ETEK Optima User manual

!§.[EE
World Wide Music
OPTIMA
PROFESSIONAL 24-BIT DIGITAL AUDIO PHOCESOH
" " - . :I- -- - -.-.'-
' I '-'-- 1.5- -_ ‘I _ . ||.' _l. 'I -[fit 'Ei|l'r-1-I-I-It
iii? II
OWNER'S MANUAL
-i
ENGLISH
ITALIANO

SAFETY PRECAUTIONS AND
INSTRUCTIONS
I-'t'i".‘1-It-if-JF ELECII -‘:1 '
DU HUT ID-FEH.
CALFHUN: "no REDUCE THE aisk oi= ELECTRIC snack.
oo i~ii:rr neviovs oovEi=i. no uses S-EHVICEAELE PARTS
i;i~rsioi=.nEFEasi:Fivicii~ie1‘oouai.ii=iiao Pei=isouiiiEi_
EXPLANATION OF GRAPHIC SYMBOLS:
The arrowheaded lightning flash symbol, inside an equilateral triangle, is
5: intended to alert the user to the presence of "dangerous voltages" inside the
product. They mav be of sufficient level to constitute a risk of electric shock to
persons coming into contact with these.
The exclamation mark inside an equilateral triangle indicates thepresence of
imponant operating and maintenance (senricing} instructions in the literature
accompanying the product.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY TO PERSONS.
WARNING: To REDUCE THE RISK oi= FIRE on ELECTRIC
SHOCK, oo NOT E)-(PDSE THIS Paooucr To RAIN on
MOISTURE.
& - EARTHING (GROUNDING) INSTRUCTIONS -
This product must be earthed (grounded). lf it should function badly or breakdown,
earthing (grounding) provides the lowest resistance path to reduce the risk of electric
shock. It is supplied with a mains lead [power cord) containing an equipment-earthing
[grounding] conductor and an earthing {grounding} plug [for Great Britain see the special
instructions at the top of page 4). The plug must be inserted into an appropriate AB
voltage wall socket that is properly installed and earthed {grounded} in accordance with
all local safety rules and regulations.
DANGER -_ improper connection of the equipment earthing (grounding) conductor can
result in a risk of electric shock. Check with a qualified electrician if you have any doubts
as to whether the product is properly eaithed (grounded) or not.
2

IMPORTANT SAFETY AND INSTALLATION
INSTRUCTIONS
I lg
-" when using electrical products. observe the foilowing basic precautions;
Read all the safety, installation and operating instructions before using the product and refer
to the instructions on pages 2, 3 and 4 to ensure a correct and safe installation-
WATER AND MOISTURE - Do not use the unit near water, for example near a bath tub.
washbowl, kitchen sink, or near a swimming pool etc., or in a wet or damp basement.
VENTILATION - The unit should be placed in a position that will provide adequate ventilation
to enable it to operate at the correct temperature- Do not place it on_a bed, sofa or rug or in
a closed unit such as a bookcase or cabinet that may block the ventilation slots and prevent
sufficient flow.
HEAT - The unit should never be positioned near heat sources such as radiators, heaters or
other products, including amplifiers, that produce heat. _ _ _ _
Do not use the unit in extremely hot or damp locations or in dusty or dill? conditions.
VIBRATIDNS - Do not position the unit where excessive vibrations can occur.
POWER CONNECTIONS - The unit should only be connected to a AO supply of the type
and voltage corresponding to that described in the operating instructions or as shown on the
label on the instrument. This label, contains all electrical data, waming messages and
identification data.
PLUG POLARIZATION - This product may be equipped with a polarized plug (one blade
wider than the other)- This is a safety feature. if you are unable to insert the plug into the wall
socket, contact an electrician to replace your obsolete wall socket. Do not defeat the safety
purpose of the plug.
The mains lead {power cord} should be unplugged when the instrument is not used for long
periods. Do not pull the mains lead (power cord], but hold the plug when unplugging.
GENERAL CARE - Care should be taken to avoid foreign objects falling into or liquid being
spliit into the inside of the instrument through any of the slots or openings in the case-
This instrument should be referred to an approved service centre when:
a. The mains lead {power cord] or plug has been damaged.
Objects have fallen into the instrument or liquid has been spilt into or over it.
lt has been exposed to rain.
. It appears to operate incorrectly or shows a marked change in performance.
It has been dropped or ii the case has been damaged.
PP-PF
WARNING - Never attempt to remove the cover ct the product to repair the instn.iment
yourself. Any operation should be referred to authorized personnel, otherwise the guarantee
will be declared void. For maintenance and servicing always refer to qualified personnel
specifically authorized by El'El't'. E-I-r.I.
SAVE THESE INSTRUCTIONS
3

