EUPRY NR4GL User manual

User Guide
February 2023
Eupry 4G Router
Wi-Fi basestation with heartbeat
NR4GL
User Guide: Eupry 4G Router
Rev. 0.1 - February 2023 Page 1 of 7
Eupry ApS | Dortheavej 59, 3rd Floor. | 2400 Copenhagen NV | www.eupry.com | [phone] |[e-mail]

1 Contents
1 Contents 2
2 Introduction 2
2.1 Intended Purpose 2
2.2 Package Contents 3
3 The Front Panel 3
4 Technical Specifications 4
5 Setting up the router 5
5.1 Attach the antennas to the router 5
5.2 Insert the power supply cable 5
5.3 Turn on the router 6
6 Support 6
7 Revision history 6
User Guide: Eupry 4G Router
Rev. 0.1 - February 2023 Page 2 of 7
Eupry ApS | Dortheavej 59, 3rd Floor. | 2400 Copenhagen NV | www.eupry.com | [phone] |[e-mail]

2 Introduction
2.1 Intended Purpose
The router is preconfigured to be set up with any Eupry WiFi Data Loggers that are purchased alongside it. It uses a
3G or 4G data connection to provide wireless internet that our Data Loggers can access.
2.2 Package Contents
The package includes one each of the following:
●Router RUT240
●9 W PSU
●2 x LTE antennas (swivel, SMA male)
●1 x WiFi antenna (swivel, RP-SMA male)
Router RUT240
9 W PSU
2 x LTE antennas
(swivel, SMA male)
1 x WiFi antenna
(swivel, RP-SMA
male)
User Guide: Eupry 4G Router
Rev. 0.1 - February 2023 Page 3 of 7
Eupry ApS | Dortheavej 59, 3rd Floor. | 2400 Copenhagen NV | www.eupry.com | [phone] |[e-mail]

3 The Front Panel
Name
Status
Indication
POWER
Green
Lights green when power is on
SIGNAL
Green
Shows the signal strength
2G/3G/4G
Green
Shows which internet type it is connected
to, it can be either 2G, 3G and 4G
User Guide: Eupry 4G Router
Rev. 0.1 - February 2023 Page 4 of 7
Eupry ApS | Dortheavej 59, 3rd Floor. | 2400 Copenhagen NV | www.eupry.com | [phone] |[e-mail]

4 Technical Specifications
General
Dimensions (W x H x D)
83 x 25 x 74 mm
Casing material
Aluminum housing
Operating Temperature
-40 C to 75 C
Operating Humidity
10 % to 95 % non-condensing
Ingress Protection Rating
IP30
Wireless Standards
IEEE 802.11b/g/n, Access Point (AP), Station (STA)
Network Protocol
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL
v3, TLS, ARP, VRRP, PPP, PPPoE, UPnP, SSH, DHCP, Telnet client,
SNMP, MQTT, Wake On Lan (WOL)
Indicators
LEDs
Power
9VDC, 1A, 4-pin plug
Certifications
CE/RED, FCC, IC/ISED, EAC, RCM, PTCRB, RoHS, WEEE, Wi-Fi
Certified, CCC, Anatel, GCF, REACH, Thailand NBTC, Ukraine UCRF,
SDPPI (POSTEL)
Cellular frequency bands
4G (LTE-FDD):
B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B25, B26, B28
4G (LTE-TDD):
B38, B39, B40, B41
3G:
B1, B2, B4, B5, B6, B8, B19
2G:
B2, B3, B5, B8
User Guide: Eupry 4G Router
Rev. 0.1 - February 2023 Page 5 of 7
Eupry ApS | Dortheavej 59, 3rd Floor. | 2400 Copenhagen NV | www.eupry.com | [phone] |[e-mail]

5 Setting up the router
5.1 Attach the antennas to the router
There are three antennas in the package:
1. The antennas are marked with the names that fit the ports; Wifi, Mobile and Mobile.
2. Connect the antennas firmly and pointing upwards
5.2 Insert the power supply cable
It is important to use the cable that is sent together with the router.
Do not use another power supply cable.
Do not insert a cable in the LAN or WAN input.
1. Insert the power cable on the left side of the router.
2. The cable clicks into the input when it is connected correctly
5.3 Turn on the router
1. To turn on the router, insert the power supply cable into a power socket.
2. It takes a couple of minutes before the router is connected.
3. The POWER LED lights up green
User Guide: Eupry 4G Router
Rev. 0.1 - February 2023 Page 6 of 7
Eupry ApS | Dortheavej 59, 3rd Floor. | 2400 Copenhagen NV | www.eupry.com | [phone] |[e-mail]

6 Support
If you have any problems with setting up the router, please contact Eupry support:
Tel: [phone]
E-mail: [e-mail]
7 Revision history
Revision
Date
Responsib
le
Change
0.1
Feb-2023
NHP
First revision
