Eurolux GN272 User manual

COMBI REFRIGERATOR
Fridge - Freezer
User manual
КОМБИ ХОЛОДИЛЬНИК
Морозильная и холодильная камера
инструкция по эксплуатации
COMBIN FRIGORIFIC
Frigider - Congelator
Manual de utilizare
GN272

EN - 1 -
Index
BEFORE USING THE APPLIANCE .................................................................... 2
General warnings .............................................................................................................. 2
Old and out-of-order fridges or freezers.......................................................................... 4
Safety warnings .................................................................................................................. 4
Installing and operating your fridge freezer .................................................................... 5
Before Using your fridge freezer ...................................................................................... 6
THE VARIOUS FUNCTION AND POSSIBILITIES ............................................... 6
Thermostat setting ............................................................................................................ 6
Warnings about temperature adjustments .................................................................... 6
Accessories ........................................................................................................................ 7
Ice tray .......................................................................................................................................... 7
Bottle holder .................................................................................................................................. 7
ARRANGING FOOD IN THE APPLIANCE .......................................................... 8
Fridge compartment .......................................................................................................... 8
Freezer compartment ........................................................................................................ 8
CLEANING AND MAINTENANCE ....................................................................... 9
Defrosting fridge compartment ..................................................................................... 10
Defrosting the freezer compartment ..............................................................................10
Replacing the fridge light bulb ....................................................................................... 11
TRANSPORTATION AND CHANGING OF ......................................................... 11
INSTALLATION POSITION ............................................................................... 11
Transportation and changing of installation position .................................................. 11
Repositioning the door ................................................................................................... 11
BEFORE CALLING YOUR AFTER SALES SERVICE .........................................12
Tips For Saving Energy ...................................................................................................13
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS .......................14

EN - 2 -
PART 1. BEFORE USING THE APPLIANCE
General warnings
WARNING: Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means to
accelerate the defrosting process, other than those recommended
by the manufacturer.
WARNING: Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: To avoid a hazard due to the instability of the appliance,
it must be fixed in accordance with the instructions.
• If your appliance uses R600a as a refrigerant (this information
will be provided on the label of the cooler) you should take
care during transportation and installation to prevent the cooler
elements from being damaged. R600a is an environmentally
friendly and natural gas, but it is explosive. In the event of a
leak due to damage of the cooler elements, move your fridge
away from open flames or heat sources and ventilate the room
where the appliance is located for a few minutes.
• While carrying and positioning the fridge, do not damage the
cooler gas circuit.
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
• This appliance is intended to be used in household and
domestic applications such as:
- staff kitchen areas in shops, offices and other working
environments.
- farm houses and by clients in hotels, motels and other
residential type environments.

EN - 3 -
- bed and breakfast type environments;
- catering and similar non-retail applications.
• If the socket does not match the refrigerator plug, it must be
replaced by the manufacturer, a service agent or similarly
qualified persons in order to avoid a hazard.
• A specially grounded plug has been connected to the power
cable of your refrigerator. This plug should be used with a
specially grounded socket of 16 amperes. If there is no such
socket in your house, please have one installed by an
authorised electrician.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision.
• If the supply cord is damaged, it must be replaced by the
manufacturer, an authorised service agent or similar qualified
persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes exceeding
2000 m.

EN - 4 -
Safety warnings
• Do not connect your Fridge Freezer to the mains electricity supply using an
extension lead.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow hildren
to play with the appliance or let them hang off the door.
• Never touch the power cord/plug with wet hands as this could
cause a short circuit or electric shock.
• Do not use any metal or sharp objects to accelerate the defrosting
process.
• Do not place glass bottles or beverage cans in the ice-making
compartment as they can burst as the contents freeze.
• Do not place explosive or flammable material in your fridge. Place
drinks with high alcohol content vertically in the fridge
compartment and make sure that their tops are tightly closed.
Old and out-of-order fridges or freezers
• If your old fridge has a lock, break or remove the lock before discarding
it, because children may get trapped inside it and may cause an
accident.
• Old fridges and freezers may contain isolation material and refrigerant
with CFC or HFC. Therefore, take care not to harm environment when
you are discarding your old fridges.
Please ask your municipal authority about the disposal of the WEEE reuse,
recycle and recovery purposes.
Notes:
•Please read the instruction manual carefully before installing and using your
appliance. We are not responsible for the damage occurred due to misuse.
•Follow all instructions on your appliance and instruction manual, and keep this
manual in a safe place to resolve the problems that may occur in the future.
•This appliance is produced to be used in homes and it can only be used in
domestic environments and for the specified purposes. It is not suitable for
commercial or common use. Such use will cause the guarantee of the appliance
to be cancelled and our company will not be responsible for losses incurred.
•This appliance is produced to be used in houses and it is only suitable for cooling /
storing food. It is not suitable for commercial or common use and/or for storing
substances except for food. Our company is not responsible for losses to be
incurred in the contrary case.