sway
' 1 1 ‘I '1 ‘P. T " .i :"' 11
IMPORTANT
The wires in the mains lead are coloured according to the following code:
Green — and — Yellow ::.i- Earth
Blue s Neutral
Brown er. Liee
The wires in the mains lead of this instrument may not correspond with it-re
coloured markings. you should therefore refer to this diagram to identify
the temtinals in your plug:
50"" ~--—--—-——-.-
nne-ct the GREEN and YELLOW earth wire lo the
terminal with the letter E or coloured Green or Green
and "if flow '
_ In _ Ur nfmedfiflth the gmind wmbfli Fuse should be changed to a
'— — 3AIiiIP rating type If not
nfrlltidy fltfld.
;
....e I i .-
J’.-at .."s'-.'l
I35‘ I
it;
— I gen owrrii c ire
Connect the BLUE neutral vare "Em ma TH m d vnhw
to terminal marked with m ‘Emma ma E W
itt L rcoloured Fled-
the letter N or coloured Black. mg B E; D __ _ ..._.
RADIOITV INTERFERENCE AVOIDANCE
This unit operates at radio frequencies Unless it is correctly installed and used properly - that is in Sifll-‘ll accordance
with the manufacturers instructions - it may interfere with radio and television reoel3li"J"- _
it has been carefully designed according to the rules and regulations in force at the time, and has been Equipped
with various types of screening designed to provide reasonable erfllilliilll" E-Eliliflfil such interference in a residential
installation. _
However, there is no guarantee that interference will not occur in any particular instailation._ _ _
it this equipment does appear to cause interference with radio and ‘W, which can be determined btil Ewliching it oft
to see lI the interference disappears and then switching it on again to see if it reetJi1'E3|'5. the user is encourageij
to try to correct the interference by carrying out one or more of the following measliresi
1. Tum the radio or T‘ii’ aerial {antenna} to face in a different direction-
ii. Change the instrument's position with respect to the receiver.
liilove the instrument away from the receiver.
Plug the instrument into another power socket, which is pan of a different branch circuit.
it necessary. the user should contact the dealer or an expenenced Radio.lT‘i.l‘ technician for additional adviee_
FOR USERS IN THE UNITED STATES OF AMERICA:
F":"*E"'
The user may find the following booklet prepared by the Federal Communications Commission helpful;
"How to identify and resolve Radioi'TV interference problems". This hook is available from the U,S,
Govarmant Printing Office, Washington D.C. 20402, Stock No. Uflrf-ODD-D0345-ll.
4
1-11!-I-I‘-&.‘#

