EURO ED8GS User manual

ED8GS
euro

To review the section on Troubleshooting Tips
will help you to solve some common problems
by yourself and not need to ask for the help of
professional technicians.
Dear Customer,
Please read this User Information carefully and keep it
to referto at a later date.
Pass it on to any subsequent owner of the appliance.
This manual contains sections of Safety Instructions,
Operating Instructions,
Installation Instructions and Troubleshooting Tips etc.
Carefully reading it before using the dishwasher will help
you to use and maintain the dishwasher properly.
The manufacturer, following a policy of constant
development and up-dating of the product,may
make modifications without giving prior notice.
Control Panel......................................................2
Dishwasher Features...........................................2
Rinse Aid.........................................................3,4
Detergent........................................................ 5
Not suitable for the dishwasher............................9
At the end of the wash cycle ..............................10
Wash Cycle Table...............................................11
Turning on the Appliance.................................... 12
Change the Programme................. ............. 12........
Filtering System..................................................13
Caring for the Dishwasher..........................13,14, 15
Before calling for service...............................19, 20
Error codes.......................................................20
....................................... 21Technical information
Forget to add a Dish................. ...................13........
How to use the 3in1 programme........................... 6
Water Connection...............................................16
Connection of drain hoses.................................... 16,17
Start of dishwasher 18...........................................

Under certain conditions, Hydrogen gas may be produced in a hot-water system that has not been used for two
weeks or more. HYDROGEN GAS IS EXPLOSIVE.If the hot-water system has not been used for such a period,
before using the dishwasher turn on all hot-water faucets and let the water flow from each for several minutes.
This will release any accumulated hydrogen gas. As the gas is flammable, do not smoke or use an open flame
during this time.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Do not abuse, sit on, or stand on the door or dish rack of the dishwasher
Do not touch the heating element during or immediately after use
Do not operate your dishwasher unless all enclosure panels are properly in place. Open the door very
carefully if the dishwasher is operating. There is a risk of water squirtingout.
Do not place any heavy objects on the door when it is open, or the appliance could tip forward.
When loading items to be washed:
Locate sharp items so that they are not likely to damage the door seal;
Load sharp knives with the handles up to reduce the risk of cut-type injuries;
Warning: knives and other utensils with sharp points must be loaded in the basket with their points down
or placed in a horizontal position.
When using your dishwasher, you should prevent plastic items from contacting with heating element.
Check that the detergent receptacle is empty after completion of the wash cycle.
Do not wash plastic items unless they are marked dishwasher safe or the equivalent. For plastic items not
so marked, check the manufacturer's recommendations.
Use only detergent and rinse additives designed for an automatic dishwasher. Never use soap, laundry
detergent, or hand washing detergent in your dishwasher.
Keep children away from detergent and rinse aid, keep children away from the open door of the dishwasher,
there could still be some detergent left inside.
Young children should be supervised to ensure that they do not play with the appliance.
The appliance is not intended for use by young children or infirm persons without supervision.
Dishwasher detergents are strongly alkaline. They can be extremely dangerous if swallowed. Avoid contact
with skin and eyes and keep children away from the dishwasher when the door is open.
The door should not be left in the open position since this could present a tripping hazard.
This dishwasher is designed for normal household and indoor use.
o
o
o
•
•
•
•
•
•
•
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
Please dispose of packing materialsproperly.
Use the dishwasher only for its intended function.
During installation, the power supply mustnot be excessively or dangerously bent or flattened.
Do not tamper with controls.
The appliance is to be connected to the water mains using new hose sets and the old hose-sets should not
be reused.
This appliance is not intend for use by persons(include children) with reduced physical , sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety
Please unplug before cleaning the appliance.
•
•
1

