EverFocus ECZ930 eZ.HD Series User manual

ECZ930 eZ.HD Series
720p Analog High Definition
True Day/Night Outdoor IR Bullet Camera
User’s Manual
Copyright © EverFocus Electronics Corp,
Release Date: Nov., 2014

2
Precautions
1. Do not install the camera near electric or magnetic fields. Install the camera away from
TV/radio transmitters, magnets, electric motors, transformers and audio speakers since the
electromagnetic fields generated from these devices may distort the video image or
otherwise interfere with camera operation.
2. Never disassemble the camera beyond the recommendations in this manual nor introduce
materials other than those recommended herein. Improper disassembly or introduction of
corrosive materials may result in equipment failure or other damage.
3. Try to avoid facing the camera toward the sun. In some circumstances, direct sunlight may
cause permanent damage to the sensor and/or internal circuits, as well as creating
unbalanced illumination beyond the capability of the camera to compensate.
4. Keep the power cable away from water and other liquids and never touch the power cord
with wet hands. Touching a wet power cord with your hands or touching the power cord
with wet hands may result in electric shock.
5. Never install the camera in areas exposed to oil, gas or solvents. Oil, gas or solvents may
result in equipment failure, electric shock or, in extreme cases, fire.
6. Cleaning. For cameras with interchangeable lenses, do not touch the surface of the sensor
directly with the hands. Use lens tissue or a cotton tipped applicator and ethanol to clean
the sensor and the camera lens. Use a damp soft cloth to remove any dirt from the camera
body. Please do not use complex solvents, corrosive or abrasive agents for cleaning of any
part of the camera.
7. Do not operate the camera beyond the specified temperature, humidity or power source
ratings. This camera is suitable for indoor operation only. Use the camera at temperatures
within -10°C~50°C (14°F~122°F) and humidity less than 80%; this device is not rated as
submersible. The input power source is 12VDC. Be sure to connect the proper + / - polarity
and voltage, as incorrect polarity or too high a voltage will likely cause the camera to fail,
and such damage is not covered by the warranty.
8. Mounting. Use care in selecting a solid mounting surface which will support the weight of
the camera plus any wind, snow, ice or other loading, and securely attach the camera to the
mounting surface using screws and anchors which will properly support the camera. If
necessary (e.g. when mounting to drop ceilings) use a safety wire to provide additional
support for the camera.

3
Safety Notice
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.

4
Contents
1. Introduction...................................................................................................................... 5
1.1 Packing List .....................................................................................................................5
1.2 Features ..........................................................................................................................5
2. Cable Description.............................................................................................................. 6
3. Installation ....................................................................................................................... 7
3.1 Installation and Adjustment ...........................................................................................7
4. Configuration in the OSD Menu........................................................................................10
5. Specifications...................................................................................................................14

ECZ930 eZ.HD Outdoor IR Bullet Camera
5
1. Introduction
Get incredible performance in bright light or low light, and the resolution listed in the specification
from the actual camera you install. To take full advantage of the amazing resolution available from
this advanced imaging technology, the EverFocus eZ.HD Series ECZ930 uses a fixed lens together with
1/2.8" SONY 1.37M pixels CMOS to deliver 720p high resolution. Combined with a useable native
low light sensitivity of 0 lux without using digital slow shutter and 30 LEDs with range of 15m/50ft.
Moreover, this camera truly provides color without compromise: 720p high resolution, Digital Wide
Dynamic Range for clear color images in the most challenging of bright or unbalanced scene lighting
conditions, plus true day/night IR enhanced images in low light environments with guaranteed ZERO
ghosting. The ECZ930 camera equipped with IP66 weather resistant housing has 3-axis rotation design that
delivers wall or ceiling mounting flexibility. Astounding image quality from the 3.6mm lens; 12VDC
voltage operation and a full suite of OSD Menu and DSP functions controllable at the camera (3DNR
to save DVR HDD space, privacy masking, mirroring, and much more) This is the camera that you
have been waiting for to create analog CCTV systems that produce astounding image clarity in a
wide range of outdoor applications at the widest range of light levels. The ECZ930 supports both
NTSC and PAL scanning systems, which can be switched via OSD.
1.1 Packing List
1.2 Features
720p with high flexibility and performance for astounding image
1/2.8" SONY 1.37M pixels CMOS with very low light sensitivity
30 IR LEDs for 15m/50ft.range (depending on scene IR reflectivity)
D-WDR to improve the visibility under high contrast scene
Provides 3D Noise Reduction ensures less blurry moving subjects, vivid and high SN ratio
images even under low light environments
Support 720p & 960H analog signal output, which can be easily switched by OSD
Internal wire system with anti-cut bracket
Weather Resistant IP66 and built-in heater
Supports Ceiling Mount and Wall mount
Camera Body x 1
Hexagon Wrench x1
User Manual x 1
Template Plate x1
Screw x 3
Plastic Anchor x 3

