/Hot Water (ON/OFF)
Operang Mode (ON/OFF/AUTO/ALL DAY)
Advanced temporary override is acve (ADV)
Radiator/Tap symbol show that Central Heang/Hot
Water is currently ON
+ 1hr / 2hr / 3hr temporary override is acve
15
15 16 17 18 19
20
242321 22
16
17
18
19
20
21
22
24
23

Programming the Unit
The Factory Pre-Set Programme
This Channel Programmer has been designed to be simple to use,
requiring minimal user intervenon with a pre-programmed heang
profile.
The pre-set heang mes and temperatures will suit most people
(see table below). To accept the factory pre-set sengs, move the
slider to RUN which will revert the programmer to Run Mode (the
colon (:) in the LCD display will begin to flash).
If the user changes from the factory-set programme and wants to
return to it, pressing the reset buon with a non metallic pointed
tool will return the unit to the factory-set programme. NB. Every
me the reset is pressed, the me and date must be set again (page
10).
5
Pre-Set Temperatures: 5/2 Day
In 7 day seng, the pre-set sengs are the same as 5/2 Day
programme (Mon to Fri and Sat/Sun).
7 Day:
24 Hr:
In 24hr seng, the pre-set sengs are the same as Mon to Fri of
the 5/2 Day programme.
Configuraon
2PU & 2Gr
Configuraon
3PU & 3Gr
Mon - Fri
Times
Sat - Sun
Times
1s t ON1s t ON 06:30am 07:30am
1s t OFF 1s t OFF 08:30am 10:00a m
2nd ON12:00noon 12:00noon
2nd OFF 12:00noon 12:00noon
2nd ON 3rd ON 05:00pm 05:00pm
2nd OFF 3rd OFF 10:30pm 10:30pm

Seng the Programmer Opon (5/2, 7 day, 24hr)
1. Switch the slider to HEATING. Press either the +/- buon to
move between 7 day, 5/2 day or 24hr operaon.
5/2 Day operaon is shown by MO, TU, WE, TH, FR flashing (5
Day) and then SA, SU flashing (2 Day)
7 Day operaon is shown by just one day flashing at a me
24 hr operaon is shown by MO, TU, WE, TH, FR, SA, SU flashing
at the same me.
2. Wait 15 seconds to automacally confirm or press the Home
buon. Move the slider to RUN to return to Run Mode.
Seng the Central Heang Programme
1. Move the slider to HEATING. Choose between 5/2 day, 7 day or
24 hr programmer operaon (see above steps 1-2).
2. Press the Next buon. Press the Day buon unl the
desired day/block of days you want to programme is flashing.
3. The display shows the 1st ON me. Press +/- to set the me (10
minutes increments). Press the Next buon.
4. The display shows the 1st OFF me. Press +/- to set the me (10
minutes increments). Press the Next buon.
5. The display will now show the 2nd ON me. Repeat steps 3-4
unl all remaining ON/OFF periods have been set. On the last OFF
period, press the Day buon unl the next desired day/block of
days you want to programme is flashing.
6. Repeat steps 3-5 unl all days/block of days have been
programmed. Wait 15 seconds to automacally confirm or press
the Home buon. Move the slider to RUN to return to Run Mode.
N.B. The copy buon can be used in the 7 day seng to copy any
chosen day to the next day (e.g Monday to Tuesday or Saturday to
Sunday). Simply change the program for that day, then push copy
repeatedly unl all 7 days (if you so wished) have been changed.
6

