Esse HI-PRO 1 Series User manual

USER’S MANUAL
(You can find “Installation and Programming” and “Remote Programming”
manuals inside the CD-ROM supplied with i-Pro)
7IS-80298

Page 2
Thank you for choosing an Esse-ti product
This product has been especially designed for
easy operation. It has been manufactured with
perfect workmanship using suitable materials for
long-lasting performance.
All Esse-ti products are subjected to extensive
reliability and operational testing in our
laboratories in order to provide total guarantee
for the user.
The User shall be responsible for defects arising from the use of the product. Esse-ti
shall only be responsible for defects according to and within the limitations set by the
Presidential Decree dated 24/05/1988 no. 224 (fulfilling the EEC directive no. 85/374 on
the harmonisation of statutory and administrative regulations of the Member States on
the liability for damages arising from defective products under art. 15 of Law no. 183 of
16 April 1987).
Esse-ti reserves the right to modify the characteristics of the products at any time
without prior notice.

Pagina 3
TABLE OF CONTENTS
HI-PRO SERIE DESCRIPTION............................................................................................8
SERVICES...........................................................................................................................10
Clock................................................................................................................................10
Date ............................................................................................................................................. 10
Time ............................................................................................................................................10
Profiles.............................................................................................................................11
Recalling a profile permanently................................................................................................... 11
Displaying caller identification (CLIP) ............................................................................13
Internal calls.....................................................................................................................14
Calling extension groups.............................................................................................................. 14
External calls....................................................................................................................15
Outgoing external calls................................................................................................................15
Incoming external calls................................................................................................................ 16
Call pick up......................................................................................................................16
Call pick up – external calls......................................................................................................... 17
Call pick up upon waiting tone....................................................................................................17
Selective call pick up...................................................................................................................17
Putting a call on hold – internal calls................................................................................18
Putting a call on hold – external calls...............................................................................19
Putting an external call on hold.................................................................................................... 19
Putting an external call on hold and making an internal call........................................................ 19
Putting an external call on hold and making a call over the other external line............................20
Putting a second external line on hold.......................................................................................... 20
Alternated call back..........................................................................................................21
Call transfer......................................................................................................................21
Call transfer with permission.......................................................................................................21
Automatic call transfer................................................................................................................. 22
Transferring a second external call .............................................................................................. 22
Call parking......................................................................................................................23
Parking an external call................................................................................................................23
Retrieving the parked external line .............................................................................................. 24
Conference .......................................................................................................................24
External-external conversation.........................................................................................24
Answering an external call with Pick up..........................................................................25
ETSI services over ISDN line ..........................................................................................27
AUXILIARY SERVICES....................................................................................................28
Paging...............................................................................................................................29
Announcement over external amplifier ............................................................................29
Alarm clock......................................................................................................................30
Individual alarm........................................................................................................................... 30
Daily alarm.................................................................................................................................. 30
Deleting alarm ............................................................................................................................. 31
Do not disturb...................................................................................................................31
Call forwarding ................................................................................................................32
Call forwarding all calls...............................................................................................................32
Call forwarding no answer (timed call forwarding)..................................................................... 33
Call forwarding on busy user.......................................................................................................34
Cancelling all call forwarding services........................................................................................ 35