INTRODUZIONE
Congratulations on your choice of the ETEK OPTIMA Professional Digital Multi-
Effects Module. With this purchase you have come into possession of one of the
most efticient processors available on the market today, capable of solving many
problems in your music productions.
THE COMPRESSOR
Dynamic control is fundamental in the production of music, in fact signals coming
frern microphone and pick-up sources in particular, often contain eccessive
levels and signal peaks with respect to the musical context in which they are
present. Thanks to the compressor it is possible to obviate the inconveniences
of excessive signal overloading and saturation, thereby obtaining a
hemogeneous result. Furthermore, in the hands of a capable Sound Engineer,
the compressor, pushed to its extreme values, can be a useful instrument in the
creation of special effects, especially when used with drums and other
percussive instruments.
LIMITER
In the same way as the Compressor, the Limiter is a very necessary function used to
accurately control the dynamics of the input signals. The way in which it works though
is radically different, as the Limiter immediately sets the dynamic range of the input
signal according to a previously established threshold.
ENHANCER
The Enhancer, as its name suggests, enhances the basic frequencies of the
mixing, giving a fuller, richer and more powerful sound.
Particularly of effect with percussive instruments, and guitars or basses when
played in a ‘slap’ manner.
DENOISER
The causes of background noise in the production of music are numerous;
pickups, electronic instruments, microphones etc. The Oenoiser intelligently
analyses the input signal, removing any background noise without altering the
sound content or any of the frequencies of the musical programme.
5

AGC (Automatic Gain Control}
This is the revolutionary technology used in the OPTIMA that enables dynamic
control of the signal without equal, employing a sophisticated combination of
expansion and limiting ot the signal. AGC is active in the Compressor, the
Enhancer and in the compound algorithm called “lvlULTl"- When an algorithm
that employs this function is selected, AGC is automatically activated, but it is
also possible to use the function in a personalized way with the editing of the
parameters.
Main Charactersistics of the ETEK OPTIMA:
- Extremely flexible use with the use of Compressors, Limiter, Enhancer and
Denoiser algontms.
' AGO ie-‘chnfiifigtl to always guarantee the best level of the signal to be
processed.
- Protessional quality, completely programmable effects.
- Senal interface (RS-232) and MIDI for connection to computer and keyboards.
‘ Expansion connector, for connection to digital audio equipment (5i’F‘i3iF.
ADAT...)
- PC and Mac software.
- 20 bit Sigma-Delta i‘-‘-JD and DIA converters, oversampling 641125 times,
sampling rate 4BkH:~:, bandpass 20H:-20kH.=:
- 2i'li’32 bit intemai processor.
- XLR and TRS jack connectors.
- 50 ROM presets rom and 50 locations for user programmable presets.
- LCD Aifanumeric Display with 20 X 2 caracters.
- Left and F-light input level Led Bar level indicators.
— internal power supply.
- Made to ISO 9000 Ouality System Standards.
Power On Delay System
Note: The first time the OPTIMA is switched ‘Orr’. an iniziaiizingi process
will be carried cut‘. it will not be possible to use the unit for about 4g
seconds.
Further irriaiaiizing procedures wiil last only 3 seconds.
6 l
_-__-__ i i_ ii
~l-=i~:Ht1i-i-i-

'ii* ' ‘FT-'_i'—
1.
i___i
EH95
"-
1.
2.
3.
4.
i_l__
FRONT PANEL
1 E 3 4 5 Er
I--III-I
ale BE B S SIB SIB III
I -'.':;-
M H # F Ia _' I I
3-ii-Ii 1 1 '
REFERENCE NUMBERS OF FRONT PANEL
INPUT LEVEL. Use this control to adjust the input signal level.
INPUT LEVEL VU METER. These Led bar Vu Meters indicate the level of
the input signal. When the red led turns ‘On’, this means that the signal is
close to the distorsion level and that the INPUT LEVEL control should be
backed off slightly.
ALFANUMERIC LCD DISPLAY. This display indicates the selected
algorithm, the Preset name and the corresponding number. in the PRESET
EDIT mode it shows the parameters that can be modified and the
respective values.
FUNCTIDN SELECTION PUSH BUTTONS. Each of these push buttons
selects one of the effects algorithms of which the OPTIMA makes use or
sets the unit in the edit mode.
COMPRESSOR: Pressing this button will give access to the
COMPRESSOR algorithm in the OPTIMA, and the dsplay will show the
available presets that can be selected by means of the DIAL Knob ((5) on
the right of the panel.
LIMITER: This button activates the LIMITER function in the OPTIMA.
MULTI. When this button is pressed, the MULTI algorithm is activated in
which all the algorithms of OPTIMA are linked (AGO, Limiter, Enhancer,
Compressor and Noise gate) which gives a sophisticated, complete and
flexible chain of processing for your audio signals.
ENHANCER: Activates the ENHANCER function of the OPTIMA-
DENOISER: This button sets the OPTIMA to function as a denoiser and
general input signal optimizer.
UTILITIES: The Utilities button gives access to various useful functions
such as, for example, the parameters for the OPTIMA MIDI setup, the
general input and output levels and the editing of the AGO parameters.
7
'

