esotec Napoli LED User manual

Bedienungsanleitung
Solar Pumpensysteme
Napoli LED und Siena LED
Diese Bedienungsanleitung gehört ausschließlich zu diesen Produkten. Sie
enthält wichtige Hinweise zur Inbetriebnahme und Handhabung. Achten Sie
hierauf, auch wenn Sie diese Produkte an Dritte weitergeben.
Archivieren Sie deshalb diese Bedienungsanleitung zum Nachlesen.
1. Einführung
Sehr geehrter Kunde, wir bedanken uns für den Kauf dieses Produktes.
Sie haben ein Produkt erworben, welches nach dem heutigen Stand der Technik
gebaut wurde.
Es erfüllt die Anforderungen der geltenden europäischen und natio-
nalen Richtlinien. Die Konformität wurde nachgewiesen, die entspre-
chenden Erklärungen und Unterlagen sind beim Hersteller hinterlegt.
Um diesen Zustand zu erhalten und einen gefahrlosen Betrieb sicherzustellen, müs-
sen Sie als Anwender diese Bedienungsanleitung beachten!
2. Sicherheitshinweise
Bei Schäden, die durch Nichtbeachten dieser
Bedienungsanleitung verursacht werden, erlischt der
Garantieanspruch!
Für Folgeschäden übernehmen wir keine Haftung!
Bei Sach- oder Personenschäden, die durch unsach-
gemäße Handhabung oder Nichtbeachten der
Sicherheitshinweise verursacht werden, übernehmen wir
keine Haftung.
In solchen Fällen erlischt jeder Garantieanspruch.
Aus Sicherheits- und Zulassungsgründen (CE) ist das eigenmächtige Umbauen und/
oder Verändern des Produktes nicht gestattet. Achten Sie auf eine sachgemäße
Inbetriebnahme. Beachten Sie hierbei diese Bedienungsanleitung.
In gewerblichen Einrichtungen sind die Unfallverhütungsvorschriften des Verbandes
der gewerblichen Berufsgenossenschaft für elektrische Anlagen und Betriebsmittel
zu beachten. Dieses Produkt ist nur für die Verwendung im privaten Bereich kon-
zipiert.
3. Bestimmungsgemäße Verwendung
- Das Pumpensystem ist für den Einsatz im Außenbereich in Gartenteichen kon-
zipiert. Bei Sonnenschein wird der Akkuspeicher geladen. Über einen Schalter
kann die Solarpumpe ein- oder ausgeschaltet werden. Eine LED-Anzeige infor-
miert Sie über den Ladezustand des Akkus.
- Zur korrekten Funktion wird direkte Sonneneinstrahlung benötigt.
- Das Pumpensystem zeichnet sich besonders durch seine Montagefreundlichkeit
aus. Es ist zum Aufbau kein Werkzeug erforderlich. Das System benötigt zum
Anlauf und Funktion direkte Sonneneinstrahlung auf das Solarmodul.
- Zum Fördern von Trinkwasser darf die Pumpe nicht eingesetzt werden.
- Die Leistung kann über einen Regler an der Pumpe verändert werden.
- Um ein mögliches störendes Plätschern zu vermeiden, stecken Sie einfach weni-
ger Steigrohre auf die Pumpe auf.
- Um die Förderung sicher zu unterbrechen, müssen Sie die Kabelverbindung
zwischen Akkubox und Pumpe unterbrechen.
Die Montagehinweise entnehmen Sie bitte der Anleitung der Wasserpumpe und
des Akkuspeichers. Bitte den Akkuspeicher nicht in die pralle Sonne stellen.
4. Montage und Inbetriebnahme
Die Einzelheiten der Montage und Inbetriebnahme entnehmen Sie bitte den
Anleitungen der Akkubox und Teichpumpe.
5. Pflege und Wartung
Um die Leistung der Pumpe zu erhalten, muss je nach Wasserverschmutzung die
Pumpe und Ihre Teile mit warmen Wasser ausgewaschen werden.
Hinweise für die Pflege und Wartung der Pumpe entnehmen Sie bitte der Anleitung
der Pumpe.
Wischen Sie gelegentlich das Solarmodul mit einem weichen und leicht angefeuch-
teten Tuch sauber.
Hinweis: Bevor Sie Arbeiten an der Pumpe durchführen, unterbrechen Sie die
Steckverbindung zwischen Pumpe und Akku, um ein unbeabsichtigtes Anlaufen
während der Arbeiten zu verhindern.
