EVB BCPP-A1-16 User manual

Portable
EV Charger
User Manual
evb.com
WWW.EVB.COM
VERSION: 20231121-01
www.evb.com

1. Safety Information 01
2.1. Product Appearance
2.2. Product Specification
2.3. Plug Types
2.4. Product Packing List
2.5. Product Functions
2.6. Product Features
2. Product Description
02
03
03
04
04
05
02
3. Operating Status
3.1. LED Light Description
3.2. OLED Screen Description
05
05
07
4. How to Plug and Play 07
5. How to set charging current 08
6. How to set a timed charging 08
7. How to emergency stop charging 09
8. How to set temporarily charging when the socket without ground wire 09
9. Permanently turn off the ground detection setting 10
10. Warranty Description 10
PAGE 01
www.evb.com
1. Safety Information
Thank you for purchasing and using the Benyi electric vehicle mode 2 charger.
This document contains important instructions and warnings that must be followed when using and maintaining the EV Charger.
In order to help you to use the product correctly,please read this manual carefully before charging.
Portable EV Charger
evb.com Portable EV Charger evb.com
CONTENTS
Warning
Read this entire mandatory document before using the EV charger.
This device should be supervised when used around children.
Do not install or use the EV Charger near flammable, explosive, harsh, or combustible materials, chemicals, or vapors.
Use the EV Charger only within the specified operating parameters.
Stop using and do not use the EV Charger if it is defected, cracked, frayed, broken, or otherwise damaged, or fails to operate.
Do not attempt to disassemble, repair, tamper with, or modify the EV Charger. Contact use for any repairs or maintenance.
Do not touch the EV Charger’s end terminals with sharp metallic objects, such as wire, tools ,or needles.
Do not forcefully fold or apply pressure to any part of the EV Charger or damage it with sharp objects.
Do not insert foreign objects into any part of the EV Charger.
Before use, please confirm whether the parameters of the electric vehicle match the chargers, otherwise it may cause damage to the
vehicle.
Cautions
For safe electricity usage, it is not recommended to use the device to charge in the open air on rainy days.
Do not immerse the AC Charging device in water
Do not step on the cable, pull the cable, bend the cable or tie the cable
Do not drop the control box or put heavy objects on its surface
Do not place the device near objects that generate high temperature while charging
Do not put the device in the car or in a closed space while charging
Do not operate the EV Charger in temperatures outside its operating range of -30°C to +50°C.
Notes
For electric vehicle charging only
This product must be well grounded when using
Do not use the device when the charging cable is damaged
Do not put your fingers in the charging plug
Do not use extra wires or adapters
This produce does not contain user maintainable parts, please do not attempt to repair and maintain it yourself.
If the device cannot be charger normally according to this operation manual, please contact the dealer for repair or replacement.

PAGE 02/03
2. Product Introduction
The charger is designed according to lEC 62752, IEC 61851-21-2 standard, mainly consists of control box, charging connector, plug and etc...
Which is a portable electric vehicle charging device. It enables car owners to charge electric vehicles anywhere using a standard home power
interface, featuring high efficiency and portability.
Frequency
Storage temperature
IP Protection
IEC 62752,IEC 61851-21-2
BCPP-A1-16
Standard
Model
IP66
<1.5W
50Hz/60Hz
2.2. Product Specification
2.3. Plug Types
Parameter description Parameter
Rated Input/Output Voltage 230V(100~265V)
8A/10A/13A/16A
Rate Charging Current
Standby Power Consumption
Operating Temperature -30 ~50°C °C
-40 ~85°C °C
Safety Protection
Insulation Resistance
<10000 times
Working Life
UL94-V0
Flame Retardant Rating
<2000m
L:200mm W:90mm H:55.5mm
1m
7m as standard (Customized length available)
Operating Altitude
Charger Dimension
Plug Cable Length
Total Length
2.5KV
Impulse Withstand Voltage
1430VAC/1min
Dielectrical Strength
Operating Humidity 5%~95%
>100MΩ
2.1. Product Appearance
Leakage Protection, Over Current Protection, Over Voltage Protection, Fire Protection, Under Voltage
Protection, Over Temperature Protection, Relay Adhesion Protection, Ground Protection, Lightning
Protection, CP Signal Abnormal Protection, Anti-pressure Protection
H07BZ5-F
3G 2.5mm²
ZH-3
H05VV-F
3G 2.5mm²
YP-39A
20A/250V~
AU ZA
ZH-70A
H07RN-F
3G 2.5mm²
Model Type
Current/Voltage
Wire
Material
16A/250V~ 16A/250V~
P.V.C P.V.C P.V.C
EU(German) UK BRA USA
ZH-72B
YP-61A
H05VV-F
3G 2.5mm²
H07RN-F
3G 2.5mm²
13A/250V~ 16A/250V~
P.V.C P.V.C
SJ
14AWG*3C*2.08mm²
15A/125V
ZH-02
N.P.C-45P
www.evb.com
16A Plug
Shell
OLED Screen
Touch Key-press
Shell
LED Indication
Charging Cable
Connector Cap
Bushing
Cap Link Wire
Portable EV Charger
evb.com Portable EV Charger evb.com