Page 4
External call forwarding...................................................................................................35
ETSI External Call Forwarding........................................................................................37
Forward all BRI numbers............................................................................................................. 37
Forward a single number ............................................................................................................. 39
Doorphone call forwarding...............................................................................................42
Booking on busy user.......................................................................................................43
Booking a busy extension............................................................................................................ 43
Booking the external line when busy...........................................................................................43
Calling the last caller........................................................................................................44
DISA service....................................................................................................................45
IVR (automatic operator) .................................................................................................46
Accessing control menu...............................................................................................................47
Voicemail service.............................................................................................................48
Voicemail activation.................................................................................................................... 49
Voicemail deactivation ................................................................................................................ 50
Clearing the voicemail from extension 401.................................................................................. 50
Changing the password................................................................................................................ 50
Customising voicemail message..................................................................................................51
Examples of voicemail operation.................................................................................................52
Signalling icons on ST 600 Personal Phones ...............................................................................52
Listening to messages on the voicemail....................................................................................... 53
Deleting messages from the voicemail.........................................................................................54
Doorphone calls................................................................................................................54
Outgoing doorphone call.............................................................................................................. 54
Incoming doorphone call ............................................................................................................. 54
Door opening commands..................................................................................................55
Manual door opening................................................................................................................... 55
Automatic door opening .............................................................................................................. 56
Actuator relays .................................................................................................................56
Local activation ........................................................................................................................... 57
Remote activation........................................................................................................................ 57
Action sequences..............................................................................................................58
Digital inputs ............................................................................................................................... 58
Timer........................................................................................................................................... 59
Extension alarm events................................................................................................................ 59
Alarm Dialer function ......................................................................................................59
Phonebook........................................................................................................................62
Storing a telephone number ........................................................................................................62
Deleting a telephone number ....................................................................................................... 62
Calling a telephone number ......................................................................................................... 63
Printing the call list ..........................................................................................................63
Format of the data displayed by the PC ....................................................................................... 63
Sending data to the PC................................................................................................................. 64
Cancellare il buffer di memoria ................................................................................................... 64
SUMMARY TABLES..........................................................................................................65
Tones................................................................................................................................65
Call signals (RINGS)........................................................................................................66
Numbering plan................................................................................................................67
First digit .....................................................................................................................................67
Suffixes........................................................................................................................................ 68
Timeout............................................................................................................................68
TECHNICAL SPECIFICATIONS.......................................................................................69

Pagina 5
System capacity...........................................................................................................................69
Power supply ............................................................................................................................... 69
Signalling system.........................................................................................................................69
Other features ..............................................................................................................................69
Lines............................................................................................................................................70
Dimensions.................................................................................................................................. 70
Safety system............................................................................................................................... 70

Page 6 EDITING CRITERIA
EDITING CRITERIA
This paragraph describes the editing criteria followed in this manual, together
with their meaning for easier user’s reference. The following table shows the
printing styles on the left and their meaning on the right column
Example Meaning
CHAPTER
TITLE
Style used for the title of chapters. A new
chapter begins on a new page.
P RIMARY T ITLE
Style used for the title of large sections in a
chapter, such as the main titles of the chapter.
Secondary Title
Style used for the title of a specific paragraph
in the primary title.
Tertiary Title Style used for additional sections in a specific
paragraph
Example Style used for examples.
Note Style used for explicatory notes: pay attention!
Warning Style used to indicate possible risks for
individuals and properties: caution!
Normal text Style used for normal text.
Operation to be carried out
Style used to indicate the sequence of
operations that must be carried out for
programming or service implementation.

EDITING CRITERIA Page 7
Apart from these styles, this manual also includes illustrative images and
symbols used to represent the operations to be carried out in a schematic way:
Symbol Meaning
, , , , , ,
, , , , , ,
.
Press the key that corresponds to the symbol
on the telephone keypad.
Indicates a telephone key: this symbol is
used in programming to indicate the entries
made by the operator.
Lift the handset from the Administrator
extension (or activate the handsfree mode).
Programming must be enabled.
Lift the handset from the Administrator
extension (or activate the handsfree mode).
Lift the handset (or activate the
handsfree mode) to engage the line.
Hang up (or deactivate the handsfree
mode) to clear the line.
A | B The vertical bar indicates that the possible
entry values are ‘A’ or ‘B’.
A [B] The square brackets indicate optional code
parts that can be omitted.

Page 8 I-PRO series description
HI-PRO SERIES DESCRIPTION
Hi-Pro is an high-performing professional system specifically designed for
companies and SOHO solutions.
The 280 version is equipped with 2 PSTN lines and 8 extensions (expandible
up to 4 PSTN lines and 12 extensions with the add-on board or up to 2T0 and 2
PSTN lines and 12 extensions).
The 412 Rack version is equipped with 4 PSTN lines and 12 extensions.
The 412 Rack ISDN version is equipped with 2 T0 lines and 12 extensions 2.
The Hi-Pro systems has the following features:
•7 default configurations for a rapid start-up
•3 user profiles (DAY, NIGHT, CUSTOMIZED) with manual or automatic
recall
•Internal and External Caller ID (FSK standard) on analogue and system
telephone sets
•External caller name, if present in PABX phonebook, and standard FSK
internal caller name visualization.
•Built-in Courtesy Responder
(1 channel in 280 version and 2 in the 412 one)
•Built-in IVR (Interactive Voice Response) with 10 customizable and
concatenable menus)
•Built-in Voicemail
•Built-in DISA Service
•30 customizable messages
(available for Courtesy Responder, IVR, DISA e Voicemail services)
•30 minutes available memory in 280 version and 60 for the 412 one
(among Voicemail and the 30 customizable messages)
•Waiting message (Music on hold) with A/50 or other audio source
•Automatic switch-FAX with the possibility of inserting a different FAX
extension for each external line
•Automatic switch-FAX based on ISDN number, with the possibility of
inserting a different FAX extension for each BRI
•ACD (Automatic Call Distributor)
•L.C.R. (Least Cost Routing)
•External Call Forwarding
•Doorphone call forwarding

