Everlight 19-337/R6GHBHC-A01/2T Instruction Manual

Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 2 Page: 1 of 12
Device No. : DSE-0002657 Prepared date: 07-May-2010 Prepared by : Ashley Kuo
Technical Data Sheet
0.35mm Height Chip LED with Full Color
19-337/R6GHBHC-A01/2T
Features
․Package in 8mm tape on 7〞diameter reel.
․Compatible with automatic placement equipment.
․Compatible with infrared and vapor phase reflow
solder process.
․Full-color type.
․Pb-free
․The product itself will remain within RoHS
compliant version.
Descriptions
․The 19-337 SMD LED is much smaller
than lead frame type components, thus
enable smaller board size, higher packing
density, reduced storage space and finally
smaller equipment to be obtained.
․Besides, lightweight makes them ideal for
miniature applications. etc.
Applications
․Backlighting in dashboard and switch.
․Telecommunication: indicator and backlighting in
telephone and fax.
․Flat backlight for LCD, switch and symbol.
․General use.
Device Selection Guide
Chip
Type Material Emitted Color Resin Color
R6 AlInGaN Brilliant Red
GH InGaN Brilliant Green
BH InGaN Blue
Water Clear

19-337/R6GHBHC-A01/2T
Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 2 Page: 2 of 12
Device No. : DSE-0002657 Prepared date: 07-May-2010 Prepared by : Ashley Kuo
Package Outline Dimensions
1.6
1.6
1.0
Cathode mark
1.1
2
1
3
4
5
6
0.6 0.6
0.8
0.35
0.4 0.4
B R
G
0.350.35
0.8
0.6
0.150.15
0.2 0.2
0.5
0.6
0.5
Note: The tolerances unless mentioned is ±0.1mm,Unit = mm

19-337/R6GHBHC-A01/2T
Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 2 Page: 3 of 12
Device No. : DSE-0002657 Prepared date: 07-May-2010 Prepared by : Ashley Kuo
Absolute Maximum Ratings (Ta=25℃)
Parameter Symbol Rating Unit
Reverse Voltage VR5 V
Forward Current IF
R6:25
GH:25
BH:25
mA
Peak Forward Current
(Duty 1/10 @1KHz) IFP
R6:60
GH:100
BH:100
mA
Power Dissipation Pd
R6:60
GH:95
BH:95
mW
Electrostatic Discharge(HBM) ESD
R6:2000
GH:150
BH:150
V
Operating Temperature Topr -40 ~ +85 ℃
Storage Temperature Tstg -40 ~ +90 ℃
Soldering Temperature Tsol Reflow Soldering : 260 ℃for 10 sec.
Hand Soldering : 350 ℃for 3 sec.

19-337/R6GHBHC-A01/2T
Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 2 Page: 4 of 12
Device No. : DSE-0002657 Prepared date: 07-May-2010 Prepared by : Ashley Kuo
Electro-Optical Characteristics (Ta=25℃)
Parameter Symbol Min. Typ. Max. Unit Condition
Luminous Intensity
R6
Iv GH
BH
72
112
28.5
100
180
50
----- mcd
Viewing Angle 2θ1/2 ----- 120 ----- deg
Peak Wavelength
R6
λp GH
BH
-----
632
518
468
----- nm
Dominant Wavelength
R6
λd GH
BH
-----
624
525
470
----- nm
Spectrum Radiation
Bandwidth
R6
△λ GH
BH
-----
20
35
35
----- nm
Forward Voltage
R6
VF GH
BH
-----
2.0
3.3
3.3
2.4
3.9
3.9
V
IF=20mA
Reverse Current
R6
IRGH
BH
----- -----
10
50
50
μAVR=5V
Notes:
1.Tolerance of Luminous Intensity ±11%
2.Tolerance of Dominant Wavelength ±1nm
3.Tolerance of Forward Voltage ±0.1V