6. Technische Daten
Solar Pumpensystem Napoli LED Siena LED
- Systemspannung: 12 - 24 VDC 12 - 24 VDC
Solarmodul
- Nennleistung: 10 Wp 20 Wp
- Nennspannung: 17,5 V 17 V
- Nennstrom: 580 mA 1,2 A
- Leerlaufspannung: 21,6 V 21 V
- Kurzschlußstrom: 680 mA 1,32 A
- Schutzart: IP 65 IP 65
- Temperaturbereich: -30°C bis +75°C -30°C bis +75°
- Abmessungen: 400 x 255 x 25 mm 520 x 355 x 25 mm
Wasserpumpe:
- Betriebsspannung: 12 bis 24 V DC 12 bis 24 V DC
- Leistungsaufnahme (12/24V): 3 W/ 12 W 5 W/ 22 W
- Max. Förderhöhe (12/24V): 0,8 m/ 2 m 0,9 m/ 2,8 m
- Fördermenge (12/24V): 470 l/h/ 750 l/h 900 l/h/ 1500 l/h
- Schutzart: IP 68 IP 68
- Betriebstemperaturbereich: +4 bis +40°C +4 bis +40°C
- Trockenlauf: ja ja
Akkuspeicher:
- Akku (Blei Gel): 12V/ 7Ah 12V/ 7Ah
- Ausgangsspannung: 12 bis 24 VDC 12 bis 24 VDC
- Laufzeit bei vollem Akku: max. 6 Std max. 6 Std
(bei 12 V) (bei 12 V)
- Max. Modulleistung: 20 Wp (36 Zellen) 20 Wp (36 Zellen)
- Max. Ausgangsstrom: 800 mA 800 mA
Achtung: Gehäuse nicht in die pralle Sonne stellen! Überhitzungsgefahr!
LED Lichtring:
- Einschaltung: über Dämmerungssensor am Lichtring
- Leuchtmittel: 6 LED´s 6 LED´s
- Betriebsspannung: 12 bis 24 VDC 12 bis 24 VDC
- Schutzart: IP 68 IP 68
- Betriebstemperaturbereich: +4 bis +40°C +4 bis +40°C
Hinweis: Pumpe vor Frost schützen!
In kalten Wintermonaten muss die Pumpe aus dem Wasser genommen und an einem
warmen Ort aufbewahrt werden, das Solarmodul kann im Freien überwintern.
7. Sicherheitshinweise:
GEFAHR für Kinder! Halten Sie Kinder von den verschluckbaren Kleinteilen (Steigrohr
und Sprinkler) und dem Verpackungsmaterial fern. Es besteht Erstickungsgefahr!
WARNUNG vor Stolpergefahr! Verlegen Sie das Anschlusskabel so, dass es nicht
zur Stolperfalle wird!
VORSICHT Sachschäden! Wenn Sie das Solarmodul ohne Modulhalterung aufstel-
len, müssen Sie auf ausreichende Standfestigkeit achten. Falls das Modul umkippt
oder ein Fremdkörper dagegen schlägt, kann das Solarmodul beschädigt werden.
Entsorgungshinweis für Elektrogeräte:
Werter Kunde,wenn Sie sich von dem Artikel trennen möchten,
entsorgen Sie ihn zu den aktuellen Bestimmungen.
Auskunft erteilt die kommunale Stelle.
Hersteller, Ersatzteilservice, Beratung:
esotec GmbH
Gewerbegebiet Weberschlag 9
D-92729 Weiherhammer
Tel.-Nr: 09605-92206-0
Fax.-Nr: 09605-92206-10
e-mail:[email protected]
Internet: www.esotec.de
Zubehör:
Verlängerung 5 m für Teichpumpen Napoli und Siena: Art.-Nr: 101738
Verlängerung 5 m für LED Lichtring: Art.-Nr: 101740
Copyright, Änderungen vorbehalten!
!
D
Kundenbetreuung:
Bei Problemen oder Fragen zu diesem Produkt kontaktieren Sie uns einfach!
Internet: www.esotec.de
Per Telefon: 09605-92206-0
Produkt: Hersteller Art.-Nr:
Solar Pumpensystem Napoli LED: 101774
Solar Pumpensystem Siena LED: 101780

Instruction manual
Solar pond pump set
Napoli LED and Siena LED
These instructions relate ONLY to this product and contain important infor-
mation for using the product for the first time. Please keep these instructions
for later reference and should always accompany the product in the event of
transference to a new user.
