Blood Pressure Monitor
Blutdruckmessgerät
User Manual | Bedienungsanleitung
Model | Modell: B22
EN DE Français
Español
Italiano

2
Table of Contents
Package Contents
Specifications
Safety Information
Function Diagram
Display Diagram Indicators
Getting to Know Your Blood Pressure Monitor
Information on Blood Pressure
- More Information on Blood Pressure Values
Blood Pressure Monitor Settings
- Selecting a User
- Memory
- Setting the Date and Time
- Adjusting the Speaker Volume
Using the Blood Pressure Monitor
- Batteries and Power Cable Instructions
· Batteries
· Micro USB Power Cable
- When to Take Blood Pressure
- Before Measurement
- Blood Pressure Measurement Instructions
4
4
7
10
11
12
12
16
16
16
16
17
17
18
18
18
18
18
19
20
22
22
22
22
23
25
25
25
26
26
26
27
28
29
30
41
41
42
Display Readings
- Cuff Placement Indicators
- Movement Error Indicator
- Irregular Heartbeat Indicator
Display Error Readings
Maintenance
- Handling
- Replacing Batteries
- Cleaning the Monitor
- Cleaning the Cuff
- Storage
Frequently Asked Questions
Certifications
Symbol Descriptions
EMC Declaration
Warranty Card
Warranty Information
Customer Support
EN

3
Inhaltsverzeichnis
DE
Lieferumfang
Technische Daten
Sicherheitshinweise
Funktionsdiagramm
Anzeigen auf dem Display
Ihr Blutdruckmessgerät
Über den Blutdruck
- Weitere Informationen zu Blutdruckwerten
Einstellungen am Blutdruckmessgerät
- Benutzer auswählen
- Speicher
- Datum und Uhrzeit einstellen
- Lautsprecherlautstärke einstellen
Benutzung des Blutdruckmessgeräts
- Hinweise zu Batterien und Netzkabeln
· Batterien
· Micro-USB-Netzkabel
- Wann sollte der Blutdruck gemessen werden
- Vor der Messung
- Anleitung zur Blutdruckmessung
5
5
44
47
48
49
49
53
53
53
54
54
55
55
55
55
55
56
56
58
60
60
60
60
61
62
62
62
63
63
64
64
65
66
Displayanzeigen
- Anzeigesymbole für die
Manschettenposition
- Fehlermeldung bei Bewegung
- Anzeige eines unregelmäßigen
Herzschlags
Display-Fehleranzeigen
Wartung
- Handhabung
- Auswechseln der Batterien
- Reinigung des Geräts
- Reinigung der Manschette
- Lagerung
Häufig gestellte Fragen
Garantie
Kundendienst

4
EN
Specifications
Measurement Range
Pressure: 0–280 mmHg
Pulse: 40–199 per minute
Cuff Pressure: 0–299 mmHg
Accuracy Pressure: ±3 mmHg
Pulse: ±5%
Units mmHg
Dimensions
Monitor: 11.9 x 11 x 5.3 cm / 4.7 x 4.3 x 2.1 in
Display: 9.4 x 6.4 cm / 3.7 x 2.5 in
Cuff Circumference: 22–40 cm / 8.7–15.7 in
Weight 429 g / 0.95 lb
Operating Environment
Temperature: 5°–40°C / 41°–104°F
Relative Humidity: 15–93%
Pressure: 525–795 mmHg / 70–106 kPa
Transport and Storage
Environment
Temperature: -25°–70°C / -13°–131°F
Relative Humidity: 10–93%
Pressure: 525–795 mmHg / 70–106 kPa
Power Supply 4 x 1.5 V AAA batteries, DC 6V
DC Output: 5V, 1A
Automatic Shutoff 60 seconds
1 x Blood Pressure Monitor
1 x Arm Cuff
4 x 1.5V AAA Batteries
1 x Micro USB Power Cable
1 x Storage Bag
1 x User Manual
1 x Quick Start Guide
Package Contents
EN