19-337/R6GHBHC-A01/2T
Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 2 Page: 5 of 12
Device No. : DSE-0002657 Prepared date: 07-May-2010 Prepared by : Ashley Kuo
Typical Electro-Optical Characteristics Curves
R6
Relative luminous intensity (%)
Ambient Temperature Ta (°C)
Ambient Temperature Ta (°C)
Ta=25°C
Radiation Diagram
Forward Current
Luminous Intensity vs.
Ta=25°C
F
Forward Voltage V (V)
Ta=25°C
Forward Voltage
Forward Current vs.
Wavelength λ(nm)
Ta=25°C
Spectrum Distribution
F
I (mA)Forward Current
()
%
Relative luminous intensity
Ambient Temperature
Luminous Intensity vs.
()
%
I (mA)
F
Forward Current
Forward Current Derating Curve
Relative luminous intensity

19-337/R6GHBHC-A01/2T
Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 2 Page: 6 of 12
Device No. : DSE-0002657 Prepared date: 07-May-2010 Prepared by : Ashley Kuo
Typical Electro-Optical Characteristics Curves
GH
Ta=25°C
F
Forward Voltage V (V)
Wavelength λ(nm)
Ta=25°C
30°
20°10°
50°
60°
70°
90°
0.40.2 0.6
80°
40°
1.0
0.9
0.8
0.7
0.10.30.5
0°
Radiation Diagram
Forward Current vs.
Ta=25°C
4.53.83.0 3.4 4.2
Forward Voltage
50
30
40
FI (mA)
20
25
10
0
Forward Current
2.6
Spectrum Distribution
)
600
500450 550
100
(
50
75
25
0
Relative luminous intensity
400
%
Forward Current
f=1KHz
Duty=1/10
Luminous Intensity vs
Ta=25°C
F
I (mA)
10
10
Forward Current
1000
()
%
100
10
1
Relative luminous intensity
10
Ambient Temperature
Luminous Intensity vs.
1000
()
%
100
80 10040 60 200-40 -20
85 10060
20 40
10
1
50
40
I (mA)
F
25
30
20
0
10
Forward Current
0
Ambient Temperature Ta (°C)
Forward Current Derating Curve
-60
Ambient Temperature Ta (°C)
Relative luminous intensity

19-337/R6GHBHC-A01/2T
Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 2 Page: 7 of 12
Device No. : DSE-0002657 Prepared date: 07-May-2010 Prepared by : Ashley Kuo
Typical Electro-Optical Characteristics Curves
BH
25
0
50
75
100 Ta=25°C
Forward Voltage V (V)
Relative luminous intensity (%)
-60
Forward Current Derating Curve
Ambient Temperature Ta (°C)
Forward Current F
I (mA)
1
10
-20-40 0 20 60 40 10080
Relative luminous intensity (%)
100
1000
Forward Current
Wavelength λ(nm)
Luminous Intensity vs.
Ambient Temperature
I (mA)
F
Spectrum Distribution Forward Voltage
F
Ta=25°C
Forward Current vs.
10
Relative luminous intensity (%)
1
10
100
Forward Current I (mA)
10 10
F
Ta=25°C
Luminous Intensity vs.
Forward Current
30°
20°
Ta=25°C
10°0°
Radiation Diagram
40°
60°
50°
90°
80°
0.6
70°
0.20.10.5 0.3 0.4
1.0
0.8
0.9
0.7
Ambient Temperature Ta (°C)
400 550 450 500 600 2.6
0
10
25
20
40
30
50
4.23.43.0 3.8 4.5
1000
Duty=1/10
f=1KHz
12
0
10
0
20
30
25
40
50
40
20 60 10085

19-337/R6GHBHC-A01/2T
Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 2 Page: 8 of 12
Device No. : DSE-0002657 Prepared date: 07-May-2010 Prepared by : Ashley Kuo
Label Explanation
CAT: Luminous Intensity Rank
HUE: Dom. Wavelength Rank
REF: Forward Voltage Rank
Reel Dimensions
Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm
RoHS
Pb
CPN :
PN : XXXXXXXXXXXXX
XXXXXXXXXXXXX
QTY : XXX
LOT NO : XXXXXXXXXX
Reference : XXXXXXXX
CAT : XXX
HUE : XXX
REF : XXX
EVERLIGHT
MADE IN TAIWAN

