Ever EASYLINE AVR USB User manual

EVER EASYLINE AVR USB UPS Range Operating Manual
Type 02
2017-01-27 12:25
Technical Service, tel.: [phone]
www.ever.eu
2
TABLE OF CONTENTS
TABLE OF CONTENTS...................................................................................................................................... 2
INTRODUCTION................................................................................................................................................. 3
GENERAL FEATURES OF THE UPS UNIT ................................................................................................... 4
SAFETY INSTRUCTIONS AND RECOMMENDATIONS ............................................................................ 5
UPS DESCRIPTION AND INSTALLATION ................................................................................................. 10
FRONT PANEL.................................................................................................................................................... 10
REAR PANEL...................................................................................................................................................... 10
UNPACKING THE PRODUCT........................................................................................................................... 11
INSTALLING THE UPS UNIT ........................................................................................................................... 12
Input installation...........................................................................................................................................12
Output installation........................................................................................................................................13
LCD DISPLAY ICONS........................................................................................................................................ 15
DESCRIPTION OF LCD DISPLAY ICONS.................................................................................................15
FIRST START-UP................................................................................................................................................ 16
DESCRIPTION OF OPERATION OF THE UPS........................................................................................... 17
GENERAL INFORMATION............................................................................................................................... 17
MAINS MODE (NORMAL)................................................................................................................................ 18
BACK-UP MODE (BATTERY OPERATION)................................................................................................... 18
STANDBY MODE............................................................................................................................................... 18
COLD START...................................................................................................................................................... 19
SAFEGUARDS .................................................................................................................................................... 19
Overload protection......................................................................................................................................19
Short-circuit protection ................................................................................................................................19
COMMUNICATION WITH PC ....................................................................................................................... 19
OPERATING INSTRUCTIONS ....................................................................................................................... 20
INTERACTION WITH ELECTRICAL GENERATORS.................................................................................... 20
OPERATION OF THE TELECOMMUNICATION FILTER (in the model 650/850)........................................ 20
OPERATION OF THE LAN FILTER (in the model 1200) ................................................................................. 20
STORAGE, MAINTENANCE AND TRANSPORT ........................................................................................... 21
DISPOSAL ........................................................................................................................................................... 21
TECHNICAL PARAMETERS.......................................................................................................................... 22
LEGAL REGULATIONS AND WARRANTY................................................................................................ 24
DECLARATION OF CONFORMITY................................................................................................................. 24
WARRANTY ....................................................................................................................................................... 24

EVER EASYLINE AVR USB UPS Range Operating Manual
3
www.ever.eu
Technical Service, tel.: [phone]
2017-01-27 12:25
Type 02
INTRODUCTION
Thank you for purchasing the EVER EASYLINE AVR USB UPS unit. This UPS has
been designed and engineered to meet your expectations and provide the highest
standard of protection against power failure.
This manual contains all relevant information to ensure correct and safe operation of
the unit. Please read this manual carefully and thoroughly prior to using the EVER
EASYLINE AVR USB unit. This will help to operate the unit and correctly and safely.
EASYLINE AVR USB units provide protection against power drops and losses
in the grid, consequently increasing the life and reliability of the connected
equipment.
Their main purpose of the EVER EASYLINE AVR USB series UPS units is to protect
computers, video games consoles, telecommunication networks and devices (Wi-Fi),
monitors, inkjet printers and fiscal devices.

EVER EASYLINE AVR USB UPS Range Operating Manual
Type 02
2017-01-27 12:25
Technical Service, tel.: [phone]
www.ever.eu
4
GENERAL FEATURES OF THE UPS UNIT
The EASYLINE AVR USB units are LINE-INTERACTIVE class units designed to
work with equipment supplied from ~ 230 VAC single-phase electric power mains.
They provide energy for practically any device whose power rating is not greater than
the UPS units power rating. EASYLINE AVR USB units will not switch off
automatically, even if no devices are connected to their output sockets, which means
they can be used with any low power devices. Only the max power is limited and if
the UPS is overloaded, it will generate a sound alarm and display a message on the
LCD screen.
The unit is not recommended to work with large TVs, laser printers and other devices
whose impulse consumption is significantly larger than the UPS's rated power.
Apart from excellent performance and reliability, EASYLINE AVR USB UPS units
feature these great advantages:
Automatic voltage regulation (AVR).
Complex LCD panel - visual information concerning particular work states and
parameters of the UPS.
Microchip control of all parameters.
Automatic restart after the battery is discharged and when the mains power is
back.
Mains voltage filtering.
"Cold start" –option of starting the UPS without connection to the mains.
Acoustic signaling of particular work conditions.
A USB port for communication with a PC.
PowerSoft software for controlling the operation of the UPS and shutting the
system down automatically.
Complex LCD panel - visual information concerning particular work states and
parameters of the UPS.
Telecommunication filter (in the model EASYLINE 650 / 850 AVR USB).
LAN filter (in the model EASYLINE 1200 AVR USB).

