EverFocus EPTZ3000 User manual

Speed Dome
EPTZ3000/EPTZ3000I
USER MANUAL
Date: Nov 2008

1-1
Table of Contents
1. EPTZ3000/EPTZ3000I OVERVIEW.................................................... 1-3
1.1. Introduction .............................................................................................1-3
1.2. Specifications..........................................................................................1-5
1.3. Feature .....................................................................................................1-7
1.3.1. Profile of EPTZ3000/EPTZ3000I........................................................1-7
1.3.2. EPTZ3000/EPTZ3000I Base Board ...................................................1-8
1.3.3. EPTZ3000/EPTZ3000I Control Board................................................1-9
1.4. EPTZ3000/EPTZ3000I Connection .......................................................1-10
1.5. EPTZ3000/EPTZ3000I Quick Operation Guide (Work with EKB500) .1-11
2. EPTZ3000/EPTZ3000I INSTALLATION........................................... 2-12
2.1. Packing List...........................................................................................2-12
2.2. Cable Needed.........................................................................................2-12
2.3. Initial Setup............................................................................................2-13
2.3.1. Address Setting................................................................................2-14
2.3.2. Communication Protocol Setting......................................................2-17
2.3.3. Transmission Speed Setting (Baud Rate Setting) ............................2-17
2.4. Rack and Speed Dome Installation......................................................2-19
2.4.1. Installation Requirements.................................................................2-19
2.4.2. EPTZ3000 Dome Camera Wall Mount Installation...........................2-19
2.4.3. EPTZ3000I Dome Camera Installation.............................................2-22
2.5. Accessories...........................................................................................2-25
2.5.1. EPTZ-CPMA: Ceiling Pendant Mount Adapter.................................2-25
2.5.2. EPTZ-PMA: Pole Mount Adapter......................................................2-25
2.5.3. EPTZ- CMA: Corner MountAdapter.................................................2-25

1-2
3. EPTZ3000/EPTZ3000I CAMERA SETUP MENU............................. 3-27
3.1. Structure of the Setup Menu ................................................................3-27
3.1.1. Camera Setup Menu........................................................................3-28
4. EPTZ3000/3000I FUNCTION SETUP AND OPERATION ................ 4-36
4.1. Manual Control Mode............................................................................4-36
4.2. Auto Pan Mode......................................................................................4-36
4.3. Position Setting.....................................................................................4-37
4.4. Tour Mode ..............................................................................................4-38
4.5. Alarm Link to a Position/Tour...............................................................4-39
4.6. Other operations ...................................................................................4-40
APPENDIX : The Alarm I/O Connection............................................... 4-41

1-3
1. EPTZ3000/EPTZ3000I OVERVIEW
1.1. Introduction
EPTZ3000/EPTZ3000I, an intelligent high-speed dome camera is ready to secure
your property with its omni-directional and exact monitoring. A 30X optical and 8X
digital zoom combining with a high-performance chip makes captured images clear
and vivid. The other powerful camera functions EPTZ3000/EPTZ3000I equips with:
Wide Dynamic makes objects clear in a high illumination background.
Vertical double density interline CCD with a slower shutter and true
Day/Night function.
Electronics flip, no mechanical flip is necessary.
520 color/570 B&W TVL; PAL/NTSC image formats support.
Auto and fast focus increases the searching speed and precision.
Auto Iris adjusts the monitoring image to the best brightness.
White Balance function makes the shades of color more natural in different
light conditions.
Color / B&W images auto switching to enhance the sensitivity in a low light
condition or at night.
Private zone protects your privacy.

1-4
Furthermore, the micro control unit enables camera a nimble and exact movement
from minimal 0.01°/sec to maximal 360°/sec. It can go to every preset position in 1
second. It also has other advantages such as:
192 preset positions are available.
16 cruise tours can be set, and each tour contains up to 16 positions.
Up to 256 speed domes can be supported on a RS-485 bus when all speed
domes are controlled by keyboard EKB500.
Auto heater and fan to fit all kinds of temperature (outdoor models).
Built-in 4 alarm inputs and 1 alarm output.
All of the features make the intelligent high-speed dome camera works for a wide
range and demanding application such as banks, airports, stations, casinos, streets
of cities, intelligent buildings, and etc.