5
EN
Technische Daten
Messbereich:
Druck: 0–280 mmHg
Puls: 40–199 Schläge pro Minute
Manschettendruck: 0–299 mmHg
Genauigkeit Druck: ± 3 mmHg
Puls: ± 5 %
Einheiten mmHg
Abmessungen
Gerät: 11,9 x 11 x 5,3 cm / 4,7 x 4,3 x 2,1 Zoll
Display: 9,4 x 6,4 cm / 3,7 x 2,5 Zoll
Manschettenumfang: 22–40 cm / 8,7–15,7 Zoll
Gewicht 429 g / 0,95 lb
Betriebsumgebung
Temperatur: 5–40 °C / 41–104 °F
Relative Feuchtigkeit: 15–93 %
Druck: 525–795 mmHg / 70–106 kPa
Transport- und
Lagerumgebung
Temperatur: -25–70 °C / -13–131 °F
Relative Feuchtigkeit: 10–93 %
Druck: 525–795 mmHg / 70–106 kPa
Stromversorgung 4 1,5 V AAA-Batterien, 6 V DC
DC-Ausgang: 5 V, 1 A
Automatisches
Abschalten
60 Sekunden
1 Blutdruckmessgerät
1 Armmanschette
4 1,5 V AAA-Batterien
1 Micro-USB-Netzkabel
1 Aufbewahrungsbeutel
1 Benutzerhandbuch
1 Kurzanleitung
Lieferumfang
DE

6
EN
Thank you for purchasing the
Blood Pressure Monitor by Etekcity.
If you have any questions or concerns, please
reach out to our helpful Customer Support Team at
[e-mail]. We hope you enjoy your
new blood pressure monitor!
BECOME AN ETEKCITIZEN
Get exclusive deals, giveaways, and product
registration. Better products for better living.
Find us at etekcity.com
ENGLISH • Blood Pressure Monitor B22
EN

7
EN
Safety Information
• If the arm cuff causes any discomfort, immediately press
to turn off the monitor.
• The monitor is not intended to be a diagnostic device.
The results are for reference only and cannot substitute
for a doctor’s diagnosis. Only a healthcare professional
is qualified to interpret blood pressure measurements.
• Consult your physician before using if you have any
of the following conditions: advanced age, common
arrhythmias (such as atrial or ventricular premature
beats or atrial fibrillation), arteriosclerosis, diabetes,
poor perfusion, pregnancy, pre-eclampsia, or renal
diseases.
Please read and follow all instructions and safety
guidelines in this manual.
Warning: Indicates a potentially hazardous situation
which, if not avoided, could result in death or serious injury.
• In cases of irregular heartbeat (arrhythmia),
measurements made with this blood pressure monitor
should only be evaluated after consulting with your
healthcare professional.
• Consult your physician before using on an arm with an
arterio-venous (A-V) shunt.
• Do not use the arm cuff on an arm that is injured or
undergoing medical treatment.
• Do not use the arm cuff on an arm that currently has
an intravenous drip or blood transfusion.
• Do not use the monitor at the same time as other
medical electrical (ME) equipment.
• Do not use the monitor near HF surgical equipment,
MRI, CT scanners, flammable anesthetic mixtures such
as nitrous oxide (laughing gas), or in an oxygen-rich
environment.
• Closely supervise children near the monitor. Do not
allow children to use or play with this monitor.
• Keep out of reach of children and pets. The monitor
may be damaged, and contains small pieces that may
be swallowed, and the air hose and power cable may
cause strangulation.
• Do not drape air hose around your neck.
• This monitor is intended for adults only. Consult your
doctor before using this monitor on children. Do not
use on infants.
• Never alter the dosages of drugs prescribed by your
doctor. Blood pressure readings obtained by this
monitor should be verified before prescribing or
Contraindication: Using this monitor on patients
undergoing dialysis therapy or on anticoagulants,
antiplatelets, or steroids could cause internal bleeding.
!
CAUTION

