ETEKCITY EBP-UA5 User manual

1
Questions or Concerns? [email protected] • [phone]
Upper-Arm Blood
Pressure Monitor
User Manual
Model: EBP-UA5

2
Thank you for purchasing the
Upper-Arm Blood Pressure Monitor
by Etekcity.
If you have any questions or concerns, please
reach out to our helpful Customer Support
Team at [email protected]. We hope
you enjoy your new blood pressure monitor!
BECOME AN ETEKCITIZEN
Get exclusive deals, giveaways, and product
registration. Better products for better living.
Find us at etekcity.com

3
Table of Contents
Package Contents
Specifications
Safety Information
Function Diagram
Digital Diagram
Getting to Know Your Blood Pressure Monitor
- When to Take Blood Pressure
- Selecting a User
- Memory
- Turning the Speaker On/Off
- Changing Units
Before Measurment
Using the Blood Pressure Monitor
Display Readings
Blood Pressure Classification Table for Adults
Maintenance
Frequently Asked Questions
Glossary of Symbols
Warranty Information
Customer Support
3
4
5
7
8
9
9
9
10
10
11
11
12
14
15
16
18
19
28
30
1 x Blood Pressure Monitor
1 x Arm Cuff
1 x Type-C USB Charging Cable
1 x Storage Bag
1 x Quick Start Guide
Package Contents

4
Specifications
Measurement Range Pressure: 0–290 mmHg / 0–39 kPa
Pulse: 40–199 per minute
Accuracy Pressure: 3 mmHg / 0.4 kPa
Pulse: 5%
Units mmHg / kPa
Dimensions
Monitor: 4.9 x 4.5 x 2.8 in / 12.6 x 11.5 x 7.1 cm
Cuff: 24.5 x 5.9 in / 62 x 15 cm
Cuff Circumference: 8.7–16.5 in / 22–42 cm
Weight 0.9 lb / 405 g
Operating Environment Temperature: 41°–104°F / 5°–40°C
Relative Humidity: 15–80%
Transport and Storage
Environment
Temperature: -4°–131°F / -20°–55°C
Relative Humidity: 15–93%
Battery Type 3.7V, 800mAh Li-ion battery
Rated Power 5V 1A
Charging Time 3–4 hours
Automatic Shutoff 60 seconds

5
Safety Information
• If the arm cuff causes any discomfort,
immediately press to turn off the monitor.
• The monitor is not intended to be a diagnostic
device. Consult your physician before using if you
have any of the following conditions: advanced
age, common arrhythmias (such as atrial or
ventricular premature beats or atrial fibrillation),
arteriosclerosis, diabetes, poor perfusion,
pregnancy, pre-eclampsia, or renal diseases.
• Consult your physician before using on an arm
with an arterio-venous (A-V) shunt.
•Do not use the arm cuff on an arm that is injured
or undergoing medical treatment.
•Do not use the arm cuff on an arm that currently
has an intravenous drip or blood transfusion.
•Do not use the monitor at the same time as
other medical electrical (ME) equipment.
Please read and follow all instructions and safety
guidelines in this manual.
Warning: Indicates a potentially hazardous
situation which, if not avoided, could result in death
or serious injury.
•Do not use the monitor near HF surgical
equipment, MRI, CT scanner, or in an oxygen
rich environment.
• Closely supervise children near the monitor.
Do not allow children to use or play with this
monitor.
• Keep out of reach of children. The monitor
contains small pieces that may be swallowed
and the air hose and charging cable may cause
strangulation.
• This monitor is intended for adults only. Consult
your doctor before using this monitor on
children.
Caution: Indicates a potentially hazardous
situation which, if not avoided, may result in minor
or moderate injury to the user or patient, or damage
to the equipment or other property.
• People with severe blood flow problems or blood
disorders should consult a physician before
using the monitor, as the arm cuff inflation can
cause bruising.
• Consult your physician before using the monitor
if you have had a mastectomy.