To get the best performance from your dishwasher,read all operating instructions before using it for the
first time.
11
12
Back View
Main Filter
5
Detergent Dispenser
6
Cup Shelf
7
Silverware Basket
8
Coarse Filter
9
Rinse Aid Dispenser
10
Inlet pipe connector
12
Drain pipe connector
11
Lower Basket
3
Spray Arms
2
Upper Basket
1
4
Tray ass.
10
Front view
2
5
Half washing button : To select half washing.
(Select half washing means that the lower spray
arm does not run, so you should load the upper
basket only).(Optional)
2
3
4
ON/OFF Button: To turn on/off the power supply.
Program button : To select washing program
when press the button.
Delayed Start Button: Press this button to set the
delayed hours for washing. You can delay the start
ofwashingupto24hours.Onepressonthis
button delays the start of washing by one hour.
Displa y Window: Program r emaining time, delay time,
fault codes and etc.
2
3
4
5
Inten. Heavy Rinse3In1 Normal SoakRapid
1
2
3
4
5
6
7
8
9

Before using your dishwasher for the first time:
A. Fill the rinse aid dispenser
B. Function of detergent
3
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, spot
and streak free drying.
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any
other substances (e.g. dishwasher cleaning agent, liquid detergent). This would damage
the appliance.
As the rinse aid diminishes, the size of the black dot
on the rinse aid level indicatorchanges, as illustrated right.
Full
3/4full
1/2full
1 / 4 full - Should refill to eliminate spotting
Empty
If there is no rinse-aid warning light in the control panel, you can judge the amount of rinse-aid by the color of the optical level
indicator "D" located next to the cap. When the rinse-aid container is full, the whole indicator will be dark . As the rinse-aid
diminishes, the size of the dark dot decreases. You should never let the rinse aid get below 1 / 4 full.
D(Rinse-Aidindicator)
OPEN
CLOSE
To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
Pour the rinse aid into the dispenser, being careful not to overfill.
Replace the cap by inserting it aligned with "open" arrow and turning it to the closed (right) arrow.
The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes
that can leave spots and streaks. It also improves drying by allowing water to sheet off the dishes.
Your dishwashers are designed to use liquid rinse aids. The rinse aid dispenser is located inside the
door next to the detergent dispenser. To fill the dispenser, open the cap and pour the rinse aid into
the dispenser until the level indicator turns completely black. The volume of the rinse aid container
is about 140ml.
Be careful not to overfill the dispenser, because this could cause over sudsing. Wipe away any spills
with a damp cloth. Don't forget to replace the cap before you close dishwasher door.
Attention!
Clean up any rinse aid split during filling with an absorbent cloth to avoid excess foaming
during the next wash.
1
2
3
The rinse aid dispenser has six or four settings. Always start with the dispenser set on
“2”. If spots and poor drying are problems, increase the amount of rinse aid dispensed
by removing the dispenser lid and rotating the dial to “3”. If the dishes still are not
drying properly or are spotted, adjust the dial to the next higher number until your dishes
are spot-free. We suggest you to set on “4”(Factory value is “4”)
NOTE:
Increase the dose if there are drops of water or lime spots on the dishes after washing.
Reduce it if there are sticky whitish streaks on the dishes or a bluish film on glassware or
knife blades.
Adjust lever
(Rinse)
MAX

Based on their chemical composition, dishwasher can be split in two basic types:
conventional, alkaline detergents with caustic components
low alkaline concentrated detergents with natural enzymes
The use of “heavy” washing programmes in conjunction with concentrated detergents
reduces pollution and is good for your dishes; these wash programmes are specially matched
to the dirt-dissolving properties of the enzymes of the concentrated detergent. For this reason
“heavy”wash programmes in which concentrated detergents are used can achieve the
same results that can otherwise only be achieved using “intensive” programmes.
Detergent tablets of different brands dissolve at different speeds. For this reason some
detergent tablets cannot dissolve and develop their full cleaning power during short
programmes. Therefore please use long programmes when using detergent tablets, to
unsure the complete removal of detergent residuals.
The dispenser must be refilled before the start of each wash cycle following the instructions
provided in the Wash Cycle Table. Your dishwashers use less detergent and rinse aid
then conventional dishwashers. Generally, only one tablespoon of detergent is needed for
anormal wash load. Also, more heavily soiled items need more detergent. Always add the
detergent just before starting dishwasher, otherwise it could get damp and will not dissolve
properly.
Amount of Detergent to Use
Always add the detergent just before starting each wash cycle.
Only use branded detergent aid for dishwasher.
If the lid is closed: press release button. The lid springs open.
Dishwasher detergent is corrosive! Take care to keep it out of reach of children.
Proper Use of Detergent
Use only detergent specifically made for use in dishwashers. Keep your detergent fresh
and dry. Don't put powder detergent into the dispenser until you're ready towashdishes.
4
Concentrated Detergent
Detergent Tablets
Detergent Dispenser
Detergents with its chemical ingredients are necessary to remove dirt, crush dirt and
transport it out of the dishwasher. Most of commercial quality detergents are suitable
for this purpose.
1
2

