Panasonic ET-MDNHM10 User manual

Read before use
The “Operating Instructions” explains about the interface boards to be
installed to a Panasonic display device (projector or  at panel display).
For Model No. and model names, refer to the product list (x page 4).
Thank you for purchasing this Panasonic product.
■Before using this product, please read these “Operating Instructions” and
the “Operating Instructions” of the display device carefully and save the
manuals for future use.
■Before using this product, be sure to read “Read this  rst!” (x page 3).
TQZJ729-2
Printed in China
Interface Board Commercial Use
Operating Instructions
ENGLISH
Model No. ET-MDNHM10
ET-MDNDV10
* The illustration above is an example. In this manual, illustrations of ET-MDNHM10
are used as an example unless otherwise speci ed.
ENGLISH
FRANÇAIS

2 - ENGLISH
Contents
Contents
Read this rst! 3
Precautions for use 4
Products list 4
Supported display device 4
About the handling of the product 4
Disposal 5
Accessories 5
Part names and functions 5
Installing the Interface Board 6
Before installing or removing the Interface Board 6
How to install the Interface Board 7
How to remove the Interface Board 8
Specications 9
rTrademarks
fThe terms HDMI and HDMI High-Denition Multimedia Interface, and the
HDMI Logo are trademarks or registered trademarks of HDMI Licensing
Administrator, Inc. in the United States and other countries.

ENGLISH - 3
Read this rst!
Read this rst!
WARNING:
Do not spill water on this product or allow this product to get wet.
Doing so may cause re, electric shock, or malfunction due to short circuit
or overheating.
fDo not place a container with liquid close to this product.
fConsult your dealer when liquid such as water is spilled on this
product.
Do not place the supplied screws in a location that a child can reach.
Accidentally swallowing them can cause a physical harm.
fSeek a medical advice immediately if a child might have swallowed a
screw.
Do not disassemble or modify.
Doing so may cause electric shock or re. It may also cause a malfunction.
Ask the qualied technician or your dealer to install or remove this
product to/from the at panel display.
Failure to do so may cause electric shock. It may also cause a
malfunction.
Turn o󰀨 the power and disconnect the power plug from the outlet
when installing or removing this product to/from the at panel
display.
Failure to do so may cause electric shock.
CAUTION:
Do not place this product in a location with excessive humidity or
dust, or in a location exposed to oil smoke or steam.
Doing so may cause re or electric shock.
Do not place this product in extremely hot location.
Doing so may deteriorate the part, or may cause re.
fDo not install or store in a location with direct sunlight or close to the
heating device, etc.
Turn o󰀨 the power and disconnect the power plug from the outlet
when installing or removing this product to/from the projector.
Failure to do so may cause electric shock.
Importer’s name and address within the European Union
Panasonic Marketing Europe GmbH
Panasonic Testing Centre
Winsbergring 15, 22525 Hamburg, Germany

Precautions for use
4 - ENGLISH
Precautions for use
Products list
The product names and their Model Nos. described in this document are as
follows.
Product name Product Model No. Remark
Interface Board for HDMI
2 input ET-MDNHM10 An Interface Board equipped with 2 HDMI inputs.
Interface Board for DVI-D
2 input ET-MDNDV10 An Interface Board equipped with 2 DVI-D inputs.
Supported display device
The display device (projector or at panel display) supported by the Interface
Board described in this document is as follows.
(As of March 2019)
Projector PT-RQ13K, PT-RQ32K, PT-RQ22K
Flat panel display (Support to be determined)
Note
fThe model not described in the table may also be supported. Refer to the Operating
Instructions of your display device.
About the handling of the product
rDo not touch the connector section of the Interface Board
directly with your hands.
The component may be damaged by the static electricity. Handle this
product after removing the static in your body by touching the surrounding
metal, etc.
rAsk a qualied technician to install or remove to/from the at
panel display.
There is a danger of electric shock or a malfunction may occur due to static
electricity. Consult your dealer.