ECZ930 eZ.HD Outdoor IR Bullet Camera
6
2. Cable Description
No.
Name
Descriptions
1
Power Cable
Connects to a 12VDC power source.
2
Dual Video Output
720p and 960H output, using a 75 Ohm BNC-type coaxial cable.
3
DC Power Pigtail Cable
Optional power pigtail cable. The red wire is positive (+);
while the black wire is negative (-).

ECZ930 eZ.HD Outdoor IR Bullet Camera
7
3. Installation
3.1 Installation and Adjustment
1. For Ceiling Mount / Wall Mount users: Stick the Template Plate on the position where
you want to attach the camera.
2. Drill three holes and insert the supplied Plastic Anchors into the holes, then attach the
camera to the ceiling or wall by using the supplied Screws.

ECZ930 eZ.HD Outdoor IR Bullet Camera
8
3. Connect the camera to an AHD DVR or a portable monitor with the 12VDC power source
using the supplied DC Power Pigtail Cable or a power adapter.
4. Adjust camera angles by tilting or rotating the camera. Then fasten the bracket with the
Hexagon Wrench (Note: The bracket base can be rotated by 360o , the housing body also
can be rotated by 360oand tilted by 90o).
5. Configure camera settings by using the OSD Menu Joystick.

ECZ930 eZ.HD Outdoor IR Bullet Camera
9
OSD indication as shown in the figure:
Note: The function button is not only for direction control, also for switching Video format
and Video output. Please follow the detailed instruction as below:
Push the joystick "down" button key over 5 seconds to switch video format from
PAL to NTSC.
Push the joystick "left" button key over 5 seconds to switch video output from
720p to 960H (720p is the default).
Push the joystick "right" button key over 5s to switch video output from 960H to
720p.
Push the Joystick up / down to select
among menu items.
Push the Joystick left / right to adjust the
level of the selected item.
Press the Joystick to enter the submenu or
exit the OSD Setup Menu.

ECZ930 eZ.HD Outdoor IR Bullet Camera
10
4. Configuration in the OSD Menu
You can use the Joystick on the bottom housing of the camera to configure camera settings in the
OSD menu. The OSD menu structure is as below:
No.
Main
Sub Menu
Sub Menu / Function
1
Lens
Manual*
2
Exposure
Shutter
NTSC: 1/30, 1/60, FLK, 1/240, 1/480, 1/1000, 1/2000, 1/5000,
1/10000, 1/50000, X2, X4, X6, X8, X10, X15, X20, X25, X30, Auto*
PAL: 1/25, 1/50, FLK, 1/200, 1/400, 1/1000, 1/2000, 1/5000,
1/10000, 1/50000, X2, X4, X6, X8, X10, X15, X20, X25, X30, Auto*
AGC
0 –15(15*)
Sens-up
Off*
Auto
Sens-up
X2, X4*, X6, X8, X10, X15, X20, X25,
X30
Brightness
1-100(40*)
D-WDR
Off*
On
Level
0-8(8*)
Auto
Defog
Off*
Auto
Pos/Size
Position, Size,↑,↓,→,←
Gradation
0-2(0*)
Default
3
Backlight
Off*
BLC
Level
Middle*, High, Low
Area
Position, Size,↑,↓,→,←
Default
HSBLC
Select
Area1*, Area2, Area3, Area4
Display
Off
On*
Position, Size,↑,↓,→,←
Black Mask
On*/Off
Level
0-100(20*)
Model
All Day*
Night
AGC Level
0-255(48*)
Default
4
White
Balance
ATW*
AWC→SET