5
Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as
illustrated on right:
The place of main wash cycle detergent placed ,
“MIN”means approximately 20g of detergen.
The place of pre-wash cycle detergent placed ,
approximately 5g of detergent
Please observe the manufacturers dosing and storage
recommendations as stated on thedetergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional detergent dose in the pre-wash detergent
chamber. This detergent will take effect during the pre-wash phase.
You find information about the amount of detergent for the single programmes on the
last page. Please aware, that according to the level soiling and the specific hardness of
water differences are possible.
Please observe the manufacturer's recommendations on the detergent packaging.
Detergents
There are3 sorts of detergents
1.With phosphate andwith chlorine
2.With phosphate andwithout chlorine
3.Without phosphate and without chloride
Normally new pulverised detergent is without phosphate. The water softener function of
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardness of water is only 6 dH. If detergents without phosphate were used in case of hard
water often white spots appear at dishes and glasses. In this case please add more detergent
to reach better results. Detergents without chlorine do only bleach a little. Strong and coloured
spots will not removed completely. In this case please choose a programme with higher
temperature.
NOTE:
1
2
Fill in detergent

1、Referring to the below sketch map, hang the 3 in 1 tablet container on the upper basket.
2 Referring to the below sketch map, r change the location of the container ifneed、 otate the upper sprayer and to make
sure the upper sprayer does not be cumbered by the 3 in 1 tablet container.
Your dishwasher has a 3 in 1 program which needs not salt and rinse aid but a 3 In1
tablet. And this dishwasher comes with a 3 in 1 tablet container as an accessory.
NOTE:Only3in1programuses3in1tablet.Ifusing3in1tabletinotherprograms, the
appliance will not get a best performance.
3、Put the3in1tabletintothecontainerthenstartthe3in1program.
When use 3 in 1 Combination / Compact Deter-“
Gents ,please pay attention to make sure that the size of the Combination Detergents
is fitted to the dispenser so that Combination Detergents can be ease to put in the，
dispenser ,and dispenser would not be broken.
Attention
Keep all detergents in a safe place out of children's reach.
Always add the detergent in thedispenser just before starting the dishwasher.
NOTE:
6

For best performance of the dishwasher, follow these loading guidelines. Features and
appearance of racks and silverware baskets may vary from your model.
Scrape off any large amounts of leftover food. It is not necessary to rinse the dishes under
running water. Place objects in the dishwasher in following way:
1.Items such as cups, glasses, pots/pans, etc. are stood upside down.
2.Curve items, or those with recesses, should be at a slant so that water can run off.
3.They are stacked securely and can not tip over.
4.They do not prevent the spray arms from rotating while washing takes place.
Very small items should not be washed in the dishwasher as they could easily fall out of the racks.
To prevent water dripping from the upper back into the lower back, we recommend that you
empty the lower basket first and then the upper back.
The upper rack is designed to hold more delicate and lighter dishware such as glasses, coffee
and tea cup and saucers, as well as plates, small bowls and shallow pans (as long as they are
not too dirty).
Position the dishes and cookware so that they do not get moved by the spray of water.
Attention before or after Loading the Dishwasher Racks
Removing the Dishes
Loading the Upper Rack
7
Position the dishes and cookware so that they do not get
moved by the spray of water. Always place glasses, cups &
bowls upside down.
Theupperrackisformoredelicateandlighterdishware
such as glasses, coffee & tea cups, saucers, plates, bowls,
and shallow pans (provided these are not too dirty).
NOTE:
Your dishwasher comes with an adjustable top rack (basket)
pictured at right. Its height can be adjusted by lifting the
handle in a downward or upward direction. (pls see the
figures on the right: position 1 & positong 2.)
NOTICE:
Ensure the metal rod is located in its correct position.
POSITION 1
POSITION 2
1Cups
2
3
Glasses
Saucers
2
3
1
1
1
2
2