1. Introduction
Dear Costumer, thank you for purchasing the solar pump kit.
With this solar pump kit you purchased a product manufactured according to the
current state of technology.
This product fulfils all requirements of the valid European and nati-
onal regulations. The conformity was proved. The relevant declara-
tions and documentation are deposited with the manufacturer.
To maintain this state and guarantee a safe operation, you as the user will have to
follow this operating manual!
2. Safety Instructions
- In case of damages caused by not following
this operating manual, the warranty rights
will expire! We exclude liability for any
consequential damages!
- We exclude liability for property or
personal damages caused by inappropriate
handling or not following the safety instructions.
- In these cases any guarantee rights will expire.
Due to safety and admission reasons (CE) it is not allowed to arbitrarily reconstruct
and/or change the solar pump kit.
Therefore, please keep to the operating manual.
The accident prevention rules of the association of the industrial trade cooperative
association for electric plants and working material are to be considered in industrial
environments
3. Appropriate Use
- The pumping system is designed for the outdoor use in garden ponds. The
accumulator storage is charged during sunshine. The solar pump may be swit-
ched “on” and “off” via a switch. An LED-display informs you about the charge
condition of the accumulator.
- Direct solar radiation is required for the correct function.
- The pumping system is characterized by its easy assembly. Tools are not requi-
red for the assembly.
- The pump must not be used for the raising of drinking water.
- The performance may be adjusted via a controller on the pump.
- In order to avoid any disturbing gurgling, simply attach fewer standpipes to the
pump.
- In order to safely interrupt the pumping it is required to interrupt the cable connec-
tion between solar module and pump.
4. Assembly/installation and start of operation
For the details of assembly/installation and start of operation, please see the instruc-
tion manuals of the accumulator box and the pond pump.
5. Service and Maintenance
In order to preserve the performance of the pump, it is required to wash out the pump
and its parts with warm water depending on the pollution of the water.
For directions for the service and maintenance of the pump and accumulator storage,
please see the instruction of the pump and accumulator storage.
Occasionally wipe the solar module clean with a soft and slightly moistened cloth.
Note: Before carrying out operations on the pump, interrupt the plug connection
between pump and battery pack in order to avoid any unintentional starting during
the operations.
6. Technical Data
Solar pumping system Napoli LED Siena LED
- System voltage: 12 -24 VDC 12 -24 VDC
Solar module
- Nominal power: 10 Wp 20 Wp
- Nominal voltage: 17,5 V 17 V
- Nominal current: 580 mA 1,2 A
- Open-circuit voltage: 21,6 V 21 V
- Short-circuit current: 680 mA 1,32 A
- Projection system: IP 65 IP 65
- Temperature range: -30°C to +75°C -30°C to +75°C
- Dimensions: 400 x 255 x 25 mm 520 x 355 x 25 mm
Water pump:
- Operating voltage: 12 to 24 V DC 12 to 24 V DC
- Power consumption (12/24V): 3 W/ 12 W 5 W/ 22 W
- Max. delivery height (12/24V): 0,8 m/ 2 m 0,9 m/ 2,8 m
- Delivery rate (12/24V): 470 l/h/ 750 l/h 900 l/h/ 1500 l/h
- Protection system: IP 68 IP 68
- Temperature range: +4 to +40°C +4 to +40°C
- Dry running: dry protected dry protected
Accumulator storage:
- Accumulator (lead gel): 12V/ 7Ah 12V/ 7Ah
- Output voltage: 12 to 24 VDC 12 to 24 VDC
- Runtime with fully charged
accumulator: max. 6 h max. 6 h
- Max. module capacity: 20 Wp (36 cells) 20 Wp (36 cells)
- Max. output current: 800 mA 800 mA
Attention: Do not put the housing into the blazing sun! Overheating risk!
LED Light ring:
- Activation: via twilight sensor on the light ring
- Illuminants: 6 LEDs 6 LEDs
- Operating voltage: 12 to 24 VDC 12 to 24 VDC
- Protection class: IP 68 IP 68
- Operating temperature range: +4 to +40°C +4 to +40°C
Note: Protect the pump from frost!
In cold winter months, it is required to take the pump out of the water and store it in a
warm place. The solar module may be left outside during the winter.