ECZ930 eZ.HD Outdoor IR Bullet Camera
11
Indoor
Outdoor
Manual
Blue
1-500(50*)
Red
0-100(50*)
AWB
5
Day &
Night
Ext*
D→N(Delay)
0-60(1*)
N→D(Delay)
0-60(1*)
Auto
D→N(AGC)
1-255(240*)
D→N(Delay)
0-60(1*)
N→D(AGC)
1-255(50*)
N→D(Delay)
0-60(5*)
Color
B/W
Burst
Off*/On
IR Smart
Off
On*
Level
0-15(4*)
Area
Position, Size,↑,↓,→,←
IR PWM
Off
0-100(100*)
6
NR
2DNR
Middle*/Low/Off/High
3DNR
Middle*/Low/Off/High
7
Special
Cam Title
Off*
On
0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZ▶→
←↑↓()ˉ-_▊/=&:~,.
D-effect
Freeze
Off*/On
Mirror
Off*, Mirror, V-flip, Rotate
Neg. Image
Off*/On
Motion
Off*
On
Select
Area1*,Area2,Area3,Area4
Display
On*
Position, Size,↑,↓,→,←
Off
Sensitivity
0-100(64*)
Color
Green*, Blue, White, Red
Trans
1.00*,0.75,0.50,
0.25
Alarm
View Type
Off, Block, Outline, All*
OSD View
On*/Off
Alarm Out
On*/Off
Alarm Sig
High*, Low

ECZ930 eZ.HD Outdoor IR Bullet Camera
12
Time
1-15(3*)
Default
Privacy
Off
On
Select
Area1*,Area2,Area3,Area4
Display
Off
Color*
Position, Size,↑,↓,→,
←
Mosaic
Position, Size,↑,↓,→,
←
Inv
Position, Size,↑,↓,→,
←
Color
White*, Black, Red, Blue, CYAN,
Yellow, Green
Trans
1.00*,0.75,0.50,
0.25
Default
Language
ENG*/CHN1/CHN2/GER/FRA/ITA/SPA/POL/RUS/POR/NED/TUR
Defect
Live DPC
Off
On*
AGC level
0-255(65*)
Level
0-100(100*)
White DPC
Off
On*
Pos/Size
Position, Size,↑,↓,→,
←
Start
Close the iris then press
DPC View
Off*/On
Level
0-60(5*)
AGC
0-14(14*)
Sens-up
x2*, x4, x6, x8,x10, x15,
x20, x25, x30
Black DPC
Off*
On
Pos/Siz
Position, Size,↑,↓,→,
←
Start
Press Enter
DPC View
Off*/On
Level
0-255(255*)
RS485
CAM ID
0-255(1*)
ID Display
Off*/On
Baud Rate
2400,4800,9600,19200 ,38400

ECZ930 eZ.HD Outdoor IR Bullet Camera
13
8
Adjust
Sharpness
Off
Auto*
Level
0-10(6*)
Start AGC
0-255(50*)
End AGC
0-255(200*)
CRT/LCD
CRT
Black Level
0-60(0*)
Blue Gain
0-100(50*)
Red Gain
0-255(50*)
LCD*
Gamma
User*,0.45,0.50,0.55,0.6
0,0.65,0.70,0.75,0.80,0.8
5,0.90,
0.95,1.00
Blue Gain
0-100(50*)
Red Gain
0-100(50*)
LSC
Off*/On
Video. Out
PAL/NTSC
9
Exit
Save& END /Reset/Not Saved