I-PRO series description Page 9
•Telerescue (with ST350 telephone sets)
•Alarm dialer
•Remote Ambient listening via system phones
•Remote relay activation
•Vocal notification of the operations carried out
•100-entry phonebook
•Buffer ( 1500 incoming/outgoing calls)
•System clock
•Doorphone board to allow connection to traditional doorphones 4+1
(optional for version 280, built-in for version 412 and 412 ISDN)
. 2 ringer inputs
. 1 speech input
•2 programmable relays
•1 digital input
•External amplifier exit
•External music source input
•Up to 8 ST600 Personal Phone telephone systems
•Optional batteries for emergency operation (only Rack models)
•24Vdc power supply Input for emergency operation (only Rack models)
•Local programming via DTMF telephone or via USB port
•Remote programming via V.21 MODEM
•Firmware update via USB port

Page 10 SERVICES
SERVICES
The following paragraphs describe how to use Hi-Pro PABX’s services.
Note: the following paragraphs describe how to use the telephone
services with multifrequency (MF) telephones; if you have to
use a decadic (DC) telephone, dial 2instead of pressing the
Rbutton.
C LOCK
Date
Allows you to set the date.
(day) (month) (year)
(confirm)
Pick up the handset of the system administrator extension (extension
401).
Dial the code 2100.
Dial two digits for the day, two digits for the month and four digits for
the year.
Wait for the confirmation tone and hang up.
E.g.: Supposing it’s the 10th of May, 2011, in order to program the
correct date, dial the following digits: 2100 10052011.
Time
Allows you to set the time.
(hour) (minute) (confirm)
Pick up the handset of the system administrator extension (extension
401).
Dial the code 2101.
Dial two digits for the hour and two digits for the minutes.

SERVICES Page 11
Wait for the confirmation tone and hang up.
E.g.: Supposing it is 18:05, in order to program the correct time, dial the
following digits: 2101 1805.
P ROFILES
The profile identifies the Hi-Pro behaviour according to the user’s needs:
•DAY: the user is at home/in the office;
•NIGHT: the user is not at home/in the office;
•CUSTOMIZED: the user is in a different situation.
The 3 Hi-Pro profiles (PRESENT/ABSENT/CUSTOMIZED) can be recalled in
the following ways:
- by dialling a code from the telephone of the system administrator;
- by closing or opening an alarm input;
- by pressing the special button on Esse-Ti telephones;
- automatically according to the daily and weekly time bands.
In case the previous events overlap, the priority order will be as follows:
- alarm input
- telephone code
- button
- weekly time band
- daily time band.
Note: Hi-Pro is factory set so that, whatever the default
configuration, the closure of the alarm contact ALL will
recall the NIGHT profile. The configuration of the digital
inputs ALL is made via remote programmer software..
Recalling a profile permanently
Allows recalling the DAY, NIGHT, CUSTOMIZED profiles permanently, or it
allows enabling automatic profile recall according to the set time bands.
Note: the profile used by Hi-Pro can be displayed only through the
ST 600 Personal Phone system telephone.
Note: Profile recall is not password-protected..
DEFAULT:

Page 12 SERVICES
- Default and Home configurations: AUTOMATIC mode (since the daily time
bands are not set, the DAY profile will always be used);
- all others configurations: AUTOMATIC mode (DAY profile from 8 to 12 am
and from 2 to 6 pm, NIGHT profile during the rest of the day and on Saturday
and Sunday).
DAY profile
Allows passing, alternatively, from permanent DAY profile, to automatic
profile recall.
(confirm)
Pick up the handset of the system administrator extension (extension
401).
Dial the code 230.
Wait for the enabled/disabled service message and for the confirmation
tone and hang up.
NIGHT profile
Allows passing, alternatively, from permanent NIGHT profile, to automatic
profile recall.
(confirm)
Pick up the handset of the system administrator extension (extension
401).
Dial the code 231.
Wait for the enabled/disabled service message and for the confirmation
tone and hang up.
CUSTOMIZED profile
Allows passing, alternatively, from permanent CUSTOMIZED profile, to
automatic profile recall.
(confirm)
Pick up the handset of the system administrator extension (extension
401).
Dial the code 232.
Wait for the enabled/disabled service message and for the confirmation
tone and hang up.