6
•Do not take measurements more than
necessary. It may cause bruising due to blood
flow interference.
•Do not use the monitor for any purpose other
than measuring blood pressure.
•Only use the approved arm cuff for this monitor.
Use of third-party arm cuffs may result in
incorrect measurements.
•Do not get the monitor wet or use in a wet
or humid environment. This may damage the
monitor.
•Do not store in any place that is tilted, vibrates,
or can damage the monitor.
•Do not store near chemicals or corrosive gases.
• Keep away from heat sources and direct
sunlight.
•Do not leave the monitor exposed to any
chemical solvent, lint, or dust.
•Only use, transport, and store the monitor
within the required temperature and humidity
ranges (see page 4). If the temperature
and humidity go outside these ranges, the
measurement results may be inaccurate.
•Do not hit or drop the monitor.
•Do not use the monitor in a moving vehicle,
such as a car or an airplane.
•Do not use the monitor near a mobile phone
or any other device that emits electromagnetic
fields.
• When appears, charge the monitor with
the provided USB charging cable. Do not use the
monitor while it is charging.
•Only use the charging cable that meets the
requirements for the monitor (see page 16).
•Do not make any repairs yourself. If you have
any questions, contact Customer Support (see
page 30).
Safety Information (cont.)
SAVE THESE
INSTRUCTIONS

7
A. Display
B. Air Port
C. Type-C Charging Port
D. Set/User Button
E. Start/Stop Button
F. Memory Button
G. Air Plug
H. Air Hose
I. Type-C USB Charging Cable
J. Cuff
Function Diagram
A
B
C
H
J
D
E
F
I
G

8
A. Battery
B. User
C. Systolic Blood Pressure
D. Diastolic Blood Pressure
E. Irregular Heartbeat Indicator
F. Pulse
G. Cuff Status
H. WHO Indicator
Display Diagram
B
C
D
E
G
H
A
F

9
Getting to Know Your Blood Pressure Monitor
Blood pressure monitors use the oscillometric
method of measuring blood pressure. The monitor
can detect the blood’s movement through the
brachial artery and convert it into a digital reading.
The monitor is easy and simple to use and does not
require a stethoscope.
• The best times to take your blood pressure are
within 1 hour of waking in the morning or 1 hour
before bedtime.
• When measuring in the morning, measure after
urinating and before eating breakfast.
•Always measure your blood pressure before
taking blood pressure medication.
• If you need to measure your blood pressure at
another time of day, make sure you are calm
and stable before measuring.
• Measure your blood pressure at the same time
every day.
When to Take Blood Pressure
Selecting a User
To switch between user 1 and 2:
• With the monitor off, press to show the
current user and press again to change users.
The user number will flash to indicate your
selection.
Note: If no buttons are pushed within 3 seconds,
the monitor will turn off.

10
Memory Turning the Speaker On/Off
Results are automatically saved after each
measurement. The monitor can save up to 90
results for each user.
To view saved results:
1. Select a user.
2. While the monitor is off, press
to display the average of the last 3
results. Press again to view each
result, beginning with the most recent
measurement taken.
3. Press again to view the next result.
To delete all saved results:
1. Select a user.
2. While the monitor is off, press and hold
for more than 3 seconds. While still
holding , press .
3. Once “ALL EE” appears on the display, all
results for the user are being deleted.
1. While the monitor is off, press and hold
until the display reads “SP OFF”. [Figure 1.1]
2. Press to change the reading to “SP ON”
to turn the speaker on. [Figure 1.2]
3. Press again to change the reading to
“SP OFF” to turn the speaker off.
4. Press to confirm the setting.
Figure 1.1 Figure 1.2

11
Changing Units
1. While the monitor is off, press and hold
until the display reads “SP OFF” or “SP ON”.
2. Once it blinks 2 times, press again to
change it to “PA OFF” for mmHg.
3. Press to switch to “PA ON” for kPa.
[Figure 2.1]
4. Press to confirm your desired unit.
• Sit on a chair with your feet flat on the floor and
your arms on the table so the cuff is level with
your heart. [Figure 3.1]
• Make sure the air plug is inserted into the air
port.
Before Measurement
Figure 2.1
Figure 3.1