We recommend that you place large items which are most difficult to clean into the lower rack:
pots, pans, lids, serving dishes and bowls, as shown in the figure to the right.
It is preferable to place serving dishes and lids on the side of the racks in orderto avoid blocking
therotation of the top spray arm.
Pots, serving bowls, etc. must always be placed top down.
Deep pots should be slanted to allow water to flow out.
The bottom rack feature fold down tine rows so that larger or more pots and pans can be loaded.
To improve stacking of pots and pans, the spikes can be folded down
8
*** ***: The upper rack has side flaps (pictured at left
Above basket). There are 4 (2 on each side). These can be
Adjusted into 2 positions = position 1(high) and position 2 (low).
NOTE
To move the flaps between these positions, locate the large hinges
clip each flap to the upper rack. There are two of these at
either end of each flap. Gently pull both clips off the wire rack
and move the flap to the desired position. Be careful if you have
long fingernails!
POSITION 1
The upper position will accommodate items such as glass tumblers (placed beneath flap) and wine
glasses. Wine glasses can be placed upside down so that the neck rests in the groovesatsideofflap
withthebaseoftheglassfacingupward.
POSITION 2
When the flaps are moved to the lower position, they can be used to hold additional tumblers, cups
and mugs. Always check that you are only placing items on the flaps that will clear the ceiling height
of your dishwasher when you push the rack back in. Be particularly careful with long-stemmed
glassware such as champagne glasses breakage hazard!
5
5
4
6
5
Soup plates
Dessert dishes
6
4
Dinner plates
7
Silverware basket
7

Silverware Basket
Silverware should be placed in the silverware basket with handles at the bottom: If the rack
has side baskets, the spoon should be loaded individually into the appropriate slots,
especially long utensils should be placed in the horizontal position at the front of the
upper rack.
Cutlerywithwooden,hornchinaor
mother-of-pearl handles
Plastic items that are not heat resistant
Older cutlery with glued parts that is not
temperature resistant
Bonded cutlery items or dishes
Pewter or cooper items
Lead crystal glass
Steel items subject to rusting
Wooden platters
Items made from synthetic fibres
Do not put in items that are dirty of
cigarette ash, candle wax, lacqueror
paint. If you buy new dis hes please make
sure that they are suitable for dishwashers.
Some types of glasses can become
dull after a large number of washes
Silver and aluminium parts have a
tendency to discolour during washing
Glazed patterns may fade if machine
washed frequently
Please do not overload your dishwasher. There is only space for 8 standard dishes. Do not
use dish that is not suitable for dishwashers. This is important for good results and for
reasonable energy consume.
Before loading the dishes, you should:
Remove large left-over
Soften remnants of burnt food in pans
Dishes and cutlery must not impede the rotation of the spray arms
Load hollow items such as cups, glasses, pans etc. with the opening downwards so that
water cannot collect in the container or a deep base.
NOTE:
NOTE:
Are not suitable Are of limited suitability
Loading cutlery and dishes
When loading the dishes and cutlery, please note:
9
Do not let any item extend through bottom.
Teaspoons
4
Soup spoons
2
Forks
1
Knife
5
3
Dessert spoons
12
2
5
5
5
5
5
5
5
5
2
2
2
2
2
2
3
3
1
1
1
1
1
1
1
3
3
3
3
3
3
4
4
4
4
4
4
4
4