SERVICES Page 13
AUTOMATIC Mode
Allows enabling the automatic profile recall mode according to the set time
bands.
(confirm)
Pick up the handset of the system administrator extension (extension
401).
Dial the code 233.
Wait for the enabled/disabled service message and for the confirmation
tone and hang up.
D ISPLAYING CALLER IDENTIFICATION (CLIP)
The caller identification (CLIP) is visible to all extensions provided with
displays. On predisposed telephones, it is possible to display the name
associated in the PABX phonebook.
The CLIP is displayed even when DISA, IVR or automatic FAX recognition
services are enabled and when an external call is diverted from one extension to
another.
Nota: Hi-Pro displays also the internal caller identification on
telephone systems and on telephones predisposed for
alphanumeric displaying ( FSK standard).

Page 14 SERVICES
I NTERNAL CALLS
It refers to the possibility for an extension to have a conversation with another
extension.
[ ] (extension number) (tone)
Pick up the handset.
You will receive a dialling tone.
Dial the two (or three) digits indicating the extension number (the first
digit must be a 4).
If the called user is free, you will hear a call tone.
If the called user is engaged, you will hear an engagement tone.
The called extension will pick up the handset.
The conversation starts.
When the conversation ends, hang up.
As soon as one of the two extensions hangs up, the other will receive a
dissuasion tone.
Note: in case the HOME default configuration is set, or in case an
extension is programmed with automatic engagement of the
external line, in order to make internal calls it is necessary to
press the R (flash) button before the number.
Calling extension groups
It refers to the possibility for an extension to call an extension group at the
same time. This way, it is possible to look for a person in various rooms,
without having to call all the extensions one by one. Leonardo is provided with
two internal call groups.
DEFAULT:
- group 1 (number 413): extensions 401~412;
- group 2 (number 414): extensions 401~406.
[ ] (extension group number) (tone)
Pick up the handset.
You will receive a dialling tone.

SERVICES Page 15
Dial the two (or three) digits indicating the extension number (the first
digit must be a 4).
All the extensions belonging to the called group will ring at the same time.
One of the called extensions will pick up the handset.
The conversation starts. The other extensions will stop ringing.
E XTERNAL CALLS
Outgoing external calls
It refers to the possibility for the extensions to make calls over the external
lines. Moreover, Hi-Pro is provided with an automatic routing system (L.C.R.),
which, once appropriately programmed, is able to automatically select the least
expensive line for the call to be made..
Initial situation (automatic external line engagement not enabled)
The extensions are programmed to access the public network..
[ ](line) ... (subscriber)
Pick up the handset.
You will receive the dialling tone.
Dial the number:
0 to access the first line available (according to the chosen
mode in the Lines Engagement Table) or to use the L.C.R. system
(when enabled)
81 to manually access the analogue line 01
82 to manually access the analogue line 02
83 to manually access the analogue line 03
84 to manually access the analogue line 04
Dial the number of the desired subscriber.
If it is free, you will receive a call tone.
If it is engaged, you will receive an engagement tone.
The conversation will start when the called person will pick up the handset.
Initial situation (automatic external line engagement enabled)
The extensions are programmed to access the public network.

Page 16 SERVICES
... (subscriber)
Pick up the handset.
Hi-Pro automatically engages the external line.
You will receive the dialling tone.
Dial the number of the desired subscriber.
If it is free, you will receive a call tone.
If it is engaged, you will receive an engagement tone.
The conversation will start when the called person will pick up the handset.
Note: if you do not start dialling within 10 seconds from engaging
the external line, the extension is encapsulated (the user will
receive a dissuasion tone and will have to hang up in order to
make the call).
Note: if the extension is not enabled to use an external line, and
tries to access it manually, a dissuasion tone will be received.
Note: dialling is not delayed when L.C.R. service is enabled.
Note: when L.C.R. service is enabled, and you dial 0 to engage the
external line, you will receive a modulated dialling tone
(L.C.R. tone).
Note: selecting the external line manually, will exclude the L.C.R.
service.
Incoming external calls
Allows the extensions to answer calls from external lines. This service can be
customized for each extension during the programming phase.
Initial situation 1
The extension is programmed to receive external calls.
(ring)
The extension rings.
Pick up the handset.
Conversation starts.
Initial situation 2
Extension engaged in a conversation.
(call waiting tone) (ring)