PAGE 04/05
www.evb.com
2.4. Product Packing List
2.5. Product list
2.6. Product Features
3.1. LED Light Description
Build-in with Over Current Protection, Over Voltage Protection, Under Voltage Protection, Over Temperature Protection, Relay Adhesion
Protection, Ground Protection, CP Signal Abnormal Protection, Fire Protection, Anti-pressure Protection and Type B Leakage Protection.
It can be charged by appointment, 0-24 hours.
Adjustable Charging Current for Easy Charging.
Automatically recharge after power failure recovery.
With lightning protection device to ensure personal safety.
With OLED screen display, more intuitive and clear.
With Touch key-press, more flexible and convenient operation.
IP66 protection, operating humidity range 5%-95% for indoor and outdoor.
Operating temperature range: -30°C ~ +50°C.
Standard: IEC 62752, IEC 61851-21-2.
1
2
3
1
1
1
NO.Item Quantity
Portable EV Charger
Portable EV Charger Bag
User Manual
WWW.BENY.COM
Portable
EV Charger
User Manual
x1 x1 x1
Under Voltage
Protection
Over Voltage
Protection
Over Current
Protection
Over
Temperature
Protection
Fire
Protection
A
Leakage
Protection
Relay
Adhesion
Protection
Lightning
Protection
Ground
Protection
Anti-pressure
Protection
CP Signal
Abnormal
Protection
CP
With full protection to avoid all kinds of charging safety hazards, it will automatic power off after the vehicle is fully
charged, to protect the car battery and prolong the working life.
3. Operating Status
Standby
The charger is ready,
the vehicle is not ready.
Charging normally
Plugged to start
charging
Normal Status
LED Off No Power Power is not on Check Power
Green light on
Streaming light runs
back and forth
Plug the connector
to set timer charging
(Not ready to charge)
Streaming light runs
two ends to middle
LED light runs from
middle to end
(Not to bottom)
Charging without
current
Check if connector
plugged
Streaming light runs
from middle to up and
down
Charging completed
All lights on green
LED Lights Status LED Lights Status EV Charger Status Potential Cause Action
Portable EV Charger
evb.com Portable EV Charger evb.com

PAGE 06/07
www.evb.com
OLED Screen Status
Check if socket is
grounded, if without
grounding wire,
you can turn on
emergency charging
CP Vol
Over
Current
Over
Temp
Fault Status
LED Lights Status EV Charger Status Potential Cause Action
Emergency Stop
Protection
Accidentally touch
the emergency
stop
Pull out the charging
connector and
re-plug it
CP Signal Abnormal
Protection
Charging connector
loose
Tighten charging
connector
Over Current
protection
Short Circuit Waiting for professional
repair
Over Temperature
Protection
The ambient
temperature is
too high to cause
an alarm
Wait for the temperature
recover and automatically
recharge
Poor grounding Ground wire not
connected
Relay
NO Action
Relay
Adhesion
Leakage
Under
Voltage
Over
Voltage
Emergency stop charging,
restart charger to check
if it is normal; If not,
please contact the dealer
Relay Adhesion
Relay No Action
OLED Screen Status
LED Lights Status EV Charger Status Potential Cause Action
Over Voltage
Protection
Short circuit of home
lines or unstable of
grid power
Check the home lines...
Wait for grid power to
recover
Fault Status
Under Voltage
Protection
Insufficient grid
voltage
Wait for gridpower to
recover
Leakage Protection There is residual
current
Check if there is a
leakage of end of the
vehicle
Relay Abnormal
Relay Abnormal
3.2. OLED Screen Description
Enter interface for
emergency stop charging
Enter interface of setting
Set max charging current Set timer charging
Reserve: 0h
Save SettingsSetting
Poor grounding
Wait for Plug
Ignore poor grounding
and start charging
Picture Status Press Left Key Press Right Key Press Left and
Right Together
Charging
Cancel
Emergency stop charging Stop
4. How to Plug and Play
Wait for the vehicle
to be ready to start
charging.
Power-on and self-test,
Plug the connector into
the vehicle.
Portable EV Charger
evb.com Portable EV Charger evb.com

PAGE 08/09
www.evb.com
5. How to set charging current
Press both at
same time
Wait vehicle ready,
then start charging.
Reserve: 0h
Reserve: 0h
Press the left
to select current
Press both at same time,
then plug connector into
vehicle.
6. How to set a timed charging
Press both at
same time
Reserve: 0h
Reserve: 4h
Press the right to
select time
Press both at
same time
Plug connector into
vehicle, Wait to start
charging.
7. How to emergency stop charging
Press both at
same time
Press the left to
stop charging,
Press the right to
cancel
8. How to set temporarily charging when the socket without ground wire
Plug connector
into vehicle
Wait vehicle ready,
then start charging.
Press both at
same time
Portable EV Charger
evb.com Portable EV Charger evb.com

PAGE 10/11
www.evb.com
9. Permanently turn off the ground detection setting
Double-click to enter
the setting interface
Click the left
button to confirm,
right to cancel
Double-click and hold
for 5s to enter the ground
detection setting interface
Reserve: 0h
Turn off
Gnd Detection
Yes No
10. Warranty Description
Free warranty is available for any damages or failures due to the chargers’ quality problems since 1 year from the date of producing at
the factory.
Any damages caused by failure of operations, irresistible natural reasons, wrongs installation or use against with the instructions, is not
covered by the warranty.
Non-professionals are not allowed to repair the chargers, Any problems during installation or use, please contact the dealer first.