7. Safety Instructions:
DANGER for children! Keep children away from swallowable small parts (ascending
pipe and sprinklers) and the packaging material. Danger of suffocation!
WARNING: risk of stumbling! Lay the connecting cable so that it will not become a
trip hazard!
CAUTION Material damage! When setting up the solar module without module
bracket, please pay attention to an adequate stability. The solar module may be
damaged in case of tipping or in case of an impact of a foreign object.
Disposal instruction for electric appliances:
Dear customer, if you want to get rid of the article, please dispo-
se it according to the current regulations. The municipal authority
will provide you with information.
Manufacturer:
esotec GmbH
Gewerbegebiet Weberschlag 9
D-92729 Weiherhammer
Tel.-Nr: +49 9605-92206-0
Fax.-Nr: +49 9605-92206-10
e-mail:[email protected]
Internet: www.esotec.de
Additional parts:
5 m extender cable for water pump and solar module: 101738
5 m extender cable for fountain light: 101740
Copyright esotec GmbH
!
GB
Customer support:
If you have problems or questions regarding this product, simply contact us!
Internet: www.esotec.de
By phone: +49 9605-92206-0
Product manufacturer item No.:
solar pump system Napoli LED: 101774
solar pump system Siena LED: 101780

Mode d‘employ
Kit Pompe d’étang solaire
Napoli LED en Siena LED
Ce mode d‘emploi s‘applique exclusivement à la solaire.
Il contient des informations importantes concernant la mise en service et la
manipulation de la product. Ces informations doivent être observées même
lorsque vous donnez ce produit à des tiers. Par conséquent, archivez ce mode
d‘emploi afin de pouvoir le relire ultérieurement.
1. Introduction
Cher client, nous vous remercions d‘avoir opté pour cette produit.
La product que vous venez d‘acheter est un produit qui a été conçu et fabriqué sui-
vant les dernières connaissances techniques.
Ce produit répond aux exigences des directives européennes et nationa-
les en vigueur. Sa conformité a été attestée et les explications et docu-
ments correspondants sont déposés chez le fabricant.
Afin de préserver l‘état de la lampe et de garantir un fonctionnement sans dangers,
vous devez, en tant qu‘utilisateur, observer ce mode d‘emploi !
2. Consignes de sécurité
- En cas de dommages occasionnés suite à la
non-observation de ce mode d‘emploi, le droit
à la garantie est annulé !
- Nous déclinons toute responsabilité en cas
de dommages consécutifs !
- En cas de dommages matériels ou corporels
occasionnés suite à une manipulation non
conforme ou à la non-observation des consignes
de sécurité, nous déclinons toute responsabilité.
- Dans ces cas, tout droit à la garantie est annulé.
Pour des raisons de sécurité et d‘homologation (CE), la transformation et/ou la
modification de la solaire de sa propre initiative n‘est pas autorisée. Veillez à ce que
la lampe solaire soit mise en service de façon conforme. A cet effet, observez ce
mode d‘emploi. Dans les établissements industriels, les prescriptions relatives à la
prévention contre les accidents, établies par l‘association de la corporation profes-
sionnelle pour les installations et les moyens d‘exploitation électriques, doivent être
respectées.
3. Utilisation conforme à l’usage défini
- Ce système de pompe est conçu pour une utilisation extérieure dans les étangs
de jardin. L’accumulateur est rechargé par le rayonnement solaire. Un commuta-
teur permet de mettre la pompe solaire en marche ou à l’arrêt. Un voyant à DEL
indique l’état de charge de l’accu.
- Un rayonnement solaire direct est nécessaire au bon fonctionnement de la
pompe.
- Ce système de pompe est particulièrement caractérisé par une grande facilité de
montage. A cet effet, aucun outil n‘est nécessaire.
- La pompe ne doit pas être utilisée pour l’alimentation de l’eau potable.
- La puissance peut être modifiée au moyen d’un régulateur situé sur la pompe.
- Pour éviter des clapotis susceptibles de déranger, mettez simplement moins de
tubes de remontée sur la pompe.
- Pour couper le débit en toute sécurité, vous devez interrompre la jonction de
câble entre le module solaire et la pompe.
4. Montage et mise en service
Les détails relatifs au montage et à la mise en service se trouvent dans les notices
d‘utilisation du boîtier à accumulateur et de la pompe de bassin.
