  9. ETERNAL RIVAL Art Fighstick User manual

ETERNAL RIVAL Art Fighstick User manual

ETERNAL RIVAL
S Rank Enclosure
[Art] Fighstick/Stickless/
Manual
Hardware
1A 1B 2
2
2
3A 3B 4 5 6
Included with
additional
acrylic
bottom spacer
panel (E2)
*Joystick hardware in a seperate ziplock bag with directions
*Brook PCB stands in a seperate ziplock bag with directions
4
4
x6
x14-18
x14 x14 x6
(4)
A B
C
QQ
DEE2
***Will vary depnding your button layout
Mounting Top Spacer Top
Inner Back Panel
Inner Front Panel
Bottom Window Bottom
(Bottom Spacer - Add on)
F1
F2
Outer
Back Panel
Outer
Front Panel
P1
P2
x2 inner
side panels
G
x2 Outer Side
panels
Joystick
Spacer
H
Artwork if Purchased
C
1B
B
QQ
A
Step 1 - Mounting joystick and PCB Step 2 - Assembling the top
3. Place at head (1a) screw into
countersink holes and
screw it to the the
metal stands (2) by hand x2
4. Can place the utility buttons
1. Stack (B) then (C) on top of (A)and hold it together
by hand screwing the pillar (2) to the screw (1B) placed
through the 3 panels. -If you have artwork you will place
below top panel (c)
2. Once the top panels are assmebled you can
place the buttons in.
1. Mount the joystick*
2. Mount the Brook PCB*
*Directions in seperate ziplock bag.
Notice
Countersink hole
on top. Screw will be
ush to the panel.
1A
A
D
1A
6
3A
3A
E
E2
6
4
5
3B
-If you have a extra spacer panel (E2)
use screw (3B)
Use a screw driver if needed, to push screw
through the hole.
.
Screw
Side Panels
outside
Inside
3A
45
Step 3 - Assembling the sides
1. Assemble all Side panels. See (*1). Mount neutrik
device. If bowing of the panels occur it is because
the screws were over tightened.
2. You can begin wiring at this stage easily.
Use tie straps to keep wiring managed.
3. Place side panels in slots. See (*2) the tabs
on the side panels are placed into the slots.
(it should not but secure, just
place holders till next next)
GF1 F2
HP1 P2
3A
*1
*1
Notice
Countersink hole
on top. Screw will be
ush to the panel.
Step 4 - Aseembling the box Step 5 Assemble Feet
1.Place the window’s (D) slots
into the tabs of the side panels
to keep the side panels in place
See (*2)
Make sure all side panels are in its tabs (top and btm)
before inserting the screw through window (D) to the pillar
See (*1)
X4
Step 6 Assemble Bottom Panel
Step 7 - Cover the bottom
1. Place bottom on top of
assembled enclosure. LIne up the holes
and screw it in with a screw driver.
Finished
1. If you do not
have the bottom spacer
panel (E2) still proceed
to install feet without
it.
BOTTOM COVER WITH FEET INSTALLED
*1
*2