19-337/R6GHBHC-A01/2T
Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 2 Page: 9 of 12
Device No. : DSE-0002657 Prepared date: 07-May-2010 Prepared by : Ashley Kuo
Carrier Tape Dimensions: Loaded quantity 2000 PCS per reel
Note: The tolerances unless mentioned is ±0.1mm ,Unit = mm
Moisture Resistant Packaging
Label Desiccant Label
Aluminum moisture-proof bag

19-337/R6GHBHC-A01/2T
Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 2 Page: 10 of 12
Device No. : DSE-0002657 Prepared date: 07-May-2010 Prepared by : Ashley Kuo
Reliability Test Items And Conditions
The reliability of products shall be satisfied with items listed below.
Confidence level：90%
LTPD：10%
No. Items Test Condition
Test
Hours/Cycles Sample Size Ac/Re
1 Reflow Soldering
Temp. : 260℃±5℃
Max. 10sec. 6 Min. 22 PCS. 0/1
2 Temperature Cycle
H : +100℃15min
∫5 min
L : -40℃15min
300 Cycles 22 PCS. 0/1
3 Thermal Shock
H : +100℃5min
∫10 sec
L : -10℃5min
300 Cycles 22 PCS. 0/1
4 High Temperature
Storage Temp. : 100℃1000 Hrs. 22 PCS. 0/1
5 Low Temperature
Storage Temp. : -40℃1000 Hrs. 22 PCS. 0/1
6 DC Operating Life IF= 20 mA 1000 Hrs. 22 PCS. 0/1
7 High Temperature /
High Humidity 85℃/ 85%RH 1000 Hrs. 22 PCS. 0/1

19-337/R6GHBHC-A01/2T
Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 2 Page: 11 of 12
Device No. : DSE-0002657 Prepared date: 07-May-2010 Prepared by : Ashley Kuo
Precautions For Use
1. Over-current-proof
Customer must apply resistors for protection, otherwise slight voltage shift will cause big
current change ( Burn out will happen ).
2. Storage
2.1 Do not open moisture proof bag before the products are ready to use.
2.2 Before opening the package: The LEDs should be kept at 30℃or less and 90%RH or less.
2.3 After opening the package: The LED's floor life is 1 year under 30℃or less and 60% RH or less.
If unused LEDs remain, it should be stored in moisture proof packages.
2.4 If the moisture absorbent material (silica gel) has faded away or the LEDs have exceeded the
storage time, baking treatment should be performed using the following conditions.
Baking treatment : 60±5℃for 24 hours.
3. Soldering Condition
3.1 Pb-free solder temperature profile
Pre-heating
150~200°C
60~120sec.
Above 217°C
60~150sec.
260°C Max.
10sec. Max.
6°C/sec.Max.
Above255°C
30sec.Max.
3°C/sec.Max.
3.2 Reflow soldering should not be done more than two times.
3.3 When soldering, do not put stress on the LEDs during heating.
3.4 After soldering, do not warp the circuit board.

19-337/R6GHBHC-A01/2T
Everlight Electronics Co., Ltd. http://www.everlight.com Rev. 2 Page: 12 of 12
Device No. : DSE-0002657 Prepared date: 07-May-2010 Prepared by : Ashley Kuo
4.Soldering Iron
Each terminal is to go to the tip of soldering iron temperature less than 350℃for 3 seconds within
once in less than the soldering iron capacity 25W. Leave two seconds and more intervals, and do
soldering of each terminal. Be careful because the damage of the product is often started at the time of
the hand solder.
5.Repairing
Repair should not be done after the LEDs have been soldered. When repairing is unavoidable, a
double-head soldering iron should be used (as below figure). It should be confirmed beforehand whether
the characteristics of the LEDs will or will not be damaged by repairing.
