EverFocus EZA2580 eZ.HD Series User manual

EZA2580 eZ.HD Series
5MP Dual Power IP66 IR Bullet Camera
User’s Manual
Copyright © EverFocus Electronics Corp.
Release Date: September, 2019
All the images including product pictures or screen shots in this document are for example
only. The images may vary depending on the product and software version. Information
contained in this document is subject to change without notice.
EverFocus Taiwan:
2F., No.12, Ln. 270, Sec. 3, Beishen Rd., Shenkeng Dist., New Taipei City 222, Taiwan
TEL: [phone] FAX: [phone] www.everfocus.com.tw
All manuals and user guides at all-guides.com

1
1. Introduction
Equipped with a Sony STARVIS CMOS sensor, the EZA2580 deliver 5MP image
quality. The model provides 2.8-12mm lens with ICR. Featured with True Wide
Dynamic Range (T-WDR), the camera can provide clear images even under
backlight circumstances where intensity of illumination can vary excessively.
The EZA2580 supports dual power (12VDC / 24VAC, depends on model) and
supports both NTSC and PAL scanning systems.
1.1 Packing List
Camera x 1
Mounting Sticker x 1
L-Type Wrench x 1
Screw & Screw Anchor x 3
User Manual x 1
1.2 Features
5MP Sony STARVIS CMOS sensor, delivering amazing high sensitivity
Varifocal 2.8-12mm with ICR to capture the desired field of view
Extended IR range of up to 40m / 131ft. with 4 LEDs (depends on scene
IR reflectivity)
T-WDR to improve the visibility under high contrast scene
3-Axis rotation design allows wall or ceiling mounting
IP66-rated with metal housing
Supports dual power (12VDC / 24VAC, depends on model)
Supports UTC function: Control camera OSD settings directly from DVR
end
1.3 Dimensions
128mm / 5"
280mm / 11"
91.5mm /3.6"
84mm / 3.31"
All manuals and user guides at all-guides.com

2
1.4 Optional Accessory
BAE3201
Color: White
Size (Φ x H): 138 x 54mm / 5.43” x 2.16”
Weight: 700g / 1.87
Material: Metal
1.5 Cable Description
12VDC or 24VAC Power Cable
Video Output Cable (BNC, 75Ohm)
2. Installation
1. Stick the supplied Mounting Sticker to the surface to mark the 3 screw
positions. Drill 3 holes on the surface and insert the supplied 3 Screw
Anchors into the screw holes. If you want to run the cable through the
surface, drill a hole within the 3 screw area.
2. To mount the camera to the surface, screw the Camera Base to the surface
using the supplied 3 Screws.
Mounting
Surface
Screws Screw Anchors
Camera Base
3. Connect the Power Cable to a 12VDC / 24VAC power source. Connect the
Video Output Cable to a monitor or DVR.
4. You can use the Joystick on the cable to configure camera OSD settings.
Remove the Protection Cap from the Joystick before using it.
All manuals and user guides at all-guides.com

3
UP
DN
Configuring OSD Settings:
•Push the Joystick up / down to select among
menu items.
•Push the Joystick left / right to adjust the level
of the selected item.
•Press the Joystick to enter the submenu or
exit the OSD Setup Menu.
5. For the first time installation, check whether the camera is properly
focused. If not, you can manually adjust camera Zoom or Focus using the
supplied L-Type Wrench. You can find the Zoom and Focus nuts on the
bottom of the camera.
Z
OO
M
F
O
C
U
S
6. You can optionally adjust camera angles. To do so, loosen the Tilt Screw or
Rotate Screw on the bracket using the supplied L-Type Wrench to adjust
camera angles. After adjusting camera angles, tightly screw back the
Tilt/Rotate screws.
Tilt Screw
Rotate Screw
All manuals and user guides at all-guides.com