12
Caution
•Do not measure blood pressure until at least
30 minutes after physical activity. Do not drink
stimulating beverages, such as coffee or alcohol,
or smoke before measurement.
• Sit for at least 5 minutes in a comfortable,
secure environment before measurement.
• Your blood pressure should be measured sitting
down. Take note if your blood pressure is taken
in a different position.
• Take measurements on both arms the first time
you use the monitor to make sure it is calibrated
and both readings are similar.
• Blood pressure should be measured at intervals
of no less than 3 minutes, depending on your
physical condition.
• People with arrhythmia and/or arteriosclerosis
should be measured by medical staff for a
professional diagnosis.
• Avoid pressing the cuff to your body when
taking measurements.
• Avoid any electromagnetic interference when
taking measurements.
Using the Blood Pressure
Monitor
Note: Before first use, fully charge the blood
pressure monitor (see Charging the Battery,
page 16).
Note: Your upper arm should be bare or wearing
only thin material.
1. Rest in a comfortable area for at least 5 minutes
before measuring to ensure the best results.
2. Plug the cuff into the monitor. Make sure the air
plug is completely inserted to avoid air leaking.
3. Place the cuff on your upper left arm with the
air cable on the inside of your arm. The band
should not be wrapped too tightly (leave space
to insert about 2 fingers) and the lower edge
of the cuff should be about 0.8–1.2 in / 2–3 cm
away from your elbow. [Figure 4.1]
4. Select a user (see page 9).

13
5. Place your arms on a surface so the cuff is at
the same level as your heart. Your arms should
be in a relaxed, natural position.
6. Press to begin measuring. Relax and avoid
moving or talking while measuring. When the
measuring is finished, the results will display.
7. Wait 3 minutes before taking a second
measurement, if necessary.
Using the Blood Pressure Monitor (cont.)
Note:
• Press at any time to stop measuring.
• If the cuff causes any increased discomfort,
immediately press to turn off the monitor.
• Wait at least 3 minutes before measuring
again.
•Only use the air plug to connect or disconnect
the arm cuff. Do not pull on the air hose to
disconnect from the air plug.
• If the monitor cannot read your blood pressure
on your left arm, measure on your right arm.
Figure 4.1
0.8–1.2 in / 2–3 cm

14
Display Readings
Symbol Solution
Air may be leaking or pulse may be too weak. Reattach the cuff and test
again.
Blood pressure cannot be detected due to interference. Make sure you are
seated and positioned correctly before testing again.
The measurement result is not correct. Test again.
Inflation has failed. Check the cuff and test again.
Air pressure is too high. Test again.
Charge the monitor with the provided Type-C USB charging cable.
Remove the arm cuff and wait 2–3 minutes before taking another
measurement. If this error continues to appear, contact your physician.

15
Blood Pressure Classification Table for Adults
BP Classification Systolic (mmHg) Diastolic (mmHg)
BP Classification
Normal Blood
Pressure <120 and <80
Elevated Blood
Pressure 120–129 and <80
Hypertension:
Stage 1 130–139 or 80–89
Hypertension:
Stage 2 ≥140 or ≥90
Hypertensive
Crises
Hypertensive
Urgency >180 and/
or >120
Hypertensive
Emergency
>180+ target organ
damage
and/
or
>120+ target organ
damage
According to the 2017 Guideline for the Prevention, Detection, Evaluation and Management of High
Blood Pressure in Adults, there are 4 levels for blood pressure classification and 2 hypertensive crises:
emergencies and urgencies.

16
Charging the Battery
Maintenance
The blood pressure monitor comes with a
rechargeable Li-ion battery inside. Use the included
Type-C USB cable to charge the monitor. will
appear on the screen when the monitor needs to be
charged.
1. Insert the USB charging cable into the USB
charging socket on the monitor.
2. Plug the USB charging cable into a DC 5V
adapter and plug into an outlet. [Figure 5.1]
You can also plug the cable into a powered
USB outlet.
3. The monitor is fully charged when the
indicator turns solid green.
Note:
• Charging may take 3–4 hours.
• Every 2 months (or when battery life is
significantly shorter), fully charge the monitor
and then allow the battery to drain until the
monitor shuts off. This will optimize battery
performance.
• Battery life depends on the frequency and
time of use. If battery life is unusually reduced,
contact Customer Support (see page 30).
•Only use a Type-C USB charging cable to
charge the monitor.
•Do not use the monitor while charging.
• In extreme conditions, the battery may leak
corrosive fluid. If this comes into contact with
eyes or skin, rinse immediately with water and
seek medical attention.
Figure 5.1

