ETC Source Four jr User manual

Copyright © 2008 Electronic Theatre Controls, Inc.
All Rights reserved.
Product information and specifications subject to change.
Part Number:
7062M1200-06.01 Rev C
Released: January 2010
Picking# 7062M1001-C
User Manual
Production Dates: September 2004 - Present

i
Table of Contents
ETC
®
, Emphasis
®
, Expression
®
, Insight™, Imagine™, Focus™, Express™, Unison
®
, Obsession
®
II, ETCNet2™,
EDMX™, Source Four
®
, Revolution
®
, Sensor
®
, and WYSILink™ are either registered trademarks or trademarks
of Electronic Theatre Controls, Inc. in the United States and other countries.
All other trademarks, both marked and not marked, are the propertyof their respective owners.
ETC intends this document, whether printed or electronic, to be provided in its entirety.
Basic Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Fixture information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Color frame holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Replacing the HPL lamp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Centering lamp and adjusting the field . . . . . . . . . . . . . . . . . . . .5
Focusing the beam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Shaping the beam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Adjusting the C-clamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Adjusting the yoke position . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Lens and Reflector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Switching lens assemblies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Cleaning glass lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Cleaning the reflector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

1
Basic Assembly
WARNING:
Please note the following safety warnings before use:
Do not mount the fixture on or near combustible surfaces.
Do not operate the fixture without a lens installed.
Always hang the fixture with the colour frame retaining clip in the locked
position.
Figure 1
Lamp housing
C-clamp mounting
Barrel
Drop-in iris
slot cover
Pattern holder slot
Gel frame
Zoom rear focus knob
Beam focus knob
(Zoom front focus)
Yoke
Yoke locking knob
Color frame
retaining gel clip

2Source Four jr / jr Zoom User Manual
Fixture information
HPL lamp table
Color frame holder
The color frame holder is equipped with a spring-loaded retaining clip that prevents color frames
and accessories from falling out. See Figure 2.
Step 1: Release the retaining clip by pushing it sideways while gently pulling backwards.
Step 2: Insert the color frame.
CAUTION:
The Source Four jr is rated for 575w maximum lamp. Do not use lamps other than
the HPL in Source Four fixtures. Use of lamps other than HPL or greater than
575w will void your warranty.
Lamp code Watts Volts Initial Lumen Color temp. Average rated life
HPL 550/77* 550 77 16,170 3,250° 300 hours
HPL 550/77X* 550 77 12,160 3,050° 2000 hours
HPL 575/115 575 115 16,520 3,250°K 300 hours
HPL 575/115X 575 115 12,360 3,050°K 2000 hours
HPL 375/115 375 115 10,540 3,250°K 300 hours
HPL 375/115X 375 115 8,000 3,050°K 1000 hours
HPL 575/120 575 120 16,520 3,250°K 300 hours
HPL 575/120X 575 120 12,360 3,050°K 2000 hours
HPL 575/230 575 230 14,900 3,200°K 400 hours
HPL 575/230X 575 230 11,780 3,050°K 1500 hours
HPL 375/230X 375 230 7,250 3,000°K 1000 hours
HPL 575/240 575 240 14,900 3,050°K 400 hours
HPL 575/240X 575 240 11,780 3,050°K 1500 hours
HPL 375/240X 375 240 7,250 3,000°K 1000 hours
* To be used with ETC Dimmer Doubler™
WARNING:
Make sure all color frame accessories are locked in position with the
retaining clip before hanging the Source Four.
Figure 2
Retaining clip

3
Step 3: Lock the retaining clip by pushing sideways while gently pushing forward.
Note:
The performance of saturated colors may be less than desirable in any theatrical
lighting fixture. For best results, always use high-quality color media rated for high-
temperature use.
ETC’s optional Conical Gel Extender, part # 7060A1048, will provide maximum
color media life. Gel Extenders are not recommended for 70° and 90° lens tubes
due to the extremely wide-angle beam.
A variety of heat shield products is also available from many color media
manufacturers. Follow the manufacturer’s instructions for the use of these
products.

4Source Four jr / jr Zoom User Manual
Replacing the HPL lamp
A lamp must be installed before you use the fixture.
Step 1: Disconnect power to the fixture before installing the lamp.
Step 2: Loosen the knurled bolt on the back of the lamp housing and pull the housing out.
Step 3: Holding by the base, remove the HPL lamp from its box.
Step 4: Align the flat sides of the lamp base with the retention brackets on either side of the
socket as shown in Figure 3.
Step 5: Push down on the lamp base until the lamp seats firmly. When properly installed, the top
of the lamp’s base will be even with he top edges of the retention brackets.
Step 6: Press lamp retaining clip across lamp base to secure.
Step 7: Reinstall the lamp housing by aligning the bolt hole and tightening the knurled bolt
Note:
Verify that the HPL lamp you intend to install is suitable for your facility’s voltage;
115-, 120-, 230-, and 240-volt HPL lamps are available.
See HPL lamp table, page 2. Operating HPL lamps above their rated voltage
reduces lamp life and can cause premature lamp failure.
WARNING:
Let the lamp cool before replacing.
CAUTION:
Use caution when installing or replacing any lamp.
When installing/replacing lamp, be sure to point the lamp away from your face and
away from others before inserting it firmly into the assembly.
This may prevent injuries if the lamp should break.
Note:
To avoid premature lamp failure, do not touch the lamp glass. If you do, clean it
carefully with isopropyl alcohol and a clean lint-free cloth. Allow to dry before
operation.
CAUTION:
Improperly installed lamps cause premature lamp failure and socket problems.
HPL lamp
Lamp retention clip
Figure 3
Knurled bolt
Lamp housing
Lamp retention
brackets
INCORRECT CORRECT