__,‘
EDIT: Access to the PRESET EDIT mode is obtained by pressing this
button, making available to the user the parameters for the modification of
the presets of all the algorithms of the processor.
SAVE: This button enables all the variations made to the presets in the
EDIT mode and various other settings of the unit to be memorized.
EXIT: Pressing this button enables you to leave the current page or
operating mode in which the unit is currently operating. EXIT also functions
as an “LJNDO". enabling the last operation carried out to be annulled.
BYPASS: The audio input and output of the OPTIMA are connected
together when this button is pressed to enter the BYPASS mode, excluding
any intervention by the internal DSP.
ENTER: This button is used to carry out various operations, and generally
to confirm a memorization or the selection of a preset.
DIAL KNOB. Use this round knob to select a preset number, a parameter,
or to change the value.
POWER switch. Use this switch to turn the OPTIMA ‘On’ and ‘OFF’.
I
i
.-
it"-

F""'__
I
2. REAR PANEL
1 2 3 4 5 B
L I _ '=" or Ii '5' or _ _-I I
—_ i 1-4.1 1i
Z -KI
L-
'-' *-‘.96 I. I_It_I .Q.®j__llHI®Q.
B7
REFERENCE NUMBERS OF REAR PANEL
(THE CONNECTORS AND CONTROLS FOR USP 2 ARE IDENTICAL)
POWER SUPPLY LEAD SOCKET AND FUSE HOLDER. The mains lead
(power cord) should be plugged into this socket, then the lead (cord) should
be plugged into a compatible voltage supply. To change the fuse, slide the
fuse cover with a screwdriver; replace the fuse with one of the same type as
the original.
EXTENSION. Mufti-functionConnettore, used for the connection of digital
audio united (Sr‘PDlF, ADAT...). Consult your retailer for further information
as to the suitability.
RS232. Use this connector to connect the OPTIMA directly to a PC or MAC
computer. The software driver should be included with the OPTIMA; if this
proves not to be so, contact your retailer.
MIDI. These DIN connectors permit the OPTIMA to be connected toa
computer, musical instrument, MIDI pedalboard, in order to change the
presets or modulate the parameters from a sequencer or a MIDI controller.
IN: Connect this socket to the MIDI OUT of another MIDI unit. MIDI
data will be received by this socket.
OUT: Connect this socket to the MIDI IN of another MIDI unit. The
MIDI data transmitted by OPTIMA will be sent from this socket.
THRU: This socket re-transmits the MIDI data received by the MIDI IN
socket, enabling a further MIDI unit to be connected in cascade.
OUT (BALANCED). Balanced audio output. The XLR or TRS jack sockets
can be used. When the OPTIMA is operating in stereo, the DSP 1 OUT is
the LEFT channel, while the DSP 2 OUT is the RIGHT channel.
9

