Eureka Forbes Aquasoft 600 User manual

Environment Protection:
“PROTECTION" has always been our motto and guiding principle. We
care for the environment. We urge you to recycle the packaging
material or take it to the nearest recycling facility rather than disposing it
off with the rest of your waste.
Your appliance has been designed to work for many years, however,
should you wish to upgrade or replace your old product, remember to
help protect the environment by disposing it off at your local e-waste
disposal centre. Should you have queries, the nearest authorized
service centre of Eureka Forbes will be able to guide you.
Allow us to become your environmental partner; together we can make
the world a cleaner place.
Make hard water soft
with Aquasoft.
SMS ‘<REQ>’ to 80822 99333
18602661177
USER MANUAL - AQUASOFT 600 WATER CONDITIONER

Thank you for welcoming Aquasoft 600 into your home.
Aquasoft 600 Water Conditioner efficiently removes excess
calcium and magnesium salts dissolved in water, to make hard
water, soft.
1
Dear Customer,
2
Table of Contents
Introduction.......................................................................................................................... 3
Installation Condition ........................................................................................................... 3
Installation Illustration .......................................................................................................... 4
Usage and Maintenance...................................................................................................... 6
Installation Guide................................................................................................................. 7
Technical Specifications ...................................................................................................... 8
Warranty Terms and Conditions .................................................................................... 9 -10
• Please read this User Manual carefully before operating the unit
• Keep this User Manual for future reference

Installation Illustration
1. Place the system in the desired location, push the slide
upwards, and take out the regeneration knob in an upward
direction.
2. Stretch the rear cover upward from both sides with both the
hands, and at the same time take off the cover in an upward
direction.
Introduction
• Designed for bathing, it removes hardness to provide high quality soft water which can keep
your skin smooth, healthy and beautiful, and also makes hair look shiny
• No electricity required. Safe and reliable
• Nice and compact design, space-saving, and flexible design
• Regeneration procedure is two steps only, more efficient for water usage
• Quick connections for plumbing system, easy to install and take apart
• Standby mode, longer lifespan and more stable
Installation Condition
1 A water faucet together with an individual shower head with a flexible water hose are
required for this softener. All connections thread would be BSP 1/2 inch.
2 Install the system in the bathroom with a floor drain, and place it on the floor of the
bathroom.
Installation Illustration
43
3. Connect the shower hose and the outlet of the system. When
connecting the outlet, pull out the clip of fitting to take it off, and
then the connector should be installed to its original position
after connecting the fitting and hose. Make sure of the presence
of washers during the connection of the hose. At the same time
take off the cover in an upward direction.

Installation Illustration
4. Install the cover back on the system, and make sure to
align the knob and the hole on the cover. Keep the inlet and
outlet hose free from stress.
5. Inset the Regeneration (Regen.) knob back to the knob axis in the proper direction, and turn
the knob to Service (Ser.) position, close the slide cover completely. The system is now on
standby for use. (NOTE: Knob position based on the direction indicated by tiny outshoot of
the knob.)
Note: For first use after the installation of system, it is recommended to turn ON the shower
and keep the water flowing for 2-3 minutes, in order to clean up the plumbing and fittings.
Usage and Maintenance
1. Service
Regeneration button on Service mode, can provide softened water by shower for customer use.
Note: Under service mode, water flows from the shower and the system will refill
automatically until it is finished and maintains the brine level.
2. Regeneration
Once the hardness of output water increases, it means Aquasoft ion exchange resin is
exhausting and system needs regeneration. Ensure that Aquasoft Salt tank contains
sufficient quantity of regeneration. Spin the knob to the Regeneration position, and put the
shower in the bathtub or entrance of the floor drain, turn on the shower and make the brine
flow out from shower for around 30 min. When finished, turn OFF the shower and turn back
to Service position, then turn on the shower again, rinse for 1-2 min. to drain the remnant
regenerating brine.
Note: Regenerating salt is made up of food-grade salts, and will not harm you.non-iodized
3. Add Salt
The system needs salts to regenerate its capacity. Please check the salt storage in time
during usage and keep unmelted salt in the brine tank. Open the system’s slide and put salt
into the tank equably. It is recommended you add 3-4 kg salt in each exhausted cycle.
4. Maintenance
Needs no special maintenance under normal usage. If the system is
not used for more than a week, it is recommended to rinse the
system for 1-2 min. before usage, to ensure you get high quality
fresh soft water.
65