8
EN
adjusting medication used to control hypertension (or
any other reason).
• Make sure the monitor is working correctly and not
damaged before using.
• Do not make any modifications or repairs yourself. If
you have any questions, contact Customer Support
(see page 42).
• This monitor should not be serviced or maintained
while using on a patient.
• People with severe blood flow problems or blood
disorders should consult a physician before using the
monitor, as the arm cuff inflation can cause bruising.
• Consult your physician before using the monitor if you
have had a mastectomy.
• Do not take measurements more than necessary. It
may cause bruising due to blood flow interference.
• Do not use the monitor for any purpose other than
measuring blood pressure.
• Do not use the monitor to check the frequency of heart
pacemakers.
• Only use the approved arm cuff for this monitor.
Use of third-party arm cuffs may result in incorrect
measurements.
Caution: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury to the user or patient, or damage to the equipment or
other property.
• Do not store in any place that is tilted, vibrates, or can
damage the monitor.
• Do not store near chemicals or corrosive gases.
• Keep away from heat sources and direct sunlight.
• Do not leave the monitor exposed to any chemical
solvent, lint, or dust.
• Do not get the monitor wet or use in a wet or humid
environment. This may damage the monitor.
• Only use, transport, and store the monitor within
the required temperature and humidity ranges (see
page 4). If the temperature and humidity are
outside these ranges, the measurement results may be
inaccurate.
• Do not hit or drop the monitor.
• Do not use the monitor in a moving vehicle, such as a
car or an airplane.
• When appears, replace the batteries.
• Only use a micro USB power cable that meets the
requirements for the monitor
(see page 18).
Note: A separate micro USB power cable used with this
monitor has not been evaluated according to IEC 60601-1.
The safety of the monitor shall be reappraised when it is
powered by a separate power cable.

9
EN
SAVE THESE
INSTRUCTIONS
• This monitor is not intended to replace regular medical
checkups.
• We recommend your physician review your procedure
for using this monitor.
• Do not use the monitor near a mobile phone,
microwave oven, or any other device that emits
electromagnetic fields. This can lead to incorrect
readings.
• Always remove the batteries if the monitor is not likely
to be used for 1 week or more.
Safety Notes:
• This monitor is safe for a patient to use on themselves
for monitoring blood pressure and pulse rate. A patient
can also perform routine cleaning and changing
batteries.
• The standard material used for the cuff and hose is
latex-free.

10
EN
A. Display
B. Air Hose
C. Artery Mark
D. Air Plug
E. Cuff
F. Micro USB Power Cable
G. Memory Button
H. Start/Stop Button
I. Set Button
J. Micro USB Power Socket
K. Battery Compartment
L. Air Port
M. Speaker
Function Diagram
E
B
F
M
D
J
HI
G
A
L
K
C

11
EN
SYS
mmHg
DIA
PULSE
AVG.
/min MNO.
mmHg
AB
A. Systolic Blood Pressure
B. Diastolic Blood Pressure
C. Pulse
D. Irregular Heartbeat
E. Memory
F. Date/Time
G. User A
H. User B
I. Movement Error
J. Mute
K. Average Value
L. Heartbeat
M. Battery
N. Cuff Status
O. WHO Blood Pressure Evaluation
Indicator
Display Diagram Indicators
B
D
C
E
F
G H I J MK L
N
O
A

12
EN
Getting to Know Your
Blood Pressure Monitor Information on Blood Pressure
Blood pressure monitors use the oscillometric method of
measuring blood pressure. The monitor can detect the
blood’s movement through the brachial artery and convert
it into a digital reading. The monitor is easy and simple to
use and does not require a stethoscope.
This monitor has many useful features such as a speaking
function with volume adjustment, 2 users that can save 120
measurements each, a cuff
self-check indicator, average value indicator, irregular
heartbeat indicator, WHO indicator, and external power
socket support.
Your blood pressure level is determined in the circulatory
center of your brain and adjusts to a variety of situations
through feedback from the nervous system. To adjust
blood pressure, the strength and speed of your heart (your
pulse) and the width of your circulatory blood vessels are
altered. Blood vessel width is controlled by fine muscles in
the blood vessel walls. Your level of arterial blood pressure
changes periodically during heart activity. During “blood
ejection” from the heart (systole), pressure is highest
(systolic blood pressure value / SYS). At the end of the
heart’s “rest period” (diastole), pressure is lowest (diastolic
blood pressure value / DIA). Blood pressure values must lie
within certain normal ranges in order to prevent particular
diseases.

