EuropAce EWC 6340S User manual

For optimum performance and safety purpose, please read this operating instruction
manual carefully before using and keep it for future reference.
EWC 6340S
EWC 6110S
EWC 6460S
EWC 6155S

1. Specications
2. SafetyInstructions
3. Safety Guidelines
4. Purchase Record
5. Installation Instructions
6. Operating Instructions
7. Care and Maintenance
8. Troubleshooting

3
Model EWC 6340S
Rated voltage
220V
Rated frequency
50Hz
Rated power
Product size
W493 x H842 x D585mm
N.W .42kg
G.W.46kg
100W
Model EWC 6460S
Rated voltage
220V
Rated frequency
50Hz
Rated power
Product size
W595 x H857 x D575mm
N.W .50kg
G.W.54kg
100W
Model EWC 6110S
Rated voltage
220V
Rated frequency
50Hz
Rated power
Product size
W595 x H1431 x D675mm
N.W .92kg
G.W.102kg
160W
Model EWC 6155S
Rated voltage
220V
Rated frequency
50Hz
Rated power
Product size
W595 x H1803 x D675mm
N.W .111kg
G.W.123kg
160W
SPECIFICATIONS

4
We have provided many important safety messages in this manual and on your appliance.
Always read and obey all safety messages.
This is the Safety Alert Symbol. This symbol alerts you to potential hazards
that can kill or injure you and others.
All safety messages will follow the Safety Alert Symbol and either the words:
“DANGER”, “WARNING” or “CAUTION”.
Warning means that failure to heed this safety
statement may result in extensive product
damage, serious personal injury, or death.
Caution means that failure to heed this safety
statement may result in minor or moderate
personal injury, or property or equipment
damage.
All safety messages will alert you to know what the potential hazard is, tell you how to reduce
the chance of injury, and let you know what can happen if the instructions are not followed.
Danger means that failure to heed this safety
statement may result in severe personal injury
or death.
* Your safety and the safety of others are very important. *
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electrical shock,
or injury when using your appliance, follow
these basic precautions:
Read all instructions before using the Wine Cooler.
DANGER or WARNING: Risk of child entrapment.
Child entrapment and suffocation are not problems of the past. Junked or abandoned
appliances are still dangerous . . . even if they will “just sit in the garage a few days”.
Before you throw away your old Wine Cooler: Take off the door. Leave the
shelves in place so that children may not easily climb inside.
Never allow children to operate, play with, or crawl inside the appliance.
Never clean appliance parts with flammable fluids. The fumes can create a fire
hazard or explosion.
Do not store or use gasoline or any other flammable vapors and liquids in the vicinity
of this or any other appliance. The fumes can create a fire hazard or explosion.
-Save these instructions-
S AF E T Y INSTRUCT IONS

5
Before the appliance is used, it must be properly positioned and installed as
described in this manual, so read the manual carefully. To reduce the risk of
fire outbreak, electrical shock or injury during usage, please follow the basic
precaution in the following:
Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and do not
use an extension cord.
Replace all panels before operating.
It is recommended that a separate circuit, serving only your appliance be provided. Use receptacles that
cannot be turned off by a switch or pull chain.
Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or explosion.
And do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance. The fumes can create a fire hazard or explosion.
Before proceeding with cleaning and maintenance operations, make sure the power line of the unit is
disconnected.
Do not connect or disconnect the electric plug when your hands are wet.
Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result in
electrical shock or death.
Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in
this manual. All other servicing should be referred to a qualified technician.
-FOLLOW WARNING CALL OUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL-
Use two or more people to move and install appliance. Failure to do so can result in back or other injury.
To ensure proper ventilation for your appliance, the front of the unit must be completely unobstructed.
Choose a well-ventilated area with temperatures above 60°F (16°C) and below 90°F (32°C). This unit
must be installed in an area protected from the element, such as wind, rain, water spray or drips.
The appliance should not be located next to ovens, grills or other sources of high heat.
The appliance must be installed with all electrical, water and drain connections in accordance with state
and local codes. A standard electrical supply (220-240V AC only, 50 Hz), properly grounded in
accordance with the National Electrical Code and local codes and ordinances is required.
Do not kink or pinch the power supply cord of appliance.
The fuse (or circuit breaker) size should be 10 amperes.
It is important for the appliance to be leveled in order to work properly. You may need to make several
adjustments to level it.
All installation must be in accordance with Singapore regulatory requirements.
Make certain that the pipes are not pinched or kinked or damaged during installations.
Check for leaks after connection.
Never allow children to operate, play with or crawl inside the appliance.
If you use the drainage container, you must set the drain select switch to OFF or the water can overflow
from the drainage container
Do not use solvent-based cleaning agents of abrasives on the interior. These cleaners may damage or
discolor the interior.
Do not use this apparatus for other than its intended purpose.
S AF E T Y INSTRUCT IONS