5. Entretien et maintenance
Afin de préserver le rendement de la pompe, la pompe et ses composants doivent
être lavés à l‘eau tiède, suivant l‘encrassement de l‘eau.
Vous trouverez des informations concernant l’entretien et la maintenance de la
pompe dans le mode d’emploi de la pompe.
Nettoyez, de temps à autre, le module solaire avec un chiffon doux et légèrement
humidifié.
Remarque: Avant d’exécuter des travaux sur la pompe, interrompez la connexion
par fiches entre la pompe et le module solaire afin d’éviter une mise en route non
intentionnelle pendant les travaux.
6. Caractéristiques techniques
Système de pompe solaire Napoli LED Siena LED
- Tension du système: 12 - 24 VDC 12 - 24 VDC
Module solaire
- Puissance nominale : 10 Wp 20 Wp
- Tension nominale : 17,5 V 17 V
- Courant nominal : 580 mA 1,2 A
- Tension de marche à vide : 21,6 V 21 V
- Courant de court-circuit : 680 mA 1,32 A
- Protection : IP 65 IP 65
- Plage de température : -30°C á +75°C -30°C á +75°C
- Dimensions : 400 x 255 x 25 mm 520 x 355 x 25 mm
Pompe à eau :
- Tension de service : 12 bis 24 V DC 12 bis 24 V DC
- Puissance absorbée (12/ 24VDC): 3 W/ 12 W 5 W/ 22 W
- Hauteur de refoulement (12/24VDC): 0,8/ 2 m 0,9/ 2,8 m
- Débit (12/24VDC): 470/ 750 l/h 900/ 1500 l/h
- Protection : IP 68 IP 68
- Plage de température de service: +4 to +40°C +4 to +40°C
- Fonctionnement à sec : Protection contre la marche à sec
Stockage de l‘accumulateur :
- Accumulateur (plomb gel) : 12 V/ 7 Ah 12 V/ 7 Ah
- Tension de sortie : 12 à 24 V DC 12 à 24 V DC
- Durée de fonctionnement avec
accumulateur plein : 6 h maxi 6 h maxi
- Puissance maxi du module : 20 Wp (36 cellules) 20 Wp (36 cellules)
- Courant de sortie maxi : 800 mA 800 mA
Attention : ne posez pas le boîtier en plein soleil ! Risques de surchauffe !
Anneau lumineux DEL :
- Mise en marche : grâce au capteur sur l‘anneau lumineux
signalant la tombée de la nuit
- Éclairage : 6 DEL 6 DEL
- Tension de fonctionnement : 12 à 24 V DC 12 à 24 V DC
- Type de protection : IP 68 IP 68
- Plage de température de
fonctionnement : +4 à +40 °C +4 à +40 °C
Remarque : la pompe doit être protégée du gel !
Pendant les mois d‘hiver, la pompe doit être retirée de l‘eau et conservée dans un
endroit chaud, le module solaire peut résister à l‘hiver en plein air.
7. Consignes de sécurité :
DANGER pour enfants! Tenez les enfants éloignés des petites pièces pouvant être
avalées (tuyau de montée et sprinkler) ainsi que des éléments d’emballage. Il y a un
risque d’étouffement !
MISE EN GARDE contre le risque de trébuchement! Posez le cordon de raccorde-
ment de telle manière à éviter des chutes dues à des trébuchements !
PRUDENCE! Dégâts matériels ! Si vous installez le module solaire sans support,
vous devez vous assurer que la stabilité est suffisante. Si le module bascule ou si un
corps étranger frappe contre ce dernier, le module solaire risque d’être endommagé.
Consigne de mise au rebut d’appareils électriques:
Cher client, si vous souhaitez vous séparer de l’article, procédez à sa mise au rebut
en respectant les dispositions en vigueur.
Les services communaux vous fourniront plus de renseignements.
Elimination:
Cher client,
Veuillez nous aider à réduire les déchets. Si vous voulez un jour
vous débarrasser de cet article, n’oubliez pas qu’un grand nom-
bre de ses composants sont constitués de matières premières de
valeur qui peuvent être recyclées.
Ne le jetez donc pas à la poubelle mais amenez le au centre de
collecte pour les appareils ménagers.
Merci beaucoup pour votre aide
Fabrikant
esotec GmbH
Gewerbegebiet Weberschlag 9
D-92729 Weiherhammer
Tel.-Nr: +49 9605-92206-0
Fax.-Nr: +49 9605-92206-10
e-mail:[email protected] Internet: www.esotec.de
Copyright esotec GmbH
!