5
Adjustments
Centering lamp and adjusting the field
The two concentric knobs located on the lamp housing allow you to align the lamp and adjust its
field. See Figure 4. The outer knob centers the lamp within the reflector. The inner knob adjusts the
lamp’s field.
Step 1: Turn on the fixture and aim it at a flat surface. Adjust the barrel to create a hard edge.
Step 2: Unlock and loosen the outer knob by turning it counterclockwise.
Step 3: Gently move the outer knob from side to side and up and down until the lamp is centered
within the reflector.
Step 4: Once the lamp is centered, turn the outer knob clockwise to lock it in place.
Step 5: Finally, turn the inner knob either clockwise or counterclockwise to achieve an optimum
flat field. See Figure 5.
Focusing the beam
On a fixed field angle Source Four jr., with a 26°, 36° or 50° lens, adjust the lens single beam focus
knob to focus the edge of the beam. On a Source Four jr Zoom, adjust the position of both lens
beam focus knobs to set the beam’s spread and to focus the edge of the beam. The Zoom lens
provide a range from 25° to 50°.
Step 1: Loosen the beam focus knob(s) on the underside of the barrel as shown in Figure 6.
Step 2: Slide the lens(es) forward or backward to achieve the desired beam edge.
Step 3: Once the fixture is focused, tighten the beam focus knob(s).
Outer Knob - lamp
center adjustment
Inner Knob -
peak/flat field
adjustment
Rear lamp
housing
Figure 4 Figure 5
Flat field-best adjustment
Hot spot - lamp pulled out
too far
Field with hole - lamp
pushed in too far
Beam focus knobs Figure 6

6Source Four jr / jr Zoom User Manual
Shaping the beam
The beam can be shaped using the shutters (see Figure 1, a pattern or an optional drop-in iris.
Pattern Projection
The pattern holder slot is on the top side of the barrel and in front of the shutters. It accommodates
an M-size pattern holder (see Figure 7). The pattern holder handle can be bent away from the
shutter handle to keep it from interfering with the action of the shutter handle.
Use an optional donut in the accessory holder to enhance pattern projection. Donut diameter range
should be 2.5” to 2.75”.
Drop-In Iris Slot
The drop-in iris slot is located on the top of the barrel and in front of the pattern holder slot. It
accommodates either a drop-in iris or a motorized pattern device. When the slot is not in use, a
small sheet metal cover secured with two Phillips screws prevents light leakage (see Figure 8).
Step 1: Use a Phillips screwdriver to loosen the screws on the drop-in iris slot cover. Do not
remove screws.
Step 2: Slide the cover completely forward to expose the slot.
Step 3: Insert the iris with the flat side toward the shutters and make sure the iris handle extends
from the slot.
Step 4: Slide the slot cover back toward the shutters until it meets the iris handle. Leave enough
space to move the iris handle.
Step 5: Secure the drop-in iris slot cover by tightening the screws.
Figure 7
M-Size Pattern holder
Drop-in iris slot Iris
Figure 8
Pattern holder slot

7
Adjusting the C-clamp
The C-clamp attaches the fixture to the mounting pipe and allows you to adjust the position of the
fixture once it is mounted (see Figure 9).
Step 1: Tightly fasten the C-clamp to the yoke with the provided yoke bolt and lock washer.
Step 2: Place the C-clamp on mounting pipe, then tighten the pipe bolt to secure it.
Step 3: Loosen the C-clamp pan screw and rotate the yoke to the desired position.
Step 4: Tighten the pan screw to lock the fixture.
Adjusting the yoke position
The Source Four jr / jr Zoom provide multi-positioning capabilities within its yoke for overall fixture
height and angle.
Setting the fixture height within the yoke
The fixture is equipped with a two-position yoke for modifying the overall height in which the fixture
is mounted (see Figure 10). To change the height position, perform the following steps.
Step 1: Remove the yoke locking knobs, washers, and hex bolts from either side of the fixture.
Step 2: Raise or lower the fixture to the desired position within the yoke.
Step 3: Reinstall the yoke’s hex bolts, washers, and locking knobs.
Step 4: Tighten the yoke knobs to secure in position.
CAUTION:
Tighten C-clamp pipe bolt to 15-20 ft./lbs. (approximately finger tight plus up to
one-quarter turn). Do not exceed 25 ft./lbs. Do not use excessive force.
Tighten the yoke pivot bolt to 5-10 ft./lbs. (approximately finger tight plus up to
one-eighth turn). Do not exceed 15 ft./lbs. Do not use excessive force.
ET C
C-clamp
Pipe bolt
Pan screw
Yoke bolt and
lockwasher
Figure 9
Yoke
Figure 10
Low clearance position
General use position
Yoke locking knob