Installation Guide
5. Important Note
a. This system is only for bathing , and should be and washing & not for drinking
connected to the shower. We will not assume responsibility for any losses caused by
improper installation or usage.
b. After installation, please check out all the connections whether there is a leakage or not,
and deal with it promptly.
c. Before going through the system, please control the hot and cold water mixture and at
0
right temperature. If any water more than 60 C or higher flows into the unit, Company
will not be responsible for any losses.
d. If there is a big temperature difference between shower and environment, the outlet
water temperature will stabilize itself after 1-2 minutes. We advise you to use it after the
outlet water temperature is found to be stable, in case you feel uncomfortable during
your bath.
e. The system is only fit for non-iodized salts to regenerate. We are not responsible for
any damage or losses caused by inappropriate salt used.
f. Please do not hit the tank and jacket with sharp or hard things, in case you cause
damage to the equipments.
g. Keep the slide cover closed during normal use to avoid sediment or dirty water into the
brine tank.
h. Please do not move the system when it is touching the floor, to avoid fraying the bottom
of the tank.
I. The system could also be used for a bathtub shower but it should be placed near the
floor drain.
Technical Specifications
Model Water Conditioner
Input Water Temperature 10 - 40 Degree
3
Input Water Pressure 1 - 3 Kg / Cm
Service Flow Rate < 500 LPH
Max. Salt Storage 8 kg.
Inlet / outlet 1/2 inch
Net Weight ≤8 kg
Dimensions 360×200×440 mm
Maximum Input Hardness 700 - 800 ppm
TROUBLESHOOTING
Problem
Water is not soft enough.
Too much brine in the
tank.
Cause
Needs regeneration or
regeneration period is not
long enough.
Water pressure is too low, and
the brine valve has stopped
working.
Solution
1.Delay regeneration time.
2.Change larger injector.
Note: Ensure half water in the
brine tank.
Check and correct the
working of the brine valve.
87

to equipment failure, breakdown or accident, fire or operation, or utilization of the goods
otherwise than in accordance with the User Manual by or due to any other cause or
circumstances beyond the control of the company.
f) The company’s liability, under this warranty, shall in no event and under no
circumstances exceed the price paid by the customer to the company for the goods
stated in the invoice.
General
For the purpose of this warranty, the following expressions shall have the following meanings
respectively.
1. The “Goods” shall mean the goods described in the order form.
2. The “customer” shall mean the original purchaser of the goods from the company.
3. The “company” shall mean “Eureka Forbes Limited”.
4. General terms and conditions shall mean the terms and conditions agreed upon by
the customer and the company printed on the order form.
5. “Invoice” shall mean the invoice issued by the company to the customer describing
the goods and indicating, inter alia, the total purchase price thereof and name of
the customer.
6. “User Manual” shall mean the instructions for installation, use and maintenance
contained in the leaflet supplied by the company.
Post-warranty
1. The customer may be offered a yearly service contract at the prevailing company
rates and terms.
2. In case the customer does not wish to enter the service contract, he has the option
of calling the company’s service centre and having the Aquasoft Water Conditioner
serviced on an actual basis i.e. by paying the labour cost and the spares needed
to attend to that service/complaint call at the prevailing company rates. Such
service will be rendered by the company in towns/places where the company has
its service centres.
3. The company will provide free servicing of the goods brought to its service centre
by the customer, provided that all expenses of transporting the goods to and from
the service centre shall be borne by the customer directly.
4. If during such servicing it is necessary for the company to replace or repair the
defective components or parts, the customer shall be required to pay the same as
per the company’s prevailing price list.
5. Eureka Forbes Limited reserves the right to offer an Annual Maintenance Contract/
ensure availability of spares only up to 7 years from the date of invoice.
WARRANTY TERMS AND CONDITIONS
The goods are warranted against defects arising from faulty designs, workmanship and
materials 12 months from the date of installation or 15 months from the date of sale, whichever
is earlier, subject to the following conditions.
1. The customer will notify the company, in writing, promptly of any defects noticed and give
the company or its authorized agent adequate opportunity to inspect, test and remedy them
for which the customer will deposit the goods, if so required by the company, with the
company’s office/service centre along with the original invoice, in the city when they are
sold.
2. The inspection and test reports of the company’s office/service centre will be final and
binding under the warranty for determining defects, repairs/alterations required or carried
out or certifying work of the goods thereafter.
3. In case of any service requirement post- installation, please contact the company’s service
centre.
4. The company or its authorized agent will be entitled to retain any defective part replaced
under the warranty.
5. Notwithstanding anything to the contrary contained or implied by this warranty.
a) The company’s liability under this warranty shall be limited to the first of the goods by
the company to the customer and will not apply or extend to any secondary sale of
goods by the customer.
b) The company’s liability under this warranty shall be limited only to defects in the goods
which occur under the condition of normal operation of the goods and their proper and
prescribed use. The warranty does not cover or extend to defects which are determined
by the company or its authorized agents or resulting from or attributable to negligence,
abuse, misuse, faulty care, operation or maintenance or repairs, alterations to the
goods or any part thereof by others or the use of the goods on electrical supply for
which they are not designed or damage caused by lighting or other electrical
disturbances or interruptions.
c) The company’s liability under this warranty shall remain valid only if the goods are
duly installed by the company or its authorized agency at the location specified in the
invoice and such installation is undertaken by the company or its authorized agent
or franchisee.
d) Consumable items like sediment filter and regeneration media are not covered by
this warranty.
e) The customer will have no claim against the company, its employees and its authorized
agents or franchisee under or pursuant to this warranty in respect of death or injury to
the customer or any other person or loss or damage to any property caused by or due
109
