Magicshine RAY 2600 User manual

ACCESSORY/STRUCTURE
HOW TO INSTALL
BATTERY INDICATOR
When the device is power-on, the power button light will indicatethe battery level.
When the device is power-off, short press the power button to activate the indicator light
(light will shut down automatically after 2 seconds).
PHONE CHARGING INSTRUCTION
*External charging cable needs to be purchased additionally
To prevent potential damage from high heat or even fire, it is very important to put the bicycle
light in lock mode and protect the switch from being pressed.
MAGICSHINE will not be held responsible for damages to person or property resulting from a
failure to follow the 'lock' mode instructions.
To lock -
When the light is off, press and hold the power button down for 5 seconds until the indicator
light flashes red.
To unlock -
When the light is locked, press and hold down the power button for 5 seconds until the
indicator light constant red.
MODE MEMORY FUNCTION : When you turn the light on, it lights up in the last lighting
mode you used.
MODE SELECTION : In standby mode, press the up/down button at the same time to enter
mode selection. Press the up button to select smart mode(constant blue) or press the down
button to select normal mode(flash blue).
Press the up/down button at the same time to confirm the selection mode.
SMART MODE-LIGHT SENSOR : The light sensor monitors ambient light to adjust light
output accordingly. During daytime, light's output automatically switches to dual beam with
40lumens.When entering a tunnel or shortly after sun down, light's output automatically
switches to original setting within seconds.
SMART MODE-VIBRATION SENSOR : An integrated vibration sensor detects the end of a ride
and automatically turns off the light after 3 minutes. Any further movement will turn the light
back on.
Hold 1s power button to turn on/off
SWITCHING THE LIGHTING MODE
LOCK MODE
RAY 2600 USER MANUAL
3mm HexType-C USB CableAero bar compatible strap
Gopro mount
1
4
2
3
5
RED
11%-20%
FLASH RED
0%-10%
GREEN
21%-100%
HOW TO RECHARGE
Charging
FLASH RED
Fully charged
GREEN
Standard charging time
Approx.2.5hrs (18W)
RAY 2600 Remote control Handlebar mount
1 x click 1 x click 1 x click
1 x click 1 x click 1 x click
1 x click
1 x click
1 x click 1 x click
Long press to power on/off
Double-click
Double-clickDouble-clickDouble-click

OPTIONAL PARTS
*Adaptable accessories (sold separately)
Helmet mount TTA front mount
The Magicshine lighting system is warrantied for 24 months from the
date of purchase.
If you register the lighting system on the Magicshine website you will
receive a bonus 6 month warranty.
Battery packs and AC adapters have a 6 month warranty, however,
there is no bonus warranty available.
The warranty is limited to defects in material and workmanship on the
lighting system itself, the battery pack and the AC adapter.
The warranty is only valid if the affected parts have not been tampered
with and there is no intentional damage. Please keep your proof of
purchase in a safe place. Proof of purchase must be presented in the
event of any claim. Please contact the specialist retailer from whom
you purchased the device for complaint or warranty claim.
Alternatively, you can send your complaint or claim directly to
Magicshine at
Tel: [phone]
Fax: [phone]
E-mail: [email protected] (order from Magicshine.com
online store)
ser[email protected] (order from other sales channels)
In the event of a justified warranty claim and delivery of a replacement
device, you will only be entitled to a model available when replacing.
The manufacturer retains the right to make technical modifications.
WARRANTYEN
WARNING
Don't cover the light screen when the power is on
LUMENS/RUN TIME
MODE MID
650
04 07
650
04 07
1300
02 12
HIGH
1300
02 12
1300
02 12
2600
01 34
LOW
330
11 45
330
11 45
650
05 48
330
ECOBRIGHTNESS
170
22 56
170
22 56
330
11 34
330
/
/
/
/
//
ANSI FL 1 STANDARD
183m
BEAM DISTANCE
8400cd
PEAK BEAM INTENSITY
IMPACT RESISTANCE
1m
2600
LIGHT OUTPUT
WATERPROOF
IPX6