HELP US HELP YOU...
Read this guide carefully.
It is intended to help you operate and maintain
your new Wine Cooler properly.
Keep it handy to answer your questions.
If you don't understand something or you
need more assistance, please call the local
dealer or customer service.
Keep proof of original purchase date (such as
your sales slip) with this guide to establish the
warranty period.
Write down the model and serial numbers.
You'll find them on a plate located on the rear
outside wall of the Wine Cooler.
Please write these numbers here:
____________________________________
Date of Purchase
____________________________________
Model Number
____________________________________
Serial Number
Use these numbers in any correspondence or
service calls concerning your Wine Cooler.
If you received a damaged Wine Cooler,
immediately contact the dealer (or builder) that
sold you the Wine Cooler.
Save time and money. Before you call for
service, check the Troubleshooting Guide. It
lists causes of minor operating problems that
you can correct yourself.
CAUTION:
THIS WINE COOLER IS NOT
DESIGNED FOR THE STORAGE
OF MEDICINE OR OTHER
MEDICAL PRODUCTS.
PURCHASE RECORD
6

BEFORE USING YOUR WINE COOLER
Remove the exterior and interior packing.
Check to be sure you have all of the accessories.
Before connecting the Wine Cooler to the power source, let it stand upright for approximately 2 hours.
This will reduce the possibility of a malfunction in the cooling system from handling during transportation.
Clean the interior surface with lukewarm water using a soft cloth.
Install the handle on the left side of the door.
INSTALLATION OF YOUR WINE COOLER
Model EWC 6460S is designed to be for free standing installation or built-in (fully recessed). Models
EWC 6340S and EWC 6110S are designed to be for free standing installation only, and should not
be recessed and built-in.
Place your Wine Cooler on a floor that is strong enough to support it when it is fully loaded. To level your
Wine Cooler, adjust the front leveling leg at the bottom of the Wine Cooler.
Locate the Wine Cooler away from direct sunlight and sources of heat (stove, heater, radiator, etc.).
Direct sunlight may affect the acrylic coating and heat sources may increase electrical consumption.
Extreme cold ambient temperatures may also cause the unit not to perform properly.
Avoid locating the unit in moist areas.
Plug the Wine Cooler into an exclusive, properly installed-grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong from the power cord. Any questions concerning
power and/or grounding should be directed toward a certified electrician or an authorized EuropAce
Products service center.
ELECTRICAL CONNECTION
This appliance should be properly grounded for your safety. The power cord of this appliance is equipped
with a three-prong plug which mates with standard three prong wall outlets to minimize the possibility of
electrical shock.
Do not under any circumstances cut or remove the third ground prong from the power cord supplied. For
personal safety, this appliance must be properly grounded.
This appliance requires a standard 220-240 Volt AC ~/50Hz electrical ground outlet with three-prong. Have
the wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly grounded.
When a standard 3-prong wall outlet is encountered, it is your responsibility and obligation to have it replaced
with a properly grounded 3-prong wall outlet.
The cord should be secured behind the appliance and not left exposed or dangling to prevent accidental
injury.
The appliance should always be plugged into its own individual electrical outlet which has a voltage rating
that matches the rating label on the appliance. This provides the best performance and also prevent
overloading house wiring circuits that could cause a fire hazard from overheated. Never unplug the appliance
by pulling the power cord. Always grip the plug firmly and pull straight out from the receptacle. Repair or
replace immediately all power cords that have become frayed or otherwise damaged. Do not use a cord that
shows cracks or abrasion damage along its length or at either end. When moving the appliance, be careful
not to damage the power cord.
Warning
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is
damaged, have it replaced by an authorized EuropAce Products service center.
INSTALLATION INSTRUCTIONS
7