6. IN - 10dBW+ 4dBu. This push button enables the selection of the input
level of the OPTIMA. The - 10dB‘v' setting is tor semi-professional units (like
hi-ii units etc,), while + 4dBu is for use with professional equipment
(professional mixers, studio [)ATs etc...).
OUT - 1oeew+ 4clBu, This push button enables the selection of the input
level oi the OPTIMA. The - 1UdB‘v' setting is for semi-professional units (Elke
hi-ti units etc.), white + 4dBu is for use with protessional equipment
(professional mixers, studio DATs etc..,).
IN (BALANCED). Balanced audio input. The XLFI or TBS jack sockets can
be used. When the OPTIMA is operating in stereo, the DSP 1 IN is the
LEFT channel, while the DSP 2 IN is the HIGHT channel.
3. PHESET MODE
The PHESET MODE, availble at the moment it is switched ‘On’, enables the
selection and use of the effects presets of OPTIMA, To use the numerous elfects
of the unit it is in fact sufficient to press the button of the desired algorithm and
select the various presets with the DIAL Knob (5).
3.1 HOW TO SELECT A PHESET
Once an algorithm has been selected by pressing the relative button. use the
DIAL Knob (5) to scroll through the various presets available, the names of
which will be shown in the display immediately after the selected algorithm and
just before the Preset number. (CMP for compressor, Lllvl for limiter, MULTI for
the algorithms chained together, EHN for Enhancer, DEN for Denorser},
You can select presets from El to 10 for each algorithm, The presets from_ D-10
which are preceeded by an asterisk, are factory set and CHFIFIBT DE Wefwflfieh,
7.
B.
3.2 FACTORY PBESETS mo uses VARIABLE PHESETS
The Factory Presets (locations 0-10) can be modified and saved in a Uggr
Preset (50 locations available to the user, which can be freelv used for all the
various algorithms).
BYPASS ‘
In the Preset tvlode it is possible to press the BYPASS button (LED On‘) ta
deactivate the effect of the unit, and send exactly the same signal received at
the input, to the Output. The display will show "Bypass Optima .
Press BYPASS (LED ‘Off'} to reactivate the effect of OPTIMA when the number
and name of the current preset will reappear.
‘IO
it
‘i.
r
"".
J
1

"—_“_"i_—i""
4_ PRESET EDIT MODE
Press me EDIT button to enter the Preset Edit mode, that enables the presets
tn be modified and saved in one of the 50 User Locations.
4,1 eorr PROCEDURE
-mg Preset Edit is made up of a main level, in which the parameter to be
medified is selected, and a secondary level, in which the value of the parameter
selected can be set.
1 SELECTION OF A PFIESET TO EDIT. While still in the Preset mode, select
the preset to be edited.
2, ACCESS TO THE PRESET EDIT MODE. To enter the Preset Edit mode,
press EDIT. The attivation of this mode will be confirmed by the display
which will show EDITING, and the Ieds on the EDIT, SAVE and EXIT
buttons which will light together will the button of the algorithm that you
selected to modify.
3. SELECTION OFA PARAMETER. Use the DIAL knob (5) to select the
parameter to be modified. The list of the parameters that can be edited for
each algorithm is in EDITABLE PARAMETERS in the TABLES - Section 6
of this manual.
4. HOW TO MODIFY VALUE OF A PARAMETER. Once the parameter to be
modified has been selected, press ENTER for access to its value.
The value of the parameter shows on the display, preceeded by “VALUE”
and followed by the name of the parameter. The led on the SAVE button
will turn ‘Off’ while those on the EDIT and EXIT buttons remain ‘On’. Use
the DIAL Knob (5) to make the modifications.
5. SAVING OR ANNULLING A MODIFICATION OF A PARAMETER.
At this point it is possible to:
a. Press ENTER to temporarily save the value of the parameter.
b. Press E)-(IT to cancel the modification made and return to the
f section of the parameters.
6. HOW TO MODIFY OTHER PARAMETERS. Once ENTER or EXIT has
I been pressed in point 5, the selection of the parameters is automatically
i recalled. It is possible to select a different parameter and therefore proceed
with the modifications to other parameters.
11
mm-i