F
Service clients :
En cas de problèmes ou de questions relatives à ce produit, il vous suffit
de nous contacter !
Internet: www.esotec.de
Par téléphone : +49 9605-92206-0
Par courriel, pour la commande de pièces de rechange : [email protected]
Par courriel, pour des questions relatives au produit : [email protected]
Produit : n° d‘article du fabricant :
Kit Pompe d’étang solaire Napoli LED: 101774
Kit Pompe d’étang solaire Siena LED: 101780

Gebruiksaanwijzing
Set zonnepompen voor vijvers
Napoli LED en Siena LED
Deze bedieningshandleiding hoort uitsluitend bij de product.
Deze bedieningshandleiding bevat belangrijke aanwijzingen voor de inbedri-
jfstelling en de bediening. Let hierop, ook wanneer u dit product aan derden
overhandigt.
Archiveer bijgevolg deze bedieningshandleiding na het lezen.
1. Inleiding
Zeer geachte klant, wij danken u voor de aankoop van de product.
Met deze product heeft u een product gekocht dat volgens de huidige stand van
de techniek gebouwd werd. Dit product voldoet aan de vereisten van de geldige
Europese en nationale richtlijnen. De conformiteit werd bewezen, de
dienovereenkomstige verklaringen en documenten zijn bij de fabrikant
gedeponeerd.
Om deze status te behouden en om een gevaarloos bedrijf te verzekeren moet u, als
gebruiker, deze bedrijfshandleiding in acht nemen!
2. Veiligheidsaanwijzingen
- Bij schaden, die veroorzaakt worden door
het niet naleven van deze bedieningshandleiding,
vervalt de aanspraak op garantie!
- Wij aanvaarden geen aansprakelijkheid
voor volgschaden!
- Bij materiële of persoonlijke schaden, die
veroorzaakt worden door een onvakkundige
bediening of het niet naleven van de veiligheidsaanwijzingen,
aanvaarden wij geen aansprakelijkheid.
- In dergelijke gevallen vervalt elke aanspraak op garantie.
Omwille van veiligheids- en toelatingsredenen (CE) is het niet toegestaan om de zon-
nelamp eigenhandig om te bouwen en/of te veranderen. Verzeker een vakkundige
inbedrijfstelling van de product.
In industriële inrichtingen moeten de voorschriften voor de ongevallenpreventie van
de industriële beroepsvereniging voor elektrische installaties en bedrijfsmiddelen
nageleefd worden.
3. Reglementair voorgeschreven gebruik
- Het pompsysteem is voor het gebruik buiten in tuinvijvers ontworpen. Bij zonne-
schijn wordt de accumulator geladen. Door middel van een schakelaar kan de
zonnepomp in- of uitgeschakeld worden. Een LED-display informeert u over de
laadtoestand van de accu.
- Voor een correcte werking wordt direct zonlicht benodigd.
- Het pompsysteem weet zich in het bijzonder door zijn montagevriendelijkheid te
onderscheiden. Voor de opbouw is er geen gereedschap nodig.
- De pomp mag niet gebruikt worden om drinkwater te transporteren.
- Het vermogen kan door middel van een regelaar aan de pomp gewijzigd worden.
- Om een mogelijk storend kabbelen te vermijden, speld u gewoon minder stijgbui-
zen op de pomp.
- Om het transport veilig te onderbreken, moet u de kabelverbinding tussen zonne-
module en pomp onderbreken.
4. Montage en ingebruikname
Voor de details van de montage en ingebruikname verwijzen wij naar de handleidingen van de
accubox en de vijverpomp.
5. Verzorging en onderhoud
Om het vermogen van de pomp in stand te houden, moeten de pomp en de onder-
delen van de pomp al naargelang de watervervuiling met warm water uitgewassen
worden.
Voor de verzorging en het onderhoud van de pomp verwijzen wij naar de handleiding
van de pomp.
Veeg de zonnemodule af en toe met een zacht en lichtjes bevochtigd doekje schoon.
Opmerking: voordat u werkzaamheden aan de pomp doorvoert, onderbreekt u de
steekverbinding tussen pomp en zonnemodule om een onopzettelijke inschakeling
tijdens de werkzaamheden te voorkomen.