1-5
1.2. Specifications
Model EPTZ3000 (outdoor) EPTZ3000I (indoor)
Pickup Device 1/4'' Vertical double density interline CCD
Video Format NTSC or PAL
Scanning System NTSC: 525 TV lines, 60 fields/sec
PAL: 625 TV lines, 50 fields/sec
Picture Elements 768 x 494 ( NTSC ) , 752 x 582 ( PAL )
Horizontal Resolution 520 TVL:Color ; 570TVL:B/W
Sensitivity 0.3 Lux/F=1.6 Color ; 0.05 Lux/F=1.6 B/W
S/N Ratio Over 52dB
Electronic Shutter 128x (Slow Shutter ON)~1/60~1/120,000 sec (NTSC)
128x (Slow Shutter ON)~1/50~1/120,000 sec (PAL)
Digital Slow Shutter OFF/4x/8x/12x/16x/32x/64x/128x selectable
Shutter Selection AUTO/A.FLK/Manual (x8~1/120000) selectable
Lens Type 30x optical zoom , f=3.3 mm (wide) to 99mm (tele) , F1.6 to F3.2
Zoom Ratio 240x max ( 30x Optical and 8x Digital Zoom )
True Day/Night Auto/Manual ICR
Black Light Comp. No
Auto Gain Control Auto/Manual
White Balance Auto Indoor/Auto Outdoor/One push/Man 2000K,3200K,5100K
selectable
Video Output BNC 1.0Vp-p , 75ohm
Sync. Mode Line Lock/Internal Sync
Power Source 24VAC
Power Consumption 24VAC 18W Max. ( without
heater ) 18W
24VAC 66W Max. ( with heater )
70W
24VAC 18W Max.
Operating Temperature -40°C~50°C ; -40°F~122°F 0°C~ 50°C ; 32°F~122°F
Focus Control One push/Auto/Manual
Horizontal Rotation Speed
0.1°/s~360°/s (1-239 grade shift gears)
Horizontal Rotation Range
360°unlimited rotation
Tilt Rotation Range 180°pendulum motion
Auto Zoom Speed Control
Control speed auto-adjusted according to zoom length changing
Auto Pan, 2 Points
Scanning Can set freely
Auto Pan Speed 1~239 grades available

1-6
Dwell Time (2 points) 1~127 seconds available
Preset Positions 128 positions
Running to Position Speed
1~239 grades available
Dwell Time at Preset
Position 1~239 seconds available
Tour 16 groups
Tour Point per Group 16 preset positions
Fan & Heater Fan & Heater auto starts No
Position Accuracy ±0.1°
Alarm 4 in 1 out with tour/position auto triggering
Built-in Menu for
Functions Yes
Communication RS-485
Communication Speed 1200/2400/4800/9600 bps
Built-in Protocols EVF-1 ; Pelco-P ; Pelco-D ; A –type ; Plus-D
Address Editable Yes (through DIP switch)
Speed Dome Address 0-255
Manual Pan/Tilt Speed Pan: 0.01º ~ 360º/s ; Tilt: 0.01º ~ 360º/s
Weatherproof Ratings IP66 Indoor
Safety CE ; FCC
Dimensions 330mm(W) x 365mm(H) x
220mm(O.D) /
13"(W) x 14.4" (H) x 8.7"(O.D)
208mm(W) x 215mm(H) x
208mm(O.D) /
8.7"(W) x 12.2" (H) x 8.7"(O.D)
Weight 4.2kg/9.25lbs 2.15kg/4.8lbs

1-7
1.3. Feature
1.3.1. Profile of EPTZ3000/EPTZ3000I
Wall Mount Bracket
Housing
Inner Housing
M5 Bolt (Hex) x3
M3 Bolt x3
BNC Cable
Power Cable
RS485 Cable
Connection Bus
Bulb
Mechanical Part
Camera Module
Control board
Base PCB board
Housing
Clip
BNC Cable
Power Cable
RS485 Cable
Connection Bus
Bulb
Mechanical Part
Camera Module
Control board
Base PCB board
Ceiling
Button
EPTZ3000I
EPTZ3000

1-8
1.3.2. EPTZ3000/EPTZ3000I Base Board
The base board that is on the bottom of the housing connects to power cable, video cable,
control cable, alarm cable, fan and heater. In order to connect to cables, the board needs
to be taken off, and put back after finishing connecting to all cables. The connectors of
cable names are marked on the board in white text. The details of the alarm connector
(JP5) are shown on the APPENDIX A.
For EPTZ3000 outdoor model, JP1, JP3 and JP6 that are two-pin connectors need to be
taken off during installing. JP1 and JP3 are connectors for heater, and they can be
switched. JP6 is a fan controller connector that turns on/off of the fan. The 3 cables are too
short to be connected to a wrong connector when putting them back.
RELAY
JP6 JP4
JP3 JP1
JP5
Video +
Video -
RS485 +
RS485 -
AC24
AC24
EPTZ3000 Baseboard
RELAY
JP5
Video + Video - RS485 + RS485 - AC24 AC24
EPTZ3000I Baseboard