EVER EASYLINE AVR USB UPS Range Operating Manual
5
www.ever.eu
Technical Service, tel.: [phone]
2017-01-27 12:25
Type 02
SAFETY INSTRUCTIONS AND RECOMMENDATIONS
A) General information
CAUTION! Before starting the execution of procedures described herein,
please read the general safety instructions (and also instructions in this
document), OHS information, environmental protection information and
legal regulations; please observe information and recommendations
found in these documents.
CAUTION! It is strictly forbidden for the user to perform any repair
works, as this would constitute a threat to health and/or life. Any repairs
and replacement of batteries should be conducted only by qualified
service technicians properly authorized pursuant to the valid legal
regulations.
CAUTION! The appliance should be operated and stored in conditions
concordant with those set in the specification (technical documentation).
CAUTION! The device is completely disconnected from the mains only
when the power lead is removed from the mains socket (the plug is
removed from the mains socket).
CAUTION! The appliance is equipped with an internal power source
(battery). Dangerous voltage may be present at the output terminal, even
if the device is disconnected from the mains.
CAUTION! The user should place warning labels on all primary switch
disconnectors installed far from the UPS, to warn electrical service
technicians that the circuit is powered by a UPS. The following (or
equivalent) text should be placed on such warning labels:
DISCONNECT THE UPS BEFORE STARTING WORK ON THIS CIRCUIT.
CAUTION! Opening the housing may result in electric shock.

EVER EASYLINE AVR USB UPS Range Operating Manual
Type 02
2017-01-27 12:25
Technical Service, tel.: [phone]
www.ever.eu
6
CAUTION! Do not touch any electrical connectors and internal metal
elements before disconnecting power.
CAUTION! All openings and spaces facilitating access to the UPS's
electrical connectors must be covered (with relevant covers). Failure to
observe this requirement may result in danger to health or life of people
attempting to touch such connectors or in the damage of the device.
CAUTION! In the event of a short-circuit, serious burns may be caused
by high current.
CAUTION! There are no end-user serviceable parts inside the UPS.
CAUTION! EASYLINE AVR USB UPS units are not intended for use
directly with medical equipment, life support systems or equipment that
may affect health.
B) Installation notes
CAUTION! EASYLINE AVR USB UPS UPS units may only be installed
and maintained by qualified personnel.
CAUTION! Before installation of the UPS, OHS regulations for working
with electrical equipment with voltage up to 1 kV must be read.
CAUTION! Before connecting cables or making connections in the UPS
or in electrical installations, make sure there is no dangerous voltage on
electrical terminals and cables in the system.
CAUTION! The UPS may only be connected to a ~230 V mains socket
with a grounding connection (a bolt). The building's electrical installation
to which the UPS is connected must feature overload and short-circuit
protection.

EVER EASYLINE AVR USB UPS Range Operating Manual
7
www.ever.eu
Technical Service, tel.: [phone]
2017-01-27 12:25
Type 02
CAUTION! Only TN-S or TN-C-S configuration is allowed on the UPS's
input, and only TN-S configuration is allowed on the UPS's output.
CAUTION! No extension cords should be connected to the UPS.
CAUTION! The device must not be installed near flammable materials!
Never perform works alone in conditions dangerous to health and/or life.
Shortly after moving the UPS from cold environment to warm environment,
moisture can condensate. The UPS must be completely dry before installation
and operation. The acclimatization time should be at least 2 hours.
UPS units and battery modules must not be installed in humid environment.
UPS units and battery modules must not be installed in places where they would
be subject to direct sunlight or near sources of heat.
Ventilation openings in the UPS housing must not be blocked - observe distances
to ventilation openings specified in the manual.
Before connecting the device, the technical condition of the connectors, sockets
and cables, and of the appliance itself, must be checked.
The device must be connected to a power circuit (mains socket) with three
terminals (phase, neutral and grounding), including a PE grounding conductor.
Failure to observe this requirement may result in electric shock.
To reduce the risk of electric shock (in case the grounding cannot be checked),
the device must be disconnected from the mains before installation or connecting
to other equipment - the power lead may only be connected again after making all
required connections.
A device powered through a lead with a plug has a grounding conductor that
carries away the leakage current from the receivers. The leakage currents of all
receivers connected to the UPS's output are summed in the UPS's power lead.
The summary leakage current may trigger protective devices (RCD) and result in
disconnecting power from the receivers.
When connecting and disconnecting signal cables, all activities should be
performed with one hand only (if feasible), in order to avoid electric shock from
touching two surfaces with various electrical potentials.