7
Seng the Hot Water Programme
1. Move the slider to HW. Choose between 5/2, 7 day or 24 hr
programmer operaon (see page 6)
2. Press the Next buon. Press the Day buon unl the desired
day/block of days you want to programme is flashing.
3. The display shows the 1st ON me. Press +/- to set the me (10
minutes increments). Press the Next buon.
4. The display shows the 1st OFF me. Press +/- to set the me (10
minutes increments). Press the Next buon.
5. The display will now show the 2nd ON me. Repeat steps 3-4 unl
all remaining ON/OFF periods have been set. On the last OFF
period, press the Day buon unl the next desired day/block of days
you want to programme is flashing.
6. Repeat steps 3-5 unl all days/block of days have been
programmed. Wait 15 seconds to automacally confirm ore press
the Home buon. Move the slider to RUN to return to Run Mode.
N.B. The copy buon can be used in the 7 day seng to copy any
chosen day to the next day (e.g Monday to Tuesday or Saturday to
Sunday). Simply change the program for that day, then push copy
repeatedly unl all 7 days (if you so wished) have been changed.
Seng the Operaon
1. Switch the slider to PROG. Press either the +/- buon to move
between ON/OFF/AUTO/ALL DAY. Press the Next buon to
move between the 3 channels.
ON : Central Heang and Hot Water is ON connuously
AUTO: Central Heang and Hot Water will be switched ON
and OFF in accordance with set programmes
ALL DAY: Central Heang and Hot Water will switch ON at
the first ON and switch OFF at last OFF
OFF: Central Heang and Hot Water will be permanently OFF

The Advance Funcon
The ADVANCE funcon allows the user to move to the next ON/OFF
programme for a “one off” event, without having to change the
programme or use the ON or OFF buons.
NB: The ADVANCE funcon is only available when the programme is
in AUTO or ALL DAY operang modes and the slider must be
switched to RUN.
To Advance Central Heang
1. Press the Next buon unl the radiator symbol is displayed.
Press the ADV buon. This will turn the Central Heang ON if it is in
an OFF period and OFF if it is in an ON period. The word ADV will
appear to the le hand side of the radiator symbol.
2. It will stay in this state unl either the buon is pressed again, or
unl a programmed ON/OFF period commences.
To Advance Hot Water
1. Press the Next buon unl the tap symbol is displayed. Press
the ADV buon. This will turn the Hot Water ON if it is in an OFF
period and OFF if it is in an ON period. The word ADV will appear to
the le hand side of the tap symbol.
2. It will stay in this state unl either the ADV buon is pressed
again, or unl a programmed ON/OFF period commences.
Seng the Hot Water Programme
1. Move the slider to HW. Choose between 5/2, 7 day or 24 hr
programmer operaon (see page 6)
2. Press the Next buon. Press the Day buon unl the desired
day/block of days you want to programme is flashing.
3. The display shows the 1st ON me. Press +/- to set the me (10
minutes increments). Press the Next buon.
4. The display shows the 1st OFF me. Press +/- to set the me (10
minutes increments). Press the Next buon.
5. The display will now show the 2nd ON me. Repeat steps 3-4 unl
all remaining ON/OFF periods have been set. On the last OFF
period, press the Day buon unl the next desired day/block of days
you want to programme is flashing.
6. Repeat steps 3-5 unl all days/block of days have been
programmed. Wait 15 seconds to automacally confirm ore press
the Home buon. Move the slider to RUN to return to Run Mode.
N.B. The copy buon can be used in the 7 day seng to copy any
chosen day to the next day (e.g Monday to Tuesday or Saturday to
Sunday). Simply change the program for that day, then push copy
repeatedly unl all 7 days (if you so wished) have been changed.
Seng the Operaon
1. Switch the slider to PROG. Press either the +/- buon to move
between ON/OFF/AUTO/ALL DAY. Press the Next buon to
move between the 3 channels.
ON : Central Heang and Hot Water is ON connuously
AUTO: Central Heang and Hot Water will be switched ON
and OFF in accordance with set programmes
ALL DAY: Central Heang and Hot Water will switch ON at
the first ON and switch OFF at last OFF
OFF: Central Heang and Hot Water will be permanently OFF
Temporary Manual Overrides
8
2. Wait 15 seconds to automacally confirm or press the Home
buon. Move the slider to RUN to return to Run Mode.
The +HR Boost Funcon
The +HR funcon allows the user to have up to 3 hours of extra
Central Heang or Hot Water, without having to change the
programme.