REVERSING THE DOOR SWING OF YOUR APPLIANCE FOR EWC 6460S/EWC 6110S/EWC 6155S
This wine cellar has the capability of the door opening from either the left or right side. The unit is delivered
to you with the door opening from the left side. If you desire to reverse the opening direction, follow the
following reversal instructions:
NOTE: All parts removed must be saved to allow the door swing to be reversed.
Follow these steps:
1. Open the glass door and remove the two lock screws holding the lower hinge to the glass door. Be
careful to hold the glass door firmly after removing the screws.
2. Pull up to remove the glass door and place it on a padded surface to prevent scratching it. Install the
two screws back to the two holes of the door bottom at right side.
3. Remove the right lower hinge supporter.
4. Remove the door axle from the right upper hinge then install and tighten it in the left upper hinge.
5. Take the left lower hinge bracket from the left side then install it at the designated position.
6. Remove the two screws from the door bottom at left side, set the glass door to the designated position
and install the two screws to connect the lower hinge with the glass door and tighten them before the
door is levelled.
7. Remove the handle from the left side of the door and install it on the right side of the door.
Lock screws Lower hinge Bush Lower hinge bracket Glass door Door axle1 2 3 4 5 6
8
INSTALLATION INSTRUCTIONS

REVERSING THE DOOR SWING OF YOUR APPLIANCE
This appliance has the capability of the door opening from either the left or right side. The unit is delivered to
you with the door opening from the left side. Should you desire to reverse the opening direction, please
follow the below instructions.
9
INSTALLATION INSTRUCTIONS

The Wine Cooler should be placed in where the ambient temperature is between 32-95 degrees Fahrenheit
(0-35oC). If the ambient temperature is above or below this range, the performance of the unit may be affected.
For example, placing your unit in extreme cold or hot conditions may cause interior temperatures to fluctuate.
The range of 40-65 degrees Fahrenheit (5-18 oC)may not be reached.
Following control panel are applicable to models EWC 6340S:
Following control panel are applicable to models EWC 6460S / EWC 6110S / EWC 6155S:
RECOMMENDED TEMPERATURE SETTINGS
Conservation 10 ~ 14ºC 49 ~ 57ºF
Red Wines 15 ~ 18ºC 58 ~ 65ºF
Dry/White Wines 9 ~ 14ºC 48 ~ 57ºF
Rose Wines 10 ~ 11ºC 49 ~ 51ºF
Sparkling Wines 5 ~ 8ºC 40 ~ 47ºF
ON/OFF POWER
To turn ON or OFF the appliance, press the ON/OFF button.
The LED readout will show the actual temperature in the cabinet
(the preset temperature at the factory for UPPER ZONE is 10ºC / 50ºF and for LOWER ZONE is 16ºC / 60ºF).
OPERATING INSTRUCTIONS
10