4
3. Configuration in the OSD Menu
No
Main
Sub Menu
Sub Menu / Function
1 Edge Det On
Level
0-10
Color
YEL, CYN, GRN, MAG, RED, BLU, BLK,
WHT
Off
2 Exposure
Brightness
0-20
Shutter
Auto
Mode
Normal / Deblur
Manual Speed
1/30, 1/60, 1/120, 1/250,
1/500, 1/1000, 1/2000,
1/4000, 1/8000, 1/15000,
1/30000
Flicker
Sens-Up
X2, x4, x8, x16, x32, Off
AGC
0-10
3 Backlight
HLC
Level
0-20
Color
YEL, CYN, GRN, MAG, RED, BLU, BLK,
WHT
BLC
H-POS
0-26
V-POS
0-32
H-SIZE
0-26
V-SIZE
0-32
WDR
WDR Mode
Frame, Line
ROI Mode
Box
Window Zone
0-3
Window Use
On, Off
H-POS
0-2608
V-POS
0-1960
H-SIZE
0-2608
V-SIZE
0-1960
Polygon
Window Zone
0-3
Window Use
On, Off
POS0-X
0-721
POS0-Y
0-535
POS1-X
0-721
POS1-Y
0-535
POS2-X
0-721
POS2-Y
0-535
POS3-X
0-721
POS3-Y
0-535
Off
Weight
High, Middle, Low
Off
4 Day/Night Mode
Auto
IR LED
Adaptive, Off
Anti-Sat.
0-20
D>N Thres
0-20
N>D Thres
0-20
Delay
High, Middle, Low
Color
B/W
IR LED
Adaptive, Off
All manuals and user guides at all-guides.com

5
Anti-Sat.
0-20
D>N Thres
0-20
N>D Thres
0-20
Delay
High, Middle, Low
Extern
IR LED
Adaptive, Off
Anti-Sat.
0-20
Extern SW
High, Low
D>N Thres
0-20
N>D Thres
0-20
Delay
High, Middle, Low
5 Color AWB
Auto
Autoext
Preset
Manual
C-Temp
3000K, 5000K, 8000K
R-Gain
0-20
B-Gain
0-20
Color Gain
0-20
6
DNR
High, Middle, Low, Off
7 Image
Sharpness
0-10
Gamma
0.45, 0.55, 0.65, 0.75
Mirror
On, Off
Flip
On, Off
D-Zoom
1.0X-16X
ACE
High, Middle, Low, Off
Defog On
Mode
Auto, Manual
Level
High, Middle, Low
Off
Shading
On
Weight
0%-100%
Off
Privacy
Box On
Zone Num
0-15
Zone Disp
On, Off
H-POS
0-80
V-POS
0-61
H-Size
0-80
V-Size
0-61
Y Level
0-20
CB Level
0-20
CR Level
0-20
Trans
0-3
Off
Polygon On
Zone Num
0-7
Zone Disp
On, Off
POS0-X
0-162
POS0-Y
0-122
POS1-X
0-162
POS1-Y
0-122
POS2-X
0-162
POS2-Y
0-122
POS3-X
0-162
POS3-Y
0-122
Y Level
0-20
All manuals and user guides at all-guides.com

6
CB Level
0-20
CR Level
0-20
Trans
0-3
Off
8 Motion On
Det Window
Window Use
0-3
Window Zone
On, Off
Det H-POS
0-80
Det V-POS
0-60
Det H-Size
0-80
Det V-Size
0-60
Sensitivity
0-10
Motion OSD
On, Off
Text Alarm
On, Off
Signal Out
On, Off
Off
9 System
Output
Frame Rate
4K/15fps, 4MP/30fps, 1080p/30fps,
5MP/12.5fps, 5MP/20fps, 4MP/15fps
Freq
60Hz, 50Hz
Analog Mode
AHD, TVI, CVI, CVBS
Confirm
Yes
Return
Exit
Image Range
Full
Comp
User
Offset
0-32
Color Space
HD-CbCr, SD-CbCr, YUV
Audio Mic
Not supported
Color Bar
On, Off
Language
ENG, CHN, CHN(S), JPN, KOR, POR, ESP
Cam Title
Left-Down
Right-Up
Off
Reset
On
10
Exit