ECZ930 eZ.HD Outdoor IR Bullet Camera
14
5. Specifications
Specifications and designs are subject to change for improving the functionality of this product
without notice.
P/N
ECZ930
Pickup Device
1/2.8" SONY 1.37M pixels CMOS
Video Format
NTSC and PAL( can be switched via OSD)
Effective Pixels
1280 (H)*720 (V)
Scanning System
Progressive Scan
Sensitivity
0 lux with IR on
S/N Ratio
Over 48 dB (AGC OFF)
Electronic Shutter
AUTO, Manual (X30~1/ 50000), FLK
Video Output
BNC 1.0Vp-p 75Ω
Gamma Correction
0.45
Lens Type
3.6mm fixed lens with ICR
BLC
OFF/BLC/HS BLC Selectable
AGC
0~15 Levels
White Balance
ATW/AWC-SET/INDOOR/OUTDOOR/MANUAL/AWB
Sync Mode
Internal
Day/Night
Ext, Auto, Color, B/W
IR LED
30 Units
IR Distance
Up to 15m/50ft. (depending on scene IR reflectivity)
OSD Languages
12-Language
DNR
2DNR/3DNR, Off
DEFOG
Off/Auto(under B/W mode)
D-WDR
On/Off
Sens-up
Off/On(x30~x2)
Mirror
Off, Mirror, V-flip, Rotate
Motion Detection
On/Off for 4 selectable zones
Privacy Mask
On/Off for 4 selectable zones
Environmental
IP66 Weather Resistant
Power Source
12VDC
Power Source
3.6w max.
Operating
Temperature
-10°C~50°C / 14°F~122°F
Humidity
Less than 80%
Dimensions
166.7 x 66 x 66mm / 6.56”x 2.60”x 2.60”
Weight
400g/0.88lbs
Certifications
CE/FCC/ RoHS

ECZ930 eZ.HD Outdoor IR Bullet Camera
EverFocus Electronics Corp.
EverFocus Taiwan:
12F-1, No.79, Sec. 1, Shin-Tai Wu Road,
Hsi-Chih, New Taipei City, Taiwan
TEL: [phone]
FAX: [phone]
www.everfocus.com.tw
[e-mail]
EverFocus Europe - Germany:
Albert-Einstein-Strasse 1, D-46446
Emmerich, Germany
TEL: [phone]
FAX: [phone]
www.everfocus.de
[e-mail]
EverFocus China - Beijing:
Room 609, Technology Trade Building,
Shangdi Information Industry Base,
Haidian District, Beijing 100085, China
TEL: [phone]~39
FAX: [phone]
www.everfocus.com.cn
[e-mail]
EverFocus China - Shenzhen:
4F, No. 2, D4 Building, Wan Yelong
Industrial Park, Tangtou Road, Shiyan,
Baoan, Shenzhen, Guangdong 518101, China
TEL: [phone]
FAX: [phone]
www.everfocus.com.cn
[e-mail]
EverFocus USA - California:
1801 Highland Avenue, Unit A, Duarte, CA 91010,
USA
TEL: [phone]
FAX: [phone]
www.everfocus.com
[e-mail]
EverFocus USA - New York:
415 Oser Avenue, Unit S, Hauppauge, NY 11788, USA
TEL: [phone]
FAX: [phone]
www.everfocus.com
[e-mail]
EverFocus Japan:
3F Kuramochi, Buildingll 2-2-3 Koto-Bashi,
Sumida-Ku Tokyo, 130-0022, Japan
TEL: [phone]
FAX: [phone]
www.everfocus.co.jp
[e-mail]
EverFocus China - Shanghai:
Room 403, Ruijin Business Center, No.96, Zhaojiabang
Road, Luwan district, Shanghai 200020, China
TEL: [phone]
FAX: [phone]
www.everfocus.com.cn
[e-mail]
EverFocus India:
UBS, 629/1243, 1st Floor, G Block, Behind
Teacher’s Colony, Bandra Kurla Complex,
Bandra (E), Mumbai 400 051, India
TEL: [phone]
FAX: [phone]
www.everfocus.in
[e-mail]
Your EverFocus product is designed
and manufactured with high quality
materials and components which can
be recycled and reused.
This symbol means that electrical and
electronic equipment, at their
end-of-life, should be disposed
ofseparately from your household
waste.
Please, dispose of this equipment at
your local community waste
collection/recycling centre.
In the European Union there are
separate collection systems for used
electrical and electronic product.
Please, help us to conserve the
environment we live in!
Ihr EverFocus Produkt wurde
entwickelt und hergestellt mit
qualitativ hochwertigen Materialien
und Komponenten, die recycelt und
wieder verwendet werden können.
Dieses Symbol bedeutet, dass
elektrische und elektronische Geräte
am Ende ihrer Nutzungsdauer vom
Hausmüll getrennt entsorgt werden
sollen.
Bitte entsorgen Sie dieses Gerät bei
Ihrer örtlichen kommunalen
Sammelstelle oder im Recycling
Centre.
Helfen Sie uns bitte, die Umwelt zu
erhalten, in der wir leben!