SERVICES Page 17
You will receive a call waiting tone. Extensions will hang up and the
conversation will end.
The extension rings.
Pick up the handset.
Conversation starts.
C ALL PICK UP
Call pick up – external calls
Allows extensions with call pick up enabled, to answer incoming calls over the
external line.
Initial situation
Incoming call from external line in progress and extension free.
Pick up the handset.
Dial 5.
Conversation starts.
Call pick up upon waiting tone
Allows busy extensions to answer incoming external calls or diverted calls.
Initial situation
Extension engaged in an internal or external conversation, call waiting tone.
Put the conversation on hold by pressing R.
Dial 5.
Conversation starts.
Note: if the conversation put on hold is with an extension, the call is
ended.
Note: the call waiting tone can be excluded by activating the “do
not disturb” service; see paragraph “Do not disturb”.

Page 18 SERVICES
Selective call pick up
It allows an extension to pick up external or internal calls directed to another
extension.
Initial situation
Internal or external call to another extension in progress.
[ ](extension number)
Pick up the handset and dial 353.
Dial the two (or three) digits indicating the number of the extension that
is ringing upon a call.
Conversation starts.
The called extension stops ringing.
Note: Hi-Pro can be programmed so that calls from specific
extensions cannot be answered this way; see the option
“Selective call pick up” in the paragraph “Service
activation” of the Installation and programming manual.
P UTTING A CALL ON HOLD – INTERNAL CALLS
It allows putting an internal call on hold, make a second call and then retrieve
the first one.
Initial situation
Conversation with an internal user.
[ ](extension number)
Press R.
You will hear the dialling tone.
The other extension will hear the waiting tone.
Dial the two (or three) digits indicating the number of the desired
extension.
Establish a second internal call.
Press R twice to retrieve the conversation with the first user.
The second user will hear the dissuasion tone.

SERVICES Page 19
Note: if the person who has put the first conversation on hold hangs
up, the conversation between the first and second called
person continues.
P UTTING A CALL ON HOLD – EXTERNAL CALLS
Putting an external call on hold
Allows you to temporarily suspend an ongoing conversation with an external
user.
Initial situation
Conversation in progress over the external line.
(tone)
Press R.
You will hear the dialling tone.
The external line is put on hold, and the external user will hear the waiting tone.
(within 10 seconds from putting on hold)
(after 10 seconds from putting on hold)
To retrieve the conversation: if more than 10 seconds have elapsed from
pressing R, press R twice, if not, press R once.
Note: if you hang up without resuming the external line on hold,
your telephone will ring to remind you of the external call on
hold (return call).
Putting an external call on hold and making an
internal call
Allows temporarily suspending an outgoing conversation with an external user,
making an internal call, and then retrieving the external call put on hold.
Initial situation
Conversation in progress over the external line.
[ ]( extension number)(conversation) |
Press R to put the external line on hold.

Page 20 SERVICES
Dial the two (or three) digits indicating the number of the desired
extension.
The called extension rings.
Establish the internal conversation.
To retrieve the external call put on hold, press R twice, or ask the
internal user to hang up.
In the latter case, the external line is retrieved automatically.
Note: if during the internal conversation the handset is hung up, the
conversation will continue between the other two users
Putting an external call on hold and making a call
over the other external line
Allows temporarily suspending an ongoing conversation with an external user,
to make a call over the other line.
Initial situation
Conversation in progress over an external line.
... ( subscriber) (conversation) (ring)
Press R to put the external line on hold.
Dial 0 to engage the other external line, and then dial the number of the
subscriber.
Conversation with a second external user is established.
ang up when conversation ends.
The telephone rings.
To retrieve the conversation previously put on hold, pick up the handset.
Putting a second external line on hold
It allows putting a second external line on hold, with a first one already on hold.
Initial situation
First external line on hold; conversation in progress over the second line.
[ ] (conversation) (ring)
Press R to put the second external line on hold.