Precautions for use
ENGLISH - 5
Disposal
To dispose of the product, ask your local authorities or dealer for correct
methods of disposal.
Accessories
Make sure that the following accessories are provided with your product.
Numbers enclosed in < > show the number of accessories.
Screw <4>
(XSB3+8FN)
Attention
fAppropriately discard the packaging material after unpacking the product.
fFor missing accessories, consult your dealer.
fStore small parts in an appropriate manner, and keep them away from small children.
Note
fThe supplied screws are spare. Use them when a screw to x the slot cover of the display
device is lost.
fThe model numbers of accessories are subject to change without prior notice.
Part names and functions
rInterface Board for HDMI 2 input (Model No.: ET‑MDNHM10)
13 32
1 <HDMI IN 1> terminal (when installed
in <SLOT 1> of the display device),
<HDMI IN 3> terminal (when installed
in <SLOT 2> of the display device)
This is a terminal to input the HDMI
signal.
2 <HDMI IN 2> terminal (when installed
in <SLOT 1> of the display device),
<HDMI IN 4> terminal (when installed
in <SLOT 2> of the display device)
This is a terminal to input the HDMI
signal.
3 Handle

Installing the Interface Board
6 - ENGLISH
rInterface Board for DVI‑D 2 input (Model No.: ET‑MDNDV10)
13 32
1 <DVI‑D IN 1> terminal (when installed
in <SLOT 1> of the display device),
<DVI‑D IN 3> terminal (when installed
in <SLOT 2> of the display device)
This is a terminal to input the DVI-D
signal.
2 <DVI‑D IN 2> terminal (when installed
in <SLOT 1> of the display device),
<DVI‑D IN 4> terminal (when installed
in <SLOT 2> of the display device)
This is a terminal to input the DVI-D
signal.
3 Handle
Installing the Interface Board
It is recommended to ask a qualied technician to install or remove the
Interface Board to a projector. A malfunction may occur due to static
electricity. Consult your dealer.
Ask a qualied technician to install or remove the Interface Board to/from a
at panel display. There is a danger of electric shock or a malfunction may
occur due to static electricity. Consult your dealer.
Before installing or removing the Interface Board
fAlways turn o󰀨 the power of the display device (projector or at panel
display) before installing or removing the Interface Board.
gMake sure to follow the procedure described in the Operating
Instructions of your display device when turning o󰀨 the power.
fDo not touch the connector section of the Interface Board directly with your
hands.
gThe component may be damaged by the static electricity.
fRemove the static charge from your body by touching the surrounding
metal, etc., in advance to prevent the static electricity damage.
fTake care not to get injured when installing or removing the Interface
Board.
gHands may be injured by the opening of the blank slot of the display
device or the edge of the bracket of the Interface Board.
fWhen installing the Interface Board to the slot, insert it into the connector
straight and slowly.
gIt may not operate or cause malfunction if it is not correctly installed.

Installing the Interface Board
ENGLISH - 7
fThe gure indicating the installation and removal of the Interface Board is
using the combination of the Interface Board for HDMI 2 input (Model No.:
ET-MDNHM10) and the optional projector (Model No.: PT-RQ13K) as an
example. Illustration of this document may vary from the actual product.
fThe details of the installation or removal may be di󰀨erent depending on the
display device, so conrm the Operating Instructions of your display device
too.
How to install the Interface Board
Screws (4 locations) Screws (4 locations)Salient
Guide grooveSlot cover
Fig. 1 Fig. 2 Fig. 3
1) Remove the slot cover. (Fig. 1)
fRemove the four screws xing the slot cover of the display by rotating
counterclockwise with a Phillips screwdriver. The removed screws are
used to x the Interface Board.
fWhen removing the fourth screw, hold the slot cover with your hand so
it will not fall.
fTo replace from other Interface Board, remove the Interface Board
following the procedure in “How to remove the Interface Board”
(x page 8).
2) Install the Interface Board to the display device. (Fig. 2)
fInsert the guide groove of the Interface Board aligned to the salient of
the slot. Insert the bracket rmly all the way in.
3) Fix the Interface Board. (Fig. 3)
fTighten and x with the four screws removed in Step 1).
Attention
fThe removed slot cover is required when the unnecessary Interface Board is removed. Store
it so it can be attached in the future.

