Established & Sons STACK User manual

STACK
Shay Alkalay

User Instructions
Established & Sons disclaims any responsibility
deriving from incorrect use of the mentioned object.
Please read these instructions in full prior to handling.
Keep these instructions for future reference.
NOTE: This is a heavy item! We advise a minimum
of 4 people are available for installation. Ensure this
item is kept upright at all times. DO NOT tip!
Take care to protect oor surfaces during location as
metal and wooden parts could damage oor surfaces.
User Instructions
When handling the piece we advise that all jewellery,
watches etc are removed to avoid scratches to the
surface.
The product is not suitable for outdoor use.
Hot items should not be placed directly on the surface.
Keep away from heat sources such as radiators &
replaces.
This piece should not be exposed to direct sunlight.
Do not overload the drawers. Max 5kg per drawer.
Ensure weight is evenly distributed in each drawer.
Do not place heavy items on one side of the unit only.
Be careful not to trap ngers whilst operating the
drawers.
Be aware of others using the unit at the same time as
injuries could occur.
Do not allow children to operate the drawers or leave
them unsupervised with the unit.
We recommend that xings are checked & tightened
periodically to ensure all drawers are secure.
For major maintenance or repairs, consult the retailer.
Once the product or its components are no longer
required, please make sure that they are disposed
of correctly.
IMPORTANT! Please retain the crate for any future
transportation or longterm storage.
Design 2008
Description Tower of Drawers
Dimensions
8 drawers: H1080mm x L565mm x D615mm
13 drawers: H1780mm x L565mm x D615mm
Notes
Please refer to installation instructions before unpacking
Materials
Birch Plywood, bre board, steel, lacquer
Colours
Blue, green, neutral, red, wood veneer

Installation Instructions
ATTENTION!
Never attempt to lift the Stack by the coloured panels.
This may seriously damage the piece!
DO NOT tip! Ensure this item is always kept upright.
DO NOT use a knife to undo the internal wrapping.
This could scratch the drawers inside
Uncrating
1/ Ensure the oor is level and is sufciently strong to
support the weight of the unit and its contens. unpacking
should be carried out near to its nal location.
Ensure enough space is cleared in advance and access
to the installation area checked prior to unpacking.
2/Carefully unscrew the top & all sides of the crate to allow
for full access to the unit. Remove & place away from the
unpacking area.
Maintenance Instructions
Cleaning Guidelines
Frequently dusting of this piece will help to maintain
the luster of the nish. For general maintenance, dust
regularyly with a soft, dry, lint-free cloth. Please be aware
that dust is an abrasive and can scratch the surface so
this must be done with care to prevent scratching.
If wet cleaning is required, the item should be cleaned
rst without pressure using a soft, slightly damp cloth.It
must be immediately dried with a dry, lint-free cloth. For
areas that require further cleaning a very mild detergent
and water solution can be used.
Should drawers become stiff over time, a lubricant such
as WD40 carefully applied to the runners at the central
frame will allow the mechanisms to run more smoothly.
The stack has been designed so that drawers panels
can be replaced in the event that some may become
scratched or chipped during use. Should this occur, please
contact the retailer for advice.

6/ Move the 2nd drawer from the bottom of the Stack
to one side to gain access to the lower drawer. You
will see 4 white screw caps on each side. Remove the
2 screw caps nearest the front of the drawer from both
sides. This will expose the screws which raise and lower
the castor wheels, enabling the stack to move. Repeat
procedure on opposite side.
4/ With 2 people positioned at the base and 1 supporting
the top of the piece to prevent tipping, carefully lift
from underneath the bottom white drawer panels. The
remaining person should quickly remove the base of the
crate from underneath before gently lowering to the oor.
Note: DO NOT use coloured panels to lift the piece.
DO NOT lift more than a 5cm, particularly the 13
drawer. As this is a heavy item, there is a risk of injury if
handled incorrectly.
3/ Remove polystrene boards that are used to protect
the piece within the crate. DO NOT remove the remaining
shrink & bubble wrap packaging until in position on the
oor. This will help to keep the drawers secure when
handling.
5/ Carefully remove remaining packaging foam & bubble
wrap. DO NOT use a knife to open as this could scratch
the drawers beneath the packaging. Open with care.
Remove the lid of the top drawer and place away from
the piece in a safe place. Remove the internal polystyrene
which prevents the drawers from moving by pulling the tab
up. Replace the lid.

Established & Sons
5 –7 Wenlock Road, London N1 7SL
United Kingdom
Phone [phone]
Fax [phone]
www.establishedandsons.com
8/ Manoeuvre carefully into nal position. Turn the screws
COUNTER-CLOCKWISE to raise the castor wheels
and replace the white screw caps. Now the Stack is
permanently positioned.
7/ Using a at-head screwdriver, turn CLOCKWISE to
lower the castor wheels. Turn each wheel the same
number of turns to ensure it stays stable on the ground
Note: Only extend enough to allow the unit to move
freely on the oor. Do not fully extend the castors as
they will leave their housings. screwdriver must be
large enough to drive in an M10 screw.