9
1. Press the Next buon unl the radiator symbol is displayed.
Press the +HR buon.
2. One press of the buon will give one extra hour of Central
Heang; two presses of the buon will give two extra hours; three
presses of the buon will give the maximum three extra hours.
Pressing it again will switch off the +HR funcon.
3. The + 1HR , +2HR or +3HR status will appear on the right hand side
of the radiator symbol.
To +HR Boost Central Heang
To +HR Boost Hot Water
1. Press the Next buon unl the tap symbol is displayed. Press
the +HR buon.
2. One press of the buon will give one extra hour of Hot Water; two
presses of the buon will give two extra hours; three presses of the
buon will give the maximum three extra hours. Pressing it again
will switch off the +HR funcon.
3. The + 1HR , +2HR or +3HR status will appear on the right hand side
of the tap symbol.
NB: The +HR funcon is only available when the programme is in
AUTO, ALL DAY or OFF operang modes and the slider must be
switched to RUN. If the programmer is in AUTO or ALL DAY mode
when the +HR buon is pressed and the resulng me of the boost
overlaps a START/ON me, the boost will disengage.
Holiday Mode
Holiday Mode saves energy by leng you reduce the temperature
for 1 to 99 days while you are away from home, resuming normal
operaon on your return.
1. Press to enter Holiday Mode and the screen will display d:1.

10
Basic Sengs
Seng the Time and Date
The me and date are factory set and changes between summer
and winter me are handled automacally by the unit.
1. Switch the slider to Time/Date.
2. The hour symbols will flash, use the +/- buons to adjust.
3. Press the Next buon and the minute symbols will flash, use
the +/- buons to adjust
4. Press the Next buon and the day date will flash, use the +/-
buons to adjust the day.
5. Press the Next buon and the month date will flash, use the
+/- buons to adjust the month.
6. Press the Next buon and the year date will flash, use the +/-
buons to adjust the year.
7. Press the Next buon or wait for 15 seconds to automacally
confirm and return to Run Mode.
2. Press +/- buons to select the number of days you would like the
Holiday Mode to run for (between 1-99 days).
3. Press the Home buon to confirm. The system will now turn OFF
for the number of days chosen. The number of days will alternate
with the me symbol on display and the number of days will count
down.
4. Once the countdown has finished, the programmer will return
to normal operaon. It may be advisable to set the Holiday Mode
1 day less so the house is back up to temperature for your return.
5. To cancel the Holiday Mode, press the buon to revert back
to run mode.

Reseng the Unit
Press the reset buon with a non-metallic pointed tool to reset the
unit. This will restore the built in programme and also reset the me
to 12:00pm and the date to 01/01/2000. To set the me and date,
please refer to page 10.
NB: As a safety feature aer reseng the unit will be in OFF operat-
ing mode. Reselect your required operang mode (page 6). Use of
excessive force may result in the reset buon scking behind the
front cover of the programmer. If this happens the unit will “freeze”
and the buon can only be released by a qualified installer.
11
Power Interupon
In the event of a mains supply failure the screen will go blank but the
back-up baery ensures that the programmer connues to keep the
me and retain your stored programme. When power is restored,
switch the slider to RUN to return to Run mode.
Seng the Backlight
The backlight can either be set permanently ON or OFF. The
programmer backlight is pre-set to be permanently OFF. When the
backlight is permanently OFF, the backlight will turn ON for 15
seconds when + or – buon is pressed, then turn OFF automacally.
To change seng to permanently ON, move the slider to TIME/-
DATE. Press the Next buon repeatedly unl Lit is displayed.
Press +/- to turn backlight ON or OFF. Press the Next buon or
wait for 15 seconds to automacally confirm and return to Run
Mode.
NB: Do not use Advance or +HR Boost Buon to acvate the
backlight as it may engage the Advance or +HR facility and turn on
the boiler. Only use the Home buon.