EN - 5 -
• When removing ice from the ice-making compartment, do not touch it. Ice
may cause frost burns and/or cuts.
• Do not touch frozen goods with wet hands. Do not eat ice-cream or ice
cubes immediately after you have taken them out of the ice-making
compartment.
• Do not re-freeze frozen goods after they have melted. This may cause health
issues such as food poisoning.
• Do not cover the body or top of fridge with lace. This affects the performance of
your fridge.
• Secure any accessories in the fridge during transportation to prevent damage to
the accessories.
Installing and operating your fridge freezer
Before using your fridge freezer, you should pay attention to the following points:
• The operating voltage for your fridge freezer is 220-240 V at 50Hz.
• We do not accept responsibility for any damages that occur due to ungrounded
usage.
• Place your fridge freezer where it will not be exposed to direct sunlight.
• Your appliance should be at least 50 cm away from stoves, gas ovens and heater
cores, and at least 5 cm away from electrical ovens.
• Your fridge freezer should never be used outdoors or exposed to
rain.
• When your fridge freezer is placed next to a deep freezer, there
should be at least 2 cm between them to prevent humidity
forming on the outer surface.
• Do not place anything on your fridge freezer, and install your fridge
freezer in a suitable place so that at least 15 cm of free space is
available above it.
• Do not place heavy items on the appliance.
• Use the adjustable front legs to make sure your appliance is
level and stable. You can adjust the legs by turning them in
either direction. This should be done before placing food in the
fridge freezer.
• Before using your fridge freezer, wipe all parts with a solution of
warm water and a teaspoon of sodium bicarbonate, then rinse
with clean water and dry.
Place all parts in the fridge after cleaning.
• Install the plastic distance guide (the part with black vanes at the rear) by turning it
90° (as shown in the figure) to prevent the condenser from touching the wall.
• The refrigerator should be placed against a wall with a free space not exceeding
75 mm.

EN - 6 -
PART 2. THE VARIOUS FUNCTION AND POSSIBILITIES
Thermostat setting
The fridge freezer thermostat automatically regulates the inside temperature of the
compartments. By rotating the knob from position 1 to 5, colder temperatures can be
obtained.
Thermostat setting;
1 – 2 : For short-term storage of food in the freezer compartment, you can set the knob
between the minimum and medium position.
3 – 4 : For long-term storage of food in the freezer compartment, you can set the knob
to the medium position.
5 : For freezing fresh food. The appliance will work for longer. So, after the desired
condition is reached, return the knob to the previous setting.
THERMOSTAT CONTROL
Warnings about temperature adjustments
• It is not recommended that you operate your fridge freezer in environments colder
than 10°C in terms of its efficiency.
• Temperature adjustments should be made according to the frequency of door
openings and the quantity of food kept inside the fridge freezer.
• When you first switch on the appliance, you should ideally try to run it without any
food in for 24 hours and not open the door. If you need to use it straight away, try
not to put a large quantity of food inside.
• A 5 minute delay function is included to prevent damage to the compressor of your
fridge freezer, when you unplug it and then plug it in again to operate it, or when an
energy breakdown occurs. Your fridge freezer will start to operate normally after 5
minutes.
Before Using your fridge freezer
• When using your fridge for the first time, or after transportation,
keep it in an upright position for at least 3 hours before plugging
into the mains. This allows efficient operation and prevents
damage to the compressor.
• Your fridge may have a smell when it is operated for the first time. This is normal
and the smell will fade away when your fridge starts to cool.

EN - 7 -
Climate Class Ambient Temperature (°C)
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
• Your fridge freezer is designed to operate in the ambient temperature intervals
stated in the standards, according to the climate class stated in the information
label. It is not recommended that your fridge freezer is operated in the
environments which are out of the stated temperature intervals. This will reduce
the cooling efficiency of the fridge.
• This appliance is designed for
use at an ambient temperature
within the 16°C - 32°C range.
Accessories
Ice tray
• Fill the ice tray with water and place in the freezer compartment.
• After the water has completely turned into ice, you can twist the tray as shown
below to remove the ice cubes.
Bottle holder
In order to prevent bottles from slipping or falling over, you can use the
bottle holder. This will also help to prevent the noise made by bottles
when opening or closing the door.
(Only some models)
All written and visual descriptions in the accessories may vary according to the
appliance model.