10
Di
To
T
shes and items of cutlery must not lie inside one another, or cover each other
avoid damage to glasses, they must not touch
Load large items which are most difficult to clean into the lower rack
he upper rack is designed to hold more delicate and lighter dishware such as glasses, coffee
and tea cups
Attention!
Possible causes:
Suggested remedy:
Long bladed knives stored in an upright position are a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned
horizontally in the upper basket.
Damage to glassware and other dishes
Type of glass or manufacturing process. Chemical composition of detergent.
Water temperature and duration of dishwasher programme.
Use glassware or porcelain dishes that have been marked dishwasher-proof by the
manufacturer
Use a mild detergent that is described as kind of dishes If necessary, seek further
information from detergent manufacturers.
Select a programme with as low a temperature.
To prevent damage, take glass and cutlery out of the dishwasher as soon as possible
after the programme has ended.
At the End of the Wash Cycle
When the working cycle has finished, the buzzer of dishwasher will mooing 8 seconds,
then stop. Turn of the appliance using the ON/OFF button, shut off the water supply and
open the door of the dishwasher. Wait a few minutes before unloading the dishwasher to
avoidhandlingthedishesandutensilswhiletheyarestillhotandmoresusceptible to
breakage. They will also dry better.

11
For normally soiled loads,
such as pots, plates,glasses
and lightly soiled pans.
standard daily cycle.
For lightly soiled loads,such
as plates,glasses,bowls and
lightly soiled pans.
For the heaviest soiled loads,
such as pots,pans,casserole
dishes and dishes that have
been sitting with dried food
on them for a while.
Ashorterwashforlightly
soiled loads that do not
need drying.
For dishes that need to be
rinsed and dried only.
Heavy
Normal
Intensive
Soak
Rinse
For lightly soiled loads, such
as glasses, crystal and fine
china.
155
102
161
30
85
108
170
Pre-wash
wash 45
Rinse
Rinse 70
Drying.
（℃）
（℃）
Pre-wash（50 ）
-wash
Wash (60 ℃)
Rinse (70 ℃)
Drying
℃
Pre
Pre-wash
Pre-wash
Wash (50 ℃)
Rinse (65 ℃)
Drying
Pre-wash
Wash (45 ℃)
Rinse (60 ℃)
Drying
Wash(45 )
℃
Rinse (70 ℃)
Drying
Pre-wash
Wash (40 ℃)
Rinse (70 ℃)
Drying
Wash (40 ℃)
Rinse (45 ℃)
3in1
4/20g.
4/20g.
20 g.
15 g.
15 g.
0.95
1.1
0.74
0.65
0.75
0.75
0.35
14.7
12.9
12.9
10.2
7.5
10.2
6.5
For normally soiled loads,
such as , plates,glasses
and lightly soiled pans.
standard daily cycle.
pots
(AS/NZS 2007.1)