ml -i-i-I-ii-1-I——r-I--r
O-I‘
T.
SAVING OR ANNULLING A MODIFICATION TO A PRESET. Once all the
parameters that you want to change have been completed, if you want to
save the result in a new location. then just press SAVE and it will be
automatically possible to give a name to the new preset. To do this, scroll
through the characters required with the DIAL Knob (5) and confrm them
with ENTER. The memory position will the first one available. Pressing
EXIT will return to the preset mode without saving the changes made in the
memory.
5. UTILITIES MODE
Pressing UTILITIES gives access to a series of extremely important functions
and parameters used in the control of the OPTIMA, selectable by means of the
DIAL Knob (5). The procedure for the entering of the data is the same as
explained previously, that is once the parameter has been selected by means of
the DIAL Knob (5), just press ENTER and then again with the DIAL Knob select
the value, and confirm this by pressing ENTER or, press EXIT to return to the
selection of the parameters without making any changes.
The functions and the parameters of UTILITIES are as follows:
1
2
3
4
5.
B.
‘I2
PORT SELECTION. The display shows SEL PORT and enables the
selection between the Serial RS 232 Port and the MIDI Ports to be made.
MIDI EDIT. Enables you to select the operation in the OMNI ON mode or
to select the MIDI channel on which the OPTIMA will receive the program
data and control changes.
MEMORY. With this function you can verify how many memory locations
are free for the user to memorize hisfher presets, to modify the name of a
preset already memorized and to cancel preset already memorized.
AGC EDIT. This is the important function that enables the editing of the
parameters of the AGO (Automatic Gain Control) - the parameters are
listed in the TABLES section of this manual under EDITABLE
PARAMETERS - , to bypass the function or choose which of the 8 AGQ
presets to use, as an alternative to that selected automatically by the
presets that employs the function.
IN VOL. Means Input Volume and enables the adjustment of the gener.-3|
input volume of the OPTIMA.
OUT VOL. Means Output Volume and enables the adjustment of the
general output volume of the OPTIMA.
_ ____“
ll
I"l
I.
1|-1"-‘iii-_'I
III-
I‘!
J
‘I

W-'-*
6. TAB‘-ES
6.1 E
||-1 tI'l
l
FFECTS PRESETS
D
D3
AL
COMP RESSDR
SOFT 1
SOFT2
MEDIUM I
MEDIUM 2
STRONG 1
STRONG 2
ACOUSTIC
In
DRUM
VOCAL
SPEECH
iviui.Ti
CDlViPLE oi
COMPLE cs
COMF‘LE__D3
COMPLE D4
CDIVIPLE oe
DB
COMPLE DB
D?
COMPLE gr
DJ
G
COlVl_Fl|__E _os
Iii
COMPLE US
COM PLE 1D
uuueee
NUMBER
E Preset Mode, the display shows the number of the preset selected
{allowing tables show the type of effect that corresponds to each num
I ___LIl'.IIITEFI
C1‘ ClCl "'--I {J -A
$'3.‘.'§T 1
SOFT 2
MEDI_llI_Ivl 1
ber
ME_D_lUIvl 2
_ _s_Taoi~is 1
sraoivc 2
ACOUSTIC
DRUM
VOCAL
SPEECH
Nl.lMBER___ _ ENHAI“-ICER
D1
LOUDNESS 1
D2
D3
LOUDNESS 1
LOUDNESS 1
Louonessi
D4
D5 —E-
LOUDNESS 1
oe T
ENHANC D1
D? AIR VOCALS
DB" HIGH cut
_D9 .
H Low cur
10
I _DEI~.lDlSER ___
o1_
oz_
SOFT 1
_ SOFT e
E2’.
U4
MEDIUM 1
_ I\_i]_EDIUM_2'
O?
STRONG 1
STRON
TA
U1
lac
‘D '“ ci
I"l-J
VINYL
Fx 1 _
FX
KICK DRUM