EN - 8 -
PART 3. ARRANGING FOOD IN THE APPLIANCE
Fridge compartment
• To reduce humidity and the consequent increase in frost, never place liquids in
unsealed containers in the fridge compartment. Frost tends to concentrate in the
coldest parts of the evaporating liquid and in time will more frequent defrosting
will be required.
• Never place warm food in the fridge compartment. Warm food should be allowed
to cool at room temperature and should be arranged to ensure adequate air
circulation in the fridge compartment.
• Nothing should touch the back wall of the appliance as it will cause frost and
packaging to stick to it. Do not open the fridge door too frequently.
• Arrange meat and cleaned fish (wrapped in packages or sheets of plastic) which
you intend to use in 1-2 days, in the bottom section of the fridge compartment.
• Store fruit and vegetable items loose in the crisper containers.
Freezer compartment
• Use the freezer for storing deep-frozen or frozen food for long periods of time and
making ice cubes.
• Do not put fresh or warm food in the freezer door shelves to be frozen. Only use the
shelves for the storage of frozen food.
• Do not store fresh or warm food with frozen food as it can thaw the frozen food.
• When freezing fresh food (e.g. meat, fish and mincemeat), divide it into portions
that you will consume in one sitting.
• When storing frozen food; the instructions shown on frozen food packaging
should always be followed carefully and if no information is provided, food should
not be stored for more than 3 months from the purchase date.
• When buying frozen food ensure that these have been frozen at suitable
temperatures and that the packing is intact.
• Frozen food should be transported in appropriate containers and placed in the
freezer as soon as possible. Do not use door shelves for freezing.
• If a frozen food package shows signs of humidity and abnormal swelling it is
probable that it has been previously stored at an unsuitable temperature and that
the contents have deteriorated. Do not buy such food.
• The storage life of frozen food depends on the room temperature, thermostat
setting, how often the door is opened, the type of food and the length of time
required to transport the product from the shop to your home. Always follow the
instructions printed on the packaging and never exceed the maximum storage life
indicated.
• Use the fast freezing shelf to freeze home cooking and the food which you need to
freeze more quickly. Fast freezing shelves are the middle drawers of the freezer
compartment (see page 14).

EN - 9 -
PART 4. CLEANING AND MAINTENANCE
• Disconnect the unit from the power supply before cleaning.
• Do not clean the appliance by pouring water.
• Make sure that no water enters the lamp
housing and other electrical components.
• The fridge freezer should be cleaned periodically using a solu-
tion of bicarbonate of soda and lukewarm water.
• Clean the accessories separately with soap and
water. Do not clean them in the dishwasher.
• Do not use abrasive products, detergents or soaps. After wash-
ing, rinse with clean water and dry carefully. When you have fin-
ished cleaning, reconnect the plugto the mains supply with dry
hands.
• Clean the condenser with a broom at least twice a year.
This will help you to save on energy costs and increase
productivity.
THE POWER SUPPLY MUST BE DISCONNECTED.

EN - 10 -
Defrosting fridge compartment
• Defrosting occurs fully automatically in fridge compartment during operation; the
defrosted water collected by the evaporating tray and evaporates automatically.
• The evaporating tray and water drain hole (back of the refrigerator crisper shelf)
should be cleaned periodically to prevent the water from collecting on the bottom
of the fridge instead of flowing out.
Defrosting the freezer compartment
• The frost, which covers the shelves of the freezer compartment, should be re-
moved periodically.
• Do not use sharp metal objects for this operation. They could puncture the
refrigerant circuit and cause irreparable damage to the unit. Use the plastic
scraper provided.
• When there is more than 5 mm of frost on the shelves, defrosting must be carried
out.
• Before defrosting, place the frozen food in a cool place after wrapping it in sheets
of newspaper (this will help the food to
maintain it’s tempertaure for longer).
• To accelerate the defrosting process, place
one or more bowls of warm water in the
freezer compartment.
• Dry the inside of the compartment with a
sponge or a clean cloth.
• Once the unit has been defrosted, place
the food into freezer and remember to
consume it in a short period of time.