SETTING THE TEMPERATURE CONTROL
You can select temperature display setting from Fahrenheit to Celsius degree by pushing the UP and DOWN
buttons at the same time for 5 seconds.
You can press the left side UP and DOWN buttons to control the internal temperature of the upper zone and
press the right side UP and DOWN buttons to control the internal temperature of the lower zone.
The degrees indicators will appear in the display window marked UPPER ZONE and LOWER ZONE.
The temperature range of UPPER ZONE is 5º ~ 12ºC which is suitable for storing sparkling and white wines.
The temperature range of LOWER ZONE is 12º ~ 18ºC which is suitable for storing white and red wines.
The temperature that you desire to set will increase 1ºF or 1ºC if you push the UP button once, on the
contrary the temperature will decrease 1ºF or 1ºC if you push the DOWN button once.
When you store mostly red wines, you should store them in the LOWER ZONE, the temperature which
you control by pushing the above UP and DOWN buttons need to be set at 15º - 18ºC / 58º - 65ºF.
When you store mostly white wines, you can store them in the UPPER ZONE or LOWER ZONE. When
you use the LOWER ZONE, the temperature can be set at 13º - 14ºC / 55º ~ 57ºF and the LED lamp
under “WHITE” will be lit. When you use the UPPER ZONE, the temperature can be set at 9º - 13ºC / 48
~ 55ºF and the LED lamp under “WHITE” will be lit.
When you store mostly sparkling wines, you should store them in the UPPER ZONE, the temperature
needs to be set at 5º - 8ºC / 40º - 47ºF and the LED lamp under “SPARKL” will be lit.
The temperature inside the unit will appear in blue color in the window marked “DISPLAY”.
NOTE:
If the unit is unplugged, power lost, or turned off, you must wait 3 to 5 minutes before restarting the unit.
If you attempt to restart before this time delay, the Wine Cooler will not start.
When you use the wine cooler for the first time or restart the wine cooler after having been shut off for a
long time, there could be a few degrees variance between the temperature you select and the one
indicated on the LED readout. This is normal and it is due to the length of the activation time. Once the
wine cooler is running for a few hours everything will be back to normal.
STORAGE
Many bottles may differ in size and dimensions. As such the actual number of bottles you may be able to
store may vary.
NOTE:
1. EWC 6340S - You can place 12 standard bottles in the upper zone and 22 standard bottles in the
lower zone.
EWC 6460S - You can place 16 standard bottles in the upper zone and 30 standard bottles in the
lower zone.
EWC 6110S - You can place 55 standard bottles in the upper zone and 56 standard bottles in the
lower zone.
EWC 6155S - You can place 77 standard bottles in the upper zone and 78 standard bottles in the
lower zone.
2.
3.
4.
11
OPERATING INSTRUCTIONS

INTERIOR LIGHT
Interior lights are available in both upper and lower zones.
You can turn the interior light on in each zone by pushing the button marked with the “bulb” symbol
.
The lights will turn off automatically if it remains ON for 10 minutes or more. You have to push the button
marked with the “bulb” symbol again and the light will turn back on.
DOOR LOCK
Your unit is provided with a lock and key combination.
The keys are located inside the plastic bag that contains the User’s Guide. Insert the key into the lock and
turn it counterclockwise to unlock the door. To lock the door do the reverse operation making sure metal pin
is engaged completely. Remove the key and place it in a secure place for safekeeping.
SHELVES
This appliance is equipped with a pull-out roller assembly (except for the bottom wooden shelf) and you can
move the wooden shelves out and in smoothly.
Pull-out Roller Shelves
To prevent damaging the door gasket, make sure to have the door all the way opened when pulling
shelves out of the rail compartment.
For easy access to the bottles, you must pull the shelves approximately 1/3 out of the rail compartment.
To remove the shelves out of the rail pull each shelf approximately 1/3 out. Use a long flat screwdriver to
press down the right plastic notch as shown in Figure A and at the same time lift the left plastic notch as
shown in Figure B. Then proceed to pull out the shelf slowly. Contact our service department if
assistance is needed.
Figure A Figure B
12
OPERATING INSTRUCTIONS