EVER EASYLINE AVR USB UPS Range Operating Manual
Type 02
2017-01-27 12:25
Technical Service, tel.: [phone]
www.ever.eu
8
Leads connected to the UPS's output should not be longer than 10 m, in order to
maintain conformance with the EMC directive for products sold in Europe.
Connecting leads should be placed so that people walking over them will not step
or trip on them.
To limit the risk of fire, connections should only be made to circuits (electrical
systems) whose rating is adequate for the connected loads, with properly selected
overcurrent protection. Additionally, the breaker should feature at least 3 mm
insulating air gap.
C) UPS operation remarks
OHS regulations and guidelines specified in the device's manual must be
observed when handling and operating the UPS.
The instructions must be executed step by step. If any problems emerge when
executing the instructions given in this document, please contact EVER service
support (www.ever.eu).
Do not disconnect the grounding at the UPS or in the building's electrical system
terminals, as this will remove the UPS's protective grounding.
There may be voltage on the UPS's output terminals, even if the UPS is
disconnected from the building's electrical system (due to presence of power in
the device's internal batteries).
Liquids and foreign bodies must not penetrate the UPS's housing.
WARNING: This is a C2 category UPS. If installed in residential environment, this
product may interfere with radio signals, which may require additional precautions
to be employed by the user.
D) Maintenance, repair and defects related remarks
Dangerous voltages are present in the UPS. Only qualified service technicians
may perform maintenance works.
CAUTION - risk of electric shock. Even if the device is disconnected from the
mains (terminals of the electrical system), the elements inside the UPS are
connected to the battery, which may lead to danger. Disconnect the battery before
carrying out any service and/or maintenance works. Make sure there is no
dangerous voltage on the DC circuit internal elements.
WARNING: Only properly authorized and qualified service technicians who have
legally required protection gear may replace batteries.

EVER EASYLINE AVR USB UPS Range Operating Manual
9
www.ever.eu
Technical Service, tel.: [phone]
2017-01-27 12:25
Type 02
CAUTION - risk of electric shock. Dangerous voltage may be present between the
battery circuit and the grounding point!
Batteries have high short-circuit current and pose a risk of electric shock. The
following precautions should be taken when working with batteries:
－remove jewelry, watches, rings and other metal items,
－only use tools with insulated handles.
The same number and type of batteries should be used. Using batteries of
improper type may result in explosion.
Dispose of used batteries according to the manual.
WARNING: Disposing of batteries in a fire may result in explosion.
WARNING: Opening or damaging batteries may cause electrolyte to leak;
electrolyte is harmful to skin and eyes, and may also be toxic.
To avoid the danger of fire and damage to the power system, replace broken
fuses with fuses of the same type and parameters.
Disconnect the device from the mains before cleaning. Do not use liquid or
sprayed cleaning agents.
Only qualified service technicians may disassemble UPS units.
E) Transport and packaging remarks
Exercise particular care when transporting the device.
Heavy equipment must be moved by at least two or more persons.
UPS units may be transported only in their original packaging boxes (to protect
the device from shocks and bumps).
The device should be operated and stored in conditions concordant with those set
in the specifications. UPS units must be stored in dry and well ventilated rooms.
If a UPS is to be stored for a longer time, its batteries must be recharged at least
every 6 months. The recharging procedure must be documented.
Check the recharging date. Do not use the UPS if the deadline passed and the
batteries were not recharged. If this occurs, contact service support.