EN - 11 -
PART- 5.
Replacing the fridge light bulb
1. Unplug the unit from the power supply,
2. Remove the refrigerator light cover (A) by pressing
the hooks placed both sides of the cover.
3. Change the present light bulb (B) with a new one
(not more than 15 W).
4. Place the light cover in its place and plug the unit.
A
B
Replacing LED lighting
If your refrigerator has LED lighting contact the help desk
as this should be changed by authorized personnel only.
TRANSPORTATION AND CHANGING OF
INSTALLATION POSITION
Transportation and changing of installation position
• The original packages and foamed polystyrene (PS) can be retained if required.
• During transportation, the appliance should be secured with a wide string or a
strong rope. The instructions written on the corrugated box must be followed while
transporting.
• Before transporting or changing the
installation position, all the moving
objects (ie,shelves,crisper…) should be
taken out or fixed with bands in order to
prevent them from getting damaged.
Carry your fridge freezer in the upright posi-
tion.
Repositioning the door
• It is not possible to change the opening direction of your refrigerator door, if the
door handles on your refrigerator are installed from the front surface of the door.
• It is possible to change the opening direction of the door on models without any
handles.
• If the door opening direction of your refrigerator may be changed, you should
contact the nearest authorised service agent to have the opening direction
changed.

EN - 12 -
PART 6. BEFORE CALLING YOUR AFTER SALES SERVICE
If your fridge freezer is not working properly, it may be a minor problem, therefore to save
time and money, check the following, before calling an electrician.
What to do if your appliance does not operate
Check that:
• There is no power,
• The general switch in your home is disconnected,
• The socket is not faulty. To check this, plug the appliance in to another socket
which you know is working.
What to do if your appliance performs poorly
Check that:
• You have overloaded the appliance,
• The thermostat setting is on position “1” (if so set the thermostat dial to a suitable
value).
• The doors are closed properly,
• There is no dust on the condenser,
• There is enough space at the rear and side walls.
If your fridge is operating too loudly
Normal Noises
Compressor noise
• Normal motor noise: This noise means that the compressor operates normally
• Compressor may cause more noise for a short time when it starts.
Bubbling noise and splash:
• This noise is caused by the flow of the refrigerant in the tubes of the system.
• If you hear any other noises check that:
- The appliance is level
- Nothing is touching the rear of the appliance
- The objects on the appliance are vibrating.
If there is water in the lower part of the refrigerator,
Check that:
• The drain hole for the water is not clogged (use the defrost drain plug to clean the
drain hole).
Recommendations
• If you do not intend to use the appliance for long time (for example during the
summer holidays) unplug and clean the appliance and leave the door open to
prevent the formation of mildew and smells.
• To stop the appliance completely, unplug it from the main socket (for cleaning and
when the doors are left open).

EN - 13 -
• If a problem persists after you have followed all the instructions above, please
consult the nearest Authorised Service Centre.
• The lifetime of your appliance is stated and declared by the Department of Industry.
The length of time for retaining parts required for the proper operation of the
appliance is 10 years.
Tips For Saving Energy
1.Install the appliance in a cool, well ventilated room , but not in direct sunlight and
not near a heat source (radiator, cooker.. etc). Otherwise use an insulating plate.
2.Allow warm food and drinks to cool down outside the appliance.
3.When thawing frozen food, place it in the refrigerator compartment. The low
temperature of the frozen food will help to cool the refrigerator compartment when
it is thawing. This will help to save energy. If the frozen food is put out, it results in
a waste of energy.
4.Cover drinks or other liquids when placing them in the appliance Otherwise
humidity increases in the appliance. Therefore, the working time gets longer. Also
covering drinks and other liquids helps to preserve smell and taste.
5.Try to avoid keeping the doors open for long periods or opening the doors too
frequently as warm air will enter the cabinet and cause the compressor to switch
on unnecessarily often.
6.Keep the covers of the different temperature compartments (crisper, chiller ...etc )
closed
7.Door gasket must be clean and pliable. Replace gaskets if worn.

EN - 14 -
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
1
2
A
3
4
5
6
7
B
9
10
11
13
14
8
12
A) Cooler compartment
B) Freezer compartment
1) Thermostat dial
2) Refrigerator lamp & cover
3) Refrigerator shelves
4) Crisper cover
5) Crisper
6) Bottle shelf
7) Door shelves
8) Egg holder
9) Upper freezer drawer
10) Middle freezer drawer
11) Bottom freezer drawer
12) Ice tray
13) Kick plate
14) Levelling feet
PART- 7.
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.

RU - 15 -

  
    
    
  
  
     
 
   
     
  
   
  
  
   
   
  
    
    
    

   
 
    
 
        


RU - 16 -

   
     




    

  


     
     




      
      

     





      







RU - 17 -


       





      
     

    


     
     



      

     
     

     

        
    




RU - 18 -

          

     
   
 

 
       
    
         
 
        
      
       
   
        
       

         
        
         
     
  
                  

       
      
         

       
        
 


        
       
         
     