1-9
1.3.3. EPTZ3000/EPTZ3000I Control Board
The PCB board with two dipswitches is the control board of EPTZ3000/EPTZ3000I. The
two switches are used to set address, protocol, Baud Rate, video format and terminal
resistance.
SW1
ON
12345678
CPU
ON
1 2 3 4 5 6 7 8
SW2
ID1
ID2
ID3
ID4
ID5
ID6
ID7
ID8
Protocol
BAUD

1-10
1.4. EPTZ3000/EPTZ3000I Connection
Alarm 1
Alarm 4
Alarm 3
Alarm 2
GROUND
RS485 Tx(+)
RS485 Tx(-)
24V AC110V AC
Video Out
POWER
24V AC / 3.5 A
BNC
1.0Vpp ± 0.2V, 75
RS485 Control Line
4 ALARM INPUTS
Adapter
Ω
EPTZ3000/
EPTZ3000I
ALARM OUTPUTS
N.C.
N.O.
COM

1-11
1.5. EPTZ3000/EPTZ3000I Quick Operation Guide (Work with EKB500)
EPTZ3000/EPTZ3000I and EKB500 (Keyboard) can work together by using factory
default setting. You just need to connect cables by the following steps:
1. Connect the RS-485 cable to EPTZ3000/EPTZ3000I and a keyboard (EKB500).
2. Connect a video cable from EPTZ3000/EPTZ3000I to a monitor.
3. Connect the power to the EPTZ3000/EPTZ3000I and a keyboard (EKB500).
After the EPTZ3000/EPTZ3000I finishes the self-test mode, you can start to operate
the EPTZ3000/EPTZ3000I via the keyboard.
To operate the EPTZ3000/EPTZ3000I:
IRIS
+Focus F. Zoom In
- N. Out
UP
DOWN
LEFT RIGHT
ZoomINZoomOUT
1. Shift the Joystick up/down or right/left to view from camera.
2. Turn the top of the Joystick to zoom in/out.
3. Press Zoom In/Out, Focus F. /N. and IRIS +/- function keys to operate the
EPTZ3000/EPTZ3000I.

2-12
2. EPTZ3000/EPTZ3000I INSTALLATION
2.1. Packing List
There are 3 boxes that are housing, bulb and mechanical part with a camera module, one
wall mount bracket, one power adapter and one tool packet in the package. The detail
accessories list below:
Housing x1
Bulb x1
Mechanical part with a camera module x1
Wall mount bracket x1
Adapter x1
Tool packet
Glove x2
M5 HexAllen wrench x1
Pin connector x1
M5 screw (Hex) x3 for wall mount bracket fixing
M3 screw x3 for bulb fixing
2.2. Cable Needed
Power Cable
An adapter with 24V AC/3.5A output provides the power to the EPTZ3000/EPTZ3000I. An
extension power line may be needed.
Note: The input AC voltage range of an adapter depends on different area.
Please make sure the voltage range before installing.

2-13
Video Cable
A BNC cable is used for connecting an EPTZ3000/EPTZ3000I to a DVR or a monitor. An
amplifier may be needed if the video cable is too long.
Control Cable
Basically, EPTZ3000/EPTZ3000I uses a differential pair to connect to other devices by
cascading. A cable that has low signal decline can be used as a control cable.
Alarm Cable
An alarm cable is not included in the packing list. A suitable wire that has low signal
decline can be used as an alarm cable.
2.3. Initial Setup
Initial setup includes dome address, communication protocol, transmission speed, video
format, and terminal resistance settings. All of the settings should be confirmed before the
dome is installed. The control-related setting that is address, communication protocol and
transmission speed have to be set consistently with the control device such as a keyboard
or a DVR.
Notice: Please make sure the power is off before setting, and restart the
EPTZ3000/EPTZ3000I to enable a new value after changing.

2-14
2.3.1. Address Setting
The address code of the EPTZ3000/EPTZ3000I should be set to correspond properly
with a control device to control multiple dome cameras. The address codes are made
up by the dipswitch SW1 (8 bits) on the PCB board. The 8 bits dipswitch indicates the
binary coded of the address, and there are 256 addresses can be selected (0 ~ 255, 2
8
= 256). It also means that there are up to 256 dome cameras that can cascade on the
RS-485 bus. The dipswitch setting and the indicated address are represented in the
following chart.
Note: The factory default address is 1.
Notice: Please make sure the power is off before setting, and restart the
EPTZ3000/EPTZ3000I to enable a new value after changing.
SW1
ON
12345678
CPU
ON
12345678
SW2
ID1
ID2
ID3
ID4
ID5
ID6
ID7
ID8
Protocol
BAUD

2-15
ON
12345678
Switch Address
1
ON
12345678
2
ON
12345678
3
ON
12345678
4
ON
12345678
5
ON
12345678
6
ON
12345678
7
ON
12345678
8
ON
12345678
9
ON
12345678
10
ON
12345678
11
ON
12345678
12
ON
12345678
Switch Address
13
ON
12345678
14
ON
12345678
15
ON
12345678
16
ON
12345678
17
ON
12345678
18
ON
12345678
19
ON
12345678
20
ON
12345678
21
ON
12345678
22
ON
12345678
23
ON
12345678
24
ON
12345678
25
ON
12345678
26
ON
12345678
27
ON
12345678
28
ON
12345678
29
ON
12345678
30
ON
12345678
31
ON
12345678
Switch Address
33
ON
12345678
34
ON
12345678
35
ON
12345678
36
ON
12345678
37
ON
12345678
38
ON
12345678
39
ON
12345678
40
ON
12345678
41
ON
12345678
42
ON
12345678
43
ON
12345678
44
ON
12345678
45
ON
12345678
46
ON
12345678
47
ON
12345678
48
ON
12345678
49
ON
12345678
50
ON
12345678
51
ON
12345678
52
ON
12345678
53
ON
12345678
54
ON
12345678
55
ON
12345678
56
ON
12345678
57
ON
12345678
58
ON
12345678
59
ON
12345678
60
ON
12345678
61
ON
12345678
62
ON
12345678
63
Switch Address Switch AddressSwitch AddressSwitch Address Switch AddressSwitch Address
ON
12345678
Switch Address
65
ON
12345678
66
ON
12345678
67
ON
12345678
68
ON
12345678
69
ON
12345678
70
ON
12345678
71
ON
12345678
72
ON
12345678
73
ON
12345678
74
ON
12345678
75
ON
12345678
76
ON
12345678
Switch Address
77
ON
12345678
78
ON
12345678
79
ON
12345678
80
ON
12345678
81
ON
12345678
82
ON
12345678
83
ON
12345678
84
ON
12345678
85
ON
12345678
86
ON
12345678
87
ON
12345678
88
ON
12345678
89
ON
12345678
90
ON
12345678
91
ON
12345678
92
ON
12345678
93
ON
12345678
94
ON
12345678
95
ON
12345678
Switch Address
97
ON
12345678
98
ON
12345678
99
ON
12345678
100
ON
12345678
101
ON
12345678
102
ON
12345678
103
ON
12345678
104
ON
12345678
105
ON
12345678
106
ON
12345678
107
ON
12345678
108
ON
12345678
109
ON
12345678
110
ON
12345678
111
ON
12345678
112
ON
12345678
113
ON
12345678
114
ON
12345678
115
ON
12345678
116
ON
12345678
117
ON
12345678
118
ON
12345678
119
ON
12345678
120
ON
12345678
121
ON
12345678
122
ON
12345678
123
ON
12345678
124
ON
12345678
125
ON
12345678
126
ON
12345678
127
Switch Address
ON
12345678
0
ON
12345678
32
ON
12345678
64
ON
12345678
96

2-16
ON
12345678
Switch Address
129
ON
12345678
130
ON
12345678
131
ON
12345678
132
ON
12345678
133
ON
12345678
134
ON
12345678
135
ON
12345678
136
ON
12345678
137
ON
12345678
138
ON
12345678
139
ON
12345678
140
ON
12345678
Switch Address
141
ON
12345678
142
ON
12345678
143
ON
12345678
144
ON
12345678
145
ON
12345678
146
ON
12345678
147
ON
12345678
148
ON
12345678
149
ON
12345678
150
ON
12345678
151
ON
12345678
152
ON
12345678
153
ON
12345678
154
ON
12345678
155
ON
12345678
156
ON
12345678
157
ON
12345678
158
ON
12345678
159
ON
12345678
Switch Address
161
ON
12345678
162
ON
12345678
163
ON
12345678
164
ON
12345678
165
ON
12345678
166
ON
12345678
167
ON
12345678
168
ON
12345678
169
ON
12345678
170
ON
12345678
171
ON
12345678
172
ON
12345678
173
ON
12345678
174
ON
12345678
175
ON
12345678
176
ON
12345678
177
ON
12345678
178
ON
12345678
179
ON
12345678
180
ON
12345678
181
ON
12345678
182
ON
12345678
183
ON
12345678
184
ON
12345678
185
ON
12345678
186
ON
12345678
187
ON
12345678
188
ON
12345678
189
ON
12345678
190
ON
12345678
191
Switch Address Switch AddressSwitch AddressSwitch Address Switch AddressSwitch Address
ON
12345678
Switch Address
193
ON
12345678
194
ON
12345678
195
ON
12345678
196
ON
12345678
197
ON
12345678
198
ON
12345678
199
ON
12345678
200
ON
12345678
201
ON
12345678
202
ON
12345678
203
ON
12345678
204
ON
12345678
Switch Address
205
ON
12345678
206
ON
12345678
207
ON
12345678
208
ON
12345678
209
ON
12345678
210
ON
12345678
211
ON
12345678
212
ON
12345678
213
ON
12345678
214
ON
12345678
215
ON
12345678
216
ON
12345678
217
ON
12345678
218
ON
12345678
219
ON
12345678
220
ON
12345678
221
ON
12345678
222
ON
12345678
223
ON
12345678
Switch Address
225
ON
12345678
226
ON
12345678
227
ON
12345678
228
ON
12345678
229
ON
12345678
230
ON
12345678
231
ON
12345678
232
ON
12345678
233
ON
12345678
234
ON
12345678
235
ON
12345678
236
ON
12345678
237
ON
12345678
238
ON
12345678
239
ON
12345678
240
ON
12345678
241
ON
12345678
242
ON
12345678
243
ON
12345678
244
ON
12345678
245
ON
12345678
246
ON
12345678
247
ON
12345678
248
ON
12345678
249
ON
12345678
250
ON
12345678
251
ON
12345678
252
ON
12345678
253
ON
12345678
254
ON
12345678
255
Switch Address
ON
12345678
160
ON
12345678
192
ON
12345678
224
ON
12345678
128

2-17
2.3.2. Communication Protocol Setting
The 1
st
, 2
nd
and 3
rd
bits of the SW2 are used to set communication protocol. The factory
default protocol is EVF.
ON
1 2 3 4 5 6 7 8
SW2
Protocol
Baud Rate
Terminal
Resistance
ON
1 2 3 4 5 6 7 8
EVF
ON
1 2 3 4 5 6 7 8
PELCO-D
PLUS-D
ON
1 2 3 4 5 6 7 8
PELCO-P A-TYPE
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
AUTO
Notice: Please make sure the power is off before setting, and restart the
EPTZ3000/EPTZ3000I to enable a new value after changing.
Set all of protocol switches to ON; the speed EPTZ3000/EPTZ3000I will enter a
self-test mode.
2.3.3. Transmission Speed Setting (Baud Rate Setting)
The 4
th
and 5
th
bits of the SW2 on the PCB board are used to set the Baud Rate. The
default baud rate setting is 9600.
ON
12345678
SW2
Protocol
Baud Rate
Terminal
Resistance
ON
1234 5 6 7 8
9600 BPS 4800 BPS 2400 BPS
ON
1234 5 6 7 8
ON
1234 5 6 7 8
1200 BPS
ON
1234 5 6 7 8

2-18
Notice: Please make sure the power is off before setting, and restart the
EPTZ3000/EPTZ3000I to enable a new value after changing.

2-19
2.4. Rack and Speed Dome Installation
2.4.1. Installation Requirements
1. Installation should be handled by a qualified service agent and should comply with
all local regulations. Service personnel should expect potential problems such as
surface strength, surface material, falling objects, outer breaches, building vibration
or other similar conditions.
2. Check for all necessary materials, and ensure if the selected installation location is
suitable for the EPTZ3000/EPTZ3000I.
2.4.2. EPTZ3000 Dome Camera Wall Mount Installation
Note: Installation location that is a wall, a pole or a ceiling needs to support above five
times the total weight of the camera assembly (about 16 kg) to avoid shaken images, and
dropping.
1. Set wall mount bracket on the wall. Mark the center of the holes on the wall against
the bracket holes. Use a drill to make 4 holes that can be nailed 4 0.25” X 1.25”
screws at the marks.
Note: The length of the screws depends on the surface material. The mentioned screws
are used in the normal concrete surface.