12
Turning on the Appliance
PREMISE:
1.
Otherwise, the detergent may have already been released,
and the appliance may have already drained the wash water. If this is the case,
the detergent dispenser must be refilled (see the section entitled " Loading the
Detergent " ).
2. Press current prog. Button more than 3 seconds to cancel the program ,
then you can change the program to the desiredcycle setting (see the section
entitled " Starting a wash cycle. . . ").
3. Press one of others prog. Button more than 3 seconds to cancel the runing program ,
translase the program which you press.
4. Press the delay button more than 3 seconds to re-edit delay time .
You can modified the washing program, just the dishwasher has been
running for a short time.
NOTE:
If you open the door when washing, the machine will pause. When you
close the door , the machine will keep on working after 10 seconds.
The Display window shows the state of the dishwasher:
a) Display window shows "--:--" --> stand by;
b) Display window shows "H:MM" and not blinking --> pause;
c) Display window shows "H:MM" and blinking --> run.
If display window shows error codes(page 21th), that indicates the machine is out of order,
please turn off the main power and water supply before calling a service.
NOTE:
Starting a cycle wash
5
1 Draw out the lower and upper basket, load the dishes and push them back.
It is commended That loading the lower basket first, than the upper one (see
the section entitled "Loading the Dishwasher ).
2 Pour in the detergent (see the section e`ntitled Salt, Detergent and RinseAid ).
3 Insert the plug into the socket. The power supply is 220-240 VAC /50 HZ,
the specification of the socket is 12 A 250 VAC. Make sure that the water supply is
turned on to full pressure.
“”
”
4 Close the door, press the ON/OFF button, and the ON/OFF light will turn on.
Pressthe ProgramButtontoselectadesiredWashcycle,After3seconds,the machine will work.
If you want to select half washing, you should press Half washing
button after selecting washing program, and the half washing light
will be on, then press the Start/Reset button to start.

A forgotten dish can be added any time before the detergent cup opens.
Open the door a little to stop the washing.
After the spray arms stop working, you can open the door
completely.
Add forgotten dishes.
Close the door, the dishwasher will work after ten seconds.
4
3
2
1
It is dangerous to open the door when washing, because the hot water may scaldyou.
1.Switch off the dishwasher bypressing the ON/OFF button.
2.Turn off the water tap!
Open the door carefully. Hot steam may escape when the door is opened!
Hot dishes are sensitive to knocks. The dishes should be allowed to cool down around
15 minutes before removing from the appliance.
Open thedishwasher's door, leave itajar and wait a fewminutes beforeremoving the dishes.
Inthiswaytheywillbecoolerandthedryingwillbeimproved.
Unloading the dishwasher
It is normal that the dishwasher is wet inside.
Empty the lower basket first and then the upper one. This will avoid water dripping from the
upper basket onto the dishes in the lower one.
Caring for the Dishwasher
To clean the control panel use a lightly dampened cloth then dry thoroughly.Tocleantheexterior
use a good appliance polish wax.
Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher.
If your dishwasher is left in an unheated place during the winter, ask a service technical to:
1.Cut off electrical power to the dishwasher.
2.Turn off the wa ter supply and disconnect the water inlet pipe from the water valve.
3.Drain water from the inlet pipe and water valve. (Use a pan to catch the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter in the tub the bottom and use a sponge to use up water in sump.
The program light is on but isn't blinking, only in this case the program is ended.
13
Protect Against Freezing
The filter prevent larger remnants of food or other objects from getting inside the pump. This residue can
occasionally clog up the filters.
The filter system consists of a coarse filter,a flat (Main filter)
And a microfilter(Fine filter).
Main filter
Food and soil particles trapped by this filter are pulverized by a
special jet on the lower spray arm and washed down the
drain.
Coarse filter
Larger items, such as pieces of bone or glass, that could clog
the drain are trapped in the coarse filter. To remove an item
caught in this filter, gently squeeze the taps on the top of this
filter and lift it out.
Fine filter
This filter holds soil and food residue in the sump area and
prevents it from being redeposit on the dishes during a cycle.
- Inspect the filters for obstructions every time the dishwasher has been used.
- By unscrewing the coarse filter.you can remove the filter system.Remove any food remnants and clean the
filters under running water.
2
3
1
2
3
1