13
EN
Optimal blood
pressure
(target value)
Normal blood pressure
High normal value
Mild hypertension
Moderate hypertension
Severe hypertension
120
80
85
90
100
110
130 140 160 180
Diastolic blood
pressure (mmHg)
Systolic blood
pressure (mmHg)

14
EN
There are 6 WHO (World Health Organization) Indicator levels that can be displayed on the monitor and represent different
blood pressure values and classifications.
Blood Pressure Value WHO Indicator Level WHO Classification
DIA <80 & SYS <120 1 Optimal blood pressure
DIA <85 & SYS <130 2 Normal blood pressure
DIA <90 & SYS <140 3 High normal value
DIA <100 & SYS < 160 4 Mild hypertension
DIA <110 & SYS <180 5 Moderate hypertension
DIA >=110 or SYS >=180 6 Severe hypertension

15
EN
Blood pressure is very high if your diastolic pressure is
above 90 mmHg and/or your systolic blood pressure is
over 160 mmHg, while at rest. In this case, please consult
your physician immediately. Long-term values at this level
endanger your health due to continual damage to the blood
vessels in your body.
If you have blood pressure values that are too high, (such
as systolic values between 140 mmHg and 159 mmHg and/
or under diastolic blood pressure values between 90 mmHg
and 99mmHg), consult your physician.
If you have blood pressure values that are too low, (such
as systolic values under 105 mmHg and/or diastolic values
under 60 mmHg), consult your physician.
Even with normal blood pressure values, a regular self-
check with your blood pressure monitor is recommended.
You can detect possible changes in your values early
and react appropriately. If you are undergoing medical
treatment to control your blood pressure, keep a record of
values along with time of day and date. Show these values
to your physician.
Caution: Never use the results of your measurements
to independently alter the drug doses prescribed by your
physician.
Note:
• If your values are mostly normal under resting
conditions but exceptionally high under conditions of
physical or psychological stress, you may be suffering
from “labile hypertension”. Consult your physician.
• Correctly measured diastolic blood pressure value
above 120mmHg require immediate medical treatment.

16
EN
More Information on Blood Pressure Values
• Increased blood pressure values (various forms of
hypertension) are associated with considerable health
risks over time. Arterial blood vessels in your body are
endangered due to constriction caused by deposits in
the vessel walls (arteriosclerosis). A deficient supply of
blood to important organs (heart, brain, muscles) can
result from arteriosclerosis. Furthermore, the heart
will become structurally damaged with increased blood
pressure values.
• There are many different causes of high blood pressure.
We differentiate between the common primary
(essential) hypertension, and secondary hypertension.
The latter group can be ascribed to specific organ
malfunctions. Please consult your physician for
information about the possible origins of your own
increased blood pressure values.
• There are measures which you can take to reduce
and even prevent high blood pressure. Consult your
physician.
Memory
Selecting a User
To view saved results:
1. Select a user.
2. While the monitor is off, press MEM to display the
average of the last 3 results.
3. Press MEM again to view each result, beginning
with the most recent measurement taken.
4. Press MEM again to view the next result.
5. Alternatively, press and hold MEM to scroll to any
result.
Results are automatically saved after each measurement.
The monitor can save up to 120 results for each user.
1. With the monitor off, press SET to show the current
user. The blood pressure monitor can store records for
2 users (A and B).
2. Press SET again to switch between User A and B.
Blood Pressure
Monitor Settings

17
EN
To delete all saved results:
1. Select a user.
2. Press MEM to display results.
3. Press and hold again until all measurements turn 0.
Note:
• You can’t delete individual results. All results will be
deleted at once.
• Taking out the batteries will not delete saved results.
However, it will reset some of your settings, such as
date, time, and speaker volume.
Setting the Date and Time
Adjusting the Speaker Volume
1. With the screen off, press and hold SET for 3 seconds
to show the year. The year will blink.
2. Press MEM to adjust the year.
3. Press SET again to show the month and date. Press
MEM to adjust the month and date.
4. Press SET again to show the time. Press MEM to adjust
the time.
5. Press SET to confirm.
1. With the screen off, press and hold SET for 3 seconds.
2. Press SET repeatedly until “SP” appears.
3. Press MEM to select volume level 1, 2, 3, or OFF.

