Essentials For Living MALAY User manual

PARTS LIST
CODE PARTS DESCRIPTION QTY
1
HEADBOARD 1
2
SIDE RAIL 2
3
FOOT BOARD 1
4
MIDDLE SUPPORT 1
5
MIDDLE LEG 1
6
CROSS BAR 8
7
SIDE BAR 2
ASSEMBLY INSTRUCTIONS
MALAY BED
PAGE 1 OF 5
HARDWARE LIST
CODE HARDWARE DESCRIPTION QTY
A 8
B 9
C 17
D 8
E 8
F 1
G 1
H 16
BRACKETS
JCBC BOLT
M6 X 60MM SS
FLAT WASHER
M6 x Ø18MM SS
SPRING WASHER
M6 x Ø11MM SS
NUT M6
HEX KEY L
WRENCH 10
FAB SCREW
Ø8 X 1.5'' SS
PLEASE DO NOT DISCARD ANY OF THE PACKAGING UNTIL YOU HAVE
CHECKED ALL THE PARTS AND HARDWARE HAVE BEEN SUPPLIED.
BEFORE YOU BEGIN ASSEMBLY, DECIDE ON THE HEIGHT YOU WOULD LIKE TO
SET THE CROSS BARS AS THEY CAN BE ADJUSTED TO DESIRED DISTANCE
FROM FLOOR (10” 13”).
FOLLOW INSTRUCTIONS CLOSELY AS DEVIATION FROM THEM MAY VOID
YOUR WARRANTY AND PRESENT A POSSIBLE SAFETY RISK.
IT IS RECOMMENDED THAT ASSEMBLY IS DONE ON A SOFT SURFACE LIKE
CARPET TO AVOID ANY DAMAGE.
THOUGH NOT NECESSARY, IT IS ADVISED THAT ASSEMBLY BE COMPLETED BY
A TEAM OF AT LEAST TWO PEOPLE.

2
A
FIT IN TO THE CROSS BARS)
SELECT THE HEIGHT
OF THE CROSS BARS
(ENSURE PINS OF BRACKETS
STEP 1 STEP 2
STEP 3 STEP 4
PAGE 2 OF 5
ENSURE ALL BRACKETS ARE INSTALLED
AT THE SAME HEIGHT POSITION BEFORE CONTINUING
3
2
2
1
1
2
2
1
2
PIN

Available Height Options ( Positions)
The Lowest Position 2nd Position
3rd Position The Highest Position
PAGE 3 OF 5
13''
10''
2nd Position
Go Up One Hole Again Or
In The Top 2 Holes
In The Bottom 2 Holes
11''
12''
3rd Position

A
3
MATCH POSITION OF CROSS BARS
CHOSEN IN STEP
1
A
1
MATCH POSITION OF CROSS BARS
CHOSEN IN STEP
7
A
2
STEP 6
STEP 7 STEP 8
PAGE OF 5
STEP 5
F
B
C
D
E
G
C

ADJUST
FOOT LEVELER
ROTATE TO SET HEIGHT
OF MIDDLE LEG
HEIGHT OF CROSS BARS
CAN BE ADJUSTED AFTER
ASSEMBLY
FOLLOW STEP 9-
BACKWARDS TO RESET
BRACKET POSITION THEN REPEAT
STEP -9
B
F
5
C
B
C
D
E
C
G
F
H
6
6
H
6
7
STEP 10
STEP 11
PAGE 5 OF 5
FINISH
STEP 9