17
Optimizing Battery Performance Storage
Cleaning the Monitor
For best results allow the monitor to go through 2
full charge and use cycles.
1. Fully charge the battery.
2. Use the monitor and allow the battery to
drain until the monitor shuts off.
3. Repeat steps 1 and 2 a second time.
1. Turn the monitor off and disconnect the arm
cuff.
2. Wipe gently with a damp cloth and wipe dry
immediately.
Note:
•Do not use chemicals or detergents to
clean the monitor.
•Do not let water get into the monitor.
• Turn the monitor off and unplug the air plug
from the air port.
• Place the cuff and the machine in the storage
bag.
Note: Do not roll or fold the air hose or cuff too
tightly.
•Do not store in wet, damp, or humid places.
•Do not store in any place that is tilted, vibrates,
or can damage the monitor.
•Do not store near chemicals or corrosive gases.
• Keep away from heat sources and direct
sunlight.
•Do not store in places that can be easily
reached by children.
•Do not leave the monitor exposed to any
chemical solvent, lint, or dust.
• When not in use for a long period of time,
recharge the battery monthly.

18
Frequently Asked Questions
Why are my blood pressure readings different?
• The area you are in as well as your mental and
physical state both factor into your readings.
Your readings may come out lower when you
are at home and at peace as compared to when
you are at the hospital and feeling nervous.
• If the cuff position is higher or lower than
the heart, the blood pressure reading may be
inaccurate. Make sure the cuff is 0.8–1.2 in /
2–3 cm away from your elbow.
• The cuff may be too loose, causing the blood
pressure reading to be too high. Tighten the
cuff on your arm.
• Your sitting posture, such as bending over
or sitting cross-legged, can raise your blood
pressure. Sit in a chair with your arms elevated
on a table (see Before Measurement,
page 11).
Why are the blood pressure readings different
every time I measure?
• Your blood pressure will vary throughout the
day, even if it is measured every 10 seconds. It
will fluctuate for a variety of reasons. Eating,
drinking, smoking, bathing, and even your
mood can all affect your blood pressure.
Why does my arm ache or feel numb after taking
my blood pressure?
• The cuff will inflate to compress your arm to
briefly stop the flow of blood. This may cause
temporary numbness and discomfort. Once the
cuff is removed, allow your arm to rest.
Why is the cuff not inflating?
• Air may be leaking. Check to make sure the air
plug is inserted in the air port and the air hose
does not have holes or punctures.
If your problem is not listed, please contact Customer Support (see page 30).

19
Glossary of Symbols
Electrical devices are recyclable material and
should not be disposed of with household
waste after their useful life. Help us protect the
environment and save resources by taking this
device to the appropriate collection point. Please
contact the organization which is responsible
for waste disposal in your area if you have any
questions.
Type BF Applied Part
The name and the address of the manufacturer
Date of manufacture
Refer to instruction manual
Temperature limit:
Lower limit: -20˚C
Maximum: 55˚C
Storage humidity range:
Lower limit: 15%RH
Upper limit: 93%RH
CAUTION: This alert identifies hazards that may
cause minor personal injury, product damage, or
property damage.
WARNING: This alert identifies hazards that may
cause serious personal injury or death.
B/N The B/N code combine with destination country,
PO number, date of manufacture and serial
number.

20
IMPORTANT INFORMATION REGARDING
ELECTROMAGNETIC COMPATIBILITY (EMC)
• This product needs special precautions regarding electromagnetic compatibility (EMC) and needs to be
installed and put into service according to the EMC information provided, and this unit can be affected
by portable and mobile radiofrequency (RF) communications equipment.
•Do not use a mobile phone or other devices that emit electromagnetic fields, near the unit. This may
result in incorrect operation of the unit.
• This unit has been thoroughly tested and inspected to assure proper performance and operation.
•Caution: This machine should not be used adjacent to or stacked with other equipment and if adjacent
or stacked use is necessary, this machine should be observed to verify normal operation in the
configuration in which it will be used.