14
It is necessary to clean the spray arms regularly for hard water chemicals will clog the spray
arm jets and bearings. To remove the spray arms, screw off the nut clockwise to take out the
washerontopofthesprayarmandremovethearm.Washthearmsinsoapyandwarm water
and use a soft brush to clean the jets. Replace them after rinsing them thoroughly.
Cleaning the Spray Arms
Filter assembly
For best performance and results, the filter assembly must be cleaned. The filter efficiently
removes food particles from the wash water, allowing it to be recirculated during the cycle. For
this reason, it is a good idea to remove the larger food particles trapped in the filter after each
wash cycle by rinsing the semicircular filter and cup under running water. To remove the filter
assembly, pull on the cup handle in the upward direction. The entire filter assembly should be
cleaned once a week.
To clean the coarse filter and the fine filter, use a cleaning brush. Then, reassemble the filter
parts as shown in the figures left and reinsert the entire assembly in the dishwasher, positioning
in itsseat and pressing downward.
The dishwasher must never be used without the filters. Improper replacement of the filter may
reduce the performance level of the appliance and damage dishes and utensils.
Never run the dishwasher without the filters in place. When cleaning the filters, don't knock on
them. Otherwise, the filters could be contorted and the performance of dishwasher could be
debased.
Cleaning the Filters
1
2
1
2
1
2
3
step１ ：contrarotate the C ,
andthenliftitup;
oarse filter
step２：lift the Main filter up
step3：lifttheFinefilterup
If do it from step1 to step 3, the filter system will be removed; while if do it from step3 to step 1, the filter system
will be installed.
NOTE：

15
Never use a spray cleaner to clean the door panel for it could damage the door lock and electrical components. It is not allowed
to use the abrasive agent or some paper towel becauseof the risk of scratching or leaving spots on the stainless steel surface.
After every wash, turn off the water supply to the
appliance and leave the door slightly ajar so that
moisture and odors are not trapped inside.
Before cleaning or performing maintenance, always
remove the plug from the socket. Do not run risks.
To clean the exterior and rubber parts of the dishwasher,
do not use solvents or abrasive cleaning products.
Rather, use only a cloth and warm soapy water.
Toremovespotsorstainsfromthesurfaceofthe
interior, use a cloth dampened with water and a little
white vinegar, or a cleaning product made specifically
for dishwashers.
When you go on holiday, it is recommened that you run a
wash cycle with the dishwasher empty and then remove
the plug from the socket, turn off the water supply and
leave the door of the appliance slightly ajar. This will help
the seals last longer and prevent odors from forming
within the appliance.
If the appliance must be moved, try to keep it in the vertical
position.If absolutely necessary, it can be positioned on
its back.
One of the factors that cause odors to form in the
dishwasher is food that remains trapped in the seals.
Periodic cleaning with a damp sponge will prevent this
from occurring.
To clean the edge around the door, you should use only a soft warm, damp rag. Toprevent
penetration of water into the door lock and electrical components, do not use a spray cleaner
of any kind.
Also, never use abrasive cleaners or scouring pads on the outer surfaces because they will
scratch the finish. Some papers towels can also scratch or leave marks on thesurface.
After making sure that the voltage and the frequency values for the current in the home
correspond to those on the rating plate and that the electrical system is sized for the
maximum voltage on the ratingplate, insert the plug into an electrical socket which is
earthed properly. If the electrical socket to which the appliance must be connected is not
appropriate for the , replace the socket,rather than using a adaptors or thelikeas
they could cause overheating and burns.
plug
Insure proper ground exists before use
This appliance must be grounded. In the event of a malfunction or breakdown, grounding will
reduce the risk of electric shock by providing a path of least resistance of electric current. This
appliance is equipped with a cord having an equipment-grounding conductor and a grounding
plug. The plug must be plugged into an appropriateoutlet that is installed and grounded in accordance
with all local codes and ordinances.

Please see the rating label to know the rating voltage and connect the dishwasher to appropriate power supply, which has a
required fuse 16 amp. Time delay fuse or circuit breaker recommended and provide separate circuit serving only this appliance.

Improper connection of the equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician or service representative if you
are in doubt whether the appliance is properly grounded. Do not modify the plug
provided with the appliance; If it is not fit for the outlet. Have a proper outlet installed
by a qualified electrician.