8

9

Product Warranty
The Warranty Card is not provided in the product packaging. You can register the product
warranty online at our website https://www.europace.com.sg/ewarranty/ within 7 (seven)
days from the date of purchase. You will enjoy an additional 3 months of the product
standard warranty when you register online. Please produce your E-warranty registration
when requesting for repair and service at our Service Centres nearest to you.
In the event, if you are unable to register the product warranty online you must produce your
purchase receipt/tax invoice and such other documentary proof of purchase of the appliance
when requesting for repair and service.
Product Warranty Coverage
You may nd out your product warranty coverage at the link below before calling our Cus-
tomer Service Hotline [phone] or visiting our Service Centre.
http://europace.com.sg/ewarranty/src/cupload/settings_pd-
f/1/1-1-2c899-1563960978-WARRANTY-COVERAGE-19_0221.pdf
TERMS & CONDITIONS OF WARRANTY (THIS WARRANTY IS VALID IN SINGAPORE ONLY)
Your appliance is warranted against faulty design, workmanship or materials for a period of
12 months unless otherwise stated from the date of purchase, subject to the following terms
& conditions herein below:-
1) That the owner shall register the product warranty online at our website www.eu-
ropace.com.sg within 7 (seven) days from the date of purchase.
2) That the appliance shall be used solely for domestic purposes and not for commercial
purposes or any other purposes whatsoever and used strictly under the instruction for
operation as provided by the manufacturers or the appliance.
3) That if any time during the warranty period any part or parts of this appliance is removed,
tampered, modied, adjusted, altered, handled or repaired in any way whatsoever by any
persons other than those authorized by Strategic Marketing (S) Pte Ltd, this warranty shall
immediately cease to be valid and become void.
4) That the owner shall produce the E-warranty registration or tax invoice/receipt and such
other documentary proof of purchase of the appliance to our satisfaction as we may deem
necessary when requesting for repair and service.
5) That our decision on all queries relating to complaints as to defects either of workmanship
or of materials shall be conclusive and the owner shall agree to abide by such a decision. Any
appliance or defective part which has been replaced shall become our property.
6) The terms and conditions of this warranty shall be contained exclusively in this document
and no other presentation of provision, either written or otherwise, regardless of the origin of
the same, shall be accepted as either adding or removing from these terms and conditions.
7) That this warranty shall cease to be valid and void if the appliance is exported or
relocated from Singapore.
8) That there shall be no removal, alteration, defacement, or made illegible/tampered or any
kind of the serial number on the appliance.
9) That the owner shall be fully responsible for the due delivery and collection of the appli-
ance for any work done according to this warranty. Transportation expenses incurred for
delivery or handling the appliance are chargeable to the owner.
10) Transportation and labour charges apply after the full parts warranty expires. Refer to
https://www.europace.com.sg/ewarranty/ for more information.

In addition to the above, this warranty shall be subjected to the following limitations and
exclusions:-
a)The appliance shall be warranted by STRATEGIC MARKETING (S) PTE. LTD. from date of
purchase only for a period of:-
10 years - Heating Element warranty applies to selected models of Storage Water Heaters.
- Tank Leakage warranty applies to selected models of Storage Water Heaters.
8 years - Motor warranty applies only to selected models of Stand Fans (Walk-in warranty).
10 years - Compressor warranty applies to selected models of Refrigerators.
6 years - Motor warranty applies only to selected models of Stand Fans (Walk-in warranty).
- Compressor warranty applies only to selected models of System Air Conditioners
and Portable Air Conditioners.
5 years - Compressor warranty applies to Refrigerators, Freezers, Wine Coolers, Portable
Air Conditioners & Casement Air Conditioners (Outdoor warranty). Transportation is
chargeable from the 2nd year to 5th year.
- Compressor warranty applies to Dehumidiers (Walk-in warranty)
- Motor warranty applies only to selected models of Stand Fans (Walk-in warranty).
3 years - Full parts warranty applies only to selected models of Air Puriers & selected
models of Dehumidiers (Walk-in warranty).
- Heating Element warranty applies only to selected models of Garment Steamers
(Walk-in warranty).
- Motor warranty applies only to selected models of Jet Turbine Fans & selected
models of Air Coolers (Walk-in warranty).
2 years - Motor and internal parts warranty applies only to selected models of Stand Fans,
selected models of Oscillation Power Fans & selected models of Air Puriers
(Walk-in warranty).
- Heating Element warranty applies to selected models of Electric Ovens &
selected models of Kettle Jugs. (Walk-in warranty)
- Motor warranty applies only to selected models of Jet Turbine Fans
(Walk-in warranty).
- Full parts warranty applies only to Wine Coolers of 34 Bottles & above.
1 year - Full parts warranty applies to *Lifestyle Products (cash & carry items), Small
Kitchen Appliances, Fans, Air Coolers, Wine Coolers of 20 Bottles & below, Mini
Bar Fridge (Walk-in warranty)
- Full parts warranty apply to Refrigerators, Air Conditioners & Freezers
(Outdoor warranty).
Check out the warranty coverage of your appliance at www.europace.com.sg
b) The owner waives all or any claims to compensation monetary or otherwise which
he/she may be entitled to and shall agree to accept any compensation whatsoever by
way of additional repairs or otherwise which we in our absolute discretion may deem t
to oer. The giving of compensation shall be subjected to the other provisions of the
warranty.
c) This warranty shall not be transferable, negotiable or assignable to any third party.
d) The warranty does not include transport delivery or handling charges incurred in the
transportation of the appliance to and from Strategic Marketing (S) Pte Ltd.
e) Damage caused during transit where the appliance is transported for servicing, repair,
or in relation thereof or connection therewith.
f) In respect of refrigerator and air conditioner only, upon the expiry of 12 months from
the date of purchase, this warranty will not cover transport, refrigerant and labour to
install a new compressor.

