EVO-1 Display
OWNER’S MANUAL
Our Team is here to help 7 days a week
contact@evelo.com |877-991-7272
Feel free to reach out!
EVELO.COM
2
EVO-1 DISPLAY
Display and Keypad
Speedometer
‘+’ Button
‘–’ Button
Trip Odometer
Current Power Usage
Set Button
On/Off Button
Battery Level
Pedal Assist Level
3
EVO-1 DISPLAY
Using Your Bike
ON/OFF and Lights
Press the ON/OFF button to power on the bike. Press the ON/OFF
button again to turn on the lights, and again to turn them off. Hold down
the ON/OFF button for three seconds to turn the bike off.
Speedometer
The speed is shown in the middle of the screen. You can choose miles or
kilometers in the settings menu.
Pedal Assist Level Selection
Press the + or - button to select your pedal assist level. You can choose
from 0 to 5, with 0 being no assistance and 5 the most assistance.
Battery Indicator
The battery frame has five segments, each representing 20% of the
battery’s capacity. When the battery is full, the five battery segments are
all lit. When the outside edge of the battery frame flashes it indicates that
the battery is severely low and needs to be recharged immediately.
Error Code Indicator
If there is something wrong with the electronic control system, the error
code and error message will display in the top of screen.
4
EVO-1 DISPLAY
Settings Menu
Hold the SET button for 2 seconds to enter the Settings menu, click + or -
to select the item, then click SET again. When the color of the setting item
turns green, then press + or - to select the desired parameter, and aer
the parameters have been changed, click SET again. The color will turn
white to indicate the change to the setting is complete.
Trip Clear
N means NO Y means YES
Select “Y” and when you return to the main interface, you will find the Trip
Odometer has been cleared.
Brightness
Adjust the brightness of your display panel
5
EVO-1 DISPLAY
Speed Limit
This setting controls the max assisted speed. When you reach that speci-
fied speed, assistance will be turned off. The limit can be raised, but you
should check your local laws before doing so.
Wheel Size
Set your wheel size. It is set correctly from the factory. You can refer-
ence the tire size printed on the tire or contact us for more information if
needed.
Units: KPH and MPH
Select MPH or KMH for the speed and mileage.
Battery
You can set the battery’s voltage here. The bike will malfunction and the
battery may possibly be damaged if you choose an incorrect voltage. It is
set correctly from the factory; please contact us if you need to know the
voltage of your bike.
Mode
This setting is not used.
Auto Off
When the bike does not move for a short time, it will power down
automatically.
Exit
Click SET, the changes will be saved and the setting interface will close.
Settings Menu
6
EVO-1 DISPLAY
Your bike stores a variet of information about your
battery. You can view it here.
Total Voltage:
The current voltage of the battery
Full Capacity:
The full capacity of the battery when new
Re: Capacity:
The remaining capacity of the battery currently
SOC:
Current State of Charge, expressed as a percent-
age
SOH:
The State of Health of the battery, expressed as a
percentage. It is simply comparing the Re: Capac-
ity to Full Capacity
Cycle Times:
The number of charge and discharge cycles the
battery has experienced
Battery Cell Info:
Detailed information about the individual cells in
the battery
Time:
Approximate hours the battery has been in use.
Temperature:
Current temperature of the battery
Battery Info
7
EVO-1 DISPLAY
Notes:
