EverFocus EDH5102 User manual

EDH5102
1080p Mini Dome Camera
User’s Manual
Copyright © EverFocus Electronics Corp,
Release Date: October, 2012

i
Precautions
1. Do not install the camera near electric or magnetic fields. Install the camera away from
TV/radio transmitters, magnets, electric motors, transformers and audio speakers since the
electromagnetic fields generated from these devices may distort the video image or otherwise
interfere with camera operation.
2. Never disassemble the camera beyond the recommendations in this manual nor
introduce materials other than those recommended herein. Improper disassembly or
introduction of corrosive materials may result in equipment failure or other damage.
3. Try to avoid facing the camera toward the sun. In some circumstances, direct sunlight may
cause permanent damage to the sensor and/or internal circuits, as well as creating unbalanced
illumination beyond the capability of the camera to compensate.
4. Keep the power cable away from water and other liquids and never touch the power cord
with wet hands. Touching a wet power cord with your hands or touching the power cord
with wet hands may result in electric shock.
5. Never install the camera in areas exposed to oil, gas or solvents. Oil, gas or solvents may
result in equipment failure, electric shock or, in extreme cases, fire.
6. Cleaning. For cameras with interchangeable lenses, do not touch the surface of the sensor
directly with the hands. Use lens tissue or a cotton tipped applicator and ethanol to clean the
sensor and the camera lens. Use a damp soft cloth to remove any dirt from the camera body.
Please do not use complex solvents, corrosive or abrasive agents for cleaning of any part of
the camera.
7. Do not operate the camera beyond the specified temperature, humidity or power source
ratings. This camera is suitable for indoor operation only. Use the camera at temperatures
within -10°C~45°C (14°F~113°F) and humidity between 20%~ 80%; this device is not rated as
submersible. The input power source is 12VDC. Be sure to connect the proper + / - polarity
and voltage, as incorrect polarity or too high a voltage will likely cause the camera to fail,
and such damage is not covered by the warranty.
8. Mounting. Use care in selecting a solid mounting surface which will support the weight of
the camera plus any wind, snow, ice or other loading, and securely attach the camera to the
mounting surface using screws and anchors which will properly support the camera. If
necessary (e.g. when mounting to drop ceilings) use a safety wire to provide additional
support for the camera.

ii
Contents
1. INTRODUCTION....................................................................................1
1.1 PACKING LIST..................................................................................................... 1
1.2 FEATURES .........................................................................................................1
2. CABLE DESCRIPTION..........................................................................2
3. INSTALLATION .....................................................................................3
3.1 INSTALLATION AND ADJUSTMENT.......................................................................... 3
4. CONFIGURATION IN THE OSD MENU.................................................5
4.1 OSD MENU.........................................................................................................5
4.1.1 EXPOSURE ..............................................................................................................................5
4.1.2 COLOR....................................................................................................................................6
4.1.3 IMAGE.....................................................................................................................................7
4.1.4 BLC........................................................................................................................................8
4.1.5 3D-DNR.................................................................................................................................9
4.1.6 MOTION..................................................................................................................................9
4.1.7 SYSTEM ................................................................................................................................10
5. SPECIFICATIONS..............................................................................13
6. APPENDIX .........................................................................................14
6.1 OSD MENU STRUCTURE ..................................................................................... 14

EDH5102 1080p Mini Dome Camera
1
1. Introduction
The EDH5102 is an HDcctv indoor mini dome camera. Based on a progressive scan CMOS sensor, the
camera provides 1080p high resolution images and superior video quality compared to traditional
CCTV images. This superior resolution not only captures more critical evidentiary information, but
the inherent ability for megapixel video also extends the area of coverage, expedites completion of
investigations, resolves complaints and reduces both capital and operational costs.
With 2.8mm lens for wide area coverage, 2-axis positioning for convenient ceiling mounting, local
SD test monitor output from the detachable setup tool included, full OSD menu features lens
shading compensation, Contrast Boost, DSS low light enhancement and 3D DNR, this Day/ Night
camera provides economical HDcctv megapixel coverage in a wide variety of indoor applications.
No major upgrade to the IT network is required to deploy this powerful technology; HDcctv cameras
communicate at digital speeds up to 1.5 Gb/s over existing or new coaxial cable (RG59 or other
types for longer distances), using industry standard BNC connectors. The EDH5102 supports both
NTSC and PAL scanning systems.
1.1 Packing List
Camera body x 1
User Manual x 1
Power Adapter (with OSD Menu Joystick) x 1
Template x 1
Accessory kit x 1 (Screw x 2 , Anchor x 2)
Power Adapter Pigtail x 1
1.2 Features
Real time HDcctv 1080p HD video over coax for superlative image detail
1/3” 2.1 megapixel Color Progressive CMOS sensor
Wide area of coverage from the 2.8mm megapixel lens
Provides 3D DNR / DSS to improve image clarity, particularly in low light scenes
Electronic Lens Shading Compensation to offset diminished light transmission through
lens periphery for uniform image illumination
CTB [Contrast Boost] to deliver properly exposed images despite bright light sources, deep
shadows and/or unbalanced lighting in the same scene
Supports Digital Zoom / BLC [Back Light Compensation] / HLMASK [Highlight Suppression
Mask] / Privacy Zones (up to 32)
DPC [Defect Pixel Correction] Dead pixel compensation for increased clarity and extended
service life
SD TV Out for aim and focus using a standard hand held test monitor

EDH5102 1080p Mini Dome Camera
2
2. Cable Description
No.
Name
Descriptions
1
Power Cable
Connects to a DC 12V power source.
2
HDcctv Output
Connects to an HDcctv device, such as a DVR or HD
monitor, using a 75 Ohm BNC-type coaxial cable.
3
RS485+ (Green)
Connects to an RS-485 device, such as EverFocus’ EKB500
keyboard.
4
RS485- (Blue)
Connects to an RS-485 device, such as EverFocus’ EKB500
keyboard.
5
Test-Out
Connects to a SD CVBS monitor for setting image aim and
focus.

EDH5102 1080p Mini Dome Camera
3
3. Installation
3.1 Installation and Adjustment
1. Stick the mounting template on the position where you want to attach the camera.
2. Drill the two holes on the template for screwing the camera with the supplied screws and
anchors, and the circle in the middle only if you want to wire the cables through the wall /
ceiling.
3. Insert the supplied anchors into the holes.
4. Remove the cover cap from the camera body.
Cover Cap
Camera
body
5. Attach the camera body to the correct position and then screw the camera body to the
wall / ceiling using the supplied two screws.
Screw
6. Connect the camera to the 12V DC power source using the supplied power adapter pigtail
or a power adapter.

EDH5102 1080p Mini Dome Camera
4
Power Adapter Pigtail
Power Cable
BNC Cable
or
Power Adapter
7. Connect the camera to a DVR or a portable monitor using the Test-Out cable for viewing
the camera view while adjusting camera angles. You can also use the OSD Menu Joystick
to configure camera settings.
a. Adjust camera angles by tilting or rotating the camera.
360o
90o
b. To configure camera settings using the OSD Menu Joystick, connect one end of the
Test-Out cable to the Test-Out connector on the camera module and the other end
to the portable monitor.
8. Screw the camera cover cap back to the camera.
Push the Joystick up / down to select
among menu items.
Push the Joystick left / right to adjust
the level of the selected item.
Press the Joystick to enter the submenu
or exit the OSD Setup Menu.

EDH5102 1080p Mini Dome Camera
5
4. Configuration in the OSD Menu
You can use the Joystick on the rear panel of the camera to configure camera settings in the OSD
menu. For details on the OSD menu structure, see OSD Menu Structure in Appendix.
4.1 OSD Menu
Press the Enter / Confirm button on the Joystick. The Setup Menu in the OSD appears.
4.1.1 Exposure
Press the Enter / Confirm button to enter the submenu.
BRIGHTNESS
Use the and buttons to increase or decrease the screen brightness from 0 to 20.
MODE
Indoor
Select this mode when the color temperature of the video image is similar to that found in
indoor environments (around 5100 to 5300°K).
Outdoor
Select this mode when the color temperature of the video image is similar to that found in
outdoor environments (around 3,000°K to 3,200°K)
Main Menu
Main menu
s Menu

EDH5102 1080p Mini Dome Camera
6
LENS
You can select the type of the lens. Two types are available: Manual and DC. By default, the
Manual type lens is selected.
Shutter
Use the and buttons to adjust the shutter speed. The options include: 1/25 ~ 1/60000, FLK,
and AUTO. Any selection other than AUTO and 1/25 will disable the DSS function.
DSS (Digital Slow Shutter)
DSS is used to maintain a vivid screen image by automatically boosting low light levels. The
value is between x2 ~ x4 and OFF.
AGC (Auto Gain Control)
The higher the AGC value, the brighter the screen, but the level of noise will also be increased.
The options include: 0~10.
4.1.2 Color
Press the Enter / Confirm button to enter the submenu.
AWB (Auto White Balance)
This mode can be used to view areas with a color temperature range. Use the and 
buttons to select the AWB options. The options include: AUTO, AUTO EXTN, PRESET, MANUAL
COLOR TEMP, R-GAIN and B-GAIN.
AUTO –Around 2500 to 9500°K
AUTO EXTN (Extension) –Around 2300 to 10800°K
PRESET –Use a pure white background to preset the white balance value.
MANUAL COLOR TEMP –Use the and buttons to adjust the speed. The options
include: LOW, MIDDLE and HIGH
R-GAIN and B-GAIN –The options include: 0~20.

EDH5102 1080p Mini Dome Camera
7
CHROMA
Use the and buttons to increase or decrease the CHROMA from 0 to 20.
R-OFFSET/B-OFFSET
Use the and buttons to increase or decrease the Red and Blue offset from 0 to 20.
4.1.3Image
Press the Enter / Confirm button to enter the submenu.
SHARPNESS
Use the and buttons to increase or decrease the SHARPNESS from 0 to 10.
MIRROR / FLIP
Turn it on to reverse / flip the image.
DZOOM
Turn it on to set up the zoom level
PRIVACY
Enter the submenu to set up the privacy masks; up to 31 zones can be created:
ON ZONE NO: Use the and buttons to select the zone from 0 to 31.
X, Y-POS, SIZ: Enter the submenu to set up the position or size of the privacy mask zone.
COLOR: Press to select a color for the selected privacy mask zone.
TRANS: Press to select the transparency of mask zone.

EDH5102 1080p Mini Dome Camera
8
SHADING
Turn it on to offset diminished light transmission through lens periphery for uniform image
illumination.
DAY&NIGHT
The options include MODE, AGC THRS, DELAY. A submenu can be entered if you select MODE.
MODE –Use the and buttons to select AUTO, COLOR and B&W. Switches to a B&W
feed in low light conditions and then switches back to a Color feed in the daytime.
AGC THRS –Use the and buttons to select the AGC Threshold from 0 to 20.
DELAY –Set up the delay time in 0,5,10 and 30 seconds for the camera to switch between
Day and Night.
HLMASK
Turn it on to select the level and color of the masking effect. You can adjust the level to control
the mask range. The higher the level, the brighter the camera will detect to apply the mask.
CTB (Contrast Boost)
Turn it on to deliver properly exposed images despite bright light sources, deep shadows and /
or unbalanced lighting in the same scene.
GAMMA
Use the and buttons to increase or decrease the GAMMA from 0.45 to 0.75.
4.1.4 BLC
Press the Enter / Confirm button to enter the submenu.

EDH5102 1080p Mini Dome Camera
9
MODE
Use the and buttons to select OFF and BLC.
BLC OSD, POS and SIZ
Select OFF to disable the BLC function, or select ON to enable the BLC function and for further
setup. After selecting an area block, enter the BLC POS / SIZ and X / Y setup page, a “POSITION”
sign displayed on the screen. Use the direction buttons to move the area to the desired
position. Press the Enter / Confirm button to confirm the position, a “SIZE”sign displayed on
the screen. Use the direction buttons to adjust the size for the area.
4.1.53D-DNR
Press the Enter / Confirm button to enter the submenu.
Switch to HIGH, MIDDLE, LOW and OFF to enable or disable noise reduction on dynamic
recordings.
4.1.6Motion
Press the Enter / Confirm button to enter the submenu.

EDH5102 1080p Mini Dome Camera
10
RESOLUTION
Use the and buttons to increase or decrease the RESOLUTION level from 0 to 4.
SENSITIVITY
Press to set up the sensitivity for the motion detection function.
WINDOW TRANS
Press to select the transparency of motion detect zone.
WINDOW USE, POS and SIZ
Select OFF to disable this function, or select ON to enable and for further setup. After
selecting an area block, enter the BLC POS / SIZ and X / Y setup page, a “POSITION”sign
displayed on the screen. Use the direction buttons to move the area to the desired position.
Press the Enter / Confirm button to confirm the position, a “SIZE”sign displayed on the screen.
Use the direction buttons to adjust the size for the area.
4.1.7System
Press the Enter / Confirm button to enter the submenu.

EDH5102 1080p Mini Dome Camera
11
F/WVER
1.00
PAL
DEFECT DET
Press to select the DPC (Defective Pixel Correction) level of defect detector. Please notice; do
not use this function without cover the lens. The camera will automatically correct pixel
defects. Misoperation will cause the abnormal image.
CAM TITLE
Switch to On and then enter the submenu to set up a camera name displayed on the screen.
RS-485
Use the and buttons to select ID, BAUDRATE, PROTOCOL and ID DISPLAY. The default of
protocol is EVF-1 (EverFocus).
DOUT SCALE: Digital Output Scale
Use the and buttons to select FULL or COMP. This function is used to select the value
range of auto brightness control. The value range of FULL and COMP is as below:
FULL: 0-255
COMP: 16-255
DOUT FORMAT : Digital Output Format
DOUT FPS: Frames per Second
FREQ: Frequency
CVBS
There are 4 options including 1080p 30FPS NTSC, 1080p 25FPS PAL, 720p 60FPS NTSC and 720p
50FPS PAL. If you want to change the format and FPS, you should change the FREQ first. Select
50HZ frequency, the CVBS will automatically change to PAL; select 60HZ frequency, the CVBS
will turn to NTSC. Then, you can select the 720P or 1080P in the format options, and the FPS

EDH5102 1080p Mini Dome Camera
12
will also change accordingly.
LANGUAGE
Select a language for the OSD text. Options include English, French, German, Simplified Chinese,
Korean and Japanese.
RESET
Turn it on to reset the settings.
F / W VERSION: Firmware Version
Press to display the firmware version of the camera.

EDH5102 1080p Mini Dome Camera
13
5. Specifications
Pickup Device
1/3” Panasonic 2.1 megapixel Color Progressive CMOS sensor
Image Pixels
1920(H) x 1080(V)
Resolution
Digital: 1080p (30 / 25), 720p (60 / 50)
Scanning System
NTSC / PAL
Sensitivity
Color: 0.4 lux, BW: 0.1 lux,
Color DSS: 0.1 lux, BW DSS: 0.025 lux
Video Output
Digital (HDcctv Output): BT.1120, HDcctv / HD-SDI: BNC
connector
Analog (Test Out): NTSC) / PAL : BNC connector
S/N Ratio
More than 50 dB (AGC OFF)
Lens
2.8mm/F2.0 fixed focal type
Positioning
2-axis; ceiling mount recommended
AGC
0-20 steps
Shutter Speed
AUTO / MANUAL(1/25(30)~1/60,000sec)
Digital Slow Shutter(DSS)
On / Off(x4)
Brightness
0-20
BLC
On / Off
Contrast Boost(CTB)
On / Off
Day&Night
Auto / Color / B&W
Auto White Balance
Auto / Auto extn / Preset / Manual
Digital Noise
Reduction(DNR)
Off / Low / Middle / High
Mirror
On / Off
Flip
On / Off
Sharpness
0 - 10 steps
Lens Shading Compensation
On / Off
Digital Zoom
0 - 96 steps
Privacy Mask
32 Zones, Programmable
Motion Detection
On / Off
RS - 485
2400~115200> baud, ID 1~255, Protocols: Pelco-D/P, EverFocus
EVF-1;
Language
English /French /German /Chinese /Korean /Japanese /Russian
Power Source
12VDC
Power Consumption
12VDC: 220mA max.
Operating Environment
-10°C~45°C / 14°F~113°F (20%~80% Humidity)
Dimensions(Φx H)
95 x 72mm / 3.7” x2.8”
Weight
0.190kg / 0.430lbs
Certifications
FCC / CE

EDH5102 1080p Mini Dome Camera
14
6. Appendix
6.1 OSD Menu Structure
The default value is marked with a star “*”.
No.
Main
Sub Menu
Sub Menu / Function
1
EXPOSURE
BRIGHTNESS
1~20 (default=6)
MODE
INDOOR*, OUTDOOR
LENS
MANUAL*, DC
SHUTTER
AUTO*
MANUAL
1/25~1/60000
FLK
DSS
OFF, X2, X3, X4*
AGC
0~10 (default=10)
2
COLOR
AWB
AUTO*
AUTO extn
PRESET
MANUAL COLOR TEMP
LOW, MIDDLE, HIGH
R-GAIN
0~20
B-GAIN
0~20
CHROMA
0~20 (default=7)
R-OFFSET
0~20 (default=12)
B-OFFSET
0~20 (default=5)
3
SHARPNESS
0~10 (default=6)
MIRROR
ON, OFF*
FLIP
ON, OFF*
D-ZOOM
0~96 (default=0)
PRIVACY
OFF*
ON ZONE NO
0~31
ZONE UP
ON, OFF
X-POS
0~60
Y-POS
0~40
X-SIZ
0~60
Y-SIZ
0~40
COLOR
TRANS
0~4

EDH5102 1080p Mini Dome Camera
15
SHADING
ON*, OFF
DAY&NIGHT
MODE
AUTO*
COLOR
B&W
AGC THRS
0~20 (default=10)
MARGIN
0~20 (default=)
DELAY
0, 5*, 10, 30 SEC
HLMASK
OFF*
ON
LEVEL
0~20 (default=10)
COLOR
BLK*/WHT/YEL/CYN/GRN/MAG/RED/BLU
CTB
ON, OFF*
GAMMA
0.45*, 0.5, 0.55, 0.65, 0.75
4
BLC
MODE
OFF*, BLC
BLC OSD
ON, OFF*
BLC POS-X
0~20 (default=7)
BLC POS-Y
0~20 (default=7)
BLC SIZ-X
0~20 (default=5)
BLC SIZ-Y
0~20 (default=5)
5
3D-DNR
HIGH, MIDDLE*, LOW, OFF
6
MOTION
OFF*
ON
RESOLUTION
0~4 (default=1)
SENSITIVITY
0~20 (default=10)
WINDOW TRANS
0~6 (default=3)
WINDOW USE
ON, OFF*
X-POS
0~60 (default=4)
Y-POS
0~40 (default=6)
X-SIZ
0~60 (default=15)
Y-SIZ
0~40 (default=20)
7
SYSTEM
DEFECT DET
DPC LEVEL
000~255 (default=26)
CAM TITLE
OFF*
ON
STRING SET
POSITION
RS-485
ID
1~255 (default=1)
BAUDRATE
2400, 4800, 9600*, 19200, 38400, 57600, 115200
PROTOCOL
PELCO-D, PELCO-P, EVF-1*
ID DISPLAY
ON, OFF
DOUT SCALE
FULL*, COMP

EDH5102 1080p Mini Dome Camera
16
DOUT
FORMAT
720P, 1080P*
DOUT FPS
50, 60 ,25*, 30
FREQ
50*, 60 HZ
CVBS
PAL*, NTSC
LANGUAGE
English*, Chinese, Japanese, Korean, French, German, Russian
RESET
PUSH, PUSHING

EDH5102 1080p Mini Dome Camera
17
EverFocus Electronics Corp.
EverFocus Taiwan:
12F, No.79, Sec. 1, Shin-Tai Wu Road,
Hsi-Chih, Taipei, Taiwan
TEL: [phone]
FAX: [phone]
www.everfocus.com.tw
[e-mail]
EverFocus Europe - Germany:
Albert-Einstein-Strasse 1, D-46446
Emmerich, Germany
TEL: [phone]
FAX: [phone]
www.everfocus.de
[e-mail]
EverFocus China - Beijing:
Room 609, Technology Trade Building,
Shangdi Information Industry Base,
Haidian District, Beijing 100085, China
TEL: [phone]~39
FAX: [phone]
www.everfocus.com.cn
[e-mail]
EverFocus China - Shenzhen:
4F, No. 2, D4 Building, Wan Yelong
Industrial Park, Tangtou Road, Shiyan,
Baoan, Shenzhen, Guangdong 518101, China
TEL: [phone]
FAX: [phone]
www.everfocus.com.cn
[e-mail]
EverFocus USA - California:
1801 Highland Avenue, Unit A, Duarte, CA 91010,
USA
TEL: [phone]
FAX: [phone]
www.everfocus.com
[e-mail]
EverFocus USA - New York:
415 Oser Avenue, Unit S, Hauppauge, NY 11788, USA
TEL: [phone]
FAX: [phone]
www.everfocus.com
[e-mail]
EverFocus Japan:
5F, Kinshicho City Building, 2-13-4
Koto-Bashi,Sumida-Ku, Tokyo, 130-0022, Japan
TEL: [phone]
FAX: [phone]
www.everfocus.co.jp
[e-mail]
EverFocus Europe - UK:
Unit 12, Spitfire Business Park,
Hawker Road, Croydon Surrey, CR0 4WD, UK
TEL: [phone]
FAX: [phone]
www.everfocusuk.co.uk
[e-mail]
EverFocus India:
Suite 803, Housefin Bhavan, C-21, Bandra Kurla
Complex, Bandra (East), Mumbai 400051, India
TEL: [phone]
FAX: [phone]
www.everfocus.in
[e-mail]
N
Your EverFocus product is designed
and manufactured with high quality
materials and components which can
be recycled and reused.
This symbol means that electrical and
electronic equipment, at their
end-of-life, should be disposed of
separately from your household waste.
Please, dispose of this equipment at
your local community waste
collection/recycling centre.
In the European Union there are
separate collection systems for used
electrical and electronic product.
Please, help us to conserve the
environment we live in!
Ihr EverFocus Produkt wurde entwickelt
und hergestellt mit qualitativ
hochwertigen Materialien und
Komponenten, die recycelt und wieder
verwendet werden können.
Dieses Symbol bedeutet, dass
elektrische und elektronische Geräte am
Ende ihrer Nutzungsdauer vom
Hausmüll getrennt entsorgt werden
sollen.
Bitte entsorgen Sie dieses Gerät bei
Ihrer örtlichen kommunalen
Sammelstelle oder im Recycling Centre.
Helfen Sie uns bitte, die Umwelt zu
erhalten, in der wir leben!