g) This warranty will not cover chemical cleaning, maintenance service, general service and
overhaul, which if conrm is chargeable.
h) Defects or fault in the appliance which has been used for commercial purposes or which
have been rented/leased or which have been otherwise subject to other than household
use.
i) Claims for damaged/missing parts after 3 days from the original date of goods received
will not be valid.
j) This warranty and the Replacement Scheme does not particularly cover damages and/or
defects arising from
• Usage of wrong electrical supply/voltage.
• Usage not according to the Instruction Manual provided by the manufacturers.
• Misuse, accidents, negligence, abuse, improper installation, or any manner of tampering.
• Normal wear and tear.
• Corrosions rusting or stains.
• Scratches, dents on the unit body, casing or paintwork of the appliance.
• Act of God, re, ood and civil unrest.
• We shall not under any obligation, legal or otherwise to repair this appliance or one to one
exchange if the same shall be required as a result of losses, damages, and malfunctions
arising from any of the causes mentioned in the paragraph.
k) All accessories, external parts and extruded parts such as front panel, casing, door, glass
cover, glass door, cable/cord assembly, batteries, adaptor, plug, remote control, control
knob, buttons, lter, UV lamp, oven tray, wooden rack, exhaust hose, xtures, panels, cover,
lid and lever, plastic parts, fan blades, blade guard, inner pots, brushes, water tanks, attach-
ments made of glass, plastic and/or porcelain, detachable parts, and other option items are
excluded from this warranty.
All services provided after the warranty period will be chargeable at standard rates deter-
mined by STRATEGIC MARKETING (S) PTE. LTD.
The terms and conditions of this warranty shall be varied except with the written and
express consent or agreement of Strategic Marketing (S) Pte. Ltd. While Strategic Marketing
(S) Pte. Ltd. endeavours to repair any defects after the warranty period, it is subject to avail-
ability.
It is hereby expressly provided that any liability of Strategic Marketing (S) Pte. Ltd. for any
loss or damage whatsoever arising from, relating to or in connection with the purchase of
the appliance shall not exceed the purchase price (excluding installation costs) of the appli-
ance. Similarly, Strategic Marketing (S) Pte. Ltd.’s liability for any breach of this warranty shall
be limited to the purchase price (excluding installation costs) of the appliance.
* Lifestyle Products - Garment Steamer, Humidier, Dehumidier, Air Purier, Mini
Bar-Fridge.
* Walk-in warranty - Customers are obliged to bring the warranted products to Strategic
Marketing (S) Pte. Ltd. Service Centre for repair/service during the warranty period.
Ver. 20 _0312
Scan QR Code for
the online Warranty
Registration

System Split Aircons | Tel: [phone]| Email: [e-mail] (Twin City)
Portable & Casement Aircons | Tel: [phone] | Email: por[email protected]om.sg (Jia Yue)
Refrigerators, Washing machines, Cookers & other major appliances |
Tel: [phone] | Email: [e-mail] (TnG)
RELATED PRODUCTS & MAIN CONTACT HOTLINE
Ver. 20 _0312
