Established & Sons GRID U SHAPE User manual

GRID U SHAPE
Ronan & Erwan Bouroullec
ESTABLISHED & SONS
United Kingdom
Phone [phone]
establishedandsons.com
ESTANDSONS LTD
Estandsons Warehouse
Intereuropa d.d.
Mednarodni prehod 8,
SI-5290 Šempeter pri Gorici,
Slovenija

GRID U SHAPE
Ronan & Erwan Bouroullec
A colourful room-within-a-room, the raw shell of the GRID System provides a base for
modular seating, shelves, tables and screens, which can be integrated in dierent ways
to create a playful and multifunctional environment for informal meetings, presentations or
simply hanging out.
THE DESIGNER
Ronan & Erwan Bouroullec have been working together for over 20 years, bonded
by diligence and challenged by their distinct personalities. From designing spaces
to furniture, taking on architectural projects to designing textile wall systems or
comprehensive collections, the brothers maintain drawing and experimental activity
as essential to the development of their work. Their designs are part of select
international museums’ permanent collections, including the Musée National d’Art
Moderne, Centre Pompidou and the Musée des Arts Décoratifs in Paris, New York’s
MoMA, the Art Institute of Chicago, the Design Museum in London, and the Museum
Boijmans van Beuningen in Rotterdam.

DESIGN
2021
DIMENSIONS
High: L2486 × D3000 × H1584mm
Low: L2486 × D3000 × H834mm
INSTRUCTIONS OF USE
GRID sofa units are designed and tested for EN 16139:2013 - Level 1 “General Use”.
Appropriate applications include oce buildings, showrooms, public halls, function rooms,
cafés, restaurants, canteens, banks and bars.
CLEANING GUIDELINES
Larch Veneered Plywood & Triply: Clean with duster. Use a lint-free cloth with warm soap
foam for tougher stains. Avoid abrasive solvents, as they may damage the material. This
product is for indoor use only. For major maintenance or repairs, consult the retailer. Once
the product or its components are no longer used, make sure that they are disposed of
correctly through the public waste disposal services.
General Information Installation
U-Shape Sofa
High Mesh
U-Shape Sofa
Low Mesh
U-Shape Sofa
High Panel
U-Shape Sofa
Low Panel
DESCRIPTION
U-Shape Sofa High & Low
MATERIALS
Powder-coated mild steel, Larch Veneered
Plywood, Polyurethane foam, removable
upholstery covers, Larch Veneered Triply.
REQUIRED FOR INSTALLATION (PANEL)
REQUIRED FOR INSTALLATION (MESH)
68x Button Head
M6×16
68x Button Head
M6×16
68x Counter Sunk
M5×10
10x Feet Inserts
68x Counter Sunk
M5×10
40x Counter Sunk
M6×60
Combi Drill
10x Feet Inserts Combi Drill
High 28x / Low 14x
Vertical Locators
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY

1. Layout contents on a rug or soft surface to prevent scratching of the components.
Check the correct bolts are included before assembling.
2. Insert vertical wood locators into legs.
Take caution not to over tighten the Vertical Locators ( ! )
( ! )
Always use a minimum of THREE PEOPLE when assembling this Product. Always be mindful
of the weight of this product and take the necessary precautions during assembly to avoid any
harm. Always use a qualied person for the installation. Damaged parts of the furniture should be
exclusively replaced by the manufacturer or a qualied person. E&S declines all responsibility for
products that are modied.
INSTRUCTIONS FOR CORRECT INSTALLATION
U-Shape Sofa High
Panel only U-Shape Sofa Low Panel only

3. Insert Plastic feet into the bottom of the legs. 4. Assemble side steel tubes with panel.
Take caution not to over tighten the M6×60mm CSK bolts ( ! )
( ! )
U-Shape Sofa High
Panel/Mesh U-Shape Sofa Low Panel/Mesh U-Shape Sofa High Panel only U-Shape Sofa Low Panel only

5. Insert the back and front legs
Take caution not to over tighten the M5×10mm CSK bolts ( ! )
( ! )
( ! )
6. Assemble back steel tubes with panel.
Take caution not to over tighten the M6×60mm CSK bolts ( ! )
( ! )
U-Shape Sofa High
Panel only
U-Shape Sofa Low
Panel only
U-Shape Sofa High
Panel/Mesh U-Shape Sofa Low Panel/Mesh

7. Ensure the recommended amount of people are assisting for this step.
Insert the two side units into the back unit and lower front tube.
Take caution not to over tighten the M5×10mm CSK bolts ( ! )
24x Bolts
( ! )
U-Shape Sofa High
Panel/Mesh
U-Shape Sofa Low
Panel/Mesh
8. Place the cross bracing in the correct position.
Take caution not to over tighten the M6×16mm Button Head bolts ( ! )
U-Shape Sofa High
Panel/Mesh
U-Shape Sofa Low
Panel/Mesh
8x Bolts

9. Assemble middle steel tubes with panel.
Take caution not to over tighten the M6×60mm CSK bolts ( ! )
U-Shape Sofa High
Panel only
U-Shape Sofa Low
Panel only
U-Shape Sofa High
Panel/Mesh
10. Ensure the recommended amount of people are assisting for this step.
Insert the two side units into the middle unit and lower front middle tube.
Take caution not to over tighten the M5×10mm CSK bolts ( ! )
12x Bolts
U-Shape Sofa Low
Panel/Mesh

Attach the brackets to the base of the frame. Ensure they
are in the correct position before tightening.
Take caution not to over tighten the M6×16 Button Head bolts ( ! )
11.
REQUIRED FOR INSTALLATION
30x Brackets
U-Shape Sofa High
Panel/Mesh
U-Shape Sofa Low
Panel/Mesh
12. Before placing the base panels, install the power and data units
REQUIRED FOR INSTALLATION
12x 2.5×15mm PH Screw

13.
( ! )
28x Bolts
U-Shape Sofa High
Panel/Mesh
U-Shape Sofa Low
Panel/Mesh
14. Place the cushions on the base panels
U-Shape Sofa High
Panel/Mesh
U-Shape Sofa Low
Panel/Mesh
Place the larch base panel. Ensure all bolts at the
front, back and sides are screwed in.
Take caution not to over tighten the M6×16mm Roundhead bolts ( ! )

15. Insert the brackets into the cross bracing.
Take caution not to over tighten the M5×10mm CSK bolts ( ! )
4x CSK Bolts M5×10mm
REQUIRED FOR INSTALLATION
( ! )
16. Place the shelf panel on the frame.
Take caution not to over tighten the M6×50mm CSK bolts ( ! )
8x CSK Bolts M6×50mm
U-Shape Sofa
High Panel/Mesh
REQUIRED FOR INSTALLATION
( ! )
U-Shape Sofa
High Panel/Mesh

17. Attach shelf to side of sofa.
Take caution not to over tighten the M6×16mm CSK bolts ( ! )
( ! )
U-Shape Sofa High
Panel/Mesh
U-Shape Sofa Low
Panel/Mesh
4x CSK Bolts M6×16mm
REQUIRED FOR INSTALLATION
Do not place items that exceed 30kg on the shelf.
18.
Max
30Kg

U-Shape Sofa High
Panel
U-Shape Sofa Low
Panel
Assembled
U-Shape Sofa High
Mesh
U-Shape Sofa Low
Mesh
Assembled