16
A hose that attaches to a sink spray can burst if it is installed on the same waterlineasthedishwasher.Ifyoursinkhasone,itis
recommended thet the hose be disconnected and the hole plugged.
Pull The safety supply hoses completely out from storage compartment locatedatrearofdishwasher.
Turn water fully on before starting the dishwasher.
1
Tighter the screws of the safety supply hose to the faucet with thread 3/4inch.
The safety supply hose consists of the double walls. The hose's system guaran tees its intervention by bl ocking the flow of w ater
in case of the supply hose breaking and when the air space between the supply hose itself and the outer corrugated hose is full
of water.
Turn off the water.
Release the water pressure by depressing the pressure release button. This relieves water pressure and protects you, and the
room, from severe splashing.
Unscrew The safety supply hose from the faucet..
3
2
1
2
3
The appliance must be connected to the water mains using new hose-sets.
The old hose-sets should not be reused.
Water pressure must be between 0,04 MPa and 1 MPa. If the pressure is below theminimum
consult our Service Department for advice.
Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that it is fastened tightly in place.
If the water pipes are new or have not been used for an extended period of time,letthewater runtomakesurethatthe
water is clear and free of impurities. If this precaution is not taken, there is a risk that the water inlet can get blocked and
damage the appliance.
The water supply to the appliance can also be connectedto the house hot water line (centralized system, heating system),
as long as it does not exceed a temperature of 60 C. In this case, the wash cycle time will be shortened by about 15 minutes
and the wash efficiency slightly reduced.
The connection must be made to the hot water line following the same procedures as those for the connection to the
cold water line.

Position the appliance in the desired location. The back should rest against the wall behind it, and the sides, along the adjacent
cabinets or wall. The dishwasher is equipped with water supply and drain hoses that can be positioned to theright or the left to
facilitate proper installation.
Dishwasher must be level for proper dish rack operation and wash performance.
Place level on door and rack track inside the tub as shown to check that the
1
dishwasher is level.
2 When level the dishwasher, please pay attention not to let the dishwasher tip over.
Insert the drain hose into a drain pipe with a minimum diameter of 40 mm, or let it run into the sink, making sure to avoid bending
or crimping it. Use the special plastic support that comes with the appliance. The free end of the hose must be at a height
between 400 and 1000mm and must not be immersed in water.
FRONT VIEW
Inlet pipe connector Drain pipe connector
POWEROUTLET
SIN K
DISHWASHER
Min 100mm
Water Outlet
Connect the waterdrain hose. The drain hose must be correctly fittedto avoid water leaks.
Ensure that the water inlet hose is not kinked or squashed.
Extension Hose
If you need a drain hose extension, observe to use a similar drain hose.
It must be no longer than 4 metres; otherwise the cleaning effect of the dishwasher could be reduced.
Syphon Connection
The waste connection must be at a height of between 50 cm (minimum) and 100 cm (maximum)
from the bottom of the dish. The water drain hose should be fixed by a hose clip.
17
In order to avoid more water staying in the inlet hose,
please close the hydrant after using.(For the models: no safety inlet hose.)
If the sink is 1000 higher from the floor, the excess water in hoses cannot
be drained directly into the sink. It will be necessary to drain excess
water from hoses into a bowl or suitable container that is held outside and lower
than the sink.

Aquasafe
The Aquasafe System is a safety valve system, preventing you from water leaks. If the water inlet
hose starts to leak during a wash cycle, the safety valve cuts off the runningwater.Donot
immerse the water inlet hose or the safety valve in water, because the electrical cable for the
safety valve is in the double-walled water inlet hose.
If water inlet hose or the safety valve is damaged, remove the main plug immediately.
Do not enlarge or shorten the inlet hose because it contains electric parts.
●
Attention
●
Start of dishwasher
The followings should be checked before starting the dishwasher.
1
Whether the dishwasher is level and fixed
2 Whether the inlet valve is opened
3
Whether there is leakage at the connections of the conducts
4 Whether the wires are tightly connected
5 Whether the power is switched on
6 Whether the inlet and drain hoses are knotted
7 All packing materials and printings should be taken out from the dishwasher
After installation, please put this manual into the bags of printings. The content
of this manual is very helpful to the users.
18