Installaon
Instrucons

12
Technical Data
Power Suooly 230VAC SOHz
Operating Tem pera-
ture o0cto 35°C
Switch Rating 230V AC 6{21ASPDT
Battery Type Lithium Cell CR2032
Enclosure Protection IP30
Plastics Thermoolastic flame reta rdant
Insulation Class Double
Wiri ng For fixed wiri ng only
Back Plate lndust rv standa rd
Dimensions 140mm (L]x 90mm {Hl x 30mm (D
Clock 12 hour am/p m, 1 minute resolu-
tion
BST/ GMT Time Change Automatic
Clock Accuracy +/ - 1 sec/ dav
Programme Cycle 24hr, 5/ 2 Day or 7 Day selecta ble
Programme ON/ OFFs
per day 2 ON/ OFFor 3 ON/ OFFselecta ble
Programme Selection Auto ON All Dav OFF
Programme Override +1 +2 +3Hr and/ or Advanee
Heating System Pumped, Gravity selecta ble
EN60730-l , EN60730-2.7, EMC
Complies with: Directive 2014/ 30/ EU , LVD Di-
rective 2014/35/ EU

Installaon Safety Instrucons
The unit must be installed by a suitably qualified person in accord-
ance with the latest IEE Wiring Regulaons.
Isolate mains supply before commencing installaon. Please read all
instrucons before proceeding.
Ensure that the fixed wiring connecons to the mains supply is via a
fuse rated at not more than 6 amps and class ‘A’ switch having a
contact separaon of a minimum of 3mm in all poles. The recom-
mended cable sizes are 1.0mm sqr or 1.5mm sqr.
No earth connecon is required as the product is double insulated
but ensure connuity of earth throughout the system.
If the unit is fied to a metal surface, IT IS ESSENTIAL that the metal
be earthed. DO NOT use a surface mounng box.
NEVER fit or remove the unit to a live wall-plate.
Maintenance
Always isolate the mains supply before commencing any work,
servicing or maintenance on the system. And please read all instruc-
ons before proceeding.
Arrange for an annual maintenance and inspecon schedule to be
carried out by a qualified person on every part of the heang and hot
water system.
WARNING!
ALWAYS ISOLATE THE AC MAINS SUPPLY BEFORE INSTALLING.
THIS PRODUCT MUST BE FITTED BY A QUALIFIED PERSON, AND
INSTALLATION MUST COMPLY WITH THE GUIDANCE PROVIDED IN
THE CURRENT EDITIONS OF BS767 (IEE WIRING REGULATIONS) AND
PART “P” OF THE BUILDING REGULATIONS.
13
Safety Noce
Technical Data

Technical Sengs
1. Move the slider to RUN. Hold down the Home buon, the Day
buon and the buon (under the facia) together for 3 seconds
to enter the Technical Seng Mode.
2. Press +/- to choose between 2 or 3 ON/OFFs per day.
3. Press the Next buon and press +/- to choose between Pu
(Pumped, allows independent control of CH and HW) or Gr (Gravity,
does not allow CH without HW but can provide HW without CH).
4. Press the Next buon and press +/- to choose between
Protecon ON/OFF. (If Protecon is ON and the system does not call
for heat for one week, the system will be turned ON for one minute
each week that the system does not call for heat.)
5. Press the Next buon and press +/- to choose between 12
hour clock or 24 hour clock.
Fing the Back Plate
1. Posion the wall-plate (terminals along top edge) with 60mm
(min) clearance to its right, 25mm (min) above, 90mm (min) below.
Ensure that the supporng surface will fully cover the back of the
programmer.
2. Offer the back plate to the wall in the posion where the
programmer is to be mounted, remembering that the back plate
fits to the le side of the programmer. Mark the fixing posions
through the slots in the back plate, drill and plug wall, then secure
back plate in posion.
3. All necessary electrical connecons should now be made. Ensure
that the wiring to the wall-plate terminals leads directly away from
the terminals and is completely enclosed within the wall-plate
aperture. Wire ends must be stripped and screwed to the terminals
so that minimal bare wire is showing.
14