6. Technische gegevens
Zonnepompsysteem Napoli LED Siena LED
- Systeemspanning: 12 - 24 VDC 12 - 24 VDC
Zonnemodule
- Nominaal vermogen: 10 Wp 20 Wp
- Nominale spanning: 17,5 V 17 V
- Nominale stroom: 580 mA 1,2 A
- Nullastspanning: 21,6 V 21 V
- Kortsluitstroom: 680 mA 1,32 A
- Beschermingsklasse: IP 65 IP 65
- Temperatuurbereik: -30°C to +75°C -30°C to +75°C
- Afmetingen: 400 x 255 x 25 mm 520 x 355 x 25 mm
Waterpomp:
- Bedrijfsspanning: 12 bis 24 V DC 12 bis 24 V DC
- Vermogenopname (12-24 VDC): 3 W/ 12 W 5 W/ 22 W
- Max. opvoerhoogte (12-24 VDC): 0,8 m/ 2 m 0,9 m/ 2,8 m
- Slagvolume (12-24 VDC): 470 l/h / 750 l/h 900 l/h / 1500 l/h
- Beschermingsklasse: IP 68 IP 68
- Bedrijfstemperatuurbereik: +4 to +40°C +4 to +40°C
- Drooglopen: Beschermen tegen het drooglopen
Accumulator:
- Accu (loodgel): 12V/ 7Ah 12V/ 7Ah
- Uitgangsspanning: 12 tot 24 VDC 12 tot 24 VDC
- Inschakelduur bij volle accu: max. 6 uren max. 6 uren
- Max. modulevermogen: 20 Wp (36 cellen) 20 Wp (36 cellen)
- Max. uitgangsstroom: 800 mA 800 mA
Opgelet: behuizing niet in de volle zon plaatsen! Gevaar voor oververhitting!
LED verlichtingsring:
- Inschakeling: via schemersensor aan de verlichtingsring
- Verlichtingsmiddel: 6 LED´s 6 LED´s
- Bedrijfsspanning: 12 tot 24 VDC 12 tot 24 VDC
- Beschermingsklasse: IP 68 IP 68
- Bedrijfstemperatuurbereik: +4 tot +40°C +4 tot +40°C
Opmerking: pomp tegen vorst beschermen!
Tijdens koude wintermaanden moet de pomp uit het water genomen en op een
warme plaats bewaard worden, de zonnemodule kan in de open lucht overwinteren.
7. Veiligheidsinstructies:
GEVAAR voor kinderen! Houd kinderen op een veilige afstand van inslikbare,
kleine onderdelen (stijgbuis en sprinklers) en het verpakkingsmateriaal. Er bestaat
verstikkingsgevaar!
WAARSCHUWING voor struikelgevaar! Leg het aansluitsnoer zodanig, dat het
geen struikelval wordt!
OPGEPAST: materiële schade! Als u de zonnemodule zonder modulehouder instal-
leert, moet u op voldoende stabiliteit letten. Indien de module omkantelt of er een
vreemd voorwerp tegen slaat, kan de zonnemodule beschadigd worden.
Aanwijzing met het oog op de afvalverwijdering
van elektrische apparaten:
Geachte klant, voer het artikel in overeenstemming met de
actuele bepalingen af als u er afscheid van wilt nemen.
Informatie verstrekt u de gemeentelijke overheid.
Fabricant
esotec GmbH
Gewerbegebiet Weberschlag 9
D-92729 Weiherhammer
Tel.-Nr: +49 9605-92206-0
Fax.-Nr: +49 9605-92206-10
Copyright esotec GmbH
!
NL
Klantenbeheer:
Bij problemen of vragen over dit product contacteert u ons gewoon!
Internet: www.esotec.de
Telefonisch: +49 9605-92206-0
Product: artikelnummer van de fabrikant:
Set zonnepompen voor vijvers Napoli LED: 101773
Set zonnepompen voor vijvers Siena LED: 101780
This manual suits for next models
1
Table of contents
Languages:
Other esotec Pond Pump manuals
Popular Pond Pump manuals by other brands

Biotop Garden
Biotop Garden D0455 User instructions

Hozelock Cyprio
Hozelock Cyprio EasyClear 6000 Installation and operating instructions

PondXpert
PondXpert pondpush PXFP03000 manual

Colibri
Colibri Verbier instruction manual

EINHELL
EINHELL BG-PP 1950 N operating instructions

AQUA FORTE
AQUA FORTE Dosatech manual