EVER EASYLINE AVR USB UPS Range Operating Manual
Type 02
2017-01-27 12:25
Technical Service, tel.: [phone]
www.ever.eu
10
UPS DESCRIPTION AND INSTALLATION
FRONT PANEL
EASYLINE 650 / 850 AVR USB
EASYLINE 1200 AVR USB
Fig. 1: Front panel elements
1. Start / shut down button
2. LCD display
3. USB port for communication with the PC
REAR PANEL
1. Power lead
2. Outlet sockets with backup
3. Phone line filter RJ11
Fig. 2: Rear panel elements EASYLINE 650 / 850 AVR USB

EVER EASYLINE AVR USB UPS Range Operating Manual
11
www.ever.eu
Technical Service, tel.: [phone]
2017-01-27 12:25
Type 02
1. Port for communication with a
PC - USB
2. LAN filter RJ45
3. Power cord socket IEC 320 C14
4. Outlet sockets:
2 x IEC 320 C13
2 x PN-E-93201
5. Circuit breaker
Fig 3: Rear panel elements EASYLINE 1200 AVR USB .
UNPACKING THE PRODUCT
The UPS unit must be properly examined upon delivery or handover. Although the
product is solidly packaged, the appliance could have been damaged due to shocks
experienced during transport. Should any product damage be discovered, the carrier
or the vendor must be notified immediately.
CAUTION! The device is delivered with a connected battery
Check carefully the contents of the packaging. The packaging should contain:
The UPS,
Quick-start guide book,
Warranty card,
USB cable for connection with computer - 1 piece.
Detachable input power cord CEE7/7 –IEC 320 C13, 10A –1piece (applies
only to version EASYLINE 1200 AVR USB).

EVER EASYLINE AVR USB UPS Range Operating Manual
Type 02
2017-01-27 12:25
Technical Service, tel.: [phone]
www.ever.eu
12
INSTALLING THE UPS UNIT
After unpacking, please inspect the device for damages. In case of any damages,
please return the UPS in its original packaging to the dealer. The UPS should only be
used in rooms where the dust, temperature, and humidity levels are within the
device's specifications.
Appropriate cooling conditions must be ensured for the UPS to work properly. For
this reason, the distance between the UPS and other objects should not be less than
20 cm.
The mains socket the UPS is to be connected to should be located near the battery
(maximum distance –1.5 m) and should be easily accessible.
CAUTION! No extension cords should be used for connecting the UPS
unit.
CAUTION! Installing a UPS unit in proximity of flammable materials or
substances is strictly prohibited!
Due to the type and placement of the fuses in the power supply unit, it is
recommended that the protection systems in the building's electric system be used
as one of the protection levels. This is necessary to ensure short circuit
protection of the power supply unit. The UPS may only be connected to a
~230V mains socket equipped with a grounding bolt.
Input installation
To make sue the UPS connection is made according to the manual, a proper pin
configuration of the power socket must be ensured.
Fig. 4: Power socket pin configuration

EVER EASYLINE AVR USB UPS Range Operating Manual
13
www.ever.eu
Technical Service, tel.: [phone]
2017-01-27 12:25
Type 02
Fig. 5 shows correct methods of connecting the UPS to various types of mains (TN-S
or TN-C-S) with different earthing systems (PE conductor connections).
Fig. 5: UPS input installation
Output installation
Although two types of pin configuration are allowed for the input side, the output
installation must be done specifically according to this manual, to prevent UPS
damage. Fig. 6 shows the diagrams of correct and incorrect output configurations.
CAUTION! Only TN-S configuration is allowed for the UPS output
installation.

EVER EASYLINE AVR USB UPS Range Operating Manual
Type 02
2017-01-27 12:25
Technical Service, tel.: [phone]
www.ever.eu
14
Fig. 6: EASYLINE AVR USB UPS output installation
Fig. 7 Shows the output socket pin configuration in EASYLINE 650/850 AVR USB
UPS units.
Output socket PN-E-93201
Output socket IEC 320 C13
Fig. 7: Output socket pin configuration in EASYLINE AVR USB UPS units.

EVER EASYLINE AVR USB UPS Range Operating Manual
15
www.ever.eu
Technical Service, tel.: [phone]
2017-01-27 12:25
Type 02
LCD DISPLAY ICONS
Figure 8 shows the display. Table 1 presents the description of information icons of
the LCD display, and Table 2 presents the description of sound signals for various
states of operation of the UPS unit.
Fig. 8: LCD display screen with information icons
DESCRIPTION OF LCD DISPLAY ICONS
Table 1. Description of LCD display icons
Icon
Description
Load capacity indication - 4-grade scale. Further
segments light up long with an increase of load.
Battery capacity level indication - 5-grade scale. Further
segments light up along with an increase of the battery
capacity level.
Display of INPUT and OUTPUT voltage and frequency
parameters.
LCD display test image is displayed for 3 seconds after
the UPS is switched on.
The UPS operates in normal mode (mains power
supply).
The following message is displayed: .
AVR system activity signalization.
The icon flashes every second.