8Source Four jr / jr Zoom User Manual
Setting the angle within the yoke
Step 1: Loosen the yoke locking knobs (see Figure 11). Do not remove them.
Step 2: Tilt the fixture to the desired position.
Step 3: Tighten the yoke locking knobs to secure in position.
Yoke locking knob Figure 11

9
Lens and Reflector
Switching lens assemblies
Follow these procedures to replace a fixed field lens with Zoom lens.
Step 1: Loosen the screw at the front of the baffle. See Figure 12.
Step 2: Pull the light baffle out of the barrel.
Step 3: Remove the beam focus knob from the bottom of the barrel and slide the lens assembly
from the barrel.
Step 4: Slide the Zoom lens rear assembly into the barrel and install its beam focus knob.
Step 5: Slide the Zoom lens front assembly into the barrel and install its beam focus knob.
Step 6: Reinstall the light baffle and secure it with the retaining screw.
Note:
Reverse steps 1-6 to replace Zoom lens with a standard lens.
Lens tray
Figure 12
Light baffle and
retaining screw

10 Source Four jr / jr Zoom User Manual
Cleaning glass lens
Replace lenses if they contain visible damage (cracks or deep scratches) that may impair their
effectiveness.
Step 1: Remove the lens assembly. See Source Four jr / jr Zoom Assembly Guide for lens
removal instructions.
Step 2: Remove dust with a blast of oil-free air or wipe with a clean, lint-free cloth. Isopropyl
alcohol, distilled water or a 50%-50% mixture of each can be used to clean the glass
surface.
Step 3: Reinstall the lens assembly.
Cleaning the reflector
To quickly clean the reflector, and. You may also wipe the reflector with a clean lint-free cloth. If
either method is not sufficient, follow these steps.
Step 1: To protect the lamp housing during cleaning, remove the lamp housing by loosening the
knurled bolt and pulling the housing straight out. See Figure 3.
Step 2: Remove the lens. See Source Four jr / jr Zoom Assembly Guide for full fixture
disassembly/assembly instructions.
Step 3: Remove dust with a blast of oil-free air or wipe with a clean, lint-free cloth. Isopropyl
alcohol, distilled water or a 50%-50% mixture of each can be used to clean the glass
surface.
Step 4: Reinstall the lamp housing and tighten the knurled bolt.
Step 5: Reinstall the lens.
WARNING:
Do not use ammonia-based or other harsh commercial cleaners. Clean lens
only as directed.
Commercially available glass cleaning agents should be avoided as they
may contain ammonia, other harsh chemical detergents or abrasive agents.
These cleaners may damage the glass surface and the Anti-Reflective
coatings. Do not immerse or soak the glass in any cleaning solution.
WARNING:
Unplug the fixture before attempting to clean the reflector.
WARNING:
Do not use ammonia-based or other harsh commercial cleaners. Clean
reflector only as directed.
Commercially available glass cleaning agents should be avoided as they
may contain ammonia, other harsh chemical detergents or abrasive agents.
These cleaners may damage the glass surface and the Anti-Reflective
coatings. Do not immerse or soak the glass in any cleaning solution.

11

12 Source Four jr / jr Zoom User Manual

13

14 Source Four jr / jr Zoom User Manual

Corporate Headquarters  3031 Pleasant View Road, P.O. Box 620979, Middleton, Wisconsin 53562-0979 USA  Tel [phone]  Fax [phone]
London, UK  Unit 26-28, Victoria Industrial Estate, Victoria Road, London W3 6UU, UK  Tel [phone]  Fax [phone]
Rome, IT  Via Ennio Quirino Visconti, 11, 00193 Rome, Italy  Tel [phone]  Fax [phone]
Holzkirchen, DE  Ohmstrasse 3, 83607 Holzkirchen, Germany  Tel [phone]  Fax [phone]
Hong Kong  Rm 1801, 18/F, Tower 1 Phase 1, Enterprise Square, 9 Sheung Yuet Road, Kowloon Bay, Kowloon, Hong Kong  Tel [phone]  Fax [phone]
Service: (Americas) [email protected]  (UK) [email protected]  (DE) [email protected]  (Asia) [email protected]
Web: www.etcconnect.com  Copyright © 2008 ETC. All Rights Reserved.  Product information and specifications subject to change.
7062M1200-06.01  Rev C  Released 2010-01