6.2 PARAMETRI EDITABILI
COM PRESSORE
CONTROLLO VALORE
Dafla
:1: :o II I“ I“ _ '-
II _- T
oi CD ro isis -t=- rvi
!!!!!|!|!
e Limiter (Th ste corr)
R1 "it Limiter (Th ste corr Da O a 24
e t volume low band [)3 i) 5
e t volume hih band De [J 3 43
iht volume low band De 0 e
iht volume hi h band Da D a
Dada
Dafla
elease Da 0 a
LIMITER _
CDNTRDLLO vetoes
e Limiter Low (Th step corr) Da 0 a
e Limiter High (Th step corr) Da D a
DaOa
11'. :.'~:.'~ iR:r::i:
"3 -.
j3'_
In u:i‘ _.
-I-L_L mm —P'-Iin-Iii-I5-DDDJTHJPO ---.|--..|l'.'.Dt'..iJ CDCDODOD-Ii--I5-I51-Iii-
I ht Limiter Low (Th step corr)
ight Limiter High (Th step corr) Da O a
e volume low band De El H
e volume hih band DH U H
iht volume low band DB I3 =3
iht volume hih band DA U A
MIX
VALORE
ODNTROLLO
eft Limiter (Th step corr) Da D a 24
I ht Limiter (Th step,corr) Da O a 24
eft enhancer Da -3 a +
I ht enhancer Da -3 a +
eh Noise Gate Da D a
i ht Noise Gate Da U a
ttacl-z Da O a 27
DaOa
—I
Cf
reshold
e ease Da O a B0
14
_____€

II-""’“
l
EH HANGER
CUNTHDLLO vetoes
° Da0a1
TI UI II: 2
ffect A/=1 Da O a 12
A DaDa
in-It
.12
U
I-_m
e ay Effect is 12
etdelay DaOa12
Da -3 a +
OO '1' O D to ci
I tor parametrico di ingresso
2 I tor parametrico di ingresso Da -3 a +
itor parametrico diingresso Da-3-a+
4 filtor parametricodiingresso Da-3a+
l1OI' parametrico di ingresso Da -3 a +
B filtor parametrico di ingresso Da -3 a +
I tor parametrico di ingresso Da -3 a +
B filtor parametrico di ingresso Da -3 a +
DENOISER
CDNTRDLLO vetus
e Threshold Da D a
I htThreshold Da O a 71
e Release Da O a 1
Right Release Da D a 27
eff Attack Da 0 a
I htAttack Da O a 12?
I tri HP e LP destri e sinistri Da -3 a +
T!
A I
1-r I] I I=- G") E-O II i-
_ ~—- II - '_ in‘
,_,. . E. 1- __ :__..
' _.i. _i.
. fie "-~I '--.l
AGC
CDNTRDLLD vetoes
atus
EIII"I DalIla1DD
Da D a IUD
reshold Datll a Isteresi
E SEISE Da Isteresi a ‘I2?
S BTBSI Da Threshold Release
Dab 4
‘I5

____€
7. TECHNICAL CHARACTERISTICS
ANALOG INPUTS
Connectors: KLR and 11'4" jack
Type: RF Filter, balanced Input
Impedance: 40 IiOhm balanced, 20 kOhm unbalanced
Nominal Operating Level: ~1DdBV to +4dBu
Maximum Input Level: +14 dE-lu
ANALOG OUTPUTS
Connectors: XLR and 11'4" iack
Type: RF Filter, balanced Output
Impedance: ED Ohm balanced. 40 Ohm unbalanced
Maximum Output Level: +14 dBu
SYSTEM SPECIFICATIONS
Bandpass: ED Hz - so kHz, +i'- 0.5 dB
Noise: :=- - SD dB
THD + Noise: D.D4'=lti O D dB, 1 kHz
Crosstalk: -i: - BD dB
INTERFACES
MIDI: 5 pin DIN Connectors, IN i’ OUT if THRU
Serial. RS232, 9-pole male connector
Expansion: 26-pole Female Connector
DIGITAL ELABOFIATION _ _ _ _ _ .
LISP Prijigeeeigir: AIJIIIIOI 24 hit, CDBIIIOIBFIIS. SEDDII
~ I AG‘-OP A tomatic Gain Contr ) _
§§L'i.§§§.l-',?" so bit 5[Igl'TIEi-EIBIIEI, oversampling 64.1128 times
Sampling Frequency: 43 KHZ
DISPI-RY .
Type; 3 CI'IEII'EtCI.EI' LED DISDIHY
v REOUIREMENTS
53:9? SUPPL ioo-12o v ec. 2oo-24o v ec. so-so Hz
Power Consumption: 1'3 Walls
Power Connector: Standard IEC connector
PHYSICAL SPECIFICATIONS
Size (H x L x D): 44 x 483x EDD mm.
Weight: 1-5 kg
ETEK ie eiweye eirivirig to improve the quality of its products. Consequently. it resenres the right to
modify the specifications of any products in the line that have already been released onto the market,
wiihciii previous notice. Specifications and external appearance can therefore differ from the those
iflustrated in the present documents-
(c) 2000 ETEK. Printed in China
16
-I
I
.+-E.-*1‘-Pt
-‘I-T‘ i-"=s-Si-iii‘-iii »:£‘L'§3lE-~'1fl-
.-I-. _.iI|__i-.iI _l.n.
I
‘I
-1