EVER EASYLINE AVR USB UPS Range Operating Manual
Type 02
2017-01-27 12:25
Technical Service, tel.: [phone]
www.ever.eu
16
The UPS operates in buffer (battery) mode).
The icon flashes every second.
The UPS operates in battery loading mode. The UPS is
not supplying power to output sockets. This state
occurs when the UPS power cable is plugged to the
mains socket, but the UPS is not switched on with the
front panel button.
The icon is active in case of a fault other than
overload or short circuit.
Table 2. Sound signaling of specific states of the UPS unit
UPS unit status
Sound signaling
Battery mode
Short sound every 10 seconds
Low battery
Short sound every second
Overload
Short sound every half second
Failure state
Continuous signal
FIRST START-UP
CAUTION! The UPS may only be connected to a ~230V mains socket
with a grounding connection (a bolt). The facility's electrical system to
which the UPS unit is connected must be fitted with overload and short-
circuit protection.
After unpacking, place the device in its work place and connect the power lead to the
mains in order to charge the battery up. When the power lead is connected to the
mains socket, the UPS automatically starts in the battery charging mode (see
description of signals in Table 1). It is recommended to charge the battery for at least
6 hours. You can then proceed carry out subsequent installation activities. In order to
do so:

EVER EASYLINE AVR USB UPS Range Operating Manual
17
www.ever.eu
Technical Service, tel.: [phone]
2017-01-27 12:25
Type 02
connect the devices you want to power (e.g. a PC with a monitor) to the UPS
unit's output sockets,
switch the UPS on with the button on the front panel,
switch the devices connected to the UPS on,
install the software on the main PC,
when prompted by PowerSoft's installer, connect the UPS to the PC with a USB
cable.
Once this is done, the UPS is ready to operate.
CAUTION! The batteries reach their full capacity after approximately a
month of mains operation mode.
CAUTION! For maximum battery performance is recommended by three
times their formation discharge power supply load of approximately 100
W and re-charge power supply.
DESCRIPTION OF OPERATION OF THE UPS
GENERAL INFORMATION
The main aim of the UPS is supplying electric power to appliances connected to its
outlet sockets. The energy is supplied from the battery if the level of the input voltage
or its frequency exceeds the top or bottom threshold values or a lack of mains power
is detected. The time of supplying power from the battery depends on the battery
capacity and the power consumed by appliances that are currently connected to
outlet sockets (load level).
The EASYLINE AVR USB UPS unit is a modern electronic device, an autonomous
source of ~230 V sine voltage in case of emergency. The device is an uninterruptible
line-interactive (VI) class power supply unit that comprises units synchronized with
the mains. The unit's Automatic Voltage Regulation (AVR) system corrects the
drops and peaks in the mains to ensure the receivers are supplied with voltage with
correct parameters, without using the power stored in the battery.

EVER EASYLINE AVR USB UPS Range Operating Manual
Type 02
2017-01-27 12:25
Technical Service, tel.: [phone]
www.ever.eu
18
MAINS MODE (NORMAL)
Connecting the UPS to the mains does not mean voltage is present on the UPS's
output sockets. The unit is only started when the switch button on the front panel is
pressed. When the UPS is switched on, a sound signal will be heard and the
message will be displayed on the LCD. If the mains voltage is
incorrect (voltage is too low or too high, frequency is out of range), the UPS will
switch to back-up mode, which will be indicated by the message (BACK-UP
MODE) and a sound signal will be heard every 10 seconds.
When the UPS unit is in the mains mode, the power in the output sockets is filtered
and, if needed, raised or lowered by the AVR system. The LCD panel displays the
load, the battery level, the mains mode icon and the values of the input and output
voltage.
BACK-UP MODE (BATTERY OPERATION)
When the UPS is in the normal (mains) mode and the voltage drops or its parameters
deteriorate (voltage or frequency parameters are out of range), the UPS will
automatically switch to back-up mode. This is signaled by an intermittent sound
signal (every 10 seconds) and an activated icon (MAINS MODE icon will
disappear).
If the battery charge level is low, an alarm sound is generated every second. Once
the battery is discharged, the UPS will switch off and the receivers will not be
supplied with power. When the supply voltage is back, the UPS will restart.
When the UPS is in back-up (battery) mode and there are no receivers connected or
power consumption is below the threshold value (40 W in the model EASYLINE 650
and 50 W model EASYLINE 850), the UPS will automatically switch off after 60
minutes in order to protect the battery before over-discharge them. This function can
not be deactivated.
STANDBY MODE
The UPS will switch to STANDBY mode when the battery is completely discharged or
when this mode is initiated by the managing software. The UPS will wait until the
mains parameters are correct again and will then switch back to the mains mode.