Installing the Interface Board
8 - ENGLISH
How to remove the Interface Board
Handle
Fig. 1
1) Remove the Interface Board. (Fig. 1)
fRemove the four screws xing the Interface Board by rotating
counterclockwise with a Phillips screwdriver. The removed screws are
used to x the slot cover.
fHold the handle of the Interface Board and remove it slowly.
2) Attach the slot cover.
fAttach the stored slot cover to the blank slot, and tighten and x with
the four screws removed in Step 1).
fTo replace with other Interface Board, attach the Interface Board
following the procedure in “How to install the Interface Board”
(x page 7).
Attention
fAlways attach the slot cover on the blank slot.
fStore the removed Interface Board inside an antistatic bag.

Specications
ENGLISH - 9
Specications
The specications of the Interface Board are as follows.
rInterface Board for HDMI 2 input (Model No.: ET‑MDNHM10)
Compatible slot SLOT NX specication
Connecting terminal 2 sets, HDMI 19p, HDCP 2.2 compatible, Deep Color
compatible
Compatible
signal
Resolution
Moving image signal: 480i*1/576i*1 to 4 096 x 2 160
Still image signal: 640 x 400 to 3 840 x 2 400 (non-
interlace)
Dot clock
frequency 25 MHz to 594 MHz
Dimensions
Width 151 mm (5-15/16")
Height 38.5 mm (1-17/32")
Depth 142 mm (5-19/32")
Weight 340 ] (12.0 ozs.)
*1 Pixel-Repetition signal (dot clock frequency 27.0 MHz) only
rInterface Board for DVI‑D 2 input (Model No.: ET‑MDNDV10)
Compatible slot SLOT NX specication
Connecting terminal 2 sets, DVI-D 24p, DVI 1.0 compliant (only single link
supported), HDCP compatible
Compatible
signal
Resolution
Moving image signal: 480i*1/576i*1 to 2 048 x 1 080
Still image signal: 640 x 400 to 1 920 x 1 200 (non-
interlace)
Dot clock
frequency 25 MHz to 162 MHz
Dimensions
Width 151 mm (5-15/16")
Height 38.5 mm (1-17/32")
Depth 142 mm (5-19/32")
Weight 350 ] (12.3 ozs.)
*1 Pixel-Repetition signal (dot clock frequency 27.0 MHz) only
Note
f“SLOT NX” is a name of the slot unique to Panasonic supporting the signal input for the 4K
image.
fThe video signal that can actually display will vary depending on the display device (projector
or at panel display) that the Interface Board is installed. For details, refer to the Operating
Instructions of your display device.

Product Information (for Turkey only)
AEEE Yönetmeliğine Uygundur.
Eski Ekipman ve Bataryaların İşlenmesi.
Sadece geri dönüşüm sistemleri olan Avrupa Birliği ve
ülkeleri için geçerlidir.
Ürünler, ambalaj ve/veya ekli belgeler üzerindeki bu
semboller kullanılmış elektrik ve elektronik ürünlerin genel
ev atığı ile karıştırılmaması gerektiğini ifade eder.
Eski ürünlerin toplanması ve geri kazanılması için bu atıkları
lütfen yasayla belirlenmiş olan uygun toplama merkezlerine
teslim ediniz.
Bu atıkların doğru işlenmesiyle, değerli kaynakların
korunmasına ve insan sağlığı ve çevreye olası negatif
etkilerinin engellenmesine yardımcı olabilirsiniz.
Atıkların toplanması ve geri dönüşümü için detaylı bilgi için
lütfen bağlı olduğunuz yerel yönetimlerle iletişime geçiniz.
Atıkların atılmasıyla ilgili yanlış uygulamalar yasayla
belirlenmiş olan cezalara sebebiyet verebilir.
TI1115NK2039 -PJ
Printed in China
Panasonic System Solutions Company of North America
Two Riverfront Plaza, Newark, NJ 07102
TEL: (877) 803 - 8492
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3
TEL: (905) 624 - 5010
Panasonic Corporation
Web Site : https://panasonic.net/cns/projector/
© Panasonic Corporation 2015