18
EN
Batteries and Power Cable Instructions
Batteries
When to Take Blood Pressure
Micro USB Power Cable
1. Make sure the power cable is not damaged.
2. Plug the cable into the power socket on the right side of
the blood pressure monitor.
3. Plug the USB into a 5V powered USB port.
Using the
Blood Pressure Monitor
Unwrap and insert the 4 included 1.5V AAA batteries into
the monitor.
You may also use the monitor with the 5V micro USB power
cable. Only use an approved micro USB power cable to
avoid damaging the monitor.
Note: To replace batteries, see page 25.
Note:
• No battery power is consumed while the micro USB
power cable is plugged in.
• If electrical power is interrupted (such as by
accidentally unplugging the monitor from the power
socket), the monitor must be reset by removing the
power cable from the power socket on the monitor and
reinserting it.
• The best times to take your blood pressure are within 1
hour of waking in the morning or 1 hour before bedtime.
• When measuring in the morning, measure after
urinating and before eating breakfast.
• Always measure your blood pressure before taking
blood pressure medication.
• If you need to measure your blood pressure at another
time of day, make sure you are calm and stable before
measuring.
• Measure your blood pressure at the same time every
day. Blood pressure changes during the course of the
day, as much as 20–40 mmHg.

19
EN
Before Measurement
• If the monitor is being used by multiple people, wash
hands before each measurement.
• Sit on a chair with your feet flat on the floor and your
arms on the table so the cuff is level with your heart.
[Figure 1.1]
• Remove any clothing that fits closely to your upper
arm.
• Sit for at least 5 minutes in a comfortable, secure
environment before measurement.
• Your blood pressure should be measured sitting down.
Take note if your blood pressure is taken in a different
position.
• Take measurements on both arms the first time you
use the monitor to make sure it is calibrated and both
readings are similar.
• Take measurements on the same arm (normally left).
• Avoid any electromagnetic interference when taking
measurements.
• Avoid flexing arm muscles or trying to support your
arm, as this can increase blood pressure. Use a cushion
for support if necessary.
• If the arm artery lies considerably lower or higher than
the heart, the measurement may be incorrect. Each
25–30 cm difference in height between your heart and
the cuff results in a measurement error of 10 mmHg.
• Only use the included cuff.
• A loose or improperly fitted cuff will result in incorrect
measurements.
Figure 1.1

20
EN
Blood Pressure Measurement Instructions
• Do not measure blood pressure for at least 30
minutes after physical activity. Do not smoke or
drink stimulating beverages, such as coffee or
alcohol, before measuring.
• Blood pressure should be measured at intervals
of no less than 3 minutes, depending on your
physical condition.
• People with arrhythmia and/or arteriosclerosis
should be measured by medical staff for a
professional diagnosis.
• Avoid pressing the cuff to your body when taking
measurements.
!
CAUTION
1. Measure your arm circumference using a measuring tape
in the middle of your relaxed upper arm.
2. Plug the air plug on the cuff into the air port on the
monitor. Make sure the air plug is completely inserted to
avoid air leaking, but avoid forcing the plug into the port.
3. Wrap the cuff around your upper left arm with the air
cable on the inside of your arm. The rubber tube should
be on the inside of your arm extending downward to
your hand. The lower edge of the cuff should be placed
about 2–3 cm / 0.8–1.2 in above the elbow. [Figure 1.2]
The on the edge of the cuff must lie over the artery
which runs down the inner side of the arm.
4. Secure the cuff by wrapping it around your arm and
pressing the hook-and-loop fastener together. The band
should not be wrapped too tightly (leave space to insert
about 2 fingers).
5. Select a user (see page 16). Make sure the air hose
is not kinked.
6. Rest in a comfortable area for at least 5 minutes before
measuring to ensure the best results.
0.8–1.2 in / 2–3 cm
Figure 1.2
Note: Make sure the cuff is not placed in the power
socket. The air port is on the left side of the monitor
(see page 10).