EVER EASYLINE AVR USB UPS Range Operating Manual
19
www.ever.eu
Technical Service, tel.: [phone]
2017-01-27 12:25
Type 02
COLD START
The cold start function allows to start the UPS when it is disconnected from the
mains. To do this, push the button on the front panel to switch the UPS on. The
battery operation mode is active, signaled by a sound. Next, battery operation of the
UPS is signaled by an intermittent sound, generated every 10 seconds, and by the
active icon.
SAFEGUARDS
Overload protection
In the mains operation mode, at the load over 110% of the nominal power, the UPS
indicates the overload condition by a rapid intermittent sound (every half second) and
a flashing icon . If this condition persists, the UPS will automatically switch off.
The higher the load, the sooner the UPS will switch off. In the back-up mode, an
overload causes the UPS to shut down immediately.
Short-circuit protection
Short-circuit protection on the input side is provided by an automatic mains
protection. For battery operation mode, there is an electronic protection of the UPS
output, the operation of which is signaled by active icon and a continuous
sound signal. If there is a short circuit, voltage from outlet sockets is disconnected
and the UPS remains in the signaling mode. Switch the UPS off with the button on
the front panel. Switching the UPS on again is possible only after user intervention
(elimination of the short circuit and switching the UPS on with the button).
COMMUNICATION WITH PC
EASYLINE AVR USB UPS units are equipped with a USB port enabling
communication of the UPS with a PC. The device is supplied with a USB
communication cable. In order to ensure proper communication of the device with a
PC, the monitoring and control software must be installed first, and then the UPS
must be connected to a free USB port on your PC, with the supplied USB
communication cable. For Windows operating systems, default drivers for HID
(Human Input Device) are installed. Current software and installation procedures can
be downloaded from www.ever.eu.

EVER EASYLINE AVR USB UPS Range Operating Manual
Type 02
2017-01-27 12:25
Technical Service, tel.: [phone]
www.ever.eu
20
OPERATING INSTRUCTIONS
CAUTION! EASYLINE AVR USB UPS units are C2 class appliances. In
domestic environment, they may interfere with reception of radio waves
so the user may be forced to implement additional preventive measures.
CAUTION! There are no user-serviceable parts inside the UPS unit.
INTERACTION WITH ELECTRICAL GENERATORS
The EASYLINE AVR USB UPS units are LINE INTERACTIVE (VI) class units
designed to synchronize voltage with the mains voltage. The unit has been designed
to tolerate voltage fluctuations in the range of ~ 170 - 280 V and changes of the
frequency of ± 5 Hz in relation to rated frequency of 50 Hz. Power generators are
characterized by variable frequency of the output voltage, which depends on the
changes in the load values. If the variations of frequency of the output voltage
exceed the allowed tolerance thresholds (i.e. ± 5 Hz), the UPS will consider the
parameters of the input voltage to be incorrect and it will switch to battery operation
mode.
OPERATION OF THE TELECOMMUNICATION FILTER (in the model 650/850)
In order to protect telephone land lines and the connected devices from surge
effects, EASYLINE 650 / 850 AVR USB UPS units are equipped with surge
protectors. To ensure proper operation of the filter with the protected devices, they
must be connected with a cable with RJ11 or RJ12 plugs. The cable of the existing
telephone land line must be connected to the filter's other socket. As the filter is
symmetrical, the telephone land line may be connected to either of the sockets.
OPERATION OF THE LAN FILTER (in the model 1200)
In order to protect Ethernet UTP lines and the connected devices from surge effects,
EASYLINE 1200 AVR UPS units are equipped with surge protectors. To ensure
proper operation of the filter with the protected devices, they must be connected with
a cable with RJ45 plugs. The cable of the existing Ethernet UTP line must be
connected to the filter's other socket. As the filter is symmetrical, the Ethernet UTP
line may be connected to either of the sockets.