1- 4 '
1 I "
-I I '
1 1* "
1 I P’
I I I
I ‘I I
I .1 I
I l' I
I I P
1 1 1
1 1| I
1 I I
1 .1 1
1 1- Iii
I I I
.1 1 I
1. 1 1
1 1 I
II 1| I-
1 1 I
I 1 1
1 1- I
I-
I'll".-‘Ii'--"Fl".---‘Ii.--I§I|IIfIi
-Illllriii
ill-ii-Iiii
l'i|I'I1'I-I1
lII|I1IlI-I1-I-1
I-1111-11-1
I-1--I-11111
111111.11
1111111-1
1-11-1111-1
Illililir
I- i I i j -p Q
I I I I i i Q
1- 1 1 .1 1 1 1 .1
1 1- 1 1- 1 1- 1 1-
1 1 1 1 1 1 1 1
1 1 1 1 1- 1 1. 1
1- 1 1 1 1 1 1 1
1 1- 1 1- 1 1 1 1
I 1 1- 1 1- I 1- 1
-I 1 I 1| 1 |- 1 1
1 1 1 1 1 1 1 1
1 1 1- 1 1- 1 1 1
1 1 1 1 1 1 1 1
Notes
.1 1 {I 1 .1 1. .1 1- 1 I 1 ll II
-II -i II I 1 I I -l' I I I IF ‘F’
1| I 1- I 1 1 ii -ll I -I I - *
1 .1 1- 1 1- 1- I 1 I’ I I II '-
1 1 1- 1 1 1- I I I I I I‘ "
1- 1 1- 1 I 1| 1 I -I l' I " I
1 1 .1 1 I 1- 1 I -I I I 1' "'
1 1 .1 1 I 1- 1 1 i I P F I’
1 1 1- 1 1- I 1 I -I 1- I - I’
1 1 1- 1 1| 1- 1 I 1| I I 'l' I’
1 1 1 1 1 1- 1 I -II I I I "
1 I1 1 1 -1 1- I I -I I I ‘I "
.1 1 1 1 1- 1 1 -1 1- I ll I I‘
.1 1 1 1- 1- 1 I 1- I I II I 1'
1 1 1 1 1 -I 1 I 1- I -i I 'l'
1 1 1| I 1 I I I 1| I -I 'l' I‘
1 1- 1 1 1- 1 I 1- 1 IIII
1- 1 1 1- I I I 1 I i II I I
1 1| 1- I I 1' III l' i l' I-
1 1 1 1 111 1 1- 1 1 I I
1 1 -1 1 1 1- 1 1 1 I 1- 1- I
1 1- 1 1 1 1 1 1- 1 1 I i II
1 1 .|- 1 1 1 1 1 1 1 1- 1- 1
17

I’
i-ii|¢|i--__-i_j-I
' iii-I "I K;
World Wide Music
Corsu Persiani, 77 - 62019 Hecanati (MC) Italy
www.etekengineering.c0m
[email protected]
